International Standard ISO 4649:2024(en)
Rubber, vulcanized or thermoplastic — Determination of
abrasion resistance using a rotating cylindrical drum device
WARNING 1 — Persons using this document should be familiar with normal laboratory practice. This
document does not purport to address all of the safety problems, if any, associated with its use. It is
the responsibility of the user to establish appropriate safety and health practices and to determine
the applicability of any other restrictions.
WARNING 2 — Certain procedures specified in this document might involve the use or generation of
substances or the generation of waste, that could constitute a local environmental hazard. Reference
should be made to appropriate documentation on safe handling and disposal after use.
1 Scope
This document specifies two methods for the determination of the resistance of rubber to abrasion by means
of a rotating cylindrical drum device.
The methods involve determination of the volume loss due to the abrasive action of rubbing a test piece over a
specified grade of abrasive sheet. Method A is for a non-rotating test piece and method B is for a rotating test
piece. For each method, the result can be reported as a relative volume loss or an abrasion resistance index.
These test methods are suitable for comparative testing, quality control, specification compliance testing,
referee purposes and research and development work. No close relation between the results of this abrasion
test and service performance can be inferred.
NOTE The abrasion loss is often more uniform using the rotating test piece because the whole surface of the test
piece is in contact with the abrasive sheet over the duration of the test. However, there is considerable experience
using the non-rotating test piece.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content constitutes
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
ISO 48-4, Rubber, vulcanized or thermoplastic — Determination of hardness — Part 4: Indentation hardness by
durometer method (Shore hardness)
ISO 2230, Rubber products — Guidelines for storage
ISO 2393, Rubber test mixes — Preparation, mixing and vulcanization — Equipment and procedures
ISO 2781, Rubber, vulcanized or thermoplastic — Determination of density
ISO 18899:2013, Rubber — Guide to the calibration of test equipment
ISO 23529, Rubber — General procedures for preparing and conditioning test pieces for physical test methods
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
-----------
...
