IEC 61215-1-4:2021

Terrestrial photovoltaic (PV) modules - Design qualification and type approval - Part 1-4: Special requirements for testing of thin-film Cu(In,GA)(S,Se)2 based photovoltaic (PV) modules

IEC 61215-1-4:2021 lays down requirements for the design qualification of terrestrial photovoltaic modules suitable for long-term operation in open-air climates. The useful service life of modules so qualified will depend on their design, their environment and the conditions under which they are operated. Test results are not construed as a quantitative prediction of module lifetime. This document is intended to apply to all thin-film Cu(In,Ga)(S,Se)2 based terrestrial flat plate modules. As such it addresses special requirements for testing of this technology supplementing IEC 61215-1:2021 and IEC 61215-2:2021 requirements for testing. This second edition cancels and replaces the first edition of IEC 61215-1-4, issued in 2016. This edition includes the following significant technical changes with respect to the previous edition:
a. A cyclic (dynamic) mechanical load test (MQT 20) added.
b. A test for detection of potential-induced degradation (MQT 21) added.
c. A bending test (MQT 22) for flexible modules added.
This standard is to be read in conjunction with IEC 61215-1:2021 and IEC 61215-2:2021.

Modules photovoltaïques (PV) pour applications terrestres - Qualification de la conception et homologation - Partie 1-4: Exigences particulières d'essai des modules photovoltaïques (PV) au Cu(In,Ga)(S,Se)2 à couches minces

L'IEC 61215-1-4:2021 établit les exigences pour la qualification de la conception des modules photovoltaïques (PV) pour applications terrestres adaptés à une utilisation de longue durée dans les climats à l'air libre. La durée de vie utile des modules ainsi qualifiés dépend de leur conception, de leur environnement et de leurs conditions de fonctionnement. Les résultats d’essai ne sont pas considérés comme une prévision quantitative de la durée de vie des modules. Le présent document est destiné à s'appliquer à tous les modules à plaque plane au Cu(In,Ga)(S,Se)2 à couches minces pour applications terrestres. À ce titre, il spécifie des exigences d'essai particulières à cette technologie en complément des exigences d'essai données dans l'IEC 61215-1:2021 et l'IEC 61215-2:2021. Cette deuxième édition annule et remplace la première édition de l'IEC 61215-1-4, parue en 2016. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a. Ajout d'un essai de charge mécanique (dynamique) cyclique (MQT 20).
b. Ajout d'un essai de dégradation induite par le potentiel (MQT 21).
c. Ajout d'un essai de flexion (MQT 22) dédié aux modules souples.
La présente norme doit être utilisée conjointement avec l'IEC 61215-1:2021 et l'IEC 61215‑2:2021.

General Information

• Status: Published
• Publication Date: 27-Mar-2022
• ICS: 27.160 - Solar energy engineering
• Technical Committee: TC 82 - Solar photovoltaic energy systems
• Drafting Committee: WG 2 - TC 82/WG 2
• Current Stage: PPUB - Publication issued
• Start Date: 23-Feb-2021
• Completion Date: 05-Mar-2021

Relations

• Amended By: IEC 61215-1-4:2021/AMD1:2022 - Amendment 1 - Terrestrial photovoltaic (PV) modules - Design qualification and type approval - Part 1-4: Special requirements for testing of thin-film Cu(In,Ga)(S,Se)2 based photovoltaic (PV) modules
• Effective Date: 05-Sep-2023
• Revises: IEC 61215-1-4:2016 - Terrestrial photovoltaic (PV) modules - Design qualification and type approval - Part 1-4: Special requirements for testing of thin-film Cu(In,GA)(S,Se)₂ based photovoltaic (PV) modules
• Effective Date: 05-Sep-2023

Overview

IEC 61215-1-4:2021 specifies special requirements for the design qualification and type approval of thin-film Cu(In,Ga)(S,Se)2 (CIGS) based terrestrial photovoltaic (PV) modules. It supplements the general IEC 61215 series (Part 1 and Part 2) by defining technology-specific test modifications and additions for flat‑plate CIGS modules intended for long‑term open‑air operation. The second edition (2021) updates the first edition (2016) and adds new mechanical, electrical and flexibility tests to address field‑observed failure modes.

Key topics and technical requirements

• Scope: qualification for CIGS thin‑film terrestrial modules; not for high‑concentration PV. Tests are intended to assess module capability for prolonged outdoor exposure; test outcomes are not direct lifetime predictions.
• Technology‑specific test additions and modifications that supplement IEC 61215-1:2021 and IEC 61215-2:2021, including:
  • MQT 20 - Cyclic (dynamic) mechanical load test: evaluates module durability under repeated mechanical loading.
  • MQT 21 - Potential‑Induced Degradation (PID) detection test: identifies susceptibility to voltage‑related degradation.
  • MQT 22 - Bending test: assesses flexible and semi‑flexible CIGS module mechanical integrity.
• Other referenced module tests included in the test flow:
  • Visual inspection, maximum power and STC/NMOT measurements
  • Thermal cycling, humidity‑freeze, damp heat and UV preconditioning
  • Hot‑spot endurance, wet leakage and insulation testing
  • Static mechanical load, hail impact and robustness of terminations
  • Bypass diode and stabilization procedures
• Test reporting, pass criteria and documentation requirements to support type approval and manufacturing traceability.

Practical applications and users

Who uses IEC 61215-1-4:2021:

• PV module manufacturers (CIGS): for design qualification, product development and certification.
• Independent test laboratories and certification bodies: to perform MQT test sequences and issue type approval reports.
• System designers, EPCs and asset owners: to inform procurement specifications, warranty assessment and reliability expectations.
• R&D and quality managers: to reproduce field failure modes (PID, mechanical fatigue, flexibility issues) and improve module robustness.

Benefits and use cases:

• Validates CIGS module resistance to electrical, climatic and mechanical stresses found in outdoor installations.
• Detects specific failure mechanisms (PID, dynamic mechanical fatigue, bending failures) before market deployment.
• Supports compliance with international PV module qualification frameworks and buyer/vendor specifications.

Related standards

• IEC 61215-1:2021 and IEC 61215-2:2021 (core design qualification and module test procedures)
• IEC 62506 (accelerated test methods guidance)
• IEC TS 63126 (high‑temperature test considerations)
• IEC 62941 (manufacturing quality systems) and references to IEC 60721‑2‑1 (climatic classification)

Keywords: IEC 61215-1-4, CIGS, thin-film PV modules, design qualification, type approval, MQT tests, PID testing, cyclic mechanical load, bending test, photovoltaic module testing.
