SIST EN 302 065-4 V1.1.1:2017
(Main)Short Range Devices (SRD) using Ultra Wide Band technology (UWB) - Harmonised Standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU - Part 4: Material Sensing devices using UWB technology below 10,6 GHz
Short Range Devices (SRD) using Ultra Wide Band technology (UWB) - Harmonised Standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU - Part 4: Material Sensing devices using UWB technology below 10,6 GHz
The present document specifies the requirements for material sensing applications using UWB technology operating in
all or part of the frequency band from 2,2 GHz to 8,5 GHz. Additionally, it specifies reduced emissions in the ranges
from 0,96 GHz to 2,2 GHz and 8,5 GHz to 10,6 GHz.
The present document applies to:
1) Material Sensing devices: a device enabling radio determination application designed to detect the location of
objects within a structure or to determine the physical properties of a material.
2) Equipment fitted with a non-user changeable antenna.
3) The main categories are:
a) Non fixed material sensors;
b) Non fixed building material sensors;
c) Fixed material sensors.
The present document does not apply to:
• UWB communication devices;
• Ground and wall probing radar devices;
• Through-wall radar imaging devices; and
• (Tank) Level Probing devices.
Equipment covered by the present document operates in accordance with ECC/DEC(07)01 [i.7] and Commission
Decision 2014/702/EU [i.12].
Naprave kratkega dosega (SRD), ki uporabljajo ultra širokopasovno (UWB) tehnologijo - Harmonizirani standard, ki zajema bistvene zahteve člena 3.2 direktive 2014/53/EU - 4. del: Zaznavala snovi, ki uporabljajo tehnologijo UWB s frekvencami pod 10,6 GHz
Ta dokument določa zahteve za zaznavala snovi, ki uporabljajo ultra širokopasovno tehnologijo (UWB) in delujejo v celotnem frekvenčnem pasu ali njegovem delu od 2,2 GHz do 8,5 GHz. Poleg tega določa zmanjšane emisije v območju od 0,96 GHz do 2,2 GHz in od 8,5 GHz do 10,6 GHz.
Ta dokument se uporablja za:
1) Zaznavala snovi: naprave, ki omogočajo radijsko določanje, zasnovano za zaznavanje lokacije predmetov v konstrukciji ali določanje fizičnih lastnosti materiala.
2) Opremo, ki vključuje fiksno anteno (uporabnik je ne more zamenjati).
3) Glavne kategorije so:
a) nefiksni senzorji snovi;
b) nefiksni senzorji gradbenega materiala;
c) fiksni senzorji snovi.
Ta dokument se ne uporablja za:
• komunikacijske naprave UWB;
• radarske naprave za sondiranje tal in zidov;
• radarske naprave za slikanje skozi steno in
• naprave za sondiranje nivoja v rezervoarjih.
Oprema, obravnavana v tem dokumentu, deluje v skladu z ECC/DEC(07)01 [i.7] in sklepom Komisije 2014/702/EU [i.12].
