General Information
- Abstract
This clause of Part 1 is replaced by the following:
This document applies to temperature sensing controls
– for use in, on, or in association with equipment for household appliance and similar use, including equipment for heating, air-conditioning and similar applications. The equipment can use electricity, gas, oil, solid fuel, solar thermal energy, etc., or a combination thereof.
NOTE 1 Throughout this document, the word "equipment" means "appliance and equipment" and "controls" means "temperature sensing controls".
– for building automation within the scope of ISO 16484 series and IEC 63044 series (HBES/BACS);
EXAMPLE 1 Independently mounted temperature sensing controls, controls in smart grid systems and controls for building automation systems within the scope of ISO 16484-2.
– for equipment that is used by the public, such as equipment intended to be used in shops, offices, hospitals, farms and commercial and industrial applications;
EXAMPLE 2 Controls for commercial catering, heating and air-conditioning equipment.
– that are smart enabled controls;
EXAMPLE 3 Smart grid control, remote interfaces/control of energy-consuming equipment including computer or smart phone.
– that are AC or DC powered controls with a rated voltage not exceeding 690 V AC or 600 V DC;
– used in, on, or in association with equipment that use electricity, gas, oil, solid fuel, solar thermal energy, etc., or a combination thereof;
– utilized as part of a control system or controls which are mechanically integral with multifunctional controls having non-electrical outputs;
– using NTC or PTC thermistors and to discrete thermistors, requirements for which are contained in Annex J;
– that have electrical circuits and control circuits which are, for example, operated by bimetals, magnet coils, memory metals, pressure elements, temperature-sensitive
expansion elements or electronic elements.
– as well as manual controls when such are electrically and/or mechanically integral with automatic controls.
NOTE 2 Requirements for manually actuated mechanical switches not forming part of an automatic control are contained in IEC 61058-1-1.
This document applies to
– the inherent safety of automatic electrical controls, and
– functional safety of temperature sensing controls and safety related systems,
– controls where the performance (for example the effect of EMC phenomena) of the product can impair the overall safety and performance of the controlled system,
– the operating values, operating times, and operating sequences where such are associated with equipment safety and to the testing of automatic electrical temperature sensing control devices used in, or in association with, equipment,
EXAMPLE 4 Boiler thermostats, fan controls, temperature limiters and thermal cut-outs.
– electrical safety of temperature sensing controls with non-electrical outputs such as refrigerant flow and gas controls,
– single-operation devices as defined in this document.
This document specifies the requirements for construction, operation and testing of automatic electrical controls used in, on, or in association with an equipment.
This document does not
– apply to automatic electrical temperature sensing controls intended exclusively for industrial process applications unless explicitly mentioned in the relevant part 2 or the equipment standard. However, this document can be applied to evaluate automatic electrical controls intended specifically for industrial applications in cases where no relevant safety standard exists.
– take into account the response value of an automatic action of a control, if such a response value is dependent upon the method of mounting the control in the equipment. Where a response value is of significant purpose for the protection of the user, or surroundings, the value defined in the appropriate equipment standard or as determined by the manufacturer will apply.
– address the integrity of the output signal to the networ
- Status
- Published
- Public Enquiry End Date
- 15-Sep-2024
- Publication Date
- 19-Aug-2026
- Technical Committee
- ISS EIT.NZG - Household apliances
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 14-Jul-2026
- Due Date
- 18-Sep-2026
- Completion Date
- 20-Aug-2026
Overview
SIST EN IEC 60730-2-9:2026 is a Slovenian adoption of an international standard focused on automatic electrical controls, specifically covering the particular requirements for temperature sensing controls. Developed by IEC Technical Committee 72, this standard is part of the broader IEC 60730 series and serves as a supplement to general requirements in IEC 60730-1.
The standard addresses the safety, construction, operation, and testing of temperature sensing controls used in household appliances, heating, ventilation and air conditioning (HVAC) systems, building automation applications, and commercial settings. As energy management and automation continue to advance, the relevance of robust requirements for temperature controls is essential for ensuring safe, reliable, and efficient appliance and system functioning.
Key Topics
- Product Scope: Applies to temperature sensing controls for household, commercial, and public-use equipment, as well as building automation systems in accordance with ISO 16484 and IEC 63044.
- Integration: Covers controls used with a range of energy sources, including electricity, gas, oil, solid fuel, and solar thermal energy, as well as combinations of these.
- Types of Controls: Includes requirements for various control technologies (bimetals, magnet coils, thermistors, memory metals, and pressure elements) and both AC and DC powered controls up to specific voltage limits.
- Control Classes: Encompasses both automatic and manual controls, as well as single operation devices (SODs), room thermostats, boiler thermostats, agricultural thermostats, and more.
- Functional Safety & EMC: Addresses aspects of both inherent safety and functional safety in temperature sensing controls, including electromagnetic compatibility (EMC) considerations for emissions and immunity.
- Constructional Requirements: Specifies material standards, actuation methods (e.g., push-and-turn, pull-and-turn), and requirements for parts containing liquid metal or thermistor elements.
