IEC 60695-10-3:2016

Fire hazard testing - Part 10-3: Abnormal heat - Mould stress relief distortion test

IEC 60695-10-3:2016 specifies a mould stress relief distortion test. It is applicable to electrotechnical equipment including parts made from polymeric materials. This test method is intended to evaluate the effects caused by relief of the residual process-induced stress, set in a moulded polymeric assembly of an end product. This stress relief occurs when the sample (energized or not), is exposed to conditioning at a defined temperature for a defined period of time. The test specimen is considered to have satisfactorily withstood the test if, after conditioning to room temperature, it meets defined test criteria. This basic safety publication is primarily intended for use by technical committees in the preparation of standards in accordance with the principles laid down in IEC Guide 104 and ISO/IEC Guide 51. It is not intended for use by manufacturers or certification bodies. This second edition of IEC 60695-10-3 cancels and replaces the first edition issued in 2002. It constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- Updated references;
- Updated equipment;
- Added terms and definitions;
- and added Bibliography. Key words: Fire Hazard, Abnormal Heat, Fire Safety Engineering, Mould Stress Relief Distortion Test.

Essais relatifs aux risques du feu - Partie 10-3: Chaleur anormale - Essai de déformation par réduction des contraintes de moulage

L'IEC 60695-10-3:2016 spécifie un essai de déformation par réduction des contraintes de moulage. Elle est applicable aux matériels électrotechniques, y compris les parties composées de matériaux polymères. Cette méthode d'essai est destinée à évaluer les effets provoqués par la réduction des contraintes résiduelles induites par traitement, se produisant dans un assemblage polymère moulé d'un produit final. Cette réduction de contraintes se produit lorsque l'échantillon (sous ou hors tension) est exposé au conditionnement à une température définie pendant une période de temps définie. L'éprouvette d'essai est considérée comme ayant satisfait à l'essai si, après le conditionnement à température ambiante, elle satisfait aux critères d'essai définis. La présente publication fondamentale de sécurité est essentiellement destinée à être utilisée par les comités d'études dans le cadre de l'élaboration de normes conformément aux principes établis dans le Guide IEC 104 et le Guide ISO/IEC 51. Elle n'est pas destinée à être utilisée par les fabricants ou les organismes de certification. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
- Références mises à jour;
- Matériel mis à jour;
- Termes et définitions ajoutés;
- et Bibliographie ajoutée. Mots-clés: Risques du feu, Chaleur anormale, l'ingénierie de la sécurité incendie, déformation par réduction des contraintes de moulage
