VHF air-ground and air-air Digital Link (VDL) Mode 4 radio equipment;Technical characteristics and methods of measurement for aeronautical mobile (airborne) equipment; Part 1: Physical layer

The present document applies to the following radio equipment types:
• Very High Frequency (VHF) Digital Link (VDL) Mode 4 aeronautical mobile (airborne) radio transmitters, transceivers and receivers for air-ground and air-air communications operating in the VHF band, using Gaussian Filtered Frequency Shift Keying (GFSK) modulation with 25 kHz channel spacing and capable of tuning to any of the 25 kHz channels from 112,000 MHz to 136,975 MHz as defined in ICAO VDL SARPs [2].
The present technical document provides part 1 of the technical specifications.
The present document is designed to ensure that equipment certified to it will be compatible with the relevant ICAO VDL SARPs [2] and ICAO VDL4 Technical Manual [1].
Manufacturers should note that in future the tuning range for the transmitter and receiver may cover any 25 kHz channel from 108,000 MHz to 111,975 MHz.
The present document applies to "aeronautical mobile (airborne and in some cases ground vehicles)" equipment which will hereinafter be referred to as "mobile" equipment.
The scope of the present document is limited to mobile stations. The equivalent specification for ground stations is ETSI EN 301 842 [i.7].
The VDL Mode 4 system provides digital communication exchanges between aircraft and ground-based systems and other aircraft supporting surveillance and communication applications. The supported modes of communication include:
• broadcast and point-to-point communication;
• broadcast services including Automatic Dependent Surveillance - Broadcast (ADS-B), Traffic Information Service - Broadcast (TIS-B) and Flight Information Service - Broadcast (FIS-B) capabilities;
• air-air and ground-air services;
• operation without ground infrastructure.
The present document is derived from the specifications:
• ICAO VDL4 Technical Manual [1] and ICAO VDL SARPs [2] produced under the auspices of the
International Civil Aviation Organization (ICAO).
• Other relevant standards as defined in clause 2.
It is envisaged that manufacturers may provide equipment supporting:
• broadcast services only;
• point-to-point services only;
• both broadcast and point-to-point services.
The present document deals with tests of the physical layer necessary to support all types of equipment.
The present document is organized as follows:
• clause 2 provides references to relevant documents;
• clause 3 provides general definitions, abbreviations and symbols used;
• clause 4 provides a general description and architecture of VDL Mode 4;
• clause 5 provides functional specifications applicable to the physical layer including transmitter/receiver
requirements and the modulation scheme;
• clause 6 provides VDL Mode 4 equipment requirements;
• clause 7 provides general design requirements;
• clause 8 provides environmental test requirements;
• clause 9 provides detailed test procedures for the physical layer;
• clause 10 provides installed equipment requirements;
• annex A provides a detailed cross-reference to the relevant requirements contained in reference [1];
• annex B provides an assessment of VDL Mode 4 Link Budget;
• annex C provides a Bibliography;
The full physical layer tests are provided which correspond closely to the standard set of tests used for other VDL systems.
NOTE: Flight tests are defined in ETSI EN 302 842-2 [7].
Mandating and recommendation phrases
a) "Shall"
- The use of the word "Shall" indicates a mandated criterion; e.g. compliance with the particular procedure or specification is mandatory and no alternative may be applied.
b) "Should"
- The use of the word "Should" (and phrases such as "It is recommended that...", etc.) indicate that though the procedure or criterion is regarded as the preferred option, alternative procedures, specifications or criteria may be applied, provided that the manufacturer, installer or tester can provide information or data to adequately support and justify the alternative.