- Testing & Verification: Details comprehensive testing procedures for technical performance, fault assessment, endurance, environmental stress, electrical safety, and mechanical requirements.
Applications
SIST EN IEC 60730-2-9:2026 provides essential requirements for a wide variety of applications, including:
- Household appliances: Ensuring temperature safety and performance in equipment such as ovens, water heaters, HVAC units, refrigerators, and similar appliances.
- Building automation systems: Used in modern smart homes and commercial buildings, often integrated within building management systems for climate control and energy efficiency.
- Commercial and industrial settings: Provides safety requirements for temperature sensing controls in equipment installed in shops, offices, hospitals, farms, and other commercial environments.
- Smart enabled controls: Supports the design and assessment of controls interfacing with smart grids or remote management systems, enhancing energy management and automation.
- Special applications: Includes coverage for controls used in agricultural confinement buildings and devices utilizing non-traditional sensing elements or integrated manual controls.
Related Standards
- IEC 60730-1: General requirements for automatic electrical controls, which forms the foundational standard for the entire 60730 series.
- ISO 16484 series: Standards for building automation and control systems (BACS), referenced for building automation applications.
- IEC 63044 series: Applicable to home and building electronic systems (HBES).
- IEC 60691: Pertains to thermal links, referenced for single-operation temperature sensing devices.
- IEC 60216-1: Covers ageing of electrical insulating materials, applicable for evaluating materials in temperature sensing controls.
- IEC 61058-1-1: Requirements for manually actuated mechanical switches, relevant when such switches are integrated with automatic controls.
By adhering to SIST EN IEC 60730-2-9:2026, manufacturers, designers, and conformity assessment bodies can ensure that temperature sensing controls are safe, reliable, and suitable for integration in modern appliances and automated systems, supporting ongoing innovation and energy management in household and commercial settings.
Relations
- Effective Date
- 01-Sep-2026
- Effective Date
- 01-Sep-2026
- Effective Date
- 01-Sep-2026
- Effective Date
- 16-Jun-2026
- Effective Date
- 25-Aug-2026
- Effective Date
- 07-Jul-2026
- Effective Date
- 07-Jul-2026
- Effective Date
- 07-Jul-2026
- Effective Date
- 07-Jul-2026
- Effective Date
- 07-Jul-2026
- Referred By
SIST EN 89:2015 - Gas-fired storage water heaters for the production of domestic hot water - Effective Date
- 07-Jul-2026
- Effective Date
- 07-Jul-2026
- Effective Date
- 07-Jul-2026
- Referred By
SIST EN 89:2001 - Gas-fired storage water heaters for the production of domestic hot water - Effective Date
- 07-Jul-2026
- Effective Date
- 07-Jul-2026
Frequently Asked Questions
SIST EN IEC 60730-2-9:2026 is a standard published by the Slovenian Institute for Standardization (SIST). Its full title is "Automatic electrical controls - Part 2-9: Particular requirements for temperature sensing controls". This standard covers: This clause of Part 1 is replaced by the following: This document applies to temperature sensing controls – for use in, on, or in association with equipment for household appliance and similar use, including equipment for heating, air-conditioning and similar applications. The equipment can use electricity, gas, oil, solid fuel, solar thermal energy, etc., or a combination thereof. NOTE 1 Throughout this document, the word "equipment" means "appliance and equipment" and "controls" means "temperature sensing controls". – for building automation within the scope of ISO 16484 series and IEC 63044 series (HBES/BACS); EXAMPLE 1 Independently mounted temperature sensing controls, controls in smart grid systems and controls for building automation systems within the scope of ISO 16484-2. – for equipment that is used by the public, such as equipment intended to be used in shops, offices, hospitals, farms and commercial and industrial applications; EXAMPLE 2 Controls for commercial catering, heating and air-conditioning equipment. – that are smart enabled controls; EXAMPLE 3 Smart grid control, remote interfaces/control of energy-consuming equipment including computer or smart phone. – that are AC or DC powered controls with a rated voltage not exceeding 690 V AC or 600 V DC; – used in, on, or in association with equipment that use electricity, gas, oil, solid fuel, solar thermal energy, etc., or a combination thereof; – utilized as part of a control system or controls which are mechanically integral with multifunctional controls having non-electrical outputs; – using NTC or PTC thermistors and to discrete thermistors, requirements for which are contained in Annex J; – that have electrical circuits and control circuits which are, for example, operated by bimetals, magnet coils, memory metals, pressure elements, temperature-sensitive expansion elements or electronic elements. – as well as manual controls when such are electrically and/or mechanically integral with automatic controls. NOTE 2 Requirements for manually actuated mechanical switches not forming part of an automatic control are contained in IEC 61058-1-1. This document applies to – the inherent safety of automatic electrical controls, and – functional safety of temperature sensing controls and safety related systems, – controls where the performance (for example the effect of EMC phenomena) of the product can impair the overall safety and performance of the controlled system, – the operating values, operating times, and operating sequences where such are associated with equipment safety and to the testing of automatic electrical temperature sensing control devices used in, or in association with, equipment, EXAMPLE 4 Boiler thermostats, fan controls, temperature limiters and thermal cut-outs. – electrical safety of temperature sensing controls with non-electrical outputs such as refrigerant flow