EN 1034-7:2005+A1:2009
(Main + Amendment)Safety of machinery - Safety requirements for the design and construction of paper making and finishing machines - Part 7: Chests
Safety of machinery - Safety requirements for the design and construction of paper making and finishing machines - Part 7: Chests
This European Standard applies to chests used in paper making and shall be applied together with !EN 1034 1:2000+A1:2009". It deals with all significant hazards, hazardous situations and hazard events relevant to chests when they are used as intended and under the conditions foreseen by the manufacturer (see clause 4). This European Standard does not apply to tanks for chemicals, storage tanks for starch and other additives used in paper making or basins or vessels for waste water resulting from the paper making process.
This European Standard does not apply to chests manufactured before the publication date of this European Standard.
Sicherheit von Maschinen - Sicherheitstechnische Anforderungen an Konstruktion und Bau von Maschinen der Papierherstellung und Ausrüstung - Teil 7: Bütten
Diese Europäische Norm gilt für Bütten, die zur Verwendung bei der Papierherstellung bestimmt sind, und ist gemeinsam mit EN 1034 1:2000+A1:2010 anzuwenden. Sie behandelt alle signifikanten Gefähr-dungen, Gefährdungssituationen und Gefährdungsereignisse, die auf Bütten zutreffen, wenn sie bestim-mungsgemäß und entsprechend den vorhersehbaren Bedingungen des Herstellers verwendet werden (siehe Abschnitt 4). Diese Europäische Norm gilt nicht für Behälter für Chemikalien, Silos für Stärke und andere Zuschlagstoffe, die bei der Papierherstellung verwendet werden, und Becken oder Behälter für Abwasser, das bei der Papierherstellung anfällt.
Diese Europäische Norm gilt nicht für Bütten, die hergestellt wurden, bevor CEN diese Europäische Norm veröffentlichte.
Sécurité des machines - Prescriptions de sécurité pour la conception et la construction de machines de fabrication et de finition du papier - Partie 7 : Cuviers
La présente Norme européenne s'applique aux cuviers, qui sont destinés à être employés dans la fabrication
du papier, et doit être utilisée conjointement avec l'!EN 1034-1:2000+A1:2010". Elle traite tous les phénomènes
dangereux significatifs, les situations dangereuses et les événements dangereux qui s'appliquent aux cuviers
lorsqu'ils sont utilisés dans des conditions normales et conformément aux conditions prévisibles du fabricant
(voir article 4). La présente norme européenne ne s'applique ni aux réservoirs de produits chimiques, silos pour
l’amidon et autres matières d’apport utilisés dans la fabrication du papier, ni aux bassins ou réservoirs d’eaux usées
résultant de la fabrication du papier.
La présente Norme européenne ne s'applique pas aux cuviers qui ont été fabriqués avant sa publication par le CEN.
Varnost strojev - Varnostne zahteve za načrtovanje in konstrukcijo strojev in opreme za izdelavo papirja - 7. del: Kadi
Ta evropski standard velja za kadi, ki se uporabljajo pri izdelavi papirja, in se uporablja skupaj z EN 1034-1:2000+A1:2010. Obravnava vse velike nevarnosti, nevarne situacije in primere, pomembne za kadi, kadar se uporabljajo v skladu z namembnostjo in pod pogoji, kot jih je predvidel proizvajalec (glej Klavzulo 4). Ta evropski standard ne velja za tanke za kemikalije, shranjevalne tanke za škrob in druge aditive, ki se uporabljajo pri izdelavi papirja, ali za bazene ali posode za odpadno vodo, ki nastaja pri postopku izdelave papirja.
General Information
Relations
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Sicherheit von Maschinen - Sicherheitstechnische Anforderungen an Konstruktion und Bau von Maschinen der Papierherstellung und Ausrüstung - Teil 7: BüttenSécurité des machines - Prescriptions de sécurité pour la conception et la construction de machines de fabrication et de finition du papier - Partie 7 : CuviersSafety of machinery - Safety requirements for the design and construction of paper making and finishing machines - Part 7: Chests85.100Oprema za papirno industrijoEquipment for the paper industry21.020Characteristics and design of machines, apparatus, equipment13.110Varnost strojevSafety of machineryICS:Ta slovenski standard je istoveten z:EN 1034-7:2005+A1:2009SIST EN 1034-7:2005+A1:2010en,fr01-februar-2010SIST EN 1034-7:2005+A1:2010SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 1034-7:2005+A1
December 2009 ICS 85.100 Supersedes EN 1034-7:2005English Version
Safety of machinery - Safety requirements for the design and construction of paper making and finishing machines - Part 7: Chests
Sécurité des machines - Prescriptions de sécurité pour la conception et la construction de machines de fabrication et de finition du papier - Partie 7 : Cuviers
Sicherheit von Maschinen - Sicherheitstechnische Anforderungen an Konstruktion und Bau von Maschinen der Papierherstellung und Ausrüstung - Teil 7: Bütten This European Standard was approved by CEN on 21 April 2005 and includes Amendment 1 approved by CEN on 17 November 2009.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 1034-7:2005+A1:2009: ESIST EN 1034-7:2005+A1:2010
Relationship between this European Standard and the Essential Requirements of EU Directive 98/37/EC . 11Annex ZB (informative)
!!!!Relationship between this European Standard and the Essential Requirements of EU Directive 2006/42/EC"""" . 12 SIST EN 1034-7:2005+A1:2010
The extent to which hazards, hazardous situations and hazard results are covered is indicated in the scope of this standard. For machines which have been designed and built in accordance with the stipulations of this C type standard, the following applies: where C type standard stipulations deviate from respective stipulations in A or B type standards, the stipulations made in this C type standard take precedence over stipulations in the other standards. 1 Scope This European Standard applies to chests used in paper making and shall be applied together with !EN 1034-1:2000+A1:2010". It deals with all significant hazards, hazardous situations and hazard events relevant to chests when they are used as intended and under the conditions foreseen by the manufacturer (see clause 4). This European Standard does not apply to tanks for chemicals, storage tanks for starch and other additives used in paper making or basins or vessels for waste water resulting from the paper making process. This European Standard does not apply to chests manufactured before the publication date of this European Standard. 2 Normative references The following referenced documents are indispensable for the application of this European Standard.
