INTERNATIONAL STANDARD ISO 16589-3:2011(E)
Rotary shaft lip-type seals incorporating thermoplastic sealing
elements —
Part 3:
Storage, handling and installation
1 Scope

ISO 16589 specifies seals utilizing sealing elements manufactured from suitably formulated compounds,

based on thermoplastic materials, such as polytetrafluoroethylene (PTFE). They are considered suitable for

use under low pressure conditions.

This part of ISO 16589 gives users of lip-type seals guidance on the careful storage and handling and proper

installation of rotary shaft lip-type seals; attention is drawn to the hazards involved and ways of avoiding them

are pointed out.

NOTE ISO 16589 is complementary to ISO 6194, which covers seals incorporating elastomeric sealing elements.

2 Normative references

The following referenced documents are indispensable for the application of this document. For dated

references, only the edition cited applies. For undated references, the latest edition of the referenced

document (including any amendments) applies.
ISO 2230, Rubber products — Guidelines for storage
ISO 5598, Fluid power systems and components — Vocabulary

ISO 16589-1, Rotary shaft lip-type seals incorporating thermoplastic sealing elements — Part 1: Nominal

dimensions and tolerances

ISO 16589-2, Rotary shaft lip-type seals incorporating thermoplastic sealing elements — Part 2: Vocabulary

3 Terms and definitions

For the purposes of this document, the terms and definitions given in ISO 5598 and ISO 16589-2 apply.

4 General storage

4.1 Rotary shaft lip-type seals need to be stored with caution because any damage to them can adversely

affect their life and subsequently the service life of bearings and/or other costly machined parts. They shall be

stored in accordance with ISO 2230; in addition, the requirements given in 4.2 to 4.6 apply.

4.2 Seals shall be protected from insects and rodents, some of which thrive on rubber products.

© ISO 2011 – All rights reserved 1
---------------------- Page: 6 ----------------------
ISO 16589-3:2011(E)

4.3 Lip seals should be stored in a place other than a work area to avoid possible mechanical damage by

equipment or falling objects. A closed container will provide protection from mechanical damage, as well as

from dust, grit and other contaminants.

4.4 When cartons of lip seals are stacked, take care to avoid damage to the bottom parts due to excessive

weight.

4.5 Rotary shaft seals incorporating thermoplastic sealing elements can be supplied assembled on

mandrels for ease of transport and storage. These mandrels have the advantage of protecting the sealing lip

and preventing relaxation of the lip which could result in increased interference. When this is the case, the

seals shall remain on mandrels until immediately prior to installation. In some cases, the seals are supplied

with individual mandrels that can be used as assembly tools. The seal manufacturer should ensure that the

seal/seals are assembled onto mandrels backside first, unless individual mandrels are supplied. The user

should withdraw the seal from the mandrel backside first.
4.6 Seals shall
...
