Hydrometry — Selection, establishment and operation of a
gauging station
1 Scope
This International Standard gives requirements for the establishment and operation of a gauging station
for the measurement of stage, or stage and discharge, of a lake, reservoir, river or canal or other artificial
open channel. It also describes how a gauging station utilizing one of the measurement methods listed
should be operated and maintained.
Requirements are provided for stage only measurement stations, stage–discharge stations and direct-
discharge measurement stations in natural channels, as well as for stage–discharge stations with
artificial structures. Additionally, some requirements are given for measurements under difficult
conditions, such as under ice conditions.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
ISO 772, Hydrometry — Vocabulary and symbols
3 Terms, definitions and symbols
For the purposes of this document, the terms, definitions and symbols given in ISO 772 apply.
4 General requirements and considerations
4.1 Requirements
Before commencing work on establishment and operation of a gauging station, the following requirements
shall be identified:
a) range of levels required to be measured;
b) range of flows required to be measured;
c) customer’s requirements for type of data;
d) customer’s requirements for timeliness of data;
e) allowable uncertainty in the results;
f) other potential users of the data;
g) life expectancy of the station;
h) available budget;
i) agreements for access to land and construction permits.
© ISO 2013 – All rights reserved 1
---------------------- Page: 11 ----------------------
SIST EN ISO 18365:2014
ISO 18365:2013(E)
4.2 Other constraints
In addition to the requirements as in 4.1, other constraints shall be identified including the following:
a) local environmental issues;
b) accessibility of the site under all conditions of flow;
c) availability of power and communication links;
d) stability of the watercourse embankments;
e) stability of the watercourse bed;
f) identification of any proposed hydraulic modifications planned for the future;
e.g. bridges, tunnels (including pipe crossings), harbours or piers;
g) potential of vandalism;
h) influence of submergence of the gauging site due to downstream impounding
structures (lakes, dams, weirs);
i) potential stream losses in karst areas;
j) aquatic weed growth in the watercourse;
k) ice conditions during winter in cold and arctic regions.
Knowledge of the above requirements and local constraints will ensure the provision of appropriate
measurement and recording facilities as well as the adoption of an appropriate maintenance philosophy.
5 Water level (Stage) only gauging stations
5.1 Preliminary survey and selection criteria
5.1.1 General
The site selected for determination of stage shall be selected according to the purpose for which the
readings are required. Accessibility of the site and the availability of an observer if the gauge is to be
non-recording are important criteria as is the availability of an appropriate power supply and data
communication capabilities if the gauge is to be recording.
Gauges on lakes and reservoirs are normally located near the outlet, but shall be located sufficiently far
away from the zone where an increase in velocity causes a drawdown in water level. Gauges on large
bodies of water shall also be located so as to reduce the effect of strong winds which may cause misleading
data which may not be representative of the body of water being measured. Hydraulic conditions
(preferably a sufficiently long uniform stretch of water channel with uniform bed topography) are
important factors in site selection in open channels, particularly where water levels may later be used
in the computation of discharge. To ensure repeatability of the readings, ideally a bed or channel control
shall be present, which itself shall be stable and sensitive to changes in the level of the water. For the
purpose of monitoring water levels e.g. for flood warning purposes, this may not be a strict requirement.
5.1.2 Preliminary survey
A detailed examination of a 1:50,000 or larger scale map of the area is required in the first instance.
Aerial surveys, satellite imagery, or maps available in the public domain such as Google Earth can be
used as a basis for selecting potential sites, which can then be evaluated more precisely by ground
reconnaissance. This will include a detailed visual examination. Enquiries shall be made to determine
2 © ISO 2013 – All rights reserved
---------------------- Page: 12 ----------------------
SIST EN ISO 18365:2014
ISO 18365:2013(E)
whether or not any plans exist for the modification of the river reach which would modify the stream
bed regime and would have an impact on the proposed gauging station.
