SIST EN 60432-1:2000

Incandescent lamps - Safety specifications - Part 1: Tungsten filament lamps for domestic and similar general lighting purposes

Specifies the safety and interchangeability requirements of tungsten filament incandescent lamps for general lighting service, having a rated wattage up to and including 200 W or a rated voltage from 50 V to 250 V inclusive. Replaces EN 60432 (1984).

Glühlampen - Sicherheitsanforderungen - Teil 1: Glühlampen für den Hausgebrauch und ähnliche allgemeine Beleuchtungszwecke

Lampes à incandescence - Prescriptions de sécurité - Partie 1: Lampes à filament de tungstène pour usage domestique et éclairage général similaire

Fournit les prescriptions de sécurité et d'interchangeabilité relatives aux lampes à filament de tungstène pour éclairage général ayant: une puissance nominale égale ou inférieure à 200 W; une tension nominale comprise entre 50 V et 250 V (limites incluses). Remplace la EN 60432 (1984).

Sijalke - Varnostne specifikacije - 1. del: Sijalke za uporabo v stanovanjih in podobnih primerih splošne razsvetljave (IEC 60432-1:1999, spremenjen)

Mednarodni IEC 60432-1 določa zahteve glede varnosti in zamenljivosti
sijalk za splošno uporabo v razsvetljavi, ki imajo naslednje značilnosti:
– nazivno moč do vključno 200 W;
– nazivno napetost od 50 V do vključno 250 V;
– bučke oblik* A, B, C, G, M, P, PS, PAR ali R ali druge oblike bučk, če se sijalke
uporabljajo za enak namen kot sijalke prej navedenih oblik;
– bučke z vsemi vrstami zaključkov;
– vznožke B15d, B22d, E12, E14, E17, E26**, E26d, E26/5039, E27 ali E27/5139.
Kadar je to smiselno uporabno, se ta standard uporablja tudi za sijalke z bučkami in vznožki, ki niso navedeni zgoraj, vendar se uporabljajo za enake namene. Ta standard določa metodo, ki naj bi jo proizvajalec uporabil za dokazovanje, da je njegov izdelek v skladu s tem standardom na podlagi ocene celotne proizvodnje, in sicer v zvezi z njegovimi evidencami o preskusih končnih izdelkov. To metodo je mogoče uporabiti tudi za certificiranje. Navedene so tudi podrobnosti serijskega preskusnega postopka, ki ga je mogoče uporabiti za omejeno oceno serij. Ta standard obravnava le varnostna merila in ne upošteva delovanja sijalk glede na značilnosti svetlobnega toka, življenjske dobe ali porabe energije. Bralci naj za značilnosti glede tipov, ki se običajno uporabljajo za splošno uporabo v razsvetljavi, gledajo standard IEC 60064.

General Information

• Status: Published
• Publication Date: 31-May-2000
• ICS: 29.140.20 - Incandescent lamps
• Technical Committee: IESV - Lamps and related equipment
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Jun-2000
• Due Date: 01-Jun-2000
• Completion Date: 01-Jun-2000
• Directive: 1194/2012 - Commission Regulation (EU) No 1194/2012 of 12 December 2012 implementing Directive 2009/125/EC of the European Parliament and of the Council with regard to ecodesign requirements for directional lamps, light emitting diode lamps and related equipment
• Directive: 2006/95/EC - Directive 2006/95/EC of the European Parliament and of the Council of 12 December 2006 on the harmonisation of the laws of Member States relating to electrical equipment designed for use within certain voltage limits (codified version)
• Directive: 2014/35/EU - Directive 2014/35/EU of the European Parliament and of the Council of 26 February 2014 on the harmonisation of the laws of the Member States relating to the making available on the market of electrical equipment designed for use within certain voltage limits
• Directive: 244/2009 - Commission Regulation (EC) No 244/2009 of 18 March 2009 implementing Directive 2005/32/EC of the European Parliament and of the Council with regard to ecodesign requirements for non-directional household lamps
• Directive: 73/23/EEC - Electrical equipment designed for use within certain voltage limits
• Directive: 874/2012 - Commission Delegated Regulation (EU) No 874/2012 of 12 July 2012 supplementing Directive 2010/30/EU of the European Parliament and of the Council with regard to energy labelling of electrical lamps and luminaires
• Ref Project: EN 60432-1:2000 - Incandescent lamps - Safety specifications - Part 1: Tungsten filament lamps for domestic and similar general lighting purposes

Relations

• Replaces: SIST EN 60432-1:1995 - Safety specifications for incandescent lamps -- Part 1: Tungsten filament lamps for domestic and similar general lighting purposes
• Effective Date: 06-May-2014
• Amended By: SIST EN 60432-1:2000/A2:2012 - Incandescent lamps - Safety specifications - Part 1: Tungsten filament lamps for domestic and similar general lighting purposes
• Effective Date: 17-May-2011
• Amended By: SIST EN 60432-1:2000/A1:2006 - Incandescent lamps - Safety specifications -- Part 1: Tungsten filament lamps for domestic and similar general lighting purposes (IEC 60432- 1:1999/A1:2005)
• Effective Date: 01-Jan-2006

Overview

EN 60432-1:2000 (equivalent to IEC 60432-1:1999) defines safety and interchangeability requirements for tungsten filament incandescent lamps intended for domestic and similar general lighting purposes. The standard covers lamps with rated wattage up to and including 200 W and rated voltages from 50 V to 250 V. It applies to common bulb shapes (A, B, C, G, M, P, PS, PAR, R) and a wide range of cap types (for example B15d, B22d, E12, E14, E17, E26, E27 and variants). EN 60432-1:2000 replaces the earlier EN 60432 (1984) and focuses on lamp safety - not on luminous performance or life characteristics.

