This document sets out requirements regarding the performance of characteristics of the following types of cross laminated timber to be used in buildings and bridges:
- type 1: Straight or curved cross laminated timber comprising only timber layers but no large finger joints;
- type 2: Straight cross laminated timber comprising only timber layers and large finger joints;
- type 3: Straight cross laminated timber comprising timber and wood-based panel layers but no large finger joints.
It also lays down procedures for assessment and verification of constancy of performance (AVPC) of characteristics and specifies marking and labelling of cross laminated timber.
This document covers cross laminated timber of all three types of cross laminated timber:
- manufactured according to this standard, which sets up provisions for:
- boundary conditions during manufacture of cross laminated timber;
- moisture content and temperature of timber to be bonded;
- production of finger joints and bonds between layers;
- to be used in service class 1 or 2 according to EN 1995 1 1;
- made of coniferous species and poplar listed in this standard;
- which may be made of layers made of different species having similar properties;
- bonded with phenolic or aminoplastic or moisture curing one-component polyurethane or emulsion polymer isocyanate adhesives of adhesive type I according to the respective standard;
- built up of at least three orthogonally bonded layers (at least two of them timber layers);
- which may have, depending on the number of layers, adjacent layers bonded parallel to the grain;
- made of timber layers which are made of strength graded timber according to EN 14081 1;
- made of timber layers having nominal thicknesses between 6 mm (including) and 60 mm (including) depending on the layup;
- made of timber layers
- which may comprise non-structural edge bonds; and
- have a mean gap width of less than or equal to 0,6 mm and a 90th percentile of the gap width of 2 mm;
- having nominal overall thicknesses up to 500 mm.
Additional provisions of this document apply for straight cross laminated timber comprising only timber layers and comprising large finger joints (type 2):
- made from cross laminated timber pieces having the same cross-section and layup;
- made from cross laminated timber pieces having nominal cross-sectional thicknesses from 51 mm (including) up to 345 mm (including) and nominal minimum thicknesses of the outer layers not less than 17 mm (including).
- made from cross laminated timber pieces solely comprising timber layers;
- made from plane cross laminated timber pieces;
- with parallel x-axes of the jointed components;
- with finger joints having a finger length of at least 45 mm and fingers which are visible at the two narrow sides of the components;
- bonded with phenolic or aminoplastic or moisture curing one-component polyurethane adhesives of adhesive type I according to the respective standard.
Additional provisions of this document apply for straight cross laminated timber comprising timber and wood-based panel layers but no large finger joints (type 3):
- made of structural wood-based panels specified in this European standard;
- made of one panel per layer and;
- having thicknesses between 6 mm (including) and 45 mm (including);
This document applies to cross laminated timber untreated or treated against biological attack.
This document does not cover:
- cross laminated timber treated with fire retardants;
- cross laminated timber which is produced from re-used timber or wood-based panels comprising re-used timber.
Holzbauwerke - Brettsperrholz - Anforderungen
In diesem Dokument werden die Anforderungen an die Leistungsmerkmale der folgenden Arten von Brett-sperrholz festgelegt, die in Gebäuden und Brücken verwendet werden:
- Typ 1 ebenes oder gekrümmtes Brettsperrholz, das nur Brettlagen, aber keine Universal-Keilzinken-verbindungen umfasst;
- Typ 2: ebenes Brettsperrholz, das nur Brettlagen und Universal-Keilzinkenverbindungen umfasst;
- Typ 3: ebenes Brettsperrholz, das Bretter und Holzwerkstofflagen, aber keine Universal-Keilzinken-verbindungen umfasst.
Darüber hinaus legt die Norm auch Verfahren zur Bewertung und Überprüfung der Leistungsbeständigkeit (AVCP) von Merkmalen sowie die Kennzeichnung und Etikettierung von Brettsperrholz fest.
Dieses Dokument gilt für alle drei Arten von Brettsperrholz:
- das nach dieser Norm hergestellt wurde, die folgende Bestimmungen festlegt:
- Randbedingungen bei der Herstellung von Brettsperrholz;
- Feuchtegehalt und Temperatur der zu verklebenden Bretter;
- Herstellung von Keilzinkenverbindungen und Klebverbindungen zwischen Lagen;
- das in der Nutzungsklasse 1 oder 2 nach EN 1995 1 1 angewendet wird;
- das aus Pappel oder Nadelholzarten besteht, die in dieser Norm aufgeführt sind;
- das aus Lagen bestehen darf, die aus verschiedenen Holzarten mit ähnlichen Eigenschaften hergestellt sind;
- das mit Phenoplast und Aminoplast-Klebstoffen oder einem feuchtigkeitsvernetzenden Ein-komponenten-Klebstoff auf Polyurethanbasis oder Emulsion-Polymer-Isocyanat-Klebstoffen vom Typ I nach der jeweiligen Norm verklebt ist;
- das aus mindestens drei rechtwinklig zueinander verklebten Lagen (mindestens zwei Lagen sind Brettlagen) besteht;
- bei dem je nach Anzahl der Lagen aneinandergrenzende Lagen parallel zur Faser verklebt werden dürfen;
- das aus Lagen aus Vollholz (Bretter oder Bohlen, im Folgenden als Bretter bezeichnet) besteht, das entsprechend EN 14081 1 nach Festigkeit sortiert ist;
- das aus Brettlagen mit Nenndicken von 6 mm (einschließlich) bis 60 mm (einschließlich) besteht, je nach Aufbau;
- das aus Brettlagen besteht;
- das möglicherweise keine Schmalseitenverklebungen für tragende Zwecke enthält; und
das eine mittlere Spaltbreite von kleiner oder gleich 0,6 mm und ein 90. Perzentil der Spaltbreite von 2 mm aufweist;
- das Gesamt-Nenndicken von bis zu 500 mm hat.
