IEC 61400-13:2015

Wind turbines - Part 13: Measurement of mechanical loads

IEC 61400-13:2015(B) describes the measurement of fundamental structural loads on wind turbines for the purpose of the load simulation model validation. The standard prescribes the requirements and recommendations for site selection, signal selection, data acquisition, calibration, data verification, measurement load cases, capture matrix, post-processing, uncertainty determination and reporting. Informative annexes are also provided to improve understanding of testing methods. This standard replaces IEC TS 61400-13 published in 2001; it constitutes a technical revision and transition from technical specification to International Standard.

Éoliennes - Partie 13: Mesurage des charges mécaniques

L'IEC 61400-13:2015(B) décrit le mesurage des charges structurelles fondamentales sur les éoliennes à des fins de validation des modèles de simulation de charges. La norme spécifie les exigences et recommandations concernant le choix du site, la sélection des signaux, l'acquisition des données, l'étalonnage, la vérification des données, les cas de charges de mesure, la matrice de capture, le post-traitement, la détermination de l'incertitude et les rapports d'essai. Des annexes informatives sont également fournies pour améliorer la compréhension des méthodes d'essai. Cette norme remplace l'IEC TS 61400-13 parue en 2001; elle constitue une révision technique, ainsi que la transposition d'une spécification technique en Norme internationale.

General Information

• Status: Published
• Publication Date: 02-Dec-2021
• ICS: 27.180 - Wind turbine energy systems
• Technical Committee: TC 88 - Wind energy generation systems
• Drafting Committee: MT 13 - TC 88/MT 13
• Current Stage: PPUB - Publication issued
• Start Date: 21-Dec-2015
• Completion Date: 15-Feb-2016

Relations

• Replaces: IEC TS 61400-13:2001 - Wind turbine generator systems - Part 13: Measurement of mechanical loads
• Effective Date: 31-May-2024
• Amended By: IEC 61400-13:2015/AMD1:2021 - Amendment 1 - Wind turbines - Part 13: Measurement of mechanical loads
• Effective Date: 05-Sep-2023

Overview

IEC 61400-13:2015 is an international standard from the International Electrotechnical Commission (IEC) that focuses on the measurement of mechanical loads on wind turbines. This standard is essential for professionals involved in wind turbine design, testing, and validation as it provides comprehensive guidelines to measure and analyze fundamental structural loads accurately. Its purpose is to support the validation of load simulation models, which are critical for assessing wind turbine reliability and safety.

Revised from the 2001 technical specification, this 2015 edition transitions IEC 61400-13 into a consolidated International Standard, incorporating updated requirements and recommendations. The standard addresses aspects ranging from site selection and instrumentation to data acquisition, calibration, and uncertainty estimation, ensuring precise and consistent load measurements.

Key Topics

• Measurement Load Cases (MLCs): Defined sets of operational conditions under which loads must be recorded, including steady-state, transient, and dynamic characterization scenarios.
• Site Selection: Criteria for appropriate test site conditions to ensure measurement accuracy and representativeness.
• Signal and Instrumentation Requirements: Guidance on sensor types, placement, and measurement of critical load components like blade root bending moments, rotor torque, tower bending moments, and pitch actuation loads.
• Data Acquisition: Specifications on resolution, anti-aliasing, and system design for accurate capturing of mechanical load signals.
• Calibration Procedures: Methods for determining calibration factors for load and non-load measurement channels to maintain data integrity.
• Data Verification and Post-Processing: Techniques to validate raw data, apply signal processing methods including rainflow counting and power spectral density analysis, and generate damage equivalent loads.
• Uncertainty Estimation: Procedures to evaluate and report measurement uncertainties enhancing the credibility of load data.
• Reporting Requirements: Standardized format and content to document test results and methodologies for transparency and repeatability.
• Informative Annexes: Additional guidance on coordinate systems, evaluation of uncertainties, and testing methodology to aid understanding and practical application.

Applications

IEC 61400-13:2015 is indispensable for:

• Wind Turbine Manufacturers: Helps optimize structural designs by providing reliable mechanical load data validated through standard measurement practices.
• Testing Laboratories: Establishes rigorous methodologies for conducting mechanical load measurements on-site to assure compliance with certification requirements.
• Certification Bodies: Provides a clear framework for verifying mechanical load simulations versus real measured data, crucial for safety and performance certification.
• Research and Development: Assists in developing improved models and control strategies by delivering validated load measurement data.
• Maintenance and Monitoring: Enables ongoing evaluation of turbine structural health by establishing baseline load measurements.

This standard enhances the overall confidence in wind turbine structural integrity assessments, contributing to safer, more efficient wind energy generation.

Related Standards

• IEC 61400 Series: The broader set of standards related to wind turbine design, performance, and testing, including:
  • IEC 61400-1: Design requirements
  • IEC 61400-12: Power performance measurement
  • IEC 61400-22: Conformity testing and certification
• IEC 60068: Environmental testing for electrical equipment, relevant for sensor and instrumentation robustness.
• ISO 2041: Vibration and shock terminology, aiding in understanding mechanical load measurement dynamics.

By aligning with IEC 61400-13:2015, organizations ensure that mechanical load measurements on wind turbines conform to globally recognized best practices, improving load simulation accuracy and contributing to the advancement of wind energy technology.

---

Keywords: IEC 61400-13, wind turbine mechanical loads, load measurement, load simulation validation, wind turbine testing standards, load case measurement, load calibration, wind turbine certification, structural load measurement, wind energy standards, turbine load data acquisition, turbine load uncertainty estimation.
