INTERNATIONAL STANDARD ISO 20947-3:2023(E)
Performance evaluation protocol for digital fitting
systems —
Part 3:
Digital fitting performance - Gap
1 Scope
This document specifies a protocol employed in evaluating the gap between the virtual garment and
the virtual clone, the virtual twin or the virtual fit mannequin (fit form) model in the evaluation of the
fitting performance of the virtual garment and the virtual human body.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
digital fitting system
qualitative and/or quantitative evaluation of overall and/or specific simulation garment fit through
analysis of the distribution of surface strain, gap between body and garment, tension map, cross
section, surface wrinkles, garment balance, etc.
3.2
virtual garment
three-dimensional clothing in digital form that exists in virtual space
[SOURCE: ISO 20947-2:2020, 3.1.3]
3.3
virtual human body
virtual human model based on actual body dimensions used for digital fitting in the apparel industry,
including information such as size, shape, cross section, body texture and skeletal structure
[SOURCE: ISO 18825-1:2016, 2.1.1.2, modified — Notes to entry removed.]
3.4
virtual fit mannequin (fit form) model
virtual model based on approved dimensions used for draping and examining silhouette and fit of a
garment in a virtual space used for digital fitting
1
© ISO 2023 – All rights reserved

---------------------- Page: 6 ----------------------
ISO 20947-3:2023(E)
3.5
virtual cross section
closed contour extracted from the plane cutting a virtual body segment perpendicular to its main axis
or the three principle axes
[SOURCE: ISO 18825-1: 2016, 2.2.2, modified — Notes to entry removed.]
3.6
gap
space between virtual garment and virtual human body or virtual fit mannequin (fit form model) which
is shown in virtual cross section
Note 1 to entry: The space changes depending on the weight of the clothes or the friction between the clothes and
the body.
Note 2 to entry: Space shall be expressed with difference amount of square measure or girth length between
virtual cross section of virtual garment and virtual human body or virtual fit mannequin (fit form) model or it
shall be expressed with gap amount between the virtual cross section of virtual garment and the virtual human
body or the virtual fit mannequin (fit form) model.
3.7
garment pressure
pressure (tightness) of a garment against a virtual body or a virtual fit mannequin (fit form) model
Note 1 to entry: Pressure is affected by gravity, friction, design and material properties.
4 Functions
4.1 General
The digital fitting system has six functions as given in 4.2 to 4.7.
4.2 Function to measure the perimeter on the virtual cross section
4.2.1 Function to measure the perimeter on the virtual horizontal cross section
This function measures the perimeter of the virtual garment and the virtual fit mannequin (fit form)
model from any arbitrary point on the virtual horizontal cross section. See Figure 1.
2
  © ISO 2023 – All rights reserved

---------------------- Page: 7 ----------------------
ISO 20947-3:2023(E)
a)  Virtual clone or virtual twin, upper body garment
3
© ISO 2023 – All rights reserved

---------------------- Page: 8 ----------------------
ISO 20947-3:2023(E)
b)  Virtual clone or virtual twin, lower body garment
4
  © ISO 2023 – All rights reserved

---------------------- Page: 9 ----------------------
ISO 20947-3:2023(E)
c)  Virtual clone or virtual twin, whole body garment
5
© ISO 2023 – All rights reserved

---------------------- Page: 10 ----------------------
ISO 20947-3:2023(E)
d)  Virtual fit mannequin, upper body garment
6
  © ISO 2023 – All rights reserved

---------------------- Page: 11 ----------------------
ISO 20947-3:2023(E)
e)  Virtual fit mannequin, lower body garment
7
© ISO 2023 – All rights reserved

---------------------- Page: 12 ----------------------
ISO 20947-3:2023(E)
f)  Virtual fit mannequin, whole body garment
Key
1 silhouette line of front bodice
2 silhouette line of back bodice
3 silhouette line of right back pants
4 silhouette line of right front pants
5 silhouette line of left back pants
6 silhouette line of left front pants
Figure 1 — Example of the perimeter measured on the virtual horizontal cross section
4.2.2 Function to measure the perimeter on the virtual vertical cross section (front centre)
This function measures the length of the virtual garment shape and the virtual clone, the virtual twin
or the virtual fit mannequin (fit form) model shape from any arbitrary point on the virtual vertical
cross section (front). See Figure 2.
8
  © ISO 2023 – All rights reserved

