(Main)Short Range Devices (SRD) - Radio equipment for Euroloop railway systems - Harmonised Standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU
Short Range Devices (SRD) - Radio equipment for Euroloop railway systems - Harmonised Standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU
The present document covers the technical requirements for radio transmitters and receivers used in the Euroloop
transmission system. The system is used in railway systems.
The present document applies to the following equipment:
1) The On-Board Equipment (OBE) receiving the Euroloop signal and the OBE comprises a receiver fitted with a
dedicated antenna.
2) The Track-Side Equipment (Euroloop) transmitting the Euroloop signal that is always installed in an inner or
outer foot of a rail.
The Euroloop transmission system operates in frequency bands listed in table 1 in accordance with the EC Decision
2013/752/EU [i.2], and ERC Recommendation 70-03 [i.3], annex 4.
The present document contains requirements to demonstrate that radio equipment both effectively uses and supports the
efficient use of radio spectrum in order to avoid harmful interference.
Naprave kratkega dosega (SRD) - Radijska oprema za železniške sisteme Euroloop - Harmonizirani standard, ki zajema bistvene zahteve člena 3.2 direktive 2014/53/EU
Ta dokument zajema tehnične zahteve za radijske oddajnike in sprejemnike, ki se uporabljajo v oddajnem sistemu Euroloop. Sistem se uporablja v železniških sistemih.
Ta dokument se uporablja za naslednjo opremo:
1) Oprema, vgrajena v vozilo (OBE), ki prejema signal sistema Euroloop in vključuje sprejemnik z namensko anteno.
2) Oprema ob progi (Euroloop), ki oddaja signal sistema Euroloop in je vedno nameščena na notranjem ali zunanjem vznožju tirnice.
Oddajni sistem Euroloop deluje v frekvenčnih pasovih, navedenih v preglednici 1, v skladu s sklepom Komisije 2013/752/EU [i.2] in dodatkom 4 k priporočilu ERC 70-03 [i.3].
Ta dokument vključuje zahteve, s katerimi se dokazuje, da je radijska oprema izdelana tako, da učinkovito uporablja in podpira učinkovito rabo radijskega spektra z namenom preprečevanja škodljivega motenja.