Enquiries shall also be made into any known past flow history including low water events, floods and
other high water events, existence of any overflow area leading to flow by-passing the site, and very
importantly, any knowledge of bed instability.
It may be appropriate to discuss and outline proposals at an early stage with the owners of the site
identified to ensure they are amenable to the proposed installation.
Surveys of channel geometry and flow velocity patterns using an Acoustic Doppler Current Profiler may
provide useful information.
Collection of data from hydrometric measurement stations is dominated by the use of telemetry;
availability and quality of methods of data transmission shall be investigated.
5.1.3 Selection criteria
A list of potential sites shall be established with their advantages and disadvantages identified. Site
selection can then be made according to the criteria identified in Clause 4. The establishment of the
gauge zero shall be chosen so as to avoid negative readings. Thus it shall be set well below the level of the
control feature. This zero point shall be correlated with a national datum through a station benchmark
and should be checked annually with respect to this benchmark. This will ensure that, should loss or
damage to the reference gauge occur, it can be replaced at exactly the same level.
The benchmark itself shall be checked regularly in order to confirm that it still represents the national
datum. The frequency of such checks shall be dependent on local soil dynamics.
5.2 Stage measurement and recording
5.2.1 General
The reading of stage may be required as a single instantaneous measurement, as a short series of
instantaneous measurements or as a continuous or practically continuous record of the fluctuations of
stage. The basis of any of the above shall include the installation of a vertical staff gauge, a ramp gauge,
or a wire-weight gauge.
5.2.2 Vertical staff gauge
A vertical staff gauge comprises a scale (normally 1 metre in length with graduations or scale divisions
of 5 or 10 mm) marked on or securely attached to a suitable and stable vertical surface. The gauge shall
be made of material with a low coefficient of expansion. Where the range of measurement required
exceeds the capacity of a single vertical gauge, other gauges shall be installed on the line of a cross-
section normal to the direction of flow. The scales on such a series of stepped staff gauges shall overlap
by not less than 15 cm in order to safeguard continuity of readings and also to confirm their consistency
with each other.
5.2.3 Ramp or inclined gauge
A ramp or inclined gauge consists of a scale marked on or securely attached to a suitable and stable
inclined surface, which conforms closely to the contour of the river bank. The gauge shall be made of
material with a low coefficient of expansion. Throughout its length the gauge may lie on one continuous
slope or may be a compound of two or more slopes. The gauge shall lie on a line of a cross-section normal
to the direction of flow.
5.2.4 Wire or tape weight gauge
A wire or tape weight gauge consists of a weight which is manually lowered until the weight touches
the surface of the water. The wire or tape may be wound on a drum attached to a winding mechanism
© ISO 2013 – All rights reserved 3
---------------------- Page: 13 ----------------------
SIST EN ISO 18365:2014
ISO 18365:2013(E)
or it may be a hand reel. The wire or tape gauge can be equipped with electrical contacts to improve
measurements, when there is a large vertical distance between the measuring point and the water
surface.
5.2.5 Other methods
It may be appropriate in some cases to use alternative methods for single or continuous determinations
of water level. Such methods, including maximum level gauges, are described in ISO 4373.
5.2.6 Stage recording
Customer requirements shall dictate the method of recording stage. It may be that a single record of
stage taken daily and read manually will suffice in which case a suitable person to do this work should
be identified.
It is more common to provide a continuous record of stage utilizing water level sensors, such as floats,
pressure transducers, and echo sounders, interfaced with a digital recorder (logger or telemetry) or
analog recorder (chart). Details of such systems, including the use of stilling wells, can be found in
ISO 4373. Modern gauging stations typically have two independent systems for stage measurement to
avoid or reduce data losses.
When a recorder is used, visits by the observer should be made from time to time to ensure satisfactory
performance of the sensor and recorder. It is recommended that the observer notes the time and date
of such checks along with the staff gauge and recorder values. It is essential that the staff gauge itself is
maintained in such a way as to be safely accessible and directly legible to the observer.
