SLOVENSKI STANDARD
SIST EN 60034-18-42:2018/A1:2021
01-februar-2021
Električni rotacijski stroji - 18-42. del: Električni izolacijski sistemi, odporni proti
delni razelektritvi (tip II), ki se uporabljajo v električnih rotacijskih strojih,
napajanih z napetostnimi pretvorniki - Preskusi zahtevanih pogojev (IEC 60034-18-
42:2017/A1:2020)
Rotating electrical machines - Part 18-42: Partial discharge resistant electrical insulation
systems (Type II) used in rotating electrical machines fed from voltage converters -
Qualification tests (IEC 60034-18-42:2017/A1:2020)
Drehende elektrische Maschinen - Teil 18-42: Teilentladungsresistente Isoliersysteme
(Typ II) von drehenden elektrischen Maschinen, die von Spannungsumrichtern gespeist
werden - Qualifizierungsprüfungen (IEC 60034-18-42:2017/A1:2020)
Machines électriques tournantes - Partie 18-42: Systèmes d'isolation électrique
résistants aux décharges partielles (Type II) utilisés dans des machines électriques
tournantes alimentées par convertisseurs de tension - Essais de qualification (IEC 60034
-18-42:2017/A1:2020)
Ta slovenski standard je istoveten z: EN 60034-18-42:2017/A1:2020
ICS:
29.080.30 Izolacijski sistemi Insulation systems
29.160.01 Rotacijski stroji na splošno Rotating machinery in
general
SIST EN 60034-18-42:2018/A1:2021 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
SIST EN 60034-18-42:2018/A1:2021

---------------------- Page: 2 ----------------------
SIST EN 60034-18-42:2018/A1:2021


EUROPEAN STANDARD EN 60034-18-42:2017/A1

NORME EUROPÉENNE

EUROPÄISCHE NORM
October 2020
ICS 29.160.01

English Version
Rotating electrical machines - Part 18-42: Partial discharge
resistant electrical insulation systems (Type II) used in rotating
electrical machines fed from voltage converters - Qualification
tests
(IEC 60034-18-42:2017/A1:2020)
Machines électriques tournantes - Partie 18-42: Systèmes Drehende elektrische Maschinen - Teil 18-42:
d'isolation électrique résistants aux décharges partielles Teilentladungsresistente Isoliersysteme (Typ II) von
(Type II) utilisés dans des machines électriques tournantes drehenden elektrischen Maschinen, die von
alimentées par convertisseurs de tension - Essais de Spannungsumrichtern gespeist werden -
qualification Qualifizierungsprüfungen
(IEC 60034-18-42:2017/A1:2020) (IEC 60034-18-42:2017/A1:2020)
This amendment A1 modifies the European Standard EN 60034-18-42:2017; it was approved by CENELEC on 2020-09-22. CENELEC
members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this amendment the
status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This amendment exists in three official versions (English, French, German). A version in any other language made by translation under the
responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the same status as
the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.


European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2020 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
 Ref. No. EN 60034-18-42:2017/A1:2020 E

---------------------- Page: 3 ----------------------
SIST EN 60034-18-42:2018/A1:2021
EN 60034-18-42:2017/A1:2020 (E)
European foreword
The text of document 2/1998/FDIS, future IEC 60034-18-42/A1, prepared by IEC/TC 2 "Rotating
machinery" was submitted to the IEC-CENELEC parallel vote and approved by CENELEC as
EN 60034-18-42:2017/A1:2020.
The following dates are fixed:
• latest date by which the document has to be implemented at national (dop) 2021-06-22
level by publication of an identical national standard or by endorsement
• latest date by which the national standards conflicting with the (dow) 2023-09-22
document have to be withdrawn
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC shall not be held responsible for identifying any or all such patent rights.

Endorsement notice
The text of the International Standard IEC 60034-18-42:2017/A1:2020 was approved by CENELEC as
a European Standard without any modification.


