1 Scope
This document specifies the characteristics of UV laser printable electrical lightweight wires ADA family
for use in the on-board 115 V (phase to neutral) or 200 V (phase-to-phase) AC, 28 VDC electrical
systems of aircraft at operating temperatures between −65 °C and 180 °C. These cables are
demonstrated to be arc resistant in sizes AWG 26 to 14 (115 VAC/200 VAC).
In addition, these cables are suitable for use at 230 VAC/400 VAC in pressurized zones only when
installed to take account of possible short circuit effects.
Other electrical system configurations are the responsibility of the users.
It is also possible to mark these cables by qualified compatible marking which satisfies the
requirements of EN 3838:2022.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN 2235:2022, Aerospace series — Single and multicore electrical cables, screened and jacketed —
Technical specification
EN 3475-100, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 100: General
EN 3475-201, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 201: Visual
examination
EN 3475-202, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 202: Mass
EN 3475-203, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 203: Dimensions
EN 3475-301, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 301: Ohmic
resistance per unit length
EN 3475-302, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 302: Voltage
proof test
EN 3475-303, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 303: Insulation
resistance
EN 3475-304, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 304: Surface
resistance
EN 3475-305, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 305: Overload
resistance
EN 3475-306, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 306: Continuity
of conductors
EN 3475-401, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 401: Accelerated
ageing
EN 3475-402, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 402: Shrinkage
and delamination
EN 3475-403, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 403:
Delamination and blocking
EN 3475-404, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 404: Thermal
shock
EN 3475-405, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 405: Bending at
ambient temperature
EN 3475-406, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 406: Cold bend
test
EN 3475-407, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 407:
Flammability
EN 3475-410, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 410: Thermal
endurance
EN 3475-411, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 411: Resistance
to fluids
EN 3475-412, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 412: Humidity
resistance
EN 3475-413, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 413: Wrap back
test
EN 3475-414, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 414: Differential
scanning calorimeter (DSC test)
EN 3475-418, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 418: Thermal
endurance for conductors
EN 3475-501, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 501: Dynamic
cut-through
EN 3475-502, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 502:
Notch propagation
EN 3475-503, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 503:
Scrape abrasion
EN 3475-504, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 504: Torsion
EN 3475-505, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 505: Tensile test
on conductors and strands
EN 3475-506, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 506:
Plating continuity
EN 3475-507, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 507: Adherence
of plating
EN 3475-508, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 508: Plating
thickness
EN 3475-511, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 511: Cable-to-
cable abrasion
EN 3475-512, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 512: Flexure
endurance
EN 3475-514, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 514: Porosity of
copper cladding on aluminium strands
EN 3475-601, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 601: Smoke
density
EN 3475-602, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 602: Toxicity
EN 3475-603, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 603: Resistance
to wet arc tracking
EN 3475-604, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 604: Resistance
to dry arc propagation
EN 3475-605, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 605: Wet short
circuit test
EN 3475-701, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 701:
Strippability and adherence of insulation to the conductor
EN 3475-703, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 703: Permanence
of manufacturer’s marking
EN 3475-704, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 704: Flexibility
EN 3475-705, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 705: Contrast
measurement
EN 3475-706, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 706: Laser
markability
EN 3475-707, Aerospace series — Cables, electrical, aircraft use — Test methods — Part 707:
Stabilization of assembly
EN 3719, Aerospace series — Aluminium or aluminium alloy conductors for electrical cables — Product
standard
EN 3838:2022, Aerospace series — Requirements and tests on user-applied markings on aircraft electrical
cables
Published as ASD-STAN prEN at the date of publication of this document, available at:
https://www.asd-stan.org/.
SIST EN 4681-004:202
...
