This Technical Specification (TS) has been produced by ETSI Technical Committee Speech and multimedia

In the present document "shall", "shall not", "should", "should not", "may", "need not", "will", "will not", "can" and

"cannot" are to be interpreted as described in clause 3.2 of the ETSI Drafting Rules (Verbal forms for the expression of

"must" and "must not" are NOT allowed in ETSI deliverables except when used in direct citation.

In speech communication devices of all kinds, echo artefacts and double talk impairments can occur. These might

dramatically degrade a conversation between users, i.e. the quality of experience in general. With an increasing usage of

hands-free terminals (e.g. motor vehicle, handheld or desktop devices) and new types of devices supporting voice

services (e.g. smart home devices or wearables), the cancellation of echo and providing duplex communication at the

The objective assessment of degradations caused by echo and/or poor double talk performance is already covered in

several specifications, but mainly based on simple analyses in level or spectrum. The impact on the conversation as

The auditory evaluation of a conversation between two human test subjects in a laboratory may be quite cumbersome.

Even though some listening test specifications already exist in several standardization bodies for these scenarios, the

reproducibility of results may vary a lot due to several degrees of freedom, e.g. a randomly degraded communication

The present document provides a subjective test framework for the evaluation of echo artefacts and double talk

impairments, based on the Third-Party Listening Test (TPLT) approach. On one hand, a conversation is simulated as

close as possible to human perception, in particular including the acoustics of involved terminals as well as self-hearing

and self-masking in talking phases. On the other hand, the proposed test methodology utilizes pre-recorded signals,

designed with respect to best-possible reproducibility in listening labs. This approach is well known from classical

subjective evaluations of speech, audio and/or video. This leads to a decreased naturalness and spontaneity compared to

a real conversation between subjects. However, the compromise between these two opposite approaches provides a

wider range of use cases. In addition, the signals used for subjective testing may be re-used for predictive models.

The present document provides a framework for auditory testing of echo artefacts and double talk impairments that may

The present document assesses degradations in end-to-end scenarios as perceived by the listener at the reference-side.

Only degradations caused by the terminal located at the device-side are taken into account by the framework. Since the

network delay between reference-side and device-side (and vice-versa) also has an impact on the DUT's signal

processing and/or the listener's quality of experience, this parameter is included in the present document as well - any

other degradations (e.g. packet-loss in one of the two directions) are out of scope.

Only DCR scales are supported in the auditory test, in particular for echo artefacts and double talk disturbances, which

have the most impact on conversations (more may be added in the future). ACR scales e.g. speech distortion or overall

Any instrumental model predicting results according to the introduced listening test design is out of scope.