2

---------------------- Page: 4 ----------------------
SIST EN 60034-18-42:2018/A1:2021



IEC 60034-18-42

®


Edition 1.0 2020-08




INTERNATIONAL



STANDARD




NORME


INTERNATIONALE




A MENDMENT 1

AM ENDEMENT 1





Rotating electrical machines –

Part 18-42: Partial discharge resistant electrical insulation systems (Type II)

used in rotating electrical machines fed from voltage converters – Qualification

tests



Machines électriques tournantes –


Partie 18-42: Systèmes d’isolation électrique résistants aux décharges partielles

(Type II) utilisés dans des machines électriques tournantes alimentées par

convertisseurs de tension – Essais de qualification










INTERNATIONAL

ELECTROTECHNICAL

COMMISSION


COMMISSION

ELECTROTECHNIQUE


INTERNATIONALE




ICS 29.160.01 ISBN 978-2-8322-8603-6




Warning! Make sure that you obtained this publication from an authorized distributor.

Attention! Veuillez vous assurer que vous avez obtenu cette publication via un distributeur agréé.

® Registered trademark of the International Electrotechnical Commission
Marque déposée de la Commission Electrotechnique Internationale

---------------------- Page: 5 ----------------------
SIST EN 60034-18-42:2018/A1:2021
– 2 – IEC 60034-18-42:2017/AMD1:2020
© IEC 2020
FOREWORD
This amendment has been prepared by IEC Technical Committee 2: Rotating machinery.
The text of this amendment is based on the following documents:
FDIS Report on voting
2/1998/FDIS 2/2008/RVD

Full information on the voting for the approval of this amendment can be found in the report on
voting indicated in the above table.
The committee has decided that the contents of this publication will remain unchanged until the
stability date indicated on the IEC website under "http://webstore.iec.ch" in the data related to
the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.

_____________

3 Terms and definitions
Replace the existing definitions with the following new definitions:
3.11
impulse voltage repetition rate
f
average of the inverse of the time between two successive impulses of the same polarity,
whether unipolar or bipolar, in a considered set of pulses, for example for one period
3.18
impulse voltage insulation class for Type II insulation systems
IVIC
peak to peak voltage classes 1, 2, 3, 4, 5, 6, 7, S including certain time parameters for reliable
operation, assigned by the manufacturer in relation to the rated voltage for a specified
converter-driven machine and indicated in its documentation and, if applicable, on its rating
plate
3.29
maximum allowable peak to peak phase to ground voltage
U
IVIC
maximum allowable peak to peak phase to ground voltage in service, according to the IVIC-
specification

---------------------- Page: 6 ----------------------
SIST EN 60034-18-42:2018/A1:2021
IEC 60034-18-42:2017/AMD1:2020 – 3 –
© IEC 2020
Add the following new definition:
3.30
test voltage factor
TVF
maximum allowable peak to peak operating phase-ground-voltages in units of U , divided by
N
2√2
Replace the existing Table 1 with the following:
Table 1 – Examples of the measured values of the characteristics
of the terminal voltages for two converter-fed machines
Machine rating 3,3 kV 6,6 kV
Measured peak to peak voltage on the phase to ground insulation 7,9 kV 13,9 kV
Fundamental frequency 50/60 Hz 50/60 Hz
Impulse rise time at the motor terminals 1 µs 3 µs
Impulse repetition rate 1 kHz 900 Hz
IVIC required to qualify the insulation for this service (see Table D.2, column 2) 3 2

Replace the second paragraph below Table 1 with the following:
The maximum change in voltage or jump voltage (U ) at the impulse repetition rate is shown in
j
Figure 3. This parameter is important in defining the voltage enhancement that can occur across
the first or last coil in the winding. A fundamental frequent double jump transition
(Figure 3, U )) is possible and needs to be considered accordingly.
j max

---------------------- Page: 7 ----------------------
SIST EN 60034-18-42:2018/A1:2021
– 4 – IEC 60034-18-42:2017/AMD1:2020
© IEC 2020
Replace Figure 3 with the following:

Figure 3 – Jump voltage (U or U ) at the terminals
j j max
of a machine fed from a converter drive
10.2 Test methods
Replace the fist paragraph with the following:
The purpose of testing is to show that the electrical life
...

