SIST ETS 300 396-5 E1:2003

• Abstract:

  To define the technical requirements for DMO gateways.

• Status: Published
• Publication Date: 30-Nov-2003
• ICS: 33.070.10 - Terrestrial Trunked Radio (TETRA)
• Technical Committee: SS EIT - Technical Board for the electrotechnical, information technology and telecommunications fields
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Dec-2003
• Due Date: 01-Dec-2003
• Completion Date: 01-Dec-2003
• Mandate: BC-T-344
• Mandate: T-172
• Ref Project: ETSI ETS 300 396-5 ed.1 (2000-01) - Terrestrial Trunked Radio (TETRA); Technical requirements for Direct Mode Operation (DMO); Part 5: Gateway air interface

SIST ETS 300 396-5 E1:2003 is the SIST version of ETS 300 396-5 Edition 1 for Terrestrial Trunked Radio (TETRA) Direct Mode Operation (DMO). It specifies the gateway air interface used to connect Direct Mode Mobile Stations (DM-MS) to the TETRA Voice plus Data (V+D) system, including both DM-GATE and DM-REP/GATE implementations. Engineers use it to design, integrate and test gateway call control, short data, mobility management, and the DM radio link.

What does SIST ETS 300 396-5 E1:2003 specify?

SIST ETS 300 396-5 E1:2003 focuses on the Direct Mode gateway air interface. It covers how a gateway relays traffic between the DM and V+D sides, and it applies to a standalone DM-GATE as well as a combined DM-REP/GATE.

The document says the gateway may use either a type 1A repeater, operating on a single DM RF carrier, or a type 1B repeater, operating on a pair of duplex-spaced DM RF carriers. The choice of the DM RF carrier(s) is not standardized in this part.

The standard is organized into clauses 1 to 17, followed by two normative annexes. Early clauses define the scope, references, terms and protocol overview; the middle clauses describe DM-MS and gateway services and protocols; later clauses cover gateway call control, mobility management, U-plane conversion, layer 2 behavior, PDU coding, radio aspects, and the gateway V+D protocol stack.

Annex	What it covers
Annex A	DM timers and constants in the DM-MS and gateway, including layer 2 and layer 3 values and maximum frame transmission counts
Annex B	V+D elements required for DM gateway operation, including DM-MS address and U-MM STATUS / D-MM STATUS elements

What are the key requirements of SIST ETS 300 396-5 E1:2003?

The main requirement is that the gateway shall interwork between the DM and V+D air interfaces and support only one call at a time on the DM side. In practice, that means gateway implementations must be built around a single active call context, not multiple parallel DM calls on the same DM RF resource.

• Clause 4 and 13 - The gateway relays information between Ud and Um and behaves either as DM-GATE or DM-REP/GATE. This matters because the same protocol model has to work for both a direct gateway and a repeater/gateway combination.
• Clauses 4.2, 8.4 and 13.4 - A DM channel can be free, occupied, reserved, or in a registration phase. The access rules change with each state, so terminals and gateways need state-aware channel surveillance before they transmit.
• Clauses 6.2 and 9.3 - Outgoing call set-up through a gateway is a two-phase process. The DM-MS first sends DM-GSETUP and waits for DM-GACK or DM-GCONNECT; after DM-GCONNECT, the DM-MS becomes master and sends DM-SETUP. This is important because implementers must handle the temporary reservation phase and the master/slave role change.
• Clauses 6.2, 9.3 and 13.4 - The document defines procedures for incoming calls, late entry, occupation, reservation, pre-emption and changeover using PDUs such as DM-OCCUPIED, DM-TX REQUEST, DM-PREEMPT, DM-GTX REQUEST, DM-GPREEMPT and DM-GRELEASE. In practice, these procedures decide who may talk, when a call can be interrupted, and how new traffic gains access.
• Clauses 6.3 and 9.4 - Short Data Service (SDS) can be sent on a free channel, by pre-emption, during circuit mode transmission, or as a transaction within an ongoing call. For acknowledged short data, the confirm seen by the DM side reflects successful delivery to the gateway or V+D side, not direct receipt by the called terminal.
• Clauses 6.4, 10 and Annex B - DMMM is optional on the DM-MS, but when used it supports registration and gateway presence information. The gateway also registers to the SwMI using its own ITSI, and registration can be solicited or unsolicited, accepted or rejected, or cancelled. This matters for identity management and for deciding whether a terminal is allowed to attach to the gateway.
• Clauses 7, 8, 12, 13 and Annex A - Layer 2 defines SAPs, primitives and procedures for addressing, fragmentation and reconstruction, fill-bit handling, random access, air interface encryption, timing change, and slot/frame numbering changes. Annex A provides the timers, constants and transmission limits that make these procedures work consistently in real implementations.
• Clauses 14 to 17 - The standard defines gateway-specific PDU formats, information element coding, radio aspects for DM-MS and gateway, synchronization, channel coding and scrambling, and the gateway V+D protocol stack. This is the material used when building interoperable equipment and when writing test cases.