Key Topics

The standard addresses practical, testable safety requirements and documentation practices. Major technical topics include:

• Scope and definitions for categories, classes, rated voltage/wattage and end-of-life.
• Marking requirements: mandatory legible markings (manufacturer, rated voltage or voltage range, rated wattage) and special symbols for reflector/bowl-mirror lamps or restricted operating positions.
• Protection against accidental contact for screw lampholders - compliance with gauge checks referenced in IEC 60061.
• Lamp cap temperature rise (Δts) measured per IEC 60360.
• Mechanical requirements: resistance to torque and other cap/neck mechanical tests.
• Electrical safety: insulation resistance for insulated skirts, protection of accidentally live parts, and creepage distances for certain caps.
• Safety at end of life and requirements to limit hazards during lamp failure.
• Interchangeability and information useful for luminaire design.
• Assessment and quality control: whole-production appraisal, batch testing, sampling procedures and acceptance criteria (ref. IEC 60410, ISO 3951).
• Normative annexes with test procedures (torque, induced-failure, operation-to-failure), packaging symbols and sampling tables.

Applications and Who Uses It

EN 60432-1:2000 is essential for:

• Lamp manufacturers to design, test and declare safety compliance.
• Test laboratories and certification bodies performing type and batch testing or whole-production assessment.
• Luminaire designers and OEMs who need cap temperature and interchangeability information for safe lamp–fitting integration.
• Regulatory authorities and procurement teams specifying safe domestic lighting products.
• Technical writers and standards specialists preparing declarations of conformity and product labelling.

Practical benefits include improved user safety, consistent interchangeability across markets, and clear test methods for cap temperature, mechanical integrity and end-of-life safety.

Related Standards

• IEC 60432-1 (text basis)
• IEC 60061‑1 / IEC 60061‑3 (lamp caps, holders and gauges)
• IEC 60360 (lamp cap temperature rise)
• IEC 60064 (performance of tungsten filament lamps)
• IEC 60598‑1 (luminaires - general requirements)
• IEC 60410, ISO 3951 (sampling and inspection)

Standards Content (Sample)

SLOVENSKI STANDARD
01-junij-2000
1DGRPHãþD
SIST EN 60432-1:1995
SIST EN 60432-1:1995/A1:1999
SIST EN 60432-1:1995/A2:1999
Sijalke - Varnostne specifikacije - 1. del: Sijalke za uporabo v stanovanjih in
podobnih primerih splošne razsvetljave (IEC 60432-1:1999, spremenjen)
Incandescent lamps - Safety specifications - Part 1: Tungsten filament lamps for
domestic and similar general lighting purposes
Glühlampen - Sicherheitsanforderungen - Teil 1: Glühlampen für den Hausgebrauch und
ähnliche allgemeine Beleuchtungszwecke
Lampes à incandescence - Prescriptions de sécurité - Partie 1: Lampes à filament de
tungstène pour usage domestique et éclairage général similaire
Ta slovenski standard je istoveten z: EN 60432-1:2000
ICS:
29.140.20 Žarnice z žarilno nitko Incandescent lamps
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

NORME CEI
INTERNATIONALE IEC
60432-1
INTERNATIONAL
Deuxième édition
STANDARD
Second edition
1999-08
Lampes à incandescence –
Prescriptions de sécurité –
Partie 1:
Lampes à filament de tungstène pour usage
domestique et éclairage général similaire
Incandescent lamps –
Safety specifications –
Part 1:
Tungsten filament lamps for domestic and
similar general lighting purposes
 IEC 1999 Droits de reproduction réservés  Copyright - all rights reserved
Aucune partie de cette publication ne peut être reproduite ni No part of this publication may be reproduced or utilized in
utilisée sous quelque forme que ce soit et par aucun procédé, any form or by any means, electronic or mechanical,
électronique ou mécanique, y compris la photo-copie et les including photocopying and microfilm, without permission in
microfilms, sans l'accord écrit de l'éditeur. writing from the publisher.
International Electrotechnical Commission 3, rue de Varembé Geneva, Switzerland
Telefax: [phone] e-mail: [e-mail] IEC web site http://www.iec.ch
CODE PRIX
Commission Electrotechnique Internationale
X
PRICE CODE
International Electrotechnical Commission
Pour prix, voir catalogue en vigueur
For price, see current catalogue

60432-1 © IEC:1999 – 3 –
CONTENTS
Page
FOREWORD . 5
Clause
1 General.7
1.1 Scope.7
1.2 Normative references.9
1.3 Definitions.9
2 Requirements.13
2.1 General.13
2.2 Marking.13
2.3 Protection against accidental contact in screw lampholders . 15
2.4 Lamp cap temperature rise (Δt ). 17
s
2.5 Resistance to torque . 17
2.6 Insulation resistance of B15d, B22d, E26/50×39 and E27/51×39 capped lamps
and other lamps having insulated skirts . 21
2.7 Accidentally live parts. 23
2.8 Creepage distances for B15d and B22d capped lamps . 23
2.9 Safety at end of life . 23
2.10 Interchangeability.25
2.11 Information for luminaire design . 25
3 Assessment.27
3.1 General.27
3.2 Whole production assessment by means of the manufacturer’s records . 27
3.3 Assessment of the manufacturer’s records of particular tests. 29
3.4 Rejection conditions of batches . 31
3.5 Sampling procedures for whole production testing . 31
3.6 Sampling procedures for batch testing. 35
Annex A (normative) Miscellaneous test procedures . 37
Annex B (normative) Packaging marking symbols . 39
Annex C (normative) Resistance to torque test procedures . 41
Annex D (normative) Induced-failure test . 47
Annex E (normative) Operation-to-failure test . 53
Annex F (normative) Acceptance numbers for various sample sizes and AQLs . 57
Annex G (normative) Acceptance criteria – Continuously variable results . 69
Annex H (normative) Induced-failure test – Grouping, sampling and compliance . 73
Annex J (normative) Method of measuring mains impedance . 79
Annex K (informative) Information for luminaire design. 83

