SIST EN 50563:2012/A1:2014

External a.c. - d.c. and a.c. - a.c. power supplies – Determination of no-load power and average efficiency of active modes

This European Standard specifies methods of measurement of electrical power consumption, and the reporting of results, for external power supplies. This standard is applicable to external power supplies with a rated input voltage within the range 100 V ac to 250 V ac having a single output with a rated output power not exceeding 250 W and a rated output voltage not exceeding 230 V a.c. or 325 V d.c. The output voltage may be either at a fixed voltage, or at a voltage which is user selectable, or at a voltage that is automatically selectable by the external power supply so as to be compatible with one or more product-loads.

Externe AC/DC- und AC/AC-Netzteile - Bestimmung von Nulllast und durchschnittlicher Effizienz im Betrieb

Sources d'alimentation externes c.a. - c.c. et c.a. - c.a. - Détermination de la puissance hors charge et du rendement moyen des modes actifs

Samostojne (zunanje) usmerniške (AC-DC) in transformatorske (AC-AC) naprave - Ugotavljanje moči brez obremenitve in povprečnega izkoristka aktivnih načinov

Ta evropski standard določa metode merjenja porabe električne energije in poročanje rezultatov za samostojne (zunanje) usmerniške (AC-DC) in transformatorske (AC-AC) naprave. Ta standard velja za zunanje usmerniške in transformatorske naprave z ocenjeno vhodno napetostjo v razponu od 100 V izmeničnega toka do 250 V izmeničnega toka, ki imajo enojni izhod z ocenjeno izhodno močjo, manjšo od 250 W, in ocenjeno izhodno napetostjo, ki je manjša od 230 V izmeničnega toka ali 325 V enosmernega toka. Izhodna napetost je lahko stalna napetost ali napetost, ki jo izbere uporabnik, ali napetost, ki jo avtomatsko izbere samostojna (zunanja) usmerniška (AC-DC) in transformatorska (AC-AC) naprava, ki je skladna z eno ali več produktnimi obremenitvami.

General Information

• Status: Published
• Publication Date: 20-Feb-2014
• ICS: 29.200 - Rectifiers. Convertors. Stabilized power supply
• Technical Committee: AVM - Audio, video and multimedia systems and equipment
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 17-Dec-2013
• Due Date: 21-Feb-2014
• Completion Date: 21-Feb-2014
• Directive: 2009/125/EC - Directive 2005/32/EC of the European Parliament and of the Council of 6 July 2005 establishing a framework for the setting of ecodesign requirements for energy-using products and amending Council Directive 92/42/EEC and Directives 96/57/EC and 2000/55/EC of the European Parliament and of the Council
• Directive: 278/2009 - Commission Regulation (EC) No 278/2009 implementing Directive 2005/32/EC of the European Parliament and of the Council with regard to ecodesign requirements for no-load condition electric power consumption and average active efficiency of external power supplies
• Ref Project: EN 50563:2011/A1:2013 - External a.c. - d.c. and a.c. - a.c. power supplies – Determination of no-load power and average efficiency of active modes

Relations

• Amends: SIST EN 50563:2012 - External a.c. - d.c. and a.c. - a.c. power supplies - Determination of no-load power and average efficiency of active modes
• Effective Date: 01-Jun-2014

Overview

SIST EN 50563:2012/A1:2014 is a European standard developed by CLC (European Committee for Electrotechnical Standardization) that defines the methodology for determining the no-load power consumption and average efficiency of active modes in external power supplies. This standard applies to both external alternating current to direct current (a.c.-d.c.) and alternating current to alternating current (a.c.-a.c.) power supplies. It supports the implementation of energy efficiency and ecodesign requirements under EU regulations aimed at reducing power wastage and promoting sustainable energy consumption in electronic devices.

Key Topics

• No-Load Power Measurement
  The standard provides a detailed procedure for measuring the no-load power, which is the power consumed by an external power supply when it is connected to the mains but not supplying any load. Minimizing no-load power is critical to reducing unnecessary energy consumption and aligning with energy efficiency directives.

• Average Efficiency in Active Modes
  SIST EN 50563:2012/A1:2014 specifies how to calculate the average efficiency of power supplies when operating under typical active load conditions. This metric is essential to evaluate the energy performance during normal device operation.

