DRAFT INTERNATIONAL STANDARD ISO/DIS 13322-2:2020(E)
Particle size analysis — Image analysis methods —
Part 2:
Dynamic image analysis methods
1 Scope

ISO 13322 is applicable to the analysis of images for the purpose of determining particle size

distributions.

ISO 13322-1 on static image analysis methods assumes that an adequate binary image has already been

captured and concentrates upon the analysis of these images.

ISO 13322-2 describes the transfer of images from particles having relative motion to binary images

within practical systems, in which the particles are highly diluted. Images of moving particles are created

by an optical image capture device. Effects of particle movement on the images are either minimized by

the instrumentation or corrected by software procedures. The application of this method requires the

particle images to be clearly distinguishable from a static background. Further processing of the binary

image, which is then considered as static, is described in ISO 13322-1. A dynamic image analysis system

is capable of measuring higher number of particles compared to static image analysis systems. This

International Standard provides guidance on instruments qualification and particle size distribution

measurement by using particulate reference materials. This part addresses the relative movement of the

particles with respect to each other, the effect of particle movement on the image (motion blur), the

movement and position along the optical axis (depth of field), and the orientation of the particles with

respect to the camera.
2 Normative references

The following documents are referred to in the text in such a way that some or all of their content

constitutes requirements of this document. For dated references, only the edition cited applies. For

undated references, the latest edition of the referenced document (including any amendments) applies.

ISO 13322-1:2014, Particle size analysis — Image analysis method — Part 1: Static image analysis methods

ISO 9276-1, Representation of results of particle size analysis — Part 1: Graphical representation

ISO 9276-2, Representation of results of particle size analysis — Part 2: Calculation of average particle

sizes/diameters and moments from particle size distributions

ISO 9276-6, Representation of results of particle size analysis — Part 6: Descriptive and quantitative

representation of particle shape and morphology

ISO 14488:2007, Particulate materials — Sampling and sample splitting for the determination of

particulate properties

ISO/IEC 17025, General requirements for the competence of testing and calibration laboratories

© ISO 2019 – All rights reserved
---------------------- Page: 7 ----------------------
ISO/DIS 13322-2:2019(E)
3 Terms, definitions and symbols
3.1 Terms and definitions

For the purposes of this document, the terms and definitions given in ISO 13322-1:2014 and the following

apply.
3.1.1
acceptable depth of field

depth with respect to focal depth where the sharpness of the edges of the

particle images is accepted for segmentation
3.1.2
accuracy

closeness of agreement between a test result or measurement result and the true value

Note 1 to entry: In practice, the accepted reference value is substituted for the true value.

Note 2 to entry: The term “accuracy”, when applied to a set of test or measurement results, involves a

combination of random components and a common systematic error or bias component.

Note 3 to entry: Accuracy refers to a combination of trueness and precision.
[Source, ISO 3534‐2:2006, clause 3.3.1]
3.1.3
certified reference material
CRM

reference material (RM) characterised by a metrologically valid procedure for one or more specified

properties, accompanied by an RM certificate that provides the value of the specified property, its

associated uncertainty, and a statement of metrological traceability

Note 1 to entry: The concept of value includes a nominal property or a qualitative attribute such as

identity or sequence. Uncertainties for such attributes may be expressed as probabilities or levels of

confidence.

Note 2 to entry: Metrologically valid procedures for the production and certification of RMs are given in,

among others, ISO 17034 and ISO Guide 35.
Note 3 to entry: ISO Guide 31 gives guidance on the contents of RM certificates.
Note 4 to entry: ISO/IEC Guide 99:2007 has an analogous definition (5.14).
[Source, ISO Guide 35:2017, 3.2]
3.1.4
flow-cell
measurement cell inside which the fluid-particle mixture flows
3.1.5
frame coverage

fraction of the image area that is obscured by the projection area of all

segmented particles in the image
© ISO 2019 – All rights reserved
---------------------- Page: 8 ----------------------
ISO/DIS 13322-2:2019(E)

Note to entry: Frame coverage can be expressed as a part or percentage of image area.

3.1.6
image capture device

matrix camera or line scan camera for converting an optical image to digital image data

3.1.7
measurement zone

volume in which particles are measured by an image analyser. The measurement zone is formed by the

measurement frame including a third dimension from the acceptable depth of field.

Note 1 to entry: the measurement zone is defined by the software
3.1.8
orifice tube

tube with an aperture through which a stream of fluid with dispersed particles flows

3.1.9
particle illumination

continuous illumination for image capture device with an electronic exposure time controller, or

illumination of short duration for synchronized image capture device
3.1.10
precision

closeness of agreement between independent test/measurement results obtained under stipulated

conditions

Note 1 to entry: Precision depends only on the distribution of random errors and does not relate to the

true value or the specified value.

Note 2 to entry: The measure of precision is usually expressed in terms of imprecision and computed as

a standard deviation of the test results or measurement results. Less precision is reflected by a larger

standard deviation.

Note 3 to entry: Quantitative measures of precision depend critically on the stipulated conditions.

Repeatability conditions and reproducibility conditions are particular sets of extreme stipulated

conditions.
[Source, ISO 3534‐2:2006, clause 3.3.4]
3.1.11
reference material

material, sufficiently homogeneous and stable with respect to one or more specified properties, which

has been established to be fit for its intended use in a measurement process
Note 1 to entry: RM is a generic term.

Note 2 to entry: Properties can be quantitative or qualitative, e.g. identity of substances or species.

