VHF air-ground Digital Link (VDL) Mode 4 radio equipment; Technical characteristics and methods of measurement for ground-based equipment; Part 2: General description and data link layer

REN/AERO-00020-2

Radijska oprema za digitalno povezavo VHF zrak-tla, 4. način - Tehnične karakteristike in merilne metode za talno opremo - 2. del: Splošni opis in plast podatkovnih povezav

Ta dokument se uporablja za radijsko opremo naslednjih vrst:
• talne radijske oddajnike in sprejemnike za zelo visokofrekvenčno (VHF) digitalno povezavo (VDL) za komunikacije zrak-tla, 4. način, ki delujejo v pasu VHF z uporabo modulacije frekvenčnega premičnega kodiranja prek filtra Gaussian (GFSK) z razmikom 25 kHz med kanali in so zmožni uravnavati na katerem koli izmed kanalov 25 kHz od 112.000 MHz do 136.975 MHz, kot je opredeljeno v standardih in priporočenih praksah (SARP) [1] za digitalne povezave ICAO VHF (VDL).
Ta dokument vsebuje 2. del tehničnih specifikacij.
Ta dokument zagotavlja, da bo oprema, ki bo certificirana v skladu z njim, združljiva z ustreznimi standardi in priporočenimi praksami (SARP) [1] ICAO za VDL in tehničnim priročnikom ICAO za VDL4 [i.1].
Proizvajalci naj bodo pozorni, da razpon uravnavanja za talne oddajnike-sprejemnike lahko v prihodnje zajema tudi kateri koli kanal 25 kHz od 108,000 MHz do 111,975 MHz.
Področje uporabe tega dokumenta je omejeno na zemeljske postaje. Enakovredna specifikacija za letalske postaje je ETSI EN 302 842 [i.4].
Sistem VDL, 4. način, omogoča izmenjavo podatkovne komunikacije med letalskim plovilom in talnimi sistemi, ki podpirajo nadzorne in komunikacijske aplikacije. Podprti načini komunikacije vključujejo:
• radiodifuzija in komunikacija točka-točka;
• radiodifuzijske storitve, vključno z avtomatskim odvisnim nadzorom – difuzijo (ADS-B), difuzijo nadzornih podatkov (TIS-B) in difuzijo informacij za letalstvo (FIS-B);
• storitve zrak-zrak, zrak-tla, tla-zrak in talne mobilne storitve;
• delovanje brez talne infrastrukture.
Sistem VDL, 4. način, je zasnovan kot podsistem zrak/tla aeronavtičnega telekomunikacijskega omrežja (ATN) [i.2], ki uporablja pas AM(R)S in je organiziran v skladu z modelom povezanih odprtih sistemov (OSI) (določen z ISO). Sistemu ATN zagotavlja zanesljive podomrežne storitve. Podprta so lahko tudi druga omrežja, na katera pa se ta dokument ne osredotoča.
Ta dokument določa funkcionalne specifikacije za talno opremo za komunikacijo VHF, namenjeno podatkovni komunikaciji zrak-tla in zrak-zrak. Ta dokument izhaja iz naslednjih standardov in specifikacij, vključenih v:
• standarde za digitalno povezavo VDL, 4. način, ki jih je sestavila Mednarodna organizacija civilnega letalstva (ICAO) [i.1];
• druge ustrezne standarde, ki so bili določeni v točki 2.
Predvideva se, da lahko proizvajalci zagotovijo opremo, ki podpira:
• izključno radiodifuzijske storitve;
• izključno storitve točka-točka;
• radiodifuzijske storitve in storitve točka-točka.
ETSI EN 301 842-1 [3] obravnava preskuse fizične plasti. Ta dokument določa osrednje zahteve plasti povezav za zemeljske postaje VDL, 4. način, potrebne za podporo vseh vrst opreme. Te vključujejo radiodifuzijo s preprosto postavitvijo.
Ta dokument zajema preskuse plasti povezav, ki zadostujejo za podporo osrednjih funkcij plati povezav, in poleg tega vključuje tudi zahteve in preskuse, ki zadostujejo za prepoznavanje in odgovarjanje na prenose, povezane s komunikacijo točka-točka. Ta dokument se ne nanaša na zahteve za celoten komplet sporočil ADS-B ali druge aplikacije za radiodifuzijo, ki jih oprema VDL, 4. način, lahko podpira. Te so zajete v standardu ETSI EN 301 842-3 [4]. Podrobne zahteve za komunikacijo točka-točka ne spadajo v področje uporabe tega dokumenta, ampak so vključene v standard ETSI EN 301 842-4 [5]. ETSI EN 301 842-4 [5] vsebuje tudi vmesnik do
aeronavtičnega telekomunikacijskega omrežja (ATN), definiran v standardih in priporočenih praksah za ATN [i.2].
Ker so merjeni podatki zmogljivosti opreme lahko odvisni od merilnih metod, ta dokument priporoča standardne preskusne pogoje in metode.
