ISO 3966:2025

Measurement of fluid flow in closed conduits — Velocity area method using Pitot static tubes

This document specifies a method for the determination in a closed conduit of the volume rate of flow of a regular flow a) of a fluid of substantially constant density or corresponding to a Mach number not exceeding 0,25, b) with substantially uniform stagnation temperature across the measuring cross-section, c) running full in the conduit, and d) under steady flow conditions. In particular, it deals with the technology and maintenance of Pitot static tubes, with the calculation of local velocities from measured differential pressures and with the computation of the flow rate by velocity integration.

Mesurage du débit des fluides dans les conduites fermées — Méthode d'exploration du champ des vitesses au moyen de tubes de Pitot doubles

Le présent document spécifie une méthode de détermination du débit-volume d'un écoulement régulier dans une conduite fermée a) d'un fluide de masse volumique sensiblement constante ou correspondant à un nombre de Mach inférieur ou égal à 0,25; b) dont la température d'arrêt est sensiblement uniforme dans toute la section de mesure; c) remplissant complètement la conduite; et d) en régime permanent. Il traite en particulier de la technologie et de l'entretien des tubes de Pitot doubles, du calcul des vitesses locales à partir des pressions différentielles mesurées et du calcul du débit par intégration de ces vitesses.

General Information

• Status: Published
• Publication Date: 02-Jul-2025
• ICS: 17.120.10 - Flow in closed conduits
• Technical Committee: ISO/TC 30/SC 5 - Velocity and mass methods
• Drafting Committee: ISO/TC 30/SC 5 - Velocity and mass methods
• Current Stage: 6060 - International Standard published
• Start Date: 03-Jul-2025
• Due Date: 02-Nov-2025
• Completion Date: 03-Jul-2025

Relations

• Revises: ISO 3966:2020 - Measurement of fluid flow in closed conduits — Velocity area method using Pitot static tubes
• Effective Date: 05-Nov-2022

Standards Content (Sample)

International
Standard
ISO 3966
Fourth edition
Measurement of fluid flow in closed
2025-07
conduits — Velocity area method
using Pitot static tubes
Mesurage du débit des fluides dans les conduites fermées —
Méthode d'exploration du champ des vitesses au moyen de tubes
de Pitot doubles
Reference number
© ISO 2025
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: [phone]
Email: [e-mail]
Website: www.iso.org
Published in Switzerland
ii