Comments on the state of the channel, river banks, presence of any obstruction, prevailing flow
conditions, etc. shall also be noted.
The frequency of such visits shall be subject to country-specific requirements but it is important that a
site visit shall follow a major hydraulic event to confirm continued measurement and recording of data.
6 Stage-discharge gauging stations
6.1 General
When records of water level are to be used as a basis for computation of discharge, the relation between
water level and flow must be determined.
In a stable channel with an appropriate control feature which is stable and sensitive, a single relation
may exist between water level and discharge. In this case, the relation can be determined by taking
discharge measurements throughout the range of levels and flows required to be measured.
Several techniques are available for this purpose including, but not limited to, current meter gauging
and float gauging (see ISO 748), dilution gauging (see ISO 9555-1, ISO 9555-3 and ISO 9555-4), transit
time acoustic methods (see ISO 6416), Doppler velocity meters (see ISO 15769), electromagnetic current
meters (see ISO/TS 15768) or acoustic Doppler current meters (see ISO/TR 24578).
The frequency of any maintenance or operational performance shall be such that the accuracy and
timeliness of data provision meets the user’s requirements.
4 © ISO 2013 – All rights reserved
---------------------- Page: 14 ----------------------
SIST EN ISO 18365:2014
ISO 18365:2013(E)
6.2 Main elements of a stage-discharge gauging station
6.2.1 General
The main elements required for the purpose of determining discharge in a stream from water level
records are as follows:
a) a stage measuring device (see 5.2.1);
b) a stage sensing and recording device (see 5.2.6);
c) a control section or reach (see 6.2.2);
d) a section suitable for discharge measurements (see 6.1 and 6.2.3);
e) discharge measurements for defining a stage-discharge relation (see 6.2.4).
6.2.2 Control section or control reach
A control section or control reach of a channel is a natural or artificial section or reach whose physical
characteristics can be measured and used to determine the relationship between stage and discharge.
In a control section any change in the stage downstream of the control does not affect the stage upstream
of the control. Whatever the discharge in the control section, a critical stage can be determined.
It shall be stable, i.e. no change shall occur over time to its physical characteristics. Regular inspection
of the control section shall be carried out to ensure that no changes have taken place which would alter
the relationship between stage and discharge at this site.
More than one control section may be required for discharge measurement at one gauging station
particularly when the range of levels and flows is substantial. For example, under certain flow conditions
a downstream control reach may create a water level which submerges an upstream weir which had
been acting as a control.
The sensitivity of a control section or reach shall be such that any significant change in discharge shall
result in either a measurable change in stage (for control sections) or a measurable change in stage at
one extremity of the control reach.
6.2.3 Section suitable for discharge measurements
Regardless of the method of measurement, the discharge through the discharge measuring section shall
be the same as the discharge normal to the reference staff gauge, over the range of flows to be measured.
Different measuring sections or different methods of measurement may be used to cover the range of
flows required.
A full description of a site suitable for measurement of discharge using current meters or floats is
given in ISO 748. Site requirements for dilution gauging are given in ISO 9555 Parts 1, 3, and 4. Site
requirements for the application of acoustic transit time velocity measurement techniques are given in
ISO 6416. Site requirements for the application of acoustic velocity meters using the Doppler and echo
correlation techniques are given in ISO 15769. Site requirements for the application of electromagnetic
techniques are given in ISO 9213.
6.2.4 Discharge measurements
Discharge measurements using the above techniques shall be related to a stage reading taken at the
beginning and end of the discharge measurement and during the measurement if the stage is changing
rapidly or inconsistently. When sufficient numbers of discharge measurements have been taken, a
stage–discharge relationship can be computed (see ISO 1100-2). Subsequent to the formulation of this
stage-discharge relationship, only occasional discharge measurements need be taken at flows in the
normal range to confirm the robustness of the relationship unless the site is subject to shifting control
© ISO 2013 – All rights reserved 5
-------
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