and gas controls, – single-operation devices as defined in this document. This document specifies the requirements for construction, operation and testing of automatic electrical controls used in, on, or in association with an equipment. This document does not – apply to automatic electrical temperature sensing controls intended exclusively for industrial process applications unless explicitly mentioned in the relevant part 2 or the equipment standard. However, this document can be applied to evaluate automatic electrical controls intended specifically for industrial applications in cases where no relevant safety standard exists. – take into account the response value of an automatic action of a control, if such a response value is dependent upon the method of mounting the control in the equipment. Where a response value is of significant purpose for the protection of the user, or surroundings, the value defined in the appropriate equipment standard or as determined by the manufacturer will apply. – address the integrity of the output signal to the networ
This clause of Part 1 is replaced by the following: This document applies to temperature sensing controls – for use in, on, or in association with equipment for household appliance and similar use, including equipment for heating, air-conditioning and similar applications. The equipment can use electricity, gas, oil, solid fuel, solar thermal energy, etc., or a combination thereof. NOTE 1 Throughout this document, the word "equipment" means "appliance and equipment" and "controls" means "temperature sensing controls". – for building automation within the scope of ISO 16484 series and IEC 63044 series (HBES/BACS); EXAMPLE 1 Independently mounted temperature sensing controls, controls in smart grid systems and controls for building automation systems within the scope of ISO 16484-2. – for equipment that is used by the public, such as equipment intended to be used in shops, offices, hospitals, farms and commercial and industrial applications; EXAMPLE 2 Controls for commercial catering, heating and air-conditioning equipment. – that are smart enabled controls; EXAMPLE 3 Smart grid control, remote interfaces/control of energy-consuming equipment including computer or smart phone. – that are AC or DC powered controls with a rated voltage not exceeding 690 V AC or 600 V DC; – used in, on, or in association with equipment that use electricity, gas, oil, solid fuel, solar thermal energy, etc., or a combination thereof; – utilized as part of a control system or controls which are mechanically integral with multifunctional controls having non-electrical outputs; – using NTC or PTC thermistors and to discrete thermistors, requirements for which are contained in Annex J; – that have electrical circuits and control circuits which are, for example, operated by bimetals, magnet coils, memory metals, pressure elements, temperature-sensitive expansion elements or electronic elements. – as well as manual controls when such are electrically and/or mechanically integral with automatic controls. NOTE 2 Requirements for manually actuated mechanical switches not forming part of an automatic control are contained in IEC 61058-1-1. This document applies to – the inherent safety of automatic electrical controls, and – functional safety of temperature sensing controls and safety related systems, – controls where the performance (for example the effect of EMC phenomena) of the product can impair the overall safety and performance of the controlled system, – the operating values, operating times, and operating sequences where such are associated with equipment safety and to the testing of automatic electrical temperature sensing control devices used in, or in association with, equipment, EXAMPLE 4 Boiler thermostats, fan controls, temperature limiters and thermal cut-outs. – electrical safety of temperature sensing controls with non-electrical outputs such as refrigerant flow and gas controls, – single-operation devices as defined in this document. This document specifies the requirements for construction, operation and testing of automatic electrical controls used in, on, or in association with an equipment. This document does not – apply to automatic electrical temperature sensing controls intended exclusively for industrial process applications unless explicitly mentioned in the relevant part 2 or the equipment standard. However, this document can be applied to evaluate automatic electrical controls intended specifically for industrial applications in cases where no relevant safety standard exists. – take into account the response value of an automatic action of a control, if such a response value is dependent upon the method of mounting the control in the equipment. Where a response value is of significant purpose for the protection of the user, or surroundings, the value defined in the appropriate equipment standard or as determined by the manufacturer will apply. – address the integrity of the output signal to the networ
SIST EN IEC 60730-2-9:2026 is classified under the following ICS (International Classification for Standards) categories: 97.120 - Automatic controls for household use. The ICS classification helps identify the subject area and facilitates finding related standards.
SIST EN IEC 60730-2-9:2026 has the following relationships with other standards: It is inter standard links to SIST EN IEC 60730-2-9:2019/A1:2019, SIST EN IEC 60730-2-9:2019, SIST EN IEC 60730-2-9:2019/A2:2020, SIST EN IEC 60216-1:2026, SIST EN 50465:2015, SIST EN 1596:1999, SIST EN 62282-3-100:2012, SIST EN 12897:2016, SIST EN 30-1-4:2012, SIST EN 12098-5:2018, SIST EN 89:2015, SIST EN 15500-1:2018, SIST EN 12977-5:2018, SIST EN 89:2001, SIST EN IEC 61316:2021. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
SIST EN IEC 60730-2-9:2026 is associated with the following European legislation: EU Directives/Regulations: 2014/30/EU, 2014/35/EU; Standardization Mandates: M/511, M/552. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
SIST EN IEC 60730-2-9:2026 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
