HD 21.11 S1:1995

This document specifies requirements for, and constructions and dimensions of, multicore and multipair cables rated voltage U0/U: 300/500 V, of the following types: - unscreened, sheathed for either exposed or protected wiring (0,5 mm2 to 2,5 mm2, number of cores from 2 to 48); - screened, sheathed for either exposed or protected wiring (0,5 mm2 to 2,5 mm2, number of cores from 2 to 8); - unscreened, sheathed for either exposed or protected wiring (0,5 mm2 to 1,5 mm2, number of screened pairs of...view more

This document specifies requirements for, and constructions and dimensions of, single core cables, rated voltage U0 / U = 300 /300 V, of the following type: Unscreened (0,5 mm2 to 2,5 mm2 single core) These cables are rated for occasional thermal stresses causing ageing equivalent to continuous operational life at a temperature of 105 °C. For standard cables, this is determined by the acceptance test defined in EN 50305, using accelerated long-term (5 000 h) thermal ageing indicating a 125 °C/20...view more

EN 50306-1 specifies the general requirements applicable to the cables given in EN 50306-2, EN 50306-3 and EN 50306-4. It includes the detailed requirements for S2 sheathing materials and other components called up in the separate parts. NOTE Detailed requirements for insulation systems are given in EN 50306-2. In particular, EN 50306-1 specifies those requirements relating to fire safety which enable the cables to satisfy Hazard Level 3 of EN 45545-1 and EN 45545-2. These cables are rated for o...view more

This document specifies requirements for, and constructions and dimensions of, multicore cables, rated voltage U0/ U = 300/500 V, of the following type: Screened (0,5 mm2 to 2,5 mm2, number of cores from 1 to 8). All cables have stranded tinned copper conductors, and thin wall thickness, halogen-free, insulation and sheath. They are for use in railway rolling stock as fixed wiring or wiring where limited flexing in operation is encountered. These cables are rated for occasional thermal stresses ...view more

This document specifies special test methods applicable to cables, and their constituent insulating and sheathing materials, for use in railway rolling stock. Such cables are specified in the various parts of the EN 50264 series, EN 50306 series and EN 50382 series. Other test methods required for railway rolling stock cables and their insulating and sheathing materials are listed in Annex A.

2019-02-04 - GEM - linkto LVD removed - no hEN  -  no assessment
2019-02-01 PeC: removed from citation under the LVD, TC confirmed it is a test method standard

2019-02-04 - GEM - link to LVD removed - no hEN  -  no assessment
2019-02-01 PeC: removed from citation under the LVD, TC confirmed it is a test method standard

2019-02-04 - GEM - linkto LVD removed - no hEN  -  no assessment
2019-02-01 PeC: removed from citation under the LVD, TC confirmed it is a test method standard

2019-03-22: BT D162/C049 removes link to 2014/35/EU (standard kept as supporting standard)
2019-02-01 PeC: removed from citation under the LVD, TC confirmed it is a test method standard

This part of EN 61238 applies to insulation piercing connectors for power cables for rated voltages up to 1 kV (Um = 1,2 kV), for example according to HD 603 or other buried cables and cables installed in buildings, having a) conductors complying with EN 60228 having nominal cross-sectional areas between 2,5 mm2 and 300 mm2 for copper and between 16 mm2 and 500 mm2 for aluminium, b) a maximum continuous cable temperature not exceeding the insulation material properties. This document is not appl...view more
