INTERNATIONAL STANDARD ISO 1835:2018(E)
Round steel short link chains for lifting purposes —
Medium tolerance sling chains — Grade 4, stainless steel
1 Scope

This document specifies the requirements for medium tolerance sling chains of grade 4 from stainless

steel for use preferably in chain slings of grade 4 from stainless steel or for other lifting purposes.

The range of nominal diameter, d , covered by this document is from 4 mm to 22 mm.

These sling chains are round steel short link chains with a nominal pitch, p = 3 × d , electrically

n n

welded, solution-annealed and tested. They are for use in the temperature range –100 °C to +400 °C.

They comply with the general conditions of acceptance of ISO 1834.

NOTE 1 Because sling chains are solution-annealed in the finished condition, they can be used without

restrictions with regard to the corrosion resistance of the steels according to 5.2. Higher grades of stainless steel

chains are achieved by cold drawing of the wire prior to the chain manufacturing. Therefore, solution annealing

is not possible without reduction of strength. The weld seam, in particular, represents a critical area with regard

to the corrosion resistance.
NOTE 2 Resistance butt welding and flash welding are listed in ISO 4063.
2 Normative references

The following documents are referred to in the text in such a way that some or all of their content

constitutes requirements of this document. For dated references, only the edition cited applies. For

undated references, the latest edition of the referenced document (including any amendments) applies.

ISO 1834, Short link chain for lifting purposes — General conditions of acceptance

ISO 7500-1, Metallic materials — Calibration and verification of static uniaxial testing machines — Part 1:

Tension/compression testing machines — Calibration and verification of the force-measuring system

ISO 13385-1, Geometrical product specifications (GPS) — Dimensional measuring equipment — Part 1:

Callipers; Design and metrological characteristics

ISO 16143-2, Stainless steels for general purposes — Part 2: Corrosion-resistant semi-finished products,

bars, rods and sections
3 Terms and definitions

For the purposes of this document, the terms and definitions given in ISO 1834 apply.

ISO and IEC maintain terminological databases for use in standardization at the following addresses:

— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
© ISO 2018 – All rights reserved 1
---------------------- Page: 5 ----------------------
ISO 1835:2018(E)
4 Dimensions, masses and designation
4.1 Dimensions and masses

The bases for calculation of the values for the dimensions listed in Table 1 are given in Annex A.

The bases for calculation of the values for the mass per metre listed in Table B.1 are given in Annex B.

The nominal diameter, d , of the sling chain corresponds to the nominal diameter of the steel wire as

presented in ISO 16124, or bar as presented in ISO 1035-1, from which the sling chain is made.

Preferred nominal diameters are given in Table 1, column 1. Other nominal diameters may be used,

provided the corresponding dimensions and tolerances are calculated in accordance with Annex A.

Table 1 — Dimensions
Dimensions in millimetres
1 2 3 4 5 6 7 8 9
Diameter Pitch Width Weld dimension
d p Internal External Internal
Nominal Tolerance Nominal Tolerance Type 1 Types 1 Type 2 Types 1 Type 2
and 2 and 2
d p w w w 2r G
n n 1 2
...
