IEC 61800-7-304:2015

Adjustable speed electrical power drive systems - Part 7-304: Generic interface and use of profiles for power drive systems - Mapping of profile type 4 to network technologies

IEC 61800-7-304:2015 specifies the mapping of the profile type 4 (SERCOS) specified in IEC 61800-7-204 onto different network technologies. This edition includes the following significant technical change with respect to the previous edition: Update of mapping specification.

Entraînements électriques de puissance à vitesse variable - Partie 7-304: Interface générique et utilisation de profils pour les entraînements électriques de puissance - Mise en correspondance du profil de type 4 avec les technologies de réseaux

L'IEC 61800-7-304:2015 spécifie la mise en correspondance du profil de type 4 (SERCOS), décrit dans l'IEC 61800-7-204, avec les différentes technologies de réseaux. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente: Mise à jour de la spécification de mise en correspondance.

General Information

• Status: Published
• Publication Date: 19-Nov-2015
• ICS: 29.200 - Rectifiers. Convertors. Stabilized power supply
• ICS: 35.100.05 - Multilayer applications
• Technical Committee: SC 22G - Adjustable speed electric power drive systems (PDS)
• Drafting Committee: MT 16 - TC 22/SC 22G/MT 16
• Current Stage: PPUB - Publication issued
• Start Date: 20-Nov-2015
• Completion Date: 31-Oct-2015

Relations

• Revises: IEC 61800-7-304:2007 - Adjustable speed electrical power drive systems - Part 7-304: Generic interface and use of profiles for power drive systems - Mapping of profile type 4 to network technologies
• Effective Date: 05-Sep-2023

Standards Content (Sample)

IEC 61800-7-304 ®
Edition 2.0 2015-11
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colourcolour
insinsiidede
Adjustable speed electrical power drive systems –
Part 7-304: Generic interface and use of profiles for power drive systems –
Mapping of profile type 4 to network technologies

Entraînements électriques de puissance à vitesse variable –
Partie 7-304: Interface générique et utilisation de profils pour les entraînements
électriques de puissance – Mise en correspondance du profil de type 4 avec les
technologies de réseaux
