Environmental Engineering (EE) - Power supply interface at the input to Information and Communication Technology (ICT) equipment - Part 1: Operated by Alternating Current (AC) source

The present document contains requirements for:
• the output of the power supply feeding interface A1;
• the input of the ICT equipment connected to interface A1.
The voltage at interface A1 defined in the present document is single phase and three phase AC.
The following voltage range categories are covered:
• Narrow single phase A1n-1p and narrow three phase A1n-3p AC voltage range defined to comply with nominal
European AC voltages [i.2].
• Wide single phase A1w-1p and wide three phase A1w-3p AC voltage range for worldwide nominal AC voltages.
The present document aims at providing compatibility between the power supply equipment and both the ICT equipment,
and the different load units connected to the same interface A1 (e.g. control/monitoring, cooling system, etc.).
The purpose of the present document is:
• to identify a power supply system with the same characteristics for all ICT equipment defined in the area of
application; the area of application may be any location where the interface A1 is used i.e. telecommunication
centres, Radio Base Stations, datacentres and customer premises;
• to facilitate interworking of different (types of) loads;
• to facilitate the standardization of power supply systems for ICT equipment;
• to facilitate the installation, operation and maintenance in the same network of ICT equipment and systems
from different origins. General requirements for safety and EMC are out of the scope of the present document
series unless specific requirement not defined in existing safety or EMC standards.
The present document concerns the requirements for the interface between Information and Communication
Technology (ICT) equipment and its power supply. It includes requirements relating to its stability and measurement.
Various other references and detailed measurement and test arrangements are contained in informative annexes.

Okoljski inženiring (EE) - Napajalni vmesnik na vhodu v opremo informacijske in komunikacijske tehnologije (IKT) - 1. del: Obratovanje z izmenično napetostjo virov

Ta dokument vsebuje zahteve za:
• izhod napajanja za vmesnik A1;
• vhod informacijske in komunikacijske tehnološke opreme, povezane z vmesnikom A1.
Napetost v vmesniku A1, opredeljena v tem dokumentu, je enofazna in trifazna izmenična napetost.
Obravnavane so naslednje kategorije napetostnega območja:
• ozko enofazno A1n-1p in ozko trifazno A1n-3p AC napetostno območje, ki je skladno z nazivnimi izmeničnimi napetostmi v evropskem prostoru [i.2].
• široko enofazno A1w-1p in široko trifazno A1w-3p AC napetostno območje za nazivne izmenične napetosti po vsem svetu.
Cilj tega dokumenta je zagotoviti združljivost med napajalno opremo ter informacijsko in komunikacijsko tehnološko opremo
in različnimi napajalnimi enotami, povezanimi z istim vmesnikom A1 (npr. enota za nadzor/spremljanje, hladilni sistem itd.).
Namen tega dokumenta je:
• opredeliti napajalni sistem z enakimi značilnostmi za vso informacijsko in komunikacijsko tehnološko opremo, ki je določena za območje
uporabe; območje uporabe je lahko katera koli lokacija, na kateri se uporablja vmesnik A1, tj. telekomunikacijska središča, radijske bazne postaje, podatkovna središča in prostori naročnikov;
• omogočiti medsebojno delovanje različnih (vrst) napajalnih enot;
• omogočiti standardizacijo napajalnih sistemov za informacijsko in komunikacijsko tehnološko opremo;
• omogočiti nameščanje, obratovanje in vzdrževanje informacijske in komunikacijske tehnološke opreme ter sistemov različnih izvorov
v istem omrežju. Splošne zahteve za varnost in elektromagnetno združljivost so zunaj področja uporabe te skupine dokumentov, razen če posebne zahteve niso opredeljene v obstoječih varnostnih standardih ali standardih za elektromagnetno združljivost.
Ta dokument obravnava zahteve za vmesnik med informacijsko in komunikacijsko tehnološko opremo ter njenim virom napajanja. Vključuje zahteve v zvezi s stabilnostjo in meritvami vmesnika.
Razne druge reference ter podrobne ureditve meritev in preskusov so navedene v informativnih dodatkih.
