SIST EN 61338-1-3:2002

• Abstract:

  Describes the measurement methods of the complex relative permittivity of dielectric resonator materials at microwave frequencies by means of the dielectric rod resonator method short-circuited at both ends by parallel conducting plates.

• Status: Published
• Publication Date: 31-Aug-2002
• ICS: 31.140 - Piezoelectric devices
• ICS: 33.120.10 - Coaxial cables. Waveguides
• Technical Committee: SS EIT - Technical Board for the electrotechnical, information technology and telecommunications fields
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Sep-2002
• Due Date: 01-Sep-2002
• Completion Date: 01-Sep-2002
• Ref Project: EN 61338-1-3:2000 - Waveguide type dielectric resonators - Part 1-3: General information and test conditions - Measurement method of complex relative permittivity for dielectric resonator materials at microwave frequency

• Referred By: SIST EN 61338-1-5:2015 - Waveguide type dielectric resonators - Part 1-5: General information and test conditions - Measurement method of conductivity at interface between conductor layer and dielectric substrate at microwave frequency
• Effective Date: 03-Feb-2026
• Referred By: SIST EN 61338-2:2005 - Waveguide type dielectric resonators -- Part 2: Guidelines for oscillator and filter applications
• Effective Date: 03-Feb-2026
• Referred By: SIST EN IEC 63185:2021 - Measurement of the complex permittivity for low-loss dielectric substrates balanced-type circular disk resonator method (IEC 63185:2020)
• Effective Date: 03-Feb-2026
• Referred By: SIST EN 61338-1-4:2006 - Waveguide type dielectric resonators -- Part 1-4: General information and test conditions - Measurement method of complex relative permittivity for dielectric resonator materials at millimetre-wave frequency
• Effective Date: 03-Feb-2026
• Referred By: SIST EN 61338-1:2005 - Waveguide type dielectric resonators -- Part 1: Generic specification
• Effective Date: 03-Feb-2026

SIST EN 61338-1-3:2002 is the Slovenian standard identical to EN 61338-1-3:2000, based on IEC 61338-1-3:1999 from the International Electrotechnical Commission (IEC). It specifies a dielectric rod resonator method for measuring the complex relative permittivity of dielectric resonator materials at microwave frequencies. The document focuses on the properties needed for microwave resonator and filter materials - ε′, tan δ, TCF, and the temperature dependence of tan δ - for isotropic, homogeneous materials.

What does SIST EN 61338-1-3:2002 specify?

SIST EN 61338-1-3:2002 specifies how to measure microwave dielectric properties with a dielectric rod resonator short-circuited at both ends by parallel conducting plates. Clause 1 gives the scope and object, Clauses 2 to 7 cover the parameters, theory, specimen preparation, equipment, procedure, and error estimation, and Annex A is a bibliography.

Annex	What it covers
Annex A	Bibliography

The scope is practical and measurement-oriented. It sets out the method, the quantities to be measured, and the assumptions used in the calculations, so users can prepare specimens and interpret resonance data consistently.

What are the key requirements of SIST EN 61338-1-3:2002?

The standard requires the dielectric rod resonator method to be used for microwave measurements of complex relative permittivity. It also sets the practical range for use at 2 GHz to 20 GHz, for relative permittivity between 5 and 500, and for loss factor tan δ between 10^-5 and 10^-2. In practice, that tells the user whether the material and test frequency are suitable for this method.

Measured quantities and calculation basis

Clause 2 defines the measured parameters as ε′, tan δ, and TCF, and it relates them to resonance frequency, quality factor, temperature, and specimen expansion. Clause 3 then gives the theory and calculation equations. In practice, the measurement is not just a reading from an instrument - the final values come from resonance data, geometry, and correction terms.

Relative permittivity and loss factor

Clause 3.1 shows how ε′ and tan δ are calculated from the TE mode resonance frequency and the unloaded Q of the resonator. The method also corrects tan δ for the conductivity of the conducting plates. In practice, this means you must know the plate condition before you can trust the loss value of the specimen.