For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any amendments) applies. EN 294:1992, Safety of machinery — Safety distances to prevent danger zones being reached by the upper limbs. EN 349:1993, Safety of machinery — Minimum gaps to avoid crushing of parts of the human body. EN 418:1992, Safety of machinery — Emergency stop equipment — Functional aspects. EN 547-2:1996, Safety of machinery — Human body measurement — Part 2: Principles for determining the dimensions required for access openings. EN 953:1997, Safety of machinery — Guards — General requirements for the design and construction of fixed and movable guards. EN 954-1:1996, Safety of machinery — Safety-related parts of control systems — Part 1: General principles for design. EN 982:1996, Safety of machinery — Safety requirements for fluid power systems and components — Hydraulics. EN 983:1996, Safety of machinery — Safety requirements for fluid power systems and components — Pneumatics. SIST EN 1034-7:2005+A1:2010
(IEC 60204-1:1997). EN 60974-1:1988, Arc welding equipment - Part 1: Welding power sources (IEC 60974-1:1998). EN 61000-6-2:2001, Electromagnetic compatibility (EMC) — Part 6-2: Generic standards; immunity for industrial environment (IEC 61000-6-2:1999, modified). EN ISO 12100-1:2003, Safety of machinery — Basic concepts, general principles for design — Part 1: Basic terminology, methodology (ISO 12100-1:2003). EN ISO 12100-2:2003, Safety of machinery — Basic concepts, general principles for design — Part 2: Technical principles
(ISO 12100-2:2003). EN ISO 14122:2001 (all parts), Safety of machinery — Permanent means of access to machinery. 3 Terms and definitions For the purposes of this European Standard, the definitions given in !EN 1034-1:2000+A1:2010", EN ISO 12100-1:2003, and the following definitions apply: 3.1
chest vessel usually made of special steel or concrete and equipped with a fixed agitating device, associated measuring and control devices and necessary shutoff devices intended for storing (stacking), collecting and mixing pulp 3.2 agitator part of the mixing device shaped as a propeller or agitating shaft for optimum distribution of the pulp components used and forming a suspension 3.3 pulp suspension of fibre, additives and inks for the production of paper and board 4 List of significant hazards This clause contains all the significant hazards, as far as they are dealt with in this European Standard, which are identified by risk assessment in accordance with EN 1050 as significant for this type of machinery and which require action to eliminate or reduce the risk.
Crushing hazard 5.2; 5.4.2; 5.11 5.1; 5.3 Shearing hazard 5.11 5.1 Entanglement hazard 5.2; 5.10.5 5.2 Drawing-in or trapping hazard 5.2 5.1; 5.4 Friction or abrasion hazard 5.2 5.1 High-pressure fluid ejection hazard 5.6 5.24 Ejection of parts
5.2; 5.13 5.2 Slip, trip and fall hazards 5.3; 5.4.1 5.5 Accumulation of energy in machinery 5.10.4
Electrical hazards, for example:
Electrical contact (direct or indirect) 5.5 5.23 External influences on electrical equipment 5.5 5.23 Thermal hazards resulting in:
Burns and scalds 5.10.2 5.13; 5.17 Hazards generated by noise, resulting in:
Hearing loss (deafness), other physiological disorders
5.9; 7 5.15 Interferences with speech communication, acoustic signals etc. 5.9; 7 5.15 Hazards generated by radiation:
Ionizing radiation sources 5.7.1 5.20 Hazards generated by materials and substances processed, used or exhausted by machines:
Hazards resulting from harmful gases and from anoxia 5.4.3; 5.10.3. 5.10.5; 5.10.6,
7 5.16 Explosion hazards 5.13 5.13; 5.18; 5.19; 5.23 Hazards generated by neglecting ergonomic principles in machine design caused for example by:
Excessive efforts 5.4.2
Inadequate area lighting 5.8 5.18 Hazards caused by failure of energy supply and other functional disorders, for example
Failure of energy supply 5.5; 5.10.1 5.8 Unexpected ejection of fluids 5.4.3; 5.7.2 5.24 Malfunction of control system
5.5: 5.6; 5.12 5.14 Emergency measures 5.12 5.7 SIST EN 1034-7:2005+A1:20
...