60432-1 © IEC:1999 – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
INCANDESCENT LAMPS –
SAFETY SPECIFICATIONS –
Part 1: Tungsten filament lamps for domestic and
similar general lighting purposes
FOREWORD
1) The IEC (International Electrotechnical Commission) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of the IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, the IEC publishes International Standards. Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. The IEC collaborates closely with the International Organization
for Standardization (ISO) in accordance with conditions determined by agreement between the two
organizations.
2) The formal decisions or agreements of the IEC on technical matters express, as nearly as possible, an
international consensus of opinion on the relevant subjects since each technical committee has representation
from all interested National Committees.
3) The documents produced have the form of recommendations for international use and are published in the form
of standards, technical reports or guides and they are accepted by the National Committees in that sense.
4) In order to promote international unification, IEC National Committees undertake to apply IEC International
Standards transparently to the maximum extent possible in their national and regional standards. Any
divergence between the IEC Standard and the corresponding national or regional standard shall be clearly
indicated in the latter.
5) The IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with one of its standards.
6) Attention is drawn to the possibility that some of the elements of this International Standard may be the subject
of patent rights. The IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60432-1 has been prepared by subcommittee 34A: Lamps, of IEC
technical committee 34: Lamps and related equipment.
The text of this standard is based on the following documents:
FDIS Report on voting
34A/873/FDIS 34A/887/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 3.
This second edition cancels and replaces the first edition of IEC 60432-1, published in 1993, its
Amendment 1 (1995) and Amendment 2 (1997). It constitutes a technical revision.
Annexes A through J form an integral part of this standard.
Annex K is for information only.
The committee has decided that this publication remains valid until 2003-09.
At this date, in accordance with the committee’s decision, the publication will be
• reconfirmed:
• withdrawn;
• replaced by a revised edition, or
• amended.
60432-1 © IEC:1999 – 7 –
INCANDESCENT LAMPS –
SAFETY SPECIFICATIONS –
Part 1: Tungsten filament lamps for domestic and
similar general lighting purposes
1 General
1.1 Scope
International Standard IEC 60432-1 specifies the safety and interchangeability requirements of
tungsten filament incandescent lamps for general lighting service having:
– rated wattage up to and including 200 W;
– rated voltage of 50 V to 250 V inclusive;
*
– bulbs of the A, B, C, G, M, P, PS, PAR or R shapes , or other bulb shapes where the lamps
are intended to serve the same purpose as lamps with the foregoing bulb shapes;
– bulbs with all kinds of finishes;
**
– caps B15d, B22d, E12, E14, E17, E26 , E26d, E26/50×39, E27 or E27/51×39.
As far as is reasonably practicable, this standard is also applicable to lamps with bulbs and
caps other than those mentioned above, but which serve the same purpose.
This standard specifies the method a manufacturer should use to show that his product
conforms to this standard on the basis of whole production appraisal in association with his test
records on finished products. This method can also be applied for certification purposes.
Details of a batch test procedure which can be used to make limited assessment of batches
are also given.
This standard is concerned with safety criteria only and does not take into account the
performance of tungsten filament lamps with respect to luminous flux, life or power
consumption characteristics. Readers should refer to IEC 60064 for such characteristics with
respect to types normally used for general lighting service.
__________
*
See IEC 60887 for description of the letter symbols. Associated traditional names are:
– Pear shape = A, PS
– Mushroom = M
– Candle = B, C (in North America)
– Round bulb = P
– Globular = G
– Reflector = R
– Parabolic reflector = PAR
**
There are two variations of E26 caps which are not fully compatible. In this standard separate references are
made to E26/24 caps used in North America and E26/25 caps used in Japan.

