(Main)Electromagnetic compatibility and Radio spectrum Matters (ERM) - VHF radiotelephone equipment for general communications and associated equipment for Class D Digital Selective Calling (DSC) - Part 3: Harmonized EN covering the essential requirements of article 3.3(e) of the R&TTE Directive
Electromagnetic compatibility and Radio spectrum Matters (ERM) - VHF radiotelephone equipment for general communications and associated equipment for Class D Digital Selective Calling (DSC) - Part 3: Harmonized EN covering the essential requirements of article 3.3(e) of the R&TTE Directive
The present document covers the minimum requirements for general communication for shipborne fixed installations using a VHF radiotelephone operating in certain frequency bands allocated to the maritime mobile service using 25 kHz or 25 kHz and 12,5 kHz channels with associated equipment for DSC - class D. The present document is intended to cover the provisions of Directive 1999/5/EC [i.1] (R&TTE Directive) article 3.3(e), which states that: "... radio equipment within the scope of the present document shall be so constructed that it supports certain features ensuring access to emergency services". In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of article 3 of the R&TTE Directive [i.1] will apply to equipment within the scope of the present document.
Elektromagnetna združljivost in zadeve v zvezi z radijskim spektrom (ERM) - Radiotelefonska oprema za območje VHF za splošne komunikacije in pripadajoča oprema za digitalni selektivni klic (DSC) razreda D - 3. del: Harmonizirani EN, ki zajema bistvene zahteve člena 3.3(e) direktive R&TTE
Ta dokument zajema minimalne zahteve za splošno komunikacijo z ladijskimi, stacionarnimi napravami z radiotelefonom VHF, ki deluje v določenih frekvenčnih pasovih, dodeljenih pomorskim mobilnim storitvam, ki uporabljajo kanale 25 kHz ali 25 kHz in 12,5 kHz z ustrezno opremo za digitalni selektivni klic (DSC) razreda D. Ta dokument zajema določbe člena 3.3(e) Direktive 1999/5/ES [i.1] (direktive R&TTE), ki navaja, da: mora biti radijska oprema s področja uporabe tega dokumenta skonstruirana tako, da »podpira[jo] določene funkcije, ki zagotavljajo dostop do službe za nujne primere«. Poleg tega dokumenta se za opremo s področja uporabe tega dokumenta uporabljajo tudi drugi standardi EN, ki določajo tehnične zahteve v zvezi z bistvenimi zahtevami iz drugih delov člena 3 direktive R&TTE [i.1].
