SIST EN ISO 16823:2025

Non-destructive testing - Ultrasonic testing - Through-transmission technique (ISO 16823:2025)

This document specifies the principles of ultrasonic through-transmission techniques.
Through-transmission techniques can be used for:
—     detection of discontinuities;
—     determination of sound attenuation.
The general principles required for the use of ultrasonic testing of industrial products are described in ISO 16810.
The through-transmission technique is used for the testing of flat products, e.g. plates and sheets.
Further, it can be used for tests, for example:
—     where the shape, dimensions or orientation of possible discontinuities are unfavourable for direct reflection;
—     of materials with high sound attenuation;
—     on thin test objects.

Zerstörungsfreie Prüfung - Ultraschallprüfung - Durchschallungstechnik (ISO 16823:2025)

Dieses Dokument legt die Grundsätze der Ultraschall-Durchschallungstechnik fest.
Die Durchschallungstechnik kann angewendet werden
   zum Nachweis von Inhomogenitäten;
   zur Bestimmung der Schallschwächung.
Die allgemeinen Grundsätze, die zur Anwendung der Ultraschallprüfung an Industrieerzeugnissen erforderlich sind, werden in ISO 16810 beschrieben.
Die Durchschallungstechnik wird zur Prüfung von Flacherzeugnissen wie z. B. Blechen angewendet.
Weiterhin kann sie zum Beispiel für Prüfungen angewendet werden,
   bei denen Form, Maße oder Orientierung möglicher Inhomogenitäten für eine direkte Reflexion ungünstig sind;
   bei Werkstoffen mit hoher Schallschwächung;
   an dünnen Prüfgegenständen.

Essais non destructifs - Contrôle par ultrasons - Technique par transmission (ISO 16823:2025)

Le présent document spécifie les principes des techniques de contrôle ultrasonore par transmission.
Les techniques par transmission peuvent être utilisées pour:
—     la détection des discontinuités;
—     la détermination de l’atténuation acoustique.
Les principes généraux exigés pour l’utilisation du contrôle par ultrasons de produits industriels sont décrits dans l’ISO 16810.
La technique par transmission est utilisée pour le contrôle de produits plats, par exemple plaques et tôles.
De plus, elle peut être utilisée par exemple pour:
—     d’éventuelles discontinuités dont la forme, les dimensions ou l’orientation sont défavorables au contrôle par réflexion;
—     des matériaux avec une atténuation acoustique élevée;
—     des pièces à contrôler minces.