60432-1 © IEC:1999 – 9 –
1.2 Normative references
The following normative documents contain provisions which, through reference in this text,
constitute provisions of this International Standard. For dated references, subsequent
amendments to, or revisions of, any of these publications do not apply. However, parties to
agreements based on this International Standard are encouraged to investigate the possibility
of applying the most recent editions of the normative documents indicated below. For undated
references, the latest edition of the normative document referred to applies. Members of IEC
and ISO maintain registers of currently valid International Standards.
IEC 60061-1: Lamp caps and holders together with gauges for the control of interchangeability
and safety – Part 1: Lamp caps
IEC 60061-3: Lamp caps and holders together with gauges for the control of interchangeability
and safety – Part 3: Gauges
IEC 60064: Tungsten filament lamps for domestic and similar general lighting purposes.
Performance requirements
IEC 60360: Standard method of measurement of lamp cap temperature rise
IEC 60410: Sampling plans and procedures for inspection by attributes
IEC 60432-2: Incandescent lamps – Safety specification – Part 2: Tungsten halogen lamps for
domestic and similar general lighting purposes
IEC 60598-1: Luminaires – Part 1: General requirements and tests
IEC 60887: Glass bulb designation system for lamps
ISO 3951: Sampling procedures and charts for inspection by variables for percent non-
conforming
1.3 Definitions
For the purpose of this International Standard the following definitions apply.
1.3.1
category
all lamps of one manufacturer having the same general construction (bulb shape, external
dimensions, cap type, filament type), rated voltage, rated wattage and finish
For the purposes of this standard:
a) clear, frosted and coatings equivalent to a frosted finish are considered to be the same;
b) various coloured and white finishes are not considered to be the same.
NOTE – Lamps differing only by their caps (e.g. E27 and B22d) are of different “categories”, but of the same “type”
as defined in IEC 60064.
1.3.2
type
lamps which, independent of the type of cap, are identical in photometric and electrical
characteristics
60432-1 © IEC:1999 – 11 –
1.3.3
class
all lamps of one manufacturer having the same general construction (bulb shape, external
dimensions, cap type, filament type), rated wattage and finish and differing only by their rated
voltages, when these voltages fall within the same voltage range (e.g. 100 V to 150 V, 200 V
to 250 V)
1.3.4
rated voltage
voltage or voltage range specified in the relevant lamp standard or assigned by the
manufacturer or responsible vendor
(If lamps are marked with a voltage range, it shall be interpreted that they are appropriate for
use on any supply voltage within that range.)
1.3.5
test voltage
rated voltage unless otherwise specified
(If lamps are marked with a voltage range, the test voltage shall be taken as the mean of the
voltage range unless otherwise specified.)
1.3.6
rated wattage
wattage specified in the relevant lamp standard or assigned by the manufacturer or responsible
vendor
1.3.7
end of life
instant when the energized lamp ceases to emit light
1.3.8
cap temperature rise (Δt )
s
surface temperature rise, above ambient temperature, of a standard test lampholder fitted
to the lamp’s cap, when measured in accordance with the standard method described in
IEC 60360
1.3.9
design test
test made on a sample, for the purposes of checking compliance of the design of a category,
class or group of categories with the requirements of the relevant clause
1.3.10
periodic test
test repeated at intervals in order to check that the product does not deviate in certain respects
from the given design
1.3.11
running test
test applied at frequent intervals in order to provide data for assessment
1.3.12
batch
all the lamps of one category, identified as such, and put forward at one time for checking
compliance
60432-1 © IEC:1999 – 13 –
1.3.13
whole production
production of all types of lamps within the scope of this standard manufactured during a period
of 12 months and nominated by the manufacturer in a list for inclusion in the control, this list
being incorporated in the certificate when certification is in operation
1.3.14
bowl mirror lamp
lamp with part of its bulb coated with reflecting material so as to reflect a substantial part of the
light in the general direction of the lamp cap
1.3.15
maximum cap temperature
maximum temperature which the components in the cap area of a lamp are designed to
withstand over the expected life of the lamp
1.3.16
lamp neck reference diameter
that diameter of a lamp which is of influence on the protection against accidental contact and
which is measured at a defined distance from the solder contact plate
For E14 capped lamps, this distance is 30 mm.
2 Requirements
2.1 General
Lamps shall be so designed and constructed that in normal use they present no danger to the
user or surroundings.
Lamps shall satisfy the requirements of this clause.
2.2 Marking
2.2.1 Mandatory markings
The following information shall be marked on the lamps and shall be legible and durable when
subjected to the test procedure in A.1:
a) mark of origin (this may take the form of a trade mark, the manufacturer’s name or the
name of responsible vendor);
b) the rated voltage or the rated voltage range, marked as “V” or “volts”;
c) the rated wattage, marked as “W” or “watts”.
For lamps with 40 mm diameter bulbs or larger and with a realized wattage of 14 W or less, the
wattage need not be marked.
The rated voltage marking for lamps intended for use on United Kingdom supply voltages may
be 240 volts or 240 V.
NOTE – The United Kingdom implementation of 230 V European harmonization process allows supply voltages to
remain at 240 V.
60432-1 © IEC:1999 – 15 –
2.2.2 Dichroic reflectorized (cool beam) lamps and bowl mirror lamps
The immediate lamp wrapping or container shall be marked with the relevant symbol as shown
in annex B.
2.2.3 Lamps with operating position limitations
For lamps requiring operating position limitations, such as some 60 W candle and round bulb
lamps capped with B22d or E27 caps which can comply with the requirement of the lamp cap
temperature rise only by excluding the cap-up position, the immediate lamp wrapping or
container shall be marked with the appropriate symbol. An example is shown in annex B.
NOTE – The requirements in 2.2.2 and 2.2.3 are intended as information for the end-user of the lamp.
2.3 Protection against accidental contact in screw lampholders
Dimensions of screw capped lamps shall be such that safety against accidental contact is
ensured according to IEC 60061.
The lamps shall satisfy the gauges, defined in IEC 60061-3 in accordance with table 1.
Table 1 – Gauges for checking lamps for protection against
accidental contact
Lamp cap Gauge sheet No. Lamp cap Gauge sheet No.
E12 – E26d 7006-29A
E14 see 2.3.1 E27/25 and E27/27 7006-51A
E17 – E27/51×39 7006-51
E26/24 –
E26/25 –
–
E26/50×39
NOTE – The dash marking in the Gauge sheet No. column means that at the moment no such test system has been developed.
2.3.1 E14 capped lamps
E14 capped lamps shall satisfy the following requirements:
a) candle lamps shall be fitted with caps E14/25×17 and tested with gauge 7006-55;
b) round bulb, pigmy, tubular and reflector lamps having lamp neck reference diameters of
21 mm and greater shall be fitted with caps E14/25×17 and tested with gauge 7006-55;
c) round bulb, pigmy, tubular and reflector lamps having lamp neck reference diameters
between 16 mm and 21 mm shall be fitted with caps E14/23×15 or E14/20;
d) round bulb, pigmy, tubular and reflector lamps having lamp neck reference diameters
between 14 mm and 16 mm shall be fitted with caps E14/20.
In cases c) and d) a gauge is not required, because the choice of caps guarantees the same
degree of safety as in cases a) and b).