SLOVENSKI STANDARD
SIST EN 60034-18-42:2018/oprA1:2019
01-februar-2019
(OHNWULþQLURWDFLMVNLVWURMLGHO(OHNWULþQLL]RODFLMVNLVLVWHPLRGSRUQLSURWL
GHOQLUD]HOHNWULWYLWLS,,NLVHXSRUDEOMDMRYHOHNWULþQLKURWDFLMVNLKVWURMLK
QDSDMDQLKSUHNQDSHWRVWQLKSUHWYRUQLNRY3UHVNXVL]DKWHYDQLKSRJRMHY
Rotating electrical machines - Part 18-42: Partial discharge resistant electrical insulation
systems (Type II) used in rotating electrical machines fed from voltage converters -
Qualification tests
Drehende elektrische Maschinen - Teil 18-42: Teilentladungsresistente Isoliersysteme
(Typ II) von drehenden elektrischen Maschinen, die von Spannungsumrichtern gespeist
werden - Qualifizierungsprüfungen
Machines électriques tournantes - Partie 18-42: Systèmes d'isolation électrique
résistants aux décharges partielles (Type II) utilisés dans des machines électriques
tournantes alimentées par convertisseurs de tension - Essais de qualification
Ta slovenski standard je istoveten z: EN 60034-18-42:2017/prA1:2018
ICS:
29.080.30 Izolacijski sistemi Insulation systems
29.160.01 Rotacijski stroji na splošno Rotating machinery in
general
SIST EN 60034-18-42:2018/oprA1:2019 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------

SIST EN 60034-18-42:2018/oprA1:2019

---------------------- Page: 2 ----------------------

SIST EN 60034-18-42:2018/oprA1:2019
2/1931/CDV

COMMITTEE DRAFT FOR VOTE (CDV)
PROJECT NUMBER:
IEC 60034-18-42/AMD1 ED1
DATE OF CIRCULATION: CLOSING DATE FOR VOTING:
2018-12-21 2019-03-15
SUPERSEDES DOCUMENTS:
2/1895/RR

IEC TC 2 : ROTATING MACHINERY
SECRETARIAT: SECRETARY:
United Kingdom Mr Charles Whitlock
OF INTEREST TO THE FOLLOWING COMMITTEES: PROPOSED HORIZONTAL STANDARD:


Other TC/SCs are requested to indicate their interest, if any, in
this CDV to the secretary.
FUNCTIONS CONCERNED:

EMC ENVIRONMENT QUALITY ASSURANCE SAFETY
SUBMITTED FOR CENELEC PARALLEL VOTING NOT SUBMITTED FOR CENELEC PARALLEL VOTING
Attention IEC-CENELEC parallel voting
The attention of IEC National Committees, members of
CENELEC, is drawn to the fact that this Committee Draft for
Vote (CDV) is submitted for parallel voting.
The CENELEC members are invited to vote through the
CENELEC online voting system.

This document is still under study and subject to change. It should not be used for reference purposes.
Recipients of this document are invited to submit, with their comments, notification of any relevant patent rights of which they are
aware and to provide supporting documentation.

TITLE:
Amendment 1 – Rotating electrical machines – Part 18-42: Partial discharge resistant electrical insulation
systems (Type II) used in rotating electrical machines fed from voltage converters – Qualification tests

PROPOSED STABILITY DATE: 2021

NOTE FROM TC/SC OFFICERS:
TC 2 officers support decision of MT10 to skip CD stage on this amendment with the following justifications :
• DC (2/1883/DC) which closed on 12/2017 has received plenty of comments and MT 10 has dealt with all
these comments (please see 2/1893A/INF).
• This first draft of amendment not contain fundamental changes, and appropriate to submit as CDV

Copyright © 2018 International Electrotechnical Commission, IEC. All rights reserved. It is permitted to download this
1 FOREWORD
electronic file, to make a copy and to print out the content for the sole purpose of preparing National Committee positions. You
may not copy or "mirror" the file or printed version of the document, or any part of it, for any other purpose without permission
in writing from IEC.