---------------------- Page: 13 ----------------------
ISO 20947-3:2023(E)
a)  Virtual clone or virtual twin, upper body garment
9
© ISO 2023 – All rights reserved

---------------------- Page: 14 ----------------------
ISO 20947-3:2023(E)
b)  Virtual clone or virtual twin, lower body garment
10
  © ISO 2023 – All rights reserved

---------------------- Page: 15 ----------------------
ISO 20947-3:2023(E)
c)  Virtual clone or virtual twin, whole body garment
11
© ISO 2023 – All rights reserved

---------------------- Page: 16 ----------------------
ISO 20947-3:2023(E)
d)  Virtual fit mannequin, upper body garment
12
  © ISO 2023 – All rights reserved

---------------------- Page: 17 -----------------
...

DRAFT INTERNATIONAL STANDARD
ISO/DIS 20947-3
ISO/TC 133 Secretariat: SABS
Voting begins on: Voting terminates on:
2022-04-18 2022-07-11
Performance evaluation protocol for digital fitting
systems —
Part 3:
Digital fitting performance
Protocole d'évaluation de la performance des systèmes d'essayage virtuel —
Partie 3: Performance de l'essayage virtuel
ICS: 61.020
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
THEREFORE SUBJECT TO CHANGE AND MAY
This document is circulated as received from the committee secretariat.
NOT BE REFERRED TO AS AN INTERNATIONAL
STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS
BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
USER PURPOSES, DRAFT INTERNATIONAL
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN
Reference number
NATIONAL REGULATIONS.
ISO/DIS 20947-3:2022(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2022

---------------------- Page: 1 ----------------------
ISO/DIS 20947-3:2022(E)
COPYRIGHT PROTECTED DOCUMENT
© ISO 2022
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: [phone]
Email: [e-mail]
Website: www.iso.org
Published in Switzerland
ii
  © ISO 2022 – All rights reserved

---------------------- Page: 2 ----------------------
ISO/DIS 20947-3:2022(E)
Contents Page
Foreword .iv
Introduction .v
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 2
4 Functions . 3
4.1 General . 3
4.2 Function to measure the perimeter on the virtual cross section . 3
4.2.1 Function to measure the perimeter on the virtual horizontal cross section . 3
4.2.2 Function to measure the perimeter on the virtual vertical cross section
(front center) . . . 5
4.2.3 Function to measure the perimeter on the virtual vertical cross section
(side) . 7
4.3 Function to measure the gap on the virtual cross section . 9
4.3.1 Function to measure the gap of circumference on the virtual horizontal
cross section . 9
4.3.2 Function to measure the gap at side on the virtual vertical cross section
(front) . 11
4.3.3 Function to measure the gap at center front(center back) on the virtual
vertical cross section (side) . 13
4.4 Tension Map function . 15
4.5 Garment pressure display function . 20
4.6 Grain display function.25
4.7 Display function for projected cross sectional garment view .30
4.7.1 Top . 30
4.7.2 Front . 31
4.7.3 Side . . 33
5 Quantitative evaluation of digital fitting performance on a virtual fit mannequin
based on presence of functions .34
5.1 General .34
6 Quantitative evaluation of digital fitting performance on a virtual fit mannequin
based on area measurements .34
6.1 General .34
6.2 Physical gap to be measured .34
6.2.1 3D measurements are taken on the fit mannequin (fit form) .34
6.2.2 3D measurements are taken on the fit mannequin (fit form) fitted with
garment. . 35
6.2.3 3D measurement results are synthesized. .36
6.2.4 The area of gap on the horizontal cross section is measured. 37
7 Report .37
8 Evaluation .37
Annex A (Normative) Format for report: Evaluation of a digital fitting performance .38
Annex B (Normative) Example of report: Quantitative evaluation for digital fitting
performance on virtual fit mannequin .39
iii
© ISO 2022 – All rights reserved