60432-1 © IEC:1999 – 17 –
2.4 Lamp cap temperature rise (Δt )
s
2.4.1 Average cap temperature rise
The average cap temperature rise per class of lamp manufactured in a period of 12 months
shall not exceed the following:
a) the appropriate value as specified in table 2; or
b) 45 K lower than the relevant values in table 2 where advantage is taken of the lower
maximum cap temperature of 2.5.4 b).
However, lamps fitted with E12, E17 and E26 caps with higher Δt values intended for special
s
applications are permitted, provided suitable cautionary notices accompany each lamp.
NOTE – In North America, lampholder and luminaire designs may be primarily aligned with the cap temperature rise
characteristics of common frosted, clear and white lamps. Therefore, lamps with other bulb finishes or other
characteristics yielding a higher cap temperature rise may require special cautionary notices.
2.4.2 Compliance
Compliance shall be checked by measurements of lamp cap temperature rise on lamps in the
same class in accordance with the test procedure specified in IEC 60360.
If the lamp is marked with a voltage range, the cap temperature rise shall be measured at the
mean voltage provided the limits of the voltage range do not differ by more than 2,5 % from the
mean voltage. For lamps with a wider voltage range, the measurement shall be at the highest
marked voltage.
NOTE – Table 2 shows upper limits for average cap temperature rise which apply to all lamps listed by wattage,
bulb and cap. In practice, several design features such as light centre length, mount shape and bulb finish affect
cap temperature rise, but such factors are encompassed in each limit.
2.4.3 Batch testing
For the testing of batches when the 20 lamp sample size is needed, the average shall not
exceed the appropriate value in accordance with 2.4.1, with an allowance of +9 K.
2.5 Resistance to torque
2.5.1 Caps
Caps shall be so constructed and assembled to the bulbs that they remain attached during
normal operation.
2.5.2 Unused lamps
For unused lamps, the lamp cap shall not move relative to the bulb when subjected to the
relevant torque value from table 3 as tested in accordance with C.1. Where the means of
attachment is other than by capping cement or adhesive, relative movement between bulb and
cap is permitted, provided it does not exceed 10°.
2.5.3 Resistance to heat
The lamp cap and capping cement or other means of attachment shall endure exposure to heat
at a level equal to the maximum cap temperature for which that class of lamp is designed.
The lamp cap shall not move relative to the bulb when subjected to the relevant torque values
of table 4 after the heating test specified in C.2 at the appropriate temperature of 2.5.4. In the
case where the means of attachment is other than by capping cement or adhesive, relative
movement between bulb and cap is permitted, provided it does not exceed 10°.

60432-1 © IEC:1999 – 19 –
Table 2 – Maximum allowable cap temperature rise (Δt ) for various lamp wattages and
s
classes over a 12 month period average
Δt
Group Wattage Bulb shape s max.
number (note 1)
K
W B15d B22d E12 E14 E17 E26/24 E26/25 E27
1 25 and 30 A, PS, M and other – – – – – 35 65 –
shapes intended (note 2)
for use in the same
40 – – – – – 70 85 –
luminaire
(note 2)
60 – 125 – – – 90 95 120
(note 2)
100 – 135 – – – 110 110 130
(note 2)
150 and 200 – 135 – – – 110 100 130
(note 2)
240 B, G (equal to or 135 140 – 130 – 90 – 140
less than 45 mm
60 145 125 – 140 – 90 – 120
diameter), P and
(note 4) (note 4)
other shapes
intended for use in
the same luminaire
315 C and other – – 90 – 90 – 90 –
shapes intended (note 3) (note 3)
for use in the same
25 – – 110 – 110 110 110 –
luminaire
(note 6) (note 3)
40 – – 130 – 130 135 130 –
(note 6) (note 3) (note 7)
60 – – 145 – 130 165 130 –
(note 6) (note 3) (note 7)
4 25 and 40 G (>45 mm – – – – 110 – 110 –
60 and 100 diameter) – – – – – – 110 –
525 P and G (45 mm – – – – 110 – 110 –
diameter with
40 135 135 – 135 – – 110 135
bowl mirror
135 – – 135 – – 110 –
660 A and PS with – 130 – – – – 110 130
bowl mirror
100 – 135 – – – – 110 135
150 and 200 – 135 – – – – – 135
7 25 R shapes – – – – 85 – – –
40 120 120 – 120 95 110 95 120
60 – 130 – – 105 140 105 130
(note 8)
100, 150 and 200 – 135 – – – 140 110 135
(notes 8
and 9)
875 PAR shapes – – – – – – 85 150
(note 5)
100 – – – – – – 100 150
150 – – – – – – 125 150
9 150 PAR shapes with – – – – – – 150 175
dichroic reflector
(note 5)
NOTE 1 – For lamps with intermediate wattage values, the requirement of the next higher value shown applies.
NOTE 2 – These values are established to account for applications in lower temperature lampholders as used in North America.
NOTE 3 – Under consideration.
NOTE 4 – This may require a limitation on operating position.
NOTE 5 – Lamps with skirted caps: E26/50×39, E27/51×39, etc.
NOTE 6 – Some lamp classes may be limited to operation in the cap-down or cap-down-through-horizontal positions by the
manufacturer.
NOTE 7 – Some lamp classes may be limited to operation in the cap-down position by the manufacturer.
NOTE 8 – Some lamp classes may be limited by the manufacturer to applications in high-temperature lampholders, because
low-temperature lampholders could deteriorate.
NOTE 9 – Some lamp classes may be limited by the manufacturer to applications at 260 °C maximum cap temperature in
high-temperature lampholders.
60432-1 © IEC:1999 – 21 –
2.5.4 Heating treatment temperatures
The heating treatment shall be conducted at one of the following levels:
a) the maximum cap temperature, in relation to cap type as specified in table K.1; or
b) for certain classes of lamps where 210 °C is specified in table K.1, the manufacturer may
elect to design lamps that can withstand a maximum cap temperature of 165 °C, in which
case the heating test is carried out at 165 °C, provided their rated wattage is 15 W or lower,
and the lamp is not a reflector or bowl mirror type.
NOTE – For special applications in North America, maximum cap temperatures lower than those shown in table K.1
may be assigned by the lamp manufacturer. When such a lower temperature lamp class is established, the
manufacturer is encouraged to:
– propose special limits for this standard;
– alert luminaire manufacturers.
Table 3 – Torque test values for unused lamps
Cap type Torque value
Nm
B15d 1,15
B22d 3,0
E12 0,8
E14 1,15
E17 1,5
E26, E26d, E27, E26/50×39 and E27/51×39 3,0
Table 4 – Torque test values after heating
Cap type Torque value
Nm
B15d 0,3
B22d 0,75
E12 0,5
E14 1,0
E17 1,0
2,5
E26, E26d, E27, E26/50×39 and E27/51×39
2.6 Insulation resistance of B15d, B22d, E26/50×39 and E27/51×39 capped lamps and
other lamps having insulated skirts
Insulation resistance between the shell of the cap and the contacts of bayonet capped lamps,
or between the shell and the insulated skirt of skirted Edison screw capped lamps, shall be not
less than 2 MΩ when measured in accordance with the procedure of A.3.

