ISO 14229-1:2020

Road vehicles - Unified diagnostic services (UDS) - Part 1: Application layer

This document specifies data link independent requirements of diagnostic services, which allow a diagnostic tester (client) to control diagnostic functions in an on-vehicle electronic control unit (ECU, server) such as an electronic fuel injection, automatic gearbox, anti-lock braking system, etc. connected to a serial data link embedded in a road vehicle. It specifies generic services, which allow the diagnostic tester (client) to stop or to resume non-diagnostic message transmission on the data link. This document does not apply to non-diagnostic message transmission on the vehicle's communication data link between two electronic control units. However, this document does not restrict an in-vehicle on-board tester (client) implementation in an ECU in order to utilize the diagnostic services on the vehicle's communication data link to perform bidirectional diagnostic data exchange. This document does not specify any implementation requirements.

Véhicules routiers — Services de diagnostic unifiés (SDU) — Partie 1: Couche application

General Information

• Status: Published
• Publication Date: 06-Feb-2020
• ICS: 43.180 - Diagnostic, maintenance and test equipment
• Technical Committee: ISO/TC 22/SC 31 - Data communication
• Drafting Committee: ISO/TC 22/SC 31/WG 2 - Vehicle diagnostic protocols
• Current Stage: 9092 - International Standard to be revised
• Start Date: 09-Oct-2023
• Completion Date: 13-Dec-2025

Relations

• Consolidated By: ISO 16090-1:2022 - Machine tools safety - Machining centres, milling machines, transfer machines - Part 1: Safety requirements
• Effective Date: 06-Jun-2022
• Amended By: ISO 14229-1:2020/Amd 1:2022 - Road vehicles - Unified diagnostic services (UDS) - Part 1: Application layer - Amendment 1
• Effective Date: 08-Jan-2022
• Revises: ISO 14229-1:2013 - Road vehicles - Unified diagnostic services (UDS) - Part 1: Specification and requirements
• Effective Date: 10-Dec-2016

Overview

ISO 14229-1:2020 - "Road vehicles - Unified diagnostic services (UDS) - Part 1: Application layer" defines the application-layer behaviour and data-model for vehicle diagnostic services. It specifies data-link independent requirements that allow a diagnostic tester (client) to control diagnostic functions in an on-vehicle electronic control unit (ECU, server) over an embedded serial data link. The standard defines generic UDS services and rules for request/response primitives, but does not prescribe data-link implementations or enforce ECU internals.

Key Topics and Technical Requirements

• Application-layer services and primitives: formal definitions of service request/indication and response/confirm primitives; service data unit formats and mandatory/optional parameters.
• Protocol elements: A_PDU (Application Protocol Data Unit), A_PCI (control information), SI (service identifier) and A_NR_SI (negative-response service identifier).
• Negative responses and server rules: standardised Negative Response Codes (NRC_) handling and detailed server response behaviour, including concurrent requests and SubFunction handling.
• Service description conventions: templates for request and positive response messages, data-parameter definitions, message flow examples.
• Diagnostic and communication management services: DiagnosticSessionControl, ECUReset, SecurityAccess, CommunicationControl, Authentication (PKI and challenge–response options), TesterPresent, ControlDTCSetting, ResponseOnEvent, LinkControl.
• Data transmission services: ReadDataByIdentifier, ReadMemoryByAddress, ReadScalingDataByIdentifier and other read/write diagnostic functions.
• Scope constraints: applies to diagnostic message exchange between tester and ECU; it does not govern non-diagnostic ECU-to-ECU communication and does not impose implementation requirements.

Practical Applications - Who Uses ISO 14229-1

• Automotive OEMs and Tier‑1 suppliers: design and validate ECU diagnostic interfaces and service behavior.
• Tool and test equipment vendors: implement UDS-capable diagnostic testers, scan tools and flashing tools.
• Embedded software engineers: integrate application‑layer diagnostic services into ECU firmware and conform to server response rules.
• Aftermarket service networks and repair shops: ensure interoperability of diagnostic tools across vehicle makes and models.
• Cybersecurity and remote diagnostics teams: use defined authentication and security access procedures for secure diagnostic sessions.

Typical uses include vehicle troubleshooting, ECU programming/flashing, fault code read/clear, session management, security-controlled operations, and production test automation.

Related Standards (context)

ISO 14229-1 is the application-layer part of the UDS family. It is commonly implemented together with transport and network-layer specifications and with vehicle network protocols (e.g., CAN transport). For full system design, developers combine ISO 14229-1 with the relevant data-link and transport-layer specifications used on the vehicle.
