Connectors for electrical and electronic equipment - Part 1: Detail specification for two-way, shielded or unshielded, free and fixed connectors - Mechanical mating information, pin assignment and additional requirements for Type 1 copper LC style (IEC 63171-1:2020)

This part of IEC 63171 covers two-way, shielded or unshielded, free and fixed connectors for
data transmission with frequencies up to 600 MHz and with current carrying capacity up
to 2,0 A at 60 °C. It is intended to specify the common dimensions, mechanical, electrical,
signal integrity, environmental characteristics, reliability specifications and corresponding
tests for these connectors.