60432-1 © IEC:1999 – 23 –
2.7 Accidentally live parts
2.7.1 Metal parts intended to be insulated from live parts
Metal parts intended to be insulated from live parts shall not be or become live. Any moveable
conductive material shall be placed without the use of a tool, in the most onerous position
before inspection in accordance with A.4.
2.7.2 Bayonet caps
On bayonet caps, any projection from the contact plate shall not come within 1 mm of metal
parts intended to be insulated.
2.7.3 Edison screw caps
On Edison screw caps any projection from the cap shell shall not project more than 3 mm from
the surface of the cap. See figure 1.
r = 3 mm
IEC  987/99
Figure 1 – Edison screw cap
2.8 Creepage distances for B15d and B22d capped lamps
The minimum creepage distance between the metal shell of the cap and the contacts shall be
in accordance with the distance given on the relevant cap sheet in IEC 60061-1.
2.9 Safety at end of life
When tested under the specified conditions, lamp failure shall not be accompanied by
breakage of the outer glass envelope nor its ejection from the cap. For bayonet capped lamps,
it is also required that there shall not be an internal short-circuit to the cap shell after the test.

60432-1 © IEC:1999 – 25 –
The test conditions are:
– an induced-failure test in accordance with annex D or in accordance with the alternative
induced-failure test of annex A of IEC 60432-2, and
– an operation-to-failure test in accordance with annex E.
NOTE 1 – In case of disagreement, tests of annexes D and E are the reference methods.
NOTE 2 – The induced-failure test is not suitable for lamps with rated voltages below 100 V; however, the
alternative induced-failure test is suitable for lamps with rated voltages below 100 V.
NOTE 3 – If lamps fail the induced-failure test, it is not necessary for them to be submitted to the operation-to-
failure test.
NOTE 4 – Under circumstances defined in H.3, the operation-to-failure test may be used in place of the
induced-failure test.
2.10 Interchangeability
Interchangeability shall be ensured by the use of caps that are in accordance with IEC 60061-1.
Finished lamps shall satisfy the gauges for checking the dimensions controlling inter-
changeability in accordance with table 5. The gauges are those shown on particular standard
sheets included in IEC 60061-3.
2.11 Information for luminaire design
Refer to annex K.
Table 5 – Interchangeability gauges and lamp cap dimensions
Lamp cap Cap dimensions to be checked by the gauge Gauge sheet
B15d, B22d A min. 7006-10
A max., D1 max., N min. 7006-11
Insertion of the cap in the lampholder 7006-4A
Retention of the cap in the lampholder 7006-4B
E12 Maximum diameter of screw thread 7006-27H
Additional “Go” gauge for screw thread 7006-27J
Minimum major diameter of the cap screw thread 7006-28C
E14 Maximum dimensions of screw thread 7006-27F
Minimum major diameter of screw thread 7006-28B
Dimension S1 7006-27G
E17 * *
E26, E26d Maximum dimensions of screw thread 7006-27D
Additional “Go” gauge for screw thread 7006-27E
E27 Maximum dimensions of screw thread 7006-27B
Minimum major diameter of screw thread 7006-28A
Dimension S1 7006-27C
*Under consideration.
60432-1 © IEC:1999 – 27 –
3 Assessment
3.1 General
This clause specifies the method a manufacturer should use to show that his product conforms
to this standard on the basis of whole production assessment in association with his test
records on finished products. This method can also be applied for certification purposes.
Clauses 3.2, 3.3 and 3.5 give details of assessment by means of the manufacturer’s records.
Details of a batch test procedure which can be used to make limited assessment of batches
are given in 3.4 and 3.6. Requirements for batch testing are included in order to enable the
assessment of batches presumed to contain unsafe lamps. As some safety requirements
cannot be checked by batch testing and as there may be no previous knowledge of the
manufacturer’s quality, batch testing cannot be used for certification purposes nor in any way
for an approval of the batch. Where a batch is found to be acceptable, a testing agency may
only conclude that there is no reason to reject the batch on safety grounds.
3.2 Whole production assessment by means of the manufacturer’s records
3.2.1 The manufacturer shall show evidence that his products comply with the particular
requirements of 3.3. To this end, the manufacturer shall make available all the results of his
product testing pertinent to the requirements of this standard.
3.2.2 The test results may be drawn from working records and as such may not be
immediately available in collated form.
3.2.3 The assessment shall be based in general on individual factories each meeting the
acceptance criteria of 3.3. However, a number of factories may be grouped together, providing
they are under the same quality management. For certification purposes, one certificate may
be issued to cover a nominated group of factories but the certification authority shall have the
right to visit each plant to examine the relevant local records and quality control procedures.
3.2.4 For certification purposes, the manufacturer shall declare a list of marks of origin and
corresponding lamp categories or classes which are within the scope of this standard and
manufactured in a nominated group of factories. The certificate shall be taken to include all
lamps so listed made by the manufacturer. Notification of additions or deletions may be made
at any time.
3.2.5 In presenting the test results, the manufacturer may combine results of different lamp
classes according to column 4 of table 6.
The whole production assessment requires that the quality control procedures of a
manufacturer shall satisfy recognized quality system requirements for final inspection. Within
the framework of a quality assurance system based also on in-process inspection and testing
the manufacturer may show compliance with some of the requirements of this standard by
means of in-process inspection instead of finished product testing.
