SIST EN 303 447 V1.3.1:2022
(Main)Short Range Devices (SRD) - Harmonised Standard for access to radio spectrum - Inductive loop systems for robotic mowers operating within the frequency range 100 Hz to 148,5 kHz
Short Range Devices (SRD) - Harmonised Standard for access to radio spectrum - Inductive loop systems for robotic mowers operating within the frequency range 100 Hz to 148,5 kHz
The present document specifies technical characteristics and methods of measurements for Robotic Mowers with
Inductive loop systems (RMI) operating within the frequency range 100 Hz to 148,5 kHz.
The present document covers the following RMI systems:
• RMI1 systems: RMI systems without receive only mode
• RMI2 systems: RMI systems with receive only mode
NOTE 1: In RMI1 systems the robotic mower is not able to restart automatically if the boundary signal comes back
after the loss of the boundary signal (safe mode, see clause 4.2.2.3), while in RMI2 systems the robotic
mower is able to restart automatically after the boundary signal is back. This differentiation has been
introduced to cover receiver spurious emissions for RMI2 systems.
These radio equipment types are capable of operating in all or part of the frequency bands given in table 1.
Table 1: Permitted range of operation
Permitted range of operation
Transmit 100 Hz to 148,5 kHz
Receive 100 Hz to 148,5 kHz
NOTE: It should be noted that the frequency range between 9 kHz and
148,5 kHz is EU wide harmonised for inductive Short Range
Devices according to EC Decision 2017/1483/EU [i.2].
NOTE 2: The relationship between the present document and essential requirements of article 3.2 of Directive
2014/53/EU [i.3] is given in Annex A.
The present document only covers RMI systems with antenna sizes smaller than 1,67 km, see
CEPT/ERC/REC 70-03 [i.1], Annex 9.
NOTE 3: The antenna size is described by the distance between those two points on the antenna that have the
largest distance between them (e.g. for a rectangle shaped antenna the largest diagonal; for a circular
shaped antenna the diameter).
Naprave kratkega dosega (SRD) - Harmonizirani standard za dostop do radijskega spektra - Sistemi z indukcijsko zanko za robotske kosilnice, ki delujejo v frekvenčnem območju od 100 Hz do 148,5 kHz
Ta dokument določa tehnične lastnosti in merilne metode za robotske kosilnice s sistemi z indukcijsko zanko (RMI), ki delujejo v frekvenčnem območju od 100 Hz do 148,5 kHz.
Ta dokument obravnava naslednje sisteme z indukcijsko zanko:
• sistemi RMI1: sistemi RMI brez delovanja samo v načinu za sprejemanje;
• sistemi RMI2: sistemi RMI z delovanjem samo v načinu za sprejemanje.
OPOMBA 1: V sistemih RMI1 se robotska kosilnica ne more samodejno ponovno zagnati, če se po izgubi mejnega signala ta ponovno vzpostavi (varni način, glej klavzulo 4.2.2.3), medtem ko se v sistemih RMI2 robotska kosilnica lahko samodejno znova zažene, potem ko se ponovno vzpostavi mejni signal. To razlikovanje je bilo uvedeno, da bi se zajele neželene emisije sprejemnika za sisteme RMI2.
Ti tipi radijske opreme lahko delujejo v vseh frekvenčnih pasovih iz preglednice 1 ali njihovem delu.
Preglednica 1: Dovoljeno območje delovanja
Dovoljeno območje delovanja
Oddajanje od 100 Hz do 148,5 kHz
Sprejemanje od 100 Hz do 148,5 kHz
OPOMBA: Priporočljivo je upoštevati, da je frekvenčno območje med 9 kHz
in 148,5 kHz harmonizirano za celotno EU za induktivne naprave kratkega dosega
v skladu s sklepom Komisije 2017/1483/EU [i.2].
OPOMBA 2: Razmerje med tem dokumentom in bistvenimi zahtevami člena 3.2 Direktive 2014/53/EU [i.3] je podano v dodatku A.
Ta dokument zajema samo sisteme RMI z velikostjo antene, manjšo od 1,67 km, glej CEPT/ERC/REC 70-03 [i.1], dodatek 9.
OPOMBA 3: Velikost antene je opisana z razdaljo med točkama na anteni, med katerima je razdalja največja (npr. pri pravokotni anteni največja diagonala; pri krožni anteni premer).