---------------------- Page: 3 ----------------------
ISO/DIS 20947-3:2022(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www.iso.org/patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to
the World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT), see
www.iso.org/iso/foreword.html.
This document was prepared by Technical Committee ISO/TC 133, Clothing sizing systems - size
designation, size measurement methods and digital fittings.
A list of all parts in the ISO 20947 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www.iso.org/members.html.
iv
  © ISO 2022 – All rights reserved

---------------------- Page: 4 ----------------------
ISO/DIS 20947-3:2022(E)
Introduction
Digital fitting systems are used more frequently for evaluating the fit of garments without making
actual physical patterns or physical garments. In a digital fitting system, a virtual garment is made
using virtual patterns, and the fit of physical garment on a physical human body is assessed by draping
a virtual garment on a virtual body or a virtual fit mannequin (fit form) model. Such system is useful for
designers, manufacturers, educationalists because the system helps to improve the fit of garments and
productivity.
The use of the digital fitting system, employed to evaluate the suitability of a real garments on real
human body with the use of virtual garments on a virtual human body in virtual space, is growing
in popularity. The system eliminates the need for physical garment production with fabric in product
evaluation. Using a computer-generated the virtual garment pattern, virtual garment is created and
tested on either a virtual human body or a virtual fit mannequin (fit form) model. The technology is
expected to improve garment fit and increase productivity. It benefits not only those engaged in
garment design but also consumers at the time of garment purchase, with better fit and wider choice of
sizes in mass-produced products.
Digital fitting technology is still developing, and there is a wide range of differences in the specification
and performance between digital fitting systems. This makes it difficult for users (designers,
manufacturers, educationalists and retailers of garments) to select an appropriate system for their
purposes.
Notwithstanding, the digital fitting system is still developing, with wide differences among systems
regarding functions and performance description. This makes the choice of the right system extremely
difficult for the system user (garment design and retail).
This international standard is ISO20947 series part 3, and stipulate evaluation protocol for digital
fitting performance of digital fitting system. This international standard will help and provide judging
criteria for selection of digital fitting system when garment designer or pattern engineer create virtual
garment patterns and evaluate fitting performance to virtual fitting body.
v
© ISO 2022 – All rights reserved

---------------------- Page: 5 ----------------------
DRAFT INTERNATIONAL STANDARD ISO/DIS 20947-3:2022(E)
Performance evaluation protocol for digital fitting
systems —
Part 3:
Digital fitting performance
1 Scope
This part of ISO 20947 specifies the protocol employed in evaluating the gap between the virtual
garment and the virtual clone, the virtual twin or the virtual fit mannequin (fit form) model in the
evaluation of the fitting performance of the virtual garment and the virtual human body.
In this standard, gap means space between garment and human body which is indispensable for
garment design and is an important factor for wearing comfort.
For the purpose of evaluating this gap, the standard requires the reporting of whether the perimeter
calculation function for the virtual garment and the virtual clone, the virtual twin or the virtual fit
mannequin (fit form) model, the function for calculating the gap in measurements and area between
the virtual garment and the virtual clone, the virtual twin or the virtual fit mannequin (fit form) model
and the visualization function for gap, garment pressure, and grain are available or not.
Also, evaluation of the perimeter of the virtual garment, the perimeter of the virtual clone, the virtual
twin or the virtual fit mannequin (fit form) model and the gap in area between the virtual garment and
the virtual clone, the virtual twin or the virtual fit mannequin in accordance with the method specified
herein and reporting of the results are recommended.
The users covered by this standard are those users planning to install or update digital fitting systems.
Users (developers, designers, manufacturers, educationalists, retailers etc.) of digital fitting systems
shall produce evaluation reports according to this standard and make such reports available to the
users.
This evaluation process is not limited to materials (e.g. woven). These figures are wearing woven fabric
clothing. Soft fabrics, such as knitted materials, have different results.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 8559-1, Size designation of clothes — Part 1: Anthropometric definitions for body measurement
ISO 18825-2, Clothing — Digital fittings — Part 2: Vocabulary and ter
...
