Geotechnical investigation and testing - Testing of geotechnical structures - Part 10: Testing of piles: rapid load testing (ISO 22477-10:2016)

This standard establishes the specifications for the execution of rapid pile load tests in which a single pile is subject to an axial load in compression of intermediate duration to measure its load-displacement behaviour under rapid loading and an assessment of its static behaviour. The provisions of this standard apply to piles loaded axially in compression. This standard provides specifications for:
1) Investigation tests, whereby a sacrificial pile is loaded up to ultimate limit state;
2) Control tests, whereby the pile is loaded up to a specified load in excess of the serviceability limit state.

Geotechnische Erkundung und Untersuchung - Prüfung von geotechnischen Bauwerken und Bauwerksteilen - Teil 10: Pfahlprüfungen: Schnellprüfung mit axialer Druckbelastung (ISO 22477-10:2016)

Dieser Teil von ISO 22477 bestimmt die Spezifikationen für die Ausführung von schnellen Pfahlprobebelastungen, in denen ein einziger Pfahl einer komprimierten Axialbelastung unterliegt, um sein Lastverlagerungsverhalten bei schnellen Belastungen zu messen und um eine Bewertung seiner gemessenen Druckfestigkeit (Rc, m) sowie dem entsprechenden Lastverlagerungsverhalten zu ermöglichen.
Die Bestimmungen dieser internationalen Norm gelten für axial belastete, druckbeanspruchte Pfähle.
Sämtliche in EN 1536, EN 12699 und EN 14199 genannte Pfahlarten werden von diesem Teil von ISO 22477 abgedeckt.
Die in diesem Teil von ISO 22477 berücksichtigten Prüfungen sind ausschließlich auf Schnellprüfungen mit axialer Druckbelastung beschränkt.
ANMERKUNG 1   ISO 22477-10 kann in Verbindung mit EN 1997-1 verwendet werden. Numerische Werte von Teilfaktoren für Grenzzustände aus Pfahlprobebelastungen, die beim Design berücksichtigt werden müssen, werden in EN 1997-1 zur Verfügung gestellt. Für ein Design nach EN 1997-1 werden die Ergebnisse der schnellen Pfahlprobebelastung als äquivalent zur gemessenen Druckfestigkeit Rc,m angesehen, nachdem diese einer angemessenen Analyse unterzogen wurden.
ANMERKUNG 2   Eine Hilfestellung zur Analyse der Ergebnisse der schnellen Probebelastung zur Bestimmung der gemessenen Druckfestigkeit und des entsprechenden Lastverlagerungsverhalten findet sich in Anhang A.
Dieser Teil ISO 22477 bietet Spezifikationen für:
a)   Untersuchungsprüfungen, wobei ein Probepfahl zur Ermittlung der Tragfähigkeit bis zum Grenzzustand der Tragfähigkeit belastet wird.
b)   Kontrollprüfungen, wobei der Pfahl mit einer spezifischen Last oberhalb des Grenzzustands der Gebrauchstauglichkeit belastet wird.
ANMERKUNG 3   Allgemein konzentriert sich eine Untersuchungsprüfung auf das allgemeine Wissen über einen Pfahltypen; eine Kontrollprüfung konzentriert sich auf eine spezifische Anwendung eines Pfahls.

Reconnaissance et essais géotechniques - Essais de structures géotechniques - Partie 10: Essai des pieux: essai de charge rapide (ISO 22477-10:2016)

La présente partie de l'ISO 22477 établit les spécifications pour l'exécution d'essais des pieux sous charge rapide, où un pieu unique est soumis à une charge axiale en compression afin de mesurer son comportement de déplacement en charge lors d'un chargement rapide et d'évaluer sa résistance à la compression mesurée (Rc,m) ainsi que son comportement de déplacement en charge correspondant.
Cette partie de l'ISO 22477 s'applique aux pieux sous chargement axial en compression.
Tous les types de pieux mentionnés dans les normes EN 1536, EN 12699 et EN 14199 sont couverts par cette partie de l'ISO 22477.
Les essais mentionnés dans cette partie de l'ISO 22477 sont limités aux essais de pieux sous charge rapide uniquement.
NOTE 1    Cette partie de l'ISO 22477 peut être utilisée conjointement à l'EN 1997?1. Les valeurs numériques des facteurs partiels des états limites, obtenues à partir des essais de charge des pieux et devant être prises en compte dans la conception, sont données dans l'EN 1997?1. Dans le cas d'une conception selon l'EN 1997?1, les résultats des essais des pieux sous charge rapide seront considérés comme équivalents à la résistance à la compression mesurée, Rc,m, après l'analyse appropriée.
NOTE 2    L'Annexe A fournit des indications sur l'analyse des résultats des essais des pieux sous charge rapide réalisés en vue de déterminer la résistance à la compression mesurée et le comportement de déplacement en charge correspondant.
Cette partie de l'ISO 22477 présente des spécifications pour les éléments suivants:
a)    essais préalables, au cours desquels un pieu d'essai sacrificiel est chargé jusqu'à l'état limite ultime;
b)    essais de contrôle, au cours desquels le pieu est chargé jusqu'à une charge spécifiée au-delà de l'état limite de service.
NOTE 3    En général, un essai préalable se focalise sur la connaissance générale d'un type de pieu; un essai de contrôle se focalise sur une application particulière d'un pieu.

Geotehnično preiskovanje in preskušanje - Preskušanje geotehničnih konstrukcij - 10. del: Preskušanje pilotov: hitri obremenilni preskus (ISO 22477-10:2016)

Ta standard vzpostavlja specifikacije za izvajanje hitrih obremenilnih preskusov pilotov, pri čemer je posamezen pilot izpostavljen srednje dolgi tlačni osni obremenitvi, da se izmerijo njegove lastnosti premika pri hitrih obremenitvah in ocenijo njegove statične lastnosti. Določbe iz tega standarda se uporabljajo za pilote, ki so tlačno osno obremenjeni. Ta standard podaja specifikacije za: 1) preiskovalne preskuse, pri čemer je preskušani pilot obremenjen do končnega mejnega stanja; 2) kontrolne preskuse, pri čemer je pilot obremenjen do določenega bremena, ki presega mejno stanje uporabnosti.