3.2.6 The manufacturer shall provide sufficient test records with respect to each clause as
indicated in column 5 of table 6.
3.2.7 The number of non-conformities in the manufacturer’s records shall not exceed the limits
shown in annex F relevant to the Acceptable Quality Level (AQL) values shown in column 6 of
table 6.
60432-1 © IEC:1999 – 29 –
3.2.8 The period of review for assessment purposes need not be limited to a predetermined
year, but may consist of 12 consecutive calendar months immediately preceding the date of
review.
3.2.9 A manufacturer who has met, but no longer meets the specified criteria, shall not be
disqualified from claiming compliance with this standard providing he can show that:
a) action has been taken to remedy the situation as soon as the trend was reasonably
confirmed from his test records;
b) the specified acceptance level was re-established within a period of:
– six months for 2.4.1, 2.5.3 and 2.9;
– one month for other clauses.
When compliance is assessed after corrective action has been taken in accordance with items a)
and b), the test records of these lamp categories which do not comply shall be excluded from
the 12-month summation for their period of non-compliance. The test results relating to the
period of corrective action shall be retained in the records.
3.2.10 A manufacturer who has failed to meet the requirements of a clause where grouping of
the test results is permitted under 3.2.5 shall not be disqualified for the whole of the lamp
classes so grouped if he can show by additional testing that the problem is present only in
certain classes so grouped. In this case, either these classes are dealt with in accordance with
3.2.9 or they are deleted from the list of classes which the manufacturer may claim are in
conformity with the standard.
3.2.11 In the case of a category or class which has been deleted under 3.2.10 from the list
(see 3.2.4), it may be reinstated if satisfactory results are obtained from tests on a number of
lamps equivalent to the minimum annual sample specified in table 6, required by the clause
where non-compliance occurred. This sample may be collected over a short period of time.
3.2.12 In the case of new products, there may be features which are common to existing lamp
classes, and these can be taken as being in compliance if the new product is taken into the
sampling scheme as soon as manufacture is started. Any feature not so covered shall be
tested before production starts.
3.3 Assessment of the manufacturer’s records of particular tests
3.3.1 Table 6 specifies the type of test and other information which applies to the method of
assessing compliance to the requirements of various clauses. For some particular tests, more
detailed information is given below.
A design test need only be repeated when a substantial change is made in the physical or
mechanical construction, materials, or manufacturing process used to manufacture the relevant
product. Tests are required for only those properties affected by the change.
3.3.2 With regard to the resistance to torque after the heating requirements of 2.5.3, the
manufacturer has the option of two test procedures, as set out in annex C.
NOTE – Provided that the data from the variables method C.1.4 b), form a near Gaussian distribution, normal
statistical techniques may be used to assess compliance, and an equivalent degree of confidence to that obtained
using method C.1.4 a) may be achieved with the smaller samples. In this case the assessment shall apply the rules
set out in annex G.
60432-1 © IEC:1999 – 31 –
3.3.3 With regard to the cap temperature rise requirements of 2.4, the manufacturer’s records
shall show either:
– a design test, if the cap temperature rise of each lamp in the samples of five is at least 5 K
below the value of table 2; or
– the results of periodic testing, where the average shall not exceed the value of table 2.
Where assessment is made for a lesser period than the full 12 months, a coefficient of
variation of 5 % shall be assumed in making the assessment.
3.3.4 Creepage distance is assessed as a design test. If all five lamps of the sample meet the
requirements of 2.8, the test is passed. A non-conformity is recorded if two or more lamps fail.
If one lamp fails, a further sample of five is to be taken and if no further lamps fail, the test is
passed.
3.4 Rejection conditions of batches
3.4.1 With the exception of the cap temperature rise test, which is covered by 3.4.2, rejection
is established if any rejection number in table 7 is reached. Irrespective of the quantity tested,
a batch shall be rejected as soon as the rejection number for a particular test is reached.
3.4.2 For the batch test of lamp cap temperature rise, five lamps shall be first tested.
Provided that all the lamps have a cap temperature rise at least 5 K lower than the appropriate
values shown in table 2, then no further testing for cap temperature rise is necessary. If at
least one of the five lamps in the test has a cap temperature rise within 5 K of the appropriate
value in table 2, then a total of 20 lamps shall be tested and the average temperature shall not
exceed the requirements of 2.4.2.
3.5 Sampling procedures for whole production testing
3.5.1 The conditions of table 6 apply.
3.5.2 The whole production running tests shall be applied at least once per production day.
They may also be based on in-process inspection and testing.
The frequency of application of the various tests may be different, providing the conditions of
table 6 are met.
3.5.3 Whole production tests shall be made on samples randomly selected at a rate not less
than that indicated in column 5 of table 6. Lamps selected for one test need not be used for
other tests.
3.5.4 For whole production testing of the requirements for accidentally live parts, (see 2.7),
the manufacturer shall demonstrate that there is a continuous 100 % inspection.
3.5.5 In relation to the safety at end of life (see 2.9), the manufacturer shall have a sampling
plan which does not deliberately exclude any of the classes in his nominated list.