Note 3 to entry: Uses may include the calibration of a measurement system, assessment of a measurement

procedure, assigning values to other materials, and quality control.
© ISO 2019 – All rights reserved
---------------------- Page: 9 ----------------------
ISO/DIS 13322-2:2019(E)

Note 4 to entry: ISO/IEC Guide 99:2007[3] has an analogous definition (5.13), but restricts the term

“measurement” to apply to quantitative values. However, ISO/IEC Guide 99:2007, 5.13, Note 3 (VIM),

specifically includes qualitative properties, called “nominal properties”.
[Source, ISO Guide 35:2017, 3.1]
3.1.12
repeatability
precision under repeatability conditions

Note 1 to entry: Repeatability can be expressed quantitatively in terms of the dispersion characteristics

of the results.
[Source ISO 3534‐2:2006, clause 3.3.5]
3.1.13
repeatability conditions

observation conditions where independent test/measurement results are obtained with the same

method on identical test/measurement items in the same test or measuring facility by the same operator

using the same equipment within short intervals of time
Note 1 to entry: Repeatability conditions include:
— the same measurement procedure or test procedure;
— the same operator;
— the same measuring or test equipment used under the same conditions;
— the same location;
— repetition over a short period of time.
[Source, ISO 3534‐2:2006, clause 3.3.6]
3.1.14
sampling volume

volume in which the particles are within the field of view of the image analyser including a third

dimension from the sampling volume depth
3.1.15
sampling volume depth
length which describes the extent of the particle field in front of the camera
3.1.16
sheath flow

clean fluid flow surrounding particle-laden fluid for directing particles into a specific measurement zone

3.1.17
trueness

closeness of agreement between the expectation of a test result or a measurement result and a true value

Note 1 to entry: The measure of trueness is usually expressed in terms of bias.
© ISO 2019 – All rights reserved
---------------------- Page: 10 ----------------------
ISO/DIS 13322-2:2019(E)

Note 2 to entry: Trueness is sometimes referred to as “accuracy of the mean”. This usage is not

recommended.

Note 3 to entry: In practice, the accepted reference value is substituted for the true value.

[Source, ISO 3534‐2:2006, clause 3.3.3]
3.1.18
true value

value which characterizes a quantity or quantitative characteristic perfectly defined in the conditions

which exist when that quantity or quantitative characteristic is considered

Note 1 to entry: The true value of a quantity or quantitative characteristic is a theoretical concept and, in

general, cannot be known exactly.

Note 1 to entry: For an explanation of the term “quantity”, refer to [ISO 3534‐2:2006.]

3.2 Symbols
a moving distance of a particle during time t
A projected area of particle i
b measured diameter of binary image
CF coverage factor

𝐷 particle diameter corresponding to 10 % of the cumulative undersize distribution

��,�

𝐷 particle diameter corresponding to 50 % of the cumulative undersize distribution

��,�

𝐷 particle diameter corresponding to 90 % of the cumulative undersize distribution

��,�
𝑄 cumulative undersize distribution of quantity r
r quantity type; number (𝑟 = 0), area (𝑟 = 2) or volume (𝑟 = 3)
s standard deviation of the test samples
 standard deviation
t exposure time
𝑢 measurement uncertainty
𝑢 uncertainty of an assigned values of a certified reference material
CRM
𝑢 uncertainty of a characterized values of a reference material

𝑈 total value of the uncertainty used as the final acceptance/rejection limits for qualification tests

lim
v particle velocity
x or D diameter of particle

𝑥 particle diameter corresponding to 10 % of the cumulative undersize distribution

��,�
© ISO 2019 – All rights reserved
---------------------- Page: 11 ----------------------
ISO/DIS 13322-2:2019(E)

𝑥 particle diameter corresponding to 50 % of the cumulative undersize distribution

��,�

𝑥 particle diameter corresponding to 90 % of the cumulative undersize distribution

��,�
x projected area equivalent diameter of particle i
x maximum Feret diameter of particle i
imax
x minimum Feret diameter of particle i
imin
 ratio of the measured particle diameter to the static particle diameter
4 Principle
4.1 Key components of a dynamic image analyser

Each system designated as dynamic image analyser consists of the following essential key components.

Additionally, some optional components might be used to either enhance the quality of the measurements

or to deal with particular set-up characteristics.
a) Essential
 Illumination
 Particle motion
 Optical system
 Image capture device
 Image analysis
 Conversion to meaningful particle size parameters
 Statistical representation of descriptors
b) Optional
 Particle dispersers
 Particle positioning

A general diagram for dynamic image analysis is shown in Figure 1 & Figure 2. The illumination can be

set-up in a transmitted light arrangement (Figure 1), in a reflection arrangement (Figure 2) or in a

combination of both. In a reflection arrangement a reflecting device, the vessel wall or even the particles

may reflect the light back through the measurement zone as transflected light. The type of lighting has a

great influence on the appearance of the particle images.
© ISO 2019 – All rights reserved
---------------------- Page: 12 ----------------------
ISO/DIS 13322-2:2019(E)
4 7 8
5 5
9 X
Key
1 dispersed particles 6 acceptable depth of field
2 device for control of particle motion (optional) 7 image capture device
3 measurement zone 8 image analyser
4 light source 9 representation of results
5 optical system

Figure 1 — Flow diagram for typical dynamic image analysis method (transmission set-up)

© ISO 2019 – All rights reserved
---------------------- Page: 13 ----------------------
ISO/DIS 13322-2:2019(E)
Key
1 dispersed particles 8 image
...
