SIST EN 301 926 V1.3.1:2017
(Main)Satellite Earth Stations and Systems (SES) - Radio Frequency and Modulation Standard for Telemetry, Command and Ranging (TCR) of Communications Satellites
Satellite Earth Stations and Systems (SES) - Radio Frequency and Modulation Standard for Telemetry, Command and Ranging (TCR) of Communications Satellites
The present document applies to the Telemetry, Command and Ranging (TCR) system of Communication Satellites
(geosynchronous or not), operating in the following frequency bands:
• 5 725 MHz to 7 025 MHz uplink, 3 400 MHz to 4 200 MHz and 4 500 MHz to 4 800 MHz downlink
("C-band");
• 12 750 MHz to 13 250 MHz, 13 750 MHz to 14 800 MHz and 17 300 MHz to 18 400 MHz uplink,
10 700 MHz to 12 750 MHz and 13 400 MHz to 13 650 MHz downlink ("Ku-band");
• 27 500 MHz to 30 000 MHz uplink, 17 700 MHz to 20 200 MHz downlink ("Commercial Ka-band").
Although not explicitly addressed in the present document, possible usage in other bands allocated to
FSS/MSS/BSS/SOS between 1 GHz to 51,4 GHz may be envisaged.
The TCR receiver and transmitter can have a frequency flexibility capability over a given RF band, Typical frequency
step is 100 kHz.
The present document sets out the minimum performance requirements and technical characteristics of the
ground/satellite Radio Frequency (RF) interface based on Frequency Modulation (FM), Phase Modulation (PM) and
Code Division Multiple Access (CDMA).
With the growing number of satellites, the co-location constraints and the maximization of bandwidth for
Communications Missions, real and potential interference cases have motivated the elaboration of the present document
for geostationary satellites based on CDMA techniques.
The present document addresses the following applications:
• Telemetry.
• Command (Telecommand).
• Ranging.
• Hosted Payload Management.
The aim of the present document is to replace and enhance the prior document ETSI EN 301 926 [i.2] (V1.2.1). The
present document's provisions also apply for use cases of autonomous control of hosted payloads. It is recognized that
hosted payloads may require only a subset of the functionality.
The present document applies to the typical TCR scenario shown on figure 1. The scenario includes multiple satellites,
which may be located in the same orbital location (GSO), or that can be in common view of a given TCR station during
NGSO phases (such as transfer phase to GEO, or during NGSO operations). These satellites may be controlled by m
different TCR ground stations. The TCR links defined in the present document have also to coexist with the
communication ground terminals also shown on figure 1. Some of the satellites to be controlled may use FM/PM
waveforms, and some may use a CDMA waveform, as defined later in the present document.
The scenario may also include, for some of the satellites, hosted payloads, which can be controlled independently of the
satellite platform and of the main payload.
The present document defines the modulation and coding on the TCR and HPM links. Modulation formats are specified
in clause 4 and coding in clause 7.
Satelitske zemeljske postaje in sistemi (SES) - Radiofrekvenčni in modulacijski standard za telemetrijo, vodenje in merjenje oddaljenosti (TCR) komunikacijskih satelitov
Ta dokument se uporablja za sistem za telemetrijo, vodenje in merjenje oddaljenosti (TCR) komunikacijskih satelitov (ki so ali niso geosinhroni), ki delujejo v naslednjih frekvenčnih pasovih:
• od 5725 MHz do 7025 MHz pri navzgornji povezavi, od 3400 MHz do 4200 MHz in od 4500 MHz do 4800 MHz pri navzdolnji povezavi (»pas C«);
• od 12.750 MHz do 13.250 MHz, od 13.750 MHz do 14.800 MHz in od 17.300 MHz do 18.400 MHz pri navzgornji povezavi, od 10.700 MHz do 12.750 MHz in od 13.400 MHz do 13.650 MHz pri navzdolnji povezavi (»pas Ku«);
• od 27.500 MHz do 30.000 MHz pri navzgornji povezavi, od 17.700 MHz do 20.200 MHz pri navzdolnji povezavi (»komercialni pas Ka«).
Čeprav ta dokument tega izrecno ne obravnava, je mogoče predvideti uporabo v drugih pasovih, dodeljenih za sistem FSS/MSS/BSS/SOS v območju od 1 GHz do 51,4 GHz.
Sprejemnik in oddajnik TCR lahko izkazujeta zmožnost prilagajanja frekvence v danem frekvenčnem pasu; običajni frekvenčni interval je 100 kHz.
Ta dokument določa minimalne zahteve glede zmogljivosti in tehnične lastnosti radiofrekvenčnega (RF) vmesnika zemeljske/satelitske opreme, ki temelji na frekvenčni modulaciji (FM), fazni modulaciji (PM) in neposrednem kodnem dostopu (CDMA).
Z vedno večjim številom satelitov so omejitve kolokacije in čim večje izkoriščenosti pasovne širine pri komunikacijskih misijah, resnični in potencialni primeri motenj botrovali izpopolnitvi tega dokumenta za geostacionarne satelite, ki temeljijo na tehnikah CDMA.
Ta dokument obravnava naslednje načine uporabe:
• telemetrija;
• vodenje (daljinsko vodenje);
• merjenje oddaljenosti;
• upravljanje gostujoče obremenitve.
Namen tega dokumenta je nadomestiti in izboljšati prejšnji dokument ETSI EN 301 926 [i.2] (V1.2.1). Določila tega dokumenta se uporabljajo tudi v primerih avtonomnega krmiljenja gostujočih obremenitev. Ugotovljeno je, da lahko gostujoče obremenitve zahtevajo samo podskupino funkcionalnosti.
Ta dokument se uporablja za običajni scenarij TCR, prikazan na sliki 1. Scenarij vključuje več satelitov, ki se lahko nahajajo na isti lokaciji v orbiti (GSO) ali so lahko v običajnem pogledu dane postaje TCR med fazami NGSO (kot je faza prenosa v GEO ali med operacijami NGSO). Te satelite je mogoče krmiliti z različnimi zemeljskimi postajami TCR: Povezave TCR, določene v tem dokumentu, morajo prav tako soobstajati v komunikacijskih zemeljskih terminalih, ki so ravno tako prikazani na sliki 1. Nekateri sateliti, ki jih je treba krmiliti, lahko uporabljajo valovne oblike FM/PM,
nekateri pa valovno obliko CDMA, kot je predeljeno v nadaljevanju tega dokumenta.
Scenarij lahko (za nekatere satelite) vključuje tudi gostujoče obremenitve, ki jih je mogoče krmiliti neodvisno od platforme satelita in glavne obremenitve.
Ta dokument opredeljuje modulacijo in kodiranje povezav TCR in HPM. Formati modulacije so podani v točki 4, kodiranje pa v točki 7.