60432-1 © IEC:1999 – 33 –
Table 6 – Grouping of test records, sampling and acceptable quality levels (AQL)
12 3 4 5 6
Minimum annual
sampling per grouping
1)
Clause or Tests Type Grouping of test
For lamps For lamps AQL
subclause of test records between
made made in-
%
number lamp classes
most of frequently
the year
2.2.1 Marking legibility Running All classes with same method 200 – 2,5
of marking
Marking durability Running All classes with same method 200 – 2,5
of marking
2.2.2 Presence of required Running All classes with same method –32 2,5
symbol of marking
2.3 Accidental contact Running All lamps tested with their 200 32 1,5
appropriate gauge
2.4 Cap temperature rise Design Lamps by class 5 at any design change
5)
or periodic
2.5.2 Resistance to torque
Unused lamps
a) test by attributes Running All lamps with the same 200 80 0,65
according to C.1.4 a) cement and the same cap
3)
b) test by variables Running All lamps with the same 75 25 0,65
according to C.1.4 b) cement and the same cap
2.5.3 After heating
2)
a) test by attributes Periodic All lamps with the same 125 80 0,65
according to C.2.3 a) cement and the same cap
3) 2)
b) test by variables Periodic All lamps with the same 50 20 0,65
according to C.2.3 b) cement and the same cap
2.6 Insulation resistance Running All classes with B15d, B22d, 315 0,4
E26/50×39 and E27/51×39
caps
2.7 Accidentally live parts 100 % –– – –
inspection
4)
2.8 Creepage distances Design a) All lamps with B15d caps 5 or 10 at design change
4)
b) All lamps with B22d caps 5 or 10 at design change
2.9 Induced-failure Design See H.1 H.2 H.4
Operation-to-failure Periodic All lamps of all classes 315 0,25
2.10 Interchangeability Periodic All classes with the same cap 32 2,5
1)
Use of this term and table F.1 is as put forth in IEC 60410 where operating characteristics can be found.
2)
For lamps with uncemented caps, this shall be a design test.
3)
Assessed in accordance with annex G.
4)
See 3.3.4.
5)
See 3.3.3.
60432-1 © IEC:1999 – 35 –
Table 7 – Batch sample size and rejection number
Clause or Number
subclause Test of lamps Rejection number
number tested
2.2.1 Marking legibility 200 11
2.2.1 Marking durability 200 11
2.2.2 Presence of required symbol 200 11
2.3 Accidental contact (Edison screw caps) 200 8
2.4 Cap temperature rise See 3.4.2
2.5.2 Resistance to torque (unused lamps) 125 3
2.5.3 Resistance to torque (after heating) 125 3
2.6 Insulation resistance 500 6
2.7 Accidentally live parts 500 1
2.8 Creepage distance B15d or B22d capped lamps See 3.3.4 –
2.9 End of life 200 2
2.10 Interchangeability 200 11
3.6 Sampling procedures for batch testing
3.6.1 The lamps for testing shall be selected in accordance with a mutually agreed method so
as to ensure proper representation. Selection shall be randomly made as nearly as possible
from one-third of the total number of containers in the batch, with a minimum of ten containers.
3.6.2 In order to cover the risk of accidental breakage, a certain number of lamps in addition
to the test quantity shall be selected. These lamps shall only be substituted for lamps of the
test quantities if necessary to make up the required quantities of lamps for the tests.
It is not necessary to replace an accidentally broken lamp if the results of the test are not
affected by its replacement, provided the required quantity of lamps for the following test is
available. If replaced, such a broken lamp shall be neglected in calculating the test results.
Lamps having broken bulbs when removed from the packaging after transit shall not be
included in the test.
3.6.3 Number of lamps in the batch sample
There shall be at least 500 lamps (see table 7).
3.6.4 Sequence of the tests
The testing shall be carried out in the most convenient sequence of clause or subclause
numbers listed in table 7.
60432-1 © IEC:1999 – 37 –
Annex A
(normative)
Miscellaneous test procedures
A.1  Marking
A.1.1 The presence and legibility of the marking is checked by visual inspection.
A.1.2 The durability of the marking is checked by applying the following test on unused lamps.
The area of the marking shall be rubbed by hand with a smooth cloth dampened with water for
a period of 15 s.
A.1.3 The presence of the proper marking on the immediate lamp wrapping or container is
checked by visual inspection.
A.2 Use of cap ga
...