Zusätzliche Bestimmungen dieses Dokuments gelten für ebenes Brettsperrholz, das nur Brettlagen und Universal-Keilzinkenverbindungen (Typ 2) enthält:
- das aus Brettsperrholzstücken mit gleichem Querschnitt und Aufbau besteht;
- das aus Brettsperrholzstücken mit Querschnitts-Nenndicken von 51 mm (einschließlich) bis 345 mm (einschließlich) besteht, wobei die Mindest-Nenndicken der äußeren Lagen mindestens 17 mm (einschließlich) betragen;
- das aus Brettsperrholzstücken besteht, die ausschließlich Brettlagen enthalten;
- das aus ebenen Brettsperrholzstücken besteht;
- mit parallelen x Achsen der verbundenen Bauteile;
- das Keilzinkenverbindungen mit einer Keilzinkenlänge von mindestens 45 mm enthält, wobei die Keilzinken an den beiden Schmalseiten der Komponenten sichtbar sind;
- das mit Phenoplast und Aminoplast-Klebstoffen oder einem feuchtigkeitsvernetzenden Ein-komponenten-Klebstoff auf Polyurethanbasis vom Typ I nach der jeweiligen Norm verklebt ist.
Zusätzliche Bestimmungen dieses Dokuments gelten für ebenes Brettsperrholz, das Bretter und Holz-werkstofflagen, aber keine Universal Keilzinkenverbindungen (Typ 3) enthält:
- das aus den in dieser Europäischen Norm festgelegten Holzwerkstoffen für tragende Zwecke besteht;
- das aus einer Platte je Lage besteht und;
- mit Dicken zwischen 6 mm (einschließlich) und 45 mm (einschließlich).
Dieses Dokument gilt für Brettsperrholz, das unbehandelt ist oder gegen biologischen Befall behandelt wurde.
...
Structures en bois - Bois lamellé croisé - Exigences
Le présent document établit les exigences relatives aux propriétés pour les types suivants de bois lamellé croisé devant être utilisés dans les bâtiments et les ponts :
- type 1 : Bois lamellé croisé, droit ou courbe, constitué uniquement de couches de bois et sans aboutage à entures multiples de grandes dimensions ;
- type 2 : Bois lamellé croisé droit, constitué uniquement de couches de bois et comprenant des aboutages à entures multiples de grandes dimensions ;
- type 3 : Bois lamellé croisé droit, constitué de couches de bois et de couches en panneaux à base de bois, sans aboutage à entures multiples de grandes dimensions.
Il établit également les procédures d'évaluation et de vérification de la constance des performances (EVCP) pour les caractéristiques et spécifie le marquage et l'étiquetage du bois lamellé croisé.
Le présent document couvre le bois lamellé croisé appartenant à l'ensemble des trois types de bois lamellé croisé :
- fabriqué conformément à la présente norme, qui établit les dispositions pour :
- les exigences minimales relatives à la fabrication du bois lamellé croisé ;
- la teneur en humidité et la température du bois à coller ;
- la production des aboutages à entures multiples et du collage entre les couches ;
- destiné à être utilisé en classe de service 1 ou 2 conformément à l'EN 1995 1 1 ;
- constitué des essences de bois de résineux et de peuplier énumérés dans la présente norme ;
- qui peut être constitué de couches provenant de différentes essences avec des propriétés similaires ;
- collé avec des adhésifs de nature phénolique ou aminoplaste, des adhésifs polyuréthane monocomposants durcissant à l'humidité ou des adhésifs à base d'isocyanate et de polymère en émulsion de type I conformément à la norme correspondante ;
- constitué d'au moins trois couches collées orthogonalement (au moins deux d'entre elles étant des couches de bois) ;
- pouvant comporter, en fonction du nombre de couches, des couches contigües collées parallèlement au fil ;
- comportant des couches de bois constituées de bois classé pour sa résistance mécanique conformément à l'EN 14081 1 ;
- constitué de couches de bois avec une épaisseur nominale comprise entre 6 mm et 60 mm selon la combinaison ;
- constitué de couches de bois :
- pouvant comporter des collages sur chant non structuraux ; et
- possédant une largeur de jeu moyenne inférieure ou égale à 0,6 mm et un 90e percentile pour la largeur de jeu de 2 mm ;
- ayant des épaisseurs totales nominales inférieures ou égales à 500 mm.
Des dispositions supplémentaires du présent document s'appliquent au bois lamellé croisé droit, constitué uniquement de couches de bois avec aboutages à entures multiples de grandes dimensions (type 2) :
- constitué de pièces de bois lamellé croisé ayant la même section transversale et la même combinaison ;
- constitué de pièces de bois lamellé croisé ayant des épaisseurs de section transversale nominales comprises entre 51 mm (inclus) et 345 mm (inclus), ainsi que des épaisseurs minimales nominales des couches extérieures supérieures ou égales à 17 mm ;
- constitué de pièces de bois lamellé croisé comprenant uniquement des couches de bois ;
- constitué de pièces de bois lamellé croisé planes ;
- avec des axes x parallèles pour les composants aboutés ;
- avec des aboutages à entures multiples ayant une longueur d'au moins 45 mm et des entures qui sont visibles au niveau des deux faces étroites des composants ;
- collé avec des adhésifs de nature phénolique ou aminoplaste, ou des adhésifs polyuréthane monocomposants durcissant à l'humidité de type I conformément à la norme correspondante.
...