• Testing and Reporting
  It establishes testing methodologies and the parameters for producing test reports, ensuring that measurement results are consistent, reliable, and transparent for manufacturers and regulatory bodies.

• Compliance with EU Ecodesign Directive
  This standard supports compliance with Commission Regulation (EC) No 278/2009, which enforces ecodesign requirements for external power supplies to reduce environmental impact and improve energy efficiency. Adoption of EN 50563 offers a presumption of conformity with these regulations.

Applications

SIST EN 50563:2012/A1:2014 is widely used by:

• Manufacturers of External Power Supplies:
  Design and test external power supplies to meet ecodesign regulations and optimize for low no-load power consumption and high active mode efficiency.

• Regulatory Agencies and Market Surveillance:
  Verify the compliance of power supply products with EU energy efficiency standards and directives.

• Product Certification Bodies:
  Facilitate the certification and labeling of external power supplies in accordance with European energy efficiency benchmarks.

• Energy Efficiency Consultancy:
  Assess power supply performance as part of broader energy audits and sustainability initiatives for electronic equipment.

Related Standards

• Commission Regulation (EC) No 278/2009 (implementing Directive 2005/32/EC, now replaced by 2009/125/EC)
  Regulates ecodesign requirements specifically targeting the no-load power consumption and average active efficiency of external power supplies.

• EN 50563:2011
  The original standard which the amendment A1:2013 modifies, ensuring updated and improved procedures.

• IEC 62301
  Related standard covering measurement of standby power, complementing no-load power evaluation in power supplies.

• EU Directive 2009/125/EC
  Establishes a framework for ecodesign requirements across energy-using products sold in the European market.

---

Keywords: EN 50563, external power supplies, no-load power, average efficiency, active modes, ecodesign, energy efficiency, EU regulations, power supply testing, a.c.-d.c. converters, a.c.-a.c. power supplies, Commission Regulation EC 278/2009, CLC standard.

Standards Content (Sample)

SLOVENSKI STANDARD
01-april-2014
6DPRVWRMQH]XQDQMHXVPHUQLãNH$&'&LQWUDQVIRUPDWRUVNH$&$&QDSUDYH
8JRWDYOMDQMHPRþLEUH]REUHPHQLWYHLQSRYSUHþQHJDL]NRULVWNDDNWLYQLKQDþLQRY
External a.c. - d.c. and a.c. - a.c. power supplies – Determination of no-load power and
average efficiency of active modes
Externe AC/DC- und AC/AC-Netzteile - Bestimmung von Nulllast und durchschnittlicher
Effizienz im Betrieb
Sources d'alimentation externes c.a. - c.c. et c.a. - c.a. - Détermination de la puissance
hors charge et du rendement moyen des modes actifs
Ta slovenski standard je istoveten z: EN 50563:2011/A1:2013
ICS:
29.200 8VPHUQLNL3UHWYRUQLNL Rectifiers. Convertors.
6WDELOL]LUDQRHOHNWULþQR Stabilized power supply
QDSDMDQMH
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD
EN 50563/A1
NORME EUROPÉENNE
October 2013
EUROPÄISCHE NORM
ICS 29.200
English version
External a.c. -
d.c. and a.c. -
a.c. power supplies – Determination of no-load power and average
efficiency of active modes
Sources d'alimentation externes c.a. -  Externe AC/DC- und AC/AC-Netzteile -
c.c. et c.a. - Bestimmung von Nulllast und
c.a. - durchschnittlicher Effizienz im Betrieb
Détermination de la puissance hors
charge et du rendement moyen des
modes actifs
This amendment A1 modifies the European Standard EN 50563:2011; it was approved by CENELEC on 2013-
09-30. CENELEC members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate
the conditions for giving this amendment the status of a national standard without any alteration.

Up-to-date lists and bibliographical references concerning such national standards may be obtained on
application to the CEN-CENELEC Management Centre or to any CENELEC member.

This amendment exists in three official versions (English, French, German). A version in any other language
made by translation under the responsibility of a CENELEC member into its own language and notified to the
CEN-CENELEC Management Centre has the same status as the official versions.

CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus,
the Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany,
Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland,
Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.

CENELEC
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung

CEN-CENELEC Management Centre: Avenue Marnix 17, B - 1000 Brussels

© 2013 CENELEC - All rights of exploitation in
...
