ISO/IEC 17346:2005

Information technology - Data interchange on 90 mm optical disk cartridges - Capacity: 1,3 Gbytes per cartridge

ISO/IEC 17346:2005 defines the characteristics of 90 mm Optical Disk Cartridges (ODC) with a capacity of 1,3 GB per cartridge. It specifies only Type R/W for 2 048-byte sectors of such cartridges. Type R/W provides for data to be written, read and erased many times over the entire recording surface of the disk using the thermo-magnetic and magneto-optical effects. It is also referred to as "fully rewritable". ISO/IEC 17346:2004 provides for 2 048-byte sectors only. All sectors on a disk are of the same size. ISO/IEC 17346:2005 specifies: the conditions for conformance testing and the Reference Drive; the environments in which the cartridges are to be operated and stored; the mechanical and physical characteristics of the cartridge, so as to provide mechanical interchange ability between data processing systems; the format of the information on the disk, both embossed and user-written; including the physical disposition of the tracks and sectors, the error correction codes, and the modulation method used; the characteristics of the embossed information on the disk; the magneto-optical characteristics of the disk, enabling processing systems to write data onto the disk; the minimum quality of user-written data on the disk, enabling data processing systems to read data from the disk. ISO/IEC 17346:2005 provides for interchange between optical disk drives. Together with a standard for volume and file structure, it provides for full data interchange between data processing systems.

Technologies de l'information — Échange de données sur cartouches de disque optique de 90 mm — Capacité: 1,3 Go par cartouche

General Information

• Status: Published
• Publication Date: 06-Feb-2005
• ICS: 35.220.30 - Optical storage devices
• Technical Committee: ISO/IEC JTC 1/SC 23 - Digitally recorded media for information interchange and storage
• Drafting Committee: ISO/IEC JTC 1/SC 23 - Digitally recorded media for information interchange and storage
• Current Stage: 9093 - International Standard confirmed
• Start Date: 21-Aug-2020
• Completion Date: 30-Oct-2025

Overview

ISO/IEC 17346:2005 specifies the characteristics and interchange requirements for 90 mm optical disk cartridges with a capacity of 1.3 Gbytes per cartridge (noted in the standard as 1,3 Gbytes). The standard covers Type R/W (fully rewritable) media organized in 2 048‑byte sectors only, enabling repeated write/read/erase over the disk surface using thermo‑magnetic and magneto‑optical effects. ISO/IEC 17346:2005 defines physical, optical and logical formats to ensure reliable data interchange between optical disk drives.

Key Topics and Requirements

• Media capacity and sector format
  • 90 mm Optical Disk Cartridge, capacity 1.3 Gbytes; 2 048‑byte sectors only.
• Type R/W (fully rewritable)
  • Magneto‑optical and thermo‑magnetic recording methods for repeated rewriting.
• Mechanical and physical characteristics
  • Cartridge and disk dimensions, shutters, alignment holes, clamping methods, mass, moment of inertia and tolerances to ensure mechanical interchangeability.
• Optical and magneto‑optical characteristics
  • Substrate thickness, refractive properties, reflectance and recording sensitivity required for drive compatibility.
• Information format
  • Physical track layout, sector structure (sync, ID, data, CRC/ECC), recording code and modulation methods to support data integrity.
• Error control and defect management
  • ECC/CRC definitions and Defect Management Areas (DMAs) to manage bad sectors and maintain readable data.
• Reference Drive and conformance
  • Definition of a Reference Drive and conditions for conformance testing to validate cartridge/drive interoperability.
• Environments and handling
  • Requirements for testing, operating, storage and transportation environments, plus temperature shock and safety/flamability considerations.
• Minimum quality of user‑written data
  • Criteria ensuring that data written by one system can be read reliably by another.

Applications and Who Uses It

ISO/IEC 17346:2005 is intended for:

• Optical disk drive manufacturers designing drives that accept 90 mm ODC media.
• Media manufacturers producing compliant cartridges and disks.
• System integrators and storage vendors implementing removable optical storage solutions.
• Test laboratories and certification bodies performing conformance and interoperability testing.
• Archival and enterprise users needing standardized, rewritable removable media for data interchange and backup.

Practical applications include removable backup archives, off‑line data transfer between systems, and interchangeable storage where mechanical and logical compatibility across drives is required.

Related Standards

• ISO/IEC 17346 complements standards for volume and file structure and other optical-media format standards to provide full data interchange. It should be used alongside the appropriate file‑system/volume standards adopted by implementers for end‑to‑end compatibility.

Keywords: ISO/IEC 17346, 90 mm optical disk cartridges, 1.3 Gbytes, Type R/W, magneto‑optical, 2048‑byte sectors, data interchange, Reference Drive, conformance testing, defect management.
