prEN IEC 60794-1-127:2025 specifies the Indoor simulated installation test (Method E27) for optical fibre cables. Published as part of the IEC 60794-1-1xx series, this mechanical test method is intended to reproduce demanding indoor routing conditions - tight corners, attachment points and cable storage - to assess cable robustness and optical performance for telecommunication and hybrid optical/electrical cables. The method replaces and revises the former E27 in IEC 60794-1-21:2015 and is primarily aimed at evaluating cables that use bending loss insensitive fibres.

Key topics and technical requirements

• Scope: Applies to optical fibre cables used with telecommunication equipment and cables combining optical fibres and electrical conductors.
• Sample length: A continuous cable long enough for the procedure; a minimum of 100 m is recommended.
• Apparatus: Simulated wall/fixture (stud or substrate) with sharp corners and attachment points. Metallic corners are recommended to avoid unwanted indentation artifacts.
• Test sequence (summary):
  • Multiple tight corner bends (14 × 90° corners, 1 mm apparatus corner radius) with minimal manual tension
  • Single 90° corner bend under 2 kg load
  • Single 90° corner bend under rated residual load
  • Two 10 mm mandrel wraps
  • 30 attachment points (staples, ties, adhesives as specified)
• Optical monitoring: If required, use optical monitoring per IEC 60793-1-46; measure attenuation before and after the test and calculate change in attenuation.
• Acceptance guidance: Typical stapling-related attenuation change recommended not to exceed 0.20 dB at 1550 nm (single‑mode) and 0.40 dB at 1300 nm (multimode). Final acceptance criteria are specified in the relevant product specification.
• Customizable parameters: substrate type, number/radius of bends, attachment method, test temperature, residual load, and acceptance limits must be stated in the product specification.

Practical applications

• Validates cable designs for demanding indoor deployments where routing around sharp corners, staples and constrained storage is expected (e.g., office, residential and data‑centre interiors).
• Demonstrates mechanical robustness and optical performance stability after simulated installation stress.
• Useful during product development, quality control, type testing and supplier qualification for indoor optical fibre cables.

Who should use this standard

• Cable manufacturers and R&D teams designing indoor optical fibre cables
• Independent test laboratories and certification bodies
• Telecommunications installers, specifiers and procurement teams writing product acceptance criteria
• Standards committees and compliance engineers assessing mechanical/optical resilience

Related standards

• IEC 60794-1-1 - Generic specification: general requirements and definitions
• IEC 60794-1-2 - Basic optical cable test procedures: general guidance and cross-references
• IEC 60793-1-46 - Measurement methods for monitoring changes in attenuation (optical monitoring)

Keywords: optical fibre cables, indoor simulated installation test, IEC 60794-1-127, mechanical test, corner bends, stapling, mandrel wrap, attenuation, bending loss insensitive fibre.