---------------------- Page: 3 ----------------------

SIST EN 60034-18-42:2018/oprA1:2019
2 IEC CDV 60034-18-42:2017/
AMD1 © IEC 2018

2 This amendment has been prepared by IEC Technical Committee 2: Rotating Electrical Machines.
3 The text of this amendment is based on the following documents:
Pub Report on voting
IEC 60034-18-42:2017 XX/XX/RVD
4
5 Full information on the voting for the approval of this amendment can be found in the report on
6 voting indicated in the above table.
7 The committee has decided that the contents of this publication will remain unchanged until the
8 stability date indicated on the IEC website under "http://webstore.iec.ch" in the data related to the
9 specific publication. At this date, the publication will be
10 • reconfirmed,
11 • withdrawn,
12 • replaced by a revised edition, or
13 • amended.
14
15 The National Committees are requested to note that for this publication the stability date is 2020
16 THIS TEXT IS INCLUDED FOR THE INFORMATION OF THE NATIONAL COMMITTEES AND WILL BE DELETED AT
17 THE PUBLICATION STAGE.
18
19 _____________
20

---------------------- Page: 4 ----------------------

SIST EN 60034-18-42:2018/oprA1:2019
IEC CDV 60034-18-42:2017/ 3
AMD1 © IEC 2018

21 INTERNATIONAL ELECTROTECHNICAL COMMISSION
22 ____________
23
24 ROTATING ELECTRICAL MACHINES
25
26 Part 18-42: Partial discharge resistant electrical insulation systems (Type II)
27 used in rotating electrical machines fed from voltage converters - Qualification
28 tests
29
30 Amendment 1
31
32 Replace definitions with the following
33 3.11
34 impulse voltage repetition rate
35 f
36 average of the inverse of the time between two successive impulses of the same polarity, whether
37 unipolar or bipolar – in a considered set of pulses, e.g. for one periode
38
39 3.18
40 impulse voltage insulation class for Type II insulation systems
41 IVIC
42 peak to peak voltage classes 1, 2, 3, 4, 5, 6, 7, S including certain time parameters for reliable operation,
43 assigned by the manufacturer in relation to the rated voltage for a specified converter-driven machine and
44 indicated in its documentation and, if applicable, on its rating plate
45 Replace 3.29 with the following
46 3.29
47 maximum allowable peak to peak phase to ground voltage
48 U
IVIC
49 maximum allowable peak to peak phase to ground voltage in service, according to the IVIC-specification
50 Add the following definition
51 3.30 TVF
52 Test Voltage Factor
53 TVF
54 Max. allowable peak to peak operating phase-ground-voltages in units of UN , divided by 2√2
55 Replace Table 1 with the following.
56 Table 1 – Examples of the measured values of characteristics of the terminal voltages for two
57 converter-fed machines
Machine rating 3,3 kV 6,6 kV
Measured Peak to peak voltage on the 7,9 kV 13,9 kV
phase to ground insulation
Fundamental frequency 50/60 Hz 50/60 Hz
Impulse rise time at the motor terminals 1 µs 3 µs
Impulse repetition rate 1 kHz 900 Hz
IVIC required to qualify the insulation for 3 2
this service (See Table D.2, column 2)
58

---------------------- Page: 5 ----------------------

SIST EN 60034-18-42:2018/oprA1:2019
4 IEC CDV 60034-18-42:2017/
AMD1 © IEC 2018

59 The maximum change in voltage or jump voltage (U ) at the impulse repetition rate is shown in
j
60 Figure 3. This parameter is important in defining the voltage enhancement that can occur across the
61 first or last coil in the winding. A fundamental frequent double jump transition (Figure 3, U )) is
j max
62 possible and needs to be considered accordingly.
63
64


U

t
U
j max

j
UU

Figure 3 - Jump voltage (U U ) at the terminals of a machine fed from a converter drive
j or j max
65
66 10.2 Test methods
67 The purpose of testing is to show that the electrical life of the turn insulation provides a life in
68 service which is acceptable to the customer. It is expected that the manufacturer will know the
69 maximum peak to peak voltage to appear between turns in a particular service application. The
70 worst case insulation stress (depending on winding and coil design) shall be chosen. If the
71 maximum peak to peak voltage between turns in service U is unknown, it shall be assumed that
turn
72 the complete jump voltage falls across the first coil and so the amplitude of U is the jump voltage
turn
73 divided by the number of turns (for one layer coils) or calculated according to the arrangement of
74 turns (for multilayer coils). The peak-peak turn-turn voltage is than normally twice the amplitude –
75 as the rise time and the fall time of the jumps is usually the same.
76
77
78 12.4 Stress control specimens
79 To qualify the stress control system to be used, testing of coils or bars, built to production standards
80 and fitted into representative slots, is undertaken. The slots shall be equipped with heaters for the
81 heating of the straigh
...
