(Main)Environmental Engineering (EE) - Earthing and bonding of 400 VDC data and telecom (ICT) equipment
Environmental Engineering (EE) - Earthing and bonding of 400 VDC data and telecom (ICT) equipment
The present document applies to earthing and bonding of ICT equipment installed in data and telecom centres and similar installations operating within the normal service voltage range up to 400 VDC defined in EN 300 132-3-1 [1]. Earthing and bonding network of the building (CBN), the bonding network of the equipment (SRPP), and the interconnection between these two networks are treated in the present document. It contributes to the standardization of telecommunication and datacom equipment installation.
It also co-ordinates with the pre-conditions of the installation to achieve the following targets:
- safety from electrical hazards;
- continuity of service requiring:
- reliable signal reference;
- satisfactory Electromagnetic Compatibility (EMC) performance.
The present document defines earthing and bonding configuration down to the equipment level in order to facilitate the installation, operation and maintenance of data and telecom centres in data and telecom buildings or similar installations independent of the equipment supplier. The specification of ICT equipment and of the pre-conditions of installation is subject to agreement of the parties (e.g. the supplier and the purchaser). Annex A can be used in the procedure to achieve an agreement. The present document does not cover safety and EMC aspects of the equipment. Those aspects are covered by other relevant standards. The present document applies to the installation of ICT equipment in data and telecom centres. The present document may also be applicable for ICT equipment in other locations, e.g.:
- street cabinet;
- container;
- subscriber's building;
- BTS.
Okoljski inženiring (EE) - Ozemljitev in spajanje 400 VDC podatkovne in telekomunikacijske (IKT) opreme
Ta dokument se uporablja za ozemljitev in spajanje podatkovne in telekomunikacijske (IKT) opreme, vgrajene v podatkovnih in telekomunikacijskih središčih in podobnih objektih, ki delujejo v okviru razpona napetosti ob normalni uporabi do 400 VDC, kot je opredeljeno v standardu EN 300 132-3-1 [1]. V tem dokumenti so obravnavani ozemljitveno in spajalno omrežje stavbe (CBN), spajalno omrežje opreme (SRPP) in medsebojna povezava med tema dvema omrežjema. Prispeva k standardizaciji vgradnje telekomunikacijske in podatkovno-komunikacijske opreme.
Usklajuje tudi predpogoje za vgradnjo, da se dosežejo naslednji cilji:
– varnost pred nevarnostmi zaradi elektrike;
– neprekinjeno delovanje, pri čemer se zahteva:
– zanesljiva signalna referenca;
– zadovoljivo delovanje na področju elektromagnetne združljivosti (EMC).
Ta dokument določa konfiguracijo ozemljitve in spajanja vse do ravni opreme, da bi se olajšala vgradnja, delovanje in vzdrževanje podatkovnih in telekomunikacijskih središč v podatkovnih in telekomunikacijskih stavbah ali podobnih objektih, neodvisno od dobavitelja opreme. Specifikacija opreme IKT in predpogojev za vgradnjo je predmet dogovora med strankami (npr. med dobaviteljem in kupcem). Dodatek A je mogoče uporabiti v postopku za doseganje dogovora. Ta dokument ne obravnava vidikov varnosti in elektromagnetne združljivosti opreme. Te vidike obravnavajo drugi ustrezni standardi. Ta dokument se uporablja za vgradnjo opreme IKT v podatkovnih in telekomunikacijskih središčih. Ta dokument se lahko uporablja tudi za opremo IKT na drugih lokacijah, npr.:
– cestne omarice;
– vsebniki;
– stavba naročnika;
– zbiralčni razdelilniki (BTS).