Radijska oprema za digitalno povezavo VHF (VDL) zrak-tla in zrak-zrak, 4. način - Tehnične karakteristike in merilne metode za aeronavtično mobilno (letalsko) opremo - 1. del: Fizična plast

Ta dokument se uporablja za radijsko opremo naslednjih vrst:
• aeronavtične mobilne (letalske) radijske oddajnike, oddajnike-sprejemnike in sprejemnike za zelo visokofrekvenčno (VHF) digitalno povezavo (VDL) za komunikacije zrak-tla in zrak-zrak, 4. način, ki delujejo v pasu VHF z uporabo modulacije frekvenčnega premičnega kodiranja prek filtra Gaussian (GFSK) z razmikom 25 kHz med kanali in so zmožni uravnavati na katerem koli izmed kanalov 25 kHz od 112.000 MHz do 136.975 MHz, kot je opredeljeno v standardih in priporočenih praksah (SARP) [2] ICAO za digitalne povezave (VDL).
Ta dokument vsebuje 1. del tehničnih specifikacij.
Ta dokument zagotavlja, da bo oprema, ki bo certificirana v skladu z njim, združljiva z ustreznimi standardi (SARP) [2] ICAO za VDL in tehničnim priročnikom ICAO za VDL4 [1].
Proizvajalci naj bodo pozorni, da razpon uravnavanja za oddajnik in sprejemnik lahko v prihodnje zajema kateri koli kanal 25 kHz od 108.000 MHz do 111.975 MHz.
Ta dokument se nanaša na »aeronavtično mobilno (letalska in v nekaterih primerih tudi kopenska vozila)« opremo, v nadaljnjem besedilu: »mobilna« oprema.
Področje uporabe tega dokumenta je omejeno na mobilne postaje. Enakovredna specifikacija za zemeljske postaje je ETSI EN 301 842 [i.7].
Sistem VDL, 4. način, omogoča izmenjavo podatkovne komunikacije med letalskim plovilom in talnimi sistemi ter drugimi letalskimi plovili, ki podpirajo nadzorne in komunikacijske aplikacije. Podprti načini komunikacije vključujejo:
• radiodifuzija in komunikacija točka-točka;
• radiodifuzijske storitve, vključno z avtomatskim odvisnim nadzorom – difuzijo (ADS-B), difuzijo nadzornih podatkov (TIS-B) in difuzijo informacij za letalstvo (FIS-B);
• storitve zrak-zrak in tla-zrak;
• delovanje brez talne infrastrukture.
Ta dokument izhaja iz naslednjih specifikacij:
• tehničnega priročnika ICAO za VDL4 [1], ter standardih in priporočenih praksah ICAO za VDL [2], ki jih je sestavila
Mednarodna organizacija civilnega letalstva (ICAO)).
• drugih ustreznih standardov, ki so bili določeni v točki 2.
Predvideva se, da lahko proizvajalci zagotovijo opremo, ki podpira:
• izključno radiodifuzijske storitve;
• izključno storitve točka-točka;
• radiodifuzijske storitve in storitve točka-točka.
Ta dokument zajema preskuse fizične plasti, ki so potrebni za podporo vseh vrst opreme.
Ta dokument je organiziran na naslednji način:
• točka 2 vsebuje sklice do ustreznih dokumentov;
• točka 3 vsebuje splošne opredelitve, kratice in simbole, ki se uporabljajo;
• točka 4 vsebuje splošni opis in arhitekturo digitalne povezave VDL, 4. način;
• točka 5 vsebuje funkcionalne specifikacije, ki veljajo za fizično plast, vključno z zahtevami za oddajnik/sprejemnik
in modulacijsko shemo;
• točka 6 vsebuje splošne zahteve za opremo VDL, 4. način;
• točka 7 vsebuje splošne zahteve projekta;
• točka 8 vsebuje zahteve okoljevarstvenega preskusa;
• točka 9 vsebuje podrobne preskusne postopke za fizično plast;
• točka 10 vsebuje zahteve za nameščeno opremo;
• dodatek A vsebuje podrobne sklice do ustreznih zahtev, ki so vključene v sklic [1];
• dodatek B vsebuje oceno povezovalne bilance (link budget) digitalne povezave VDL, 4. način;
• dodatek C vsebuje bibliografijo.
Podani so celotni preskusi fizične plasti, ki se natančno ujemajo s standardnim nizom preskusov, ki se uporabljajo za druge sisteme VDL.
OPOMBA: Letalski preskusi so opredeljeni v ETSI EN 302 842-2 [7].