Conductivity of the conducting plates

Clause 3.2 requires the relative conductivity of the conducting plates to be determined in advance, using two standard dielectric rod resonators cut from the same cylinder but with different heights. The higher and shorter rods are measured at the same resonance frequency, and the Q difference is used to calculate plate conductivity. In practice, the standard turns the plate surface into a measured correction factor, which is important for low-loss materials.

Temperature coefficient and temperature dependence

Clause 3.3 defines TCF as a material constant and explains how resonance frequency changes with temperature and thermal expansion. It also gives a quadratic form when the frequency change is not linear with temperature. Clause 3.4 adds that tan δ at different temperatures must be corrected for the temperature dependence of plate conductivity. In practice, a lab needs temperature-controlled measurements if it wants reliable data for component design.

Specimen preparation and geometry

Clause 4.1 describes the preparation of standard dielectric rods, including polished ends that are parallel to each other and perpendicular to the axis. Clause 4.2 explains how to choose the test specimen dimensions from the mode chart so the TE mode falls in the desired range and avoids coupling with TM or HE modes. In practice, specimen geometry has a direct effect on measurement stability and unloaded Q.

Equipment and measurement conditions

Clause 5 specifies the measurement equipment and apparatus, including parallel conducting plates, semi-rigid cables, a microwave source, detector, and network analyzer. The setup also calls for the plate diameter to be about three times the specimen diameter, and the insertion attenuation to be between 20 dB and 40 dB, typically around 30 dB. In practice, the setup must suppress field disturbance while keeping the signal measurable.

Procedure and error control

Clause 6 gives the measurement sequence for complex permittivity and temperature coefficient, including reference-level measurement, repeated readings, and humidity control. Clause 7 explains the main error sources - finite plate size, conductivity uncertainty, air gaps, and field disturbance - and gives the round robin test result. In practice, the document tells users where measurement uncertainty comes from and what to control before reporting results.

What terms does SIST EN 61338-1-3:2002 define?

• Complex relative permittivity: The document writes this as ε = ε′ - jε″, where ε′ is the real part used for the main dielectric property and ε″ is the loss-related imaginary part.
• tan δ: The loss factor, defined as ε″/ε′, so lower values indicate lower microwave loss.
• TCF: The temperature coefficient of resonance frequency, a material constant that relates resonance-frequency change to temperature after allowing for thermal expansion.
• TE mode: The transverse electric resonance mode used for the permittivity and loss measurements in this standard.
• Q_u: The unloaded quality factor, which is combined with resonance frequency to derive tan δ.
• IA: Insertion attenuation, the coupling setting adjusted during measurement so the resonator response is usable without excessive disturbance.
• σ_r: Relative conductivity of the conducting plates, measured against standard annealed copper and used as a correction in the loss calculation.

Who uses SIST EN 61338-1-3:2002?

SIST EN 61338-1-3:2002 is used by material suppliers developing dielectric resonator materials and by customers designing microwave resonators and filters. It is also used in measurement laboratories, quality control teams, and engineering groups that need comparable microwave data for candidate materials. In practice, it supports material development, incoming inspection, process comparison, and laboratory reporting.

Which standards are used with SIST EN 61338-1-3:2002?

The foreword places this document within IEC 61338, and the following companion parts are named:

• IEC 61338-1-1 - General information
• IEC 61338-1-2 - Test conditions
• IEC 61338-2 - Guide to the use of waveguide type dielectric resonators
• IEC 61338-3 - Standard outlines

These parts give the wider context for the series, while Part 1-3 focuses on the microwave permittivity measurement method.

What does the SIST EN 61338-1-3:2002 document contain?

The document contains the measurement theory, equations, specimen preparation rules, test setup descriptions, procedures, and error estimates needed to use the dielectric rod resonator method. Figures 1 to 11 show the resonator configuration, mode charts, equipment layouts, resonance responses, and error behavior, while Tables 1 to 3 give example dimensions and recommended plate materials. It also includes the formulas for ε′, tan δ, plate conductivity, TCF, and temperature-dependent correction. Annex A gives the bibliography for further reading on dielectric resonator measurement methods.