What terms does SIST ETS 300 396-5 E1:2003 define?

• Direct Mode Operation (DMO) - The TETRA mode in which DM-MSs communicate directly on the DM air interface, with optional interworking through a gateway or repeater.
• Direct Mode Gateway (DM-GATE) - A gateway that bridges DM traffic and signalling to the V+D system.
• Direct Mode Repeater/Gateway (DM-REP/GATE) - A combined repeater and gateway implementation used to relay DM communications between DM and V+D, either as type 1A or type 1B.
• Direct Mode Call Control (DMCC) - The layer 3 entity that handles DM calls and short data messages for a DM-MS operating with a gateway.
• Direct Mode Mobility Management (DMMM) - The optional layer 3 entity that handles registration and gateway presence information for a DM-MS.
• Direct Mode Mobile Station (DM-MS) - A mobile station operating in DMO.
• Group Short Subscriber Identity (GSSI) - The group identity used in the DMMM service and in gateway-related registration handling.
• Individual TETRA Subscriber Identity (ITSI) - The individual identity used when the gateway registers to the SwMI.

Who uses SIST ETS 300 396-5 E1:2003?

Gateway manufacturers, TETRA terminal vendors, system integrators, network operators and test laboratories use SIST ETS 300 396-5 E1:2003. They use it to build gateway behavior, verify call set-up and release, implement short data and registration handling, and check DM-side radio and timing behavior.

It is especially relevant when equipment must interwork between Direct Mode and a TETRA V+D network. It also matters to labs and quality teams writing interoperability and protocol tests for DM-GATE and DM-REP/GATE equipment.

What changed in SIST ETS 300 396-5 E1:2003 from the previous edition?

SIST ETS 300 396-5 E1:2003 is identified as identical to ETS 300 396-5 Edition 1.

Which standards are used with SIST ETS 300 396-5 E1:2003?

Standard	What it contributes
ETS 300 396-1	General DMO network design and overall architectural context
ETS 300 396-2	DMO radio aspects that complement the gateway air interface requirements
ETS 300 396-3	The base DMO MS-MS air interface protocol that this gateway part builds on and adapts
ETS 300 392-2	V+D-side protocol detail, especially the call-control behavior referenced for gateway operation
ETS 300 396-6	MM security PDUs used in the short-data and security-related mappings

What does the SIST ETS 300 396-5 E1:2003 document contain?

The document contains the gateway-side protocol model in detail, including service descriptions, service primitives and state machines for DM-MS and gateway behavior. It also contains the procedures for circuit mode calls, short data, registration, pre-emption, changeover and mobility management.

It provides PDU descriptions and information element coding for gateway-specific DM messages, along with mappings between DMO and V+D information elements. Annex A supplies timers and constants, and Annex B lists the V+D elements needed for DM gateway operation.

The later clauses cover the radio aspects of both the DM-MS and the gateway, including modulation, frequency bands, synchronization, channel coding, scrambling and channel multiplexing. These parts are used when implementing equipment and when checking interoperability, timing and radio performance.
