ASTM F3348-21a

Standard Specification for Plastic Press Insert Fittings with Factory Assembled Stainless Steel Press Sleeve for SDR9 Cross-linked Polyethylene (PEX) Tubing and SDR9 Polyethylene of Raised Temperature (PE-RT) Tubing

SCOPE
1.1 This specification covers plastic press insert fittings with factory assembled stainless steel press sleeves incorporating 3 view holes and a tool locator ring. These fittings are for use with cross-linked polyethylene (PEX) tubing in nominal sizes 3/8 , 1/2 , 3/4 , 1, 11/4 , 11/2 , and 2 that meet the requirements for Specification F876 or F3253 and for use with polyethylene of raised temperature (PE-RT) tubing in nominal sizes 3/8 , 1/2 , 3/4 , 1, 11/4 , 11/2 , and 2 that meet the requirements of Specification F2769. These fittings are intended for use in 100 psi (690 kPa) cold- and hot-water distribution systems operating at temperatures up to and including 180 °F (82 °C). Included are the requirements for material, molded part properties, performance, workmanship, dimensions, and markings to be used on the fittings and sleeves.
1.1.1 When used with PEX tubing in accordance with Specification F876, the fittings covered by this specification are intended for use in, but not limited to, residential and commercial, hot- and cold-potable water distribution systems, water service lines, reclaimed water, fire protection, radiant heating and cooling systems, hydronic distribution systems, snow and ice melting systems, geothermal ground loops, district heating, turf conditioning, compressed air distribution and building services pipe.
1.1.2 When used with PEX tubing in accordance with Specification F3253, the fittings covered by this specification are intended for use in residential and commercial hydronic heating and cooling systems.
1.1.3 When used with PE-RT tubing in accordance with Specification F2769, the fittings covered by this specification are intended for use in residential and commercial, hot- and cold-potable water distribution systems.
1.2 Units—The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Historical
• Publication Date: 31-Jul-2021
• ICS: 23.040.45 - Plastics fittings
• Technical Committee: F17 - Plastic Piping Systems
• Drafting Committee: F17.10 - Fittings

Standards Content (Sample)

NOTICE: This standard has either been superseded and replaced by a new version or withdrawn.
Contact ASTM International (www.astm.org) for the latest information
Designation:F3348 −21a An American National Standard
Standard Specification for
Plastic Press Insert Fittings with Factory Assembled
Stainless Steel Press Sleeve for SDR9 Cross-linked
Polyethylene (PEX) Tubing and SDR9 Polyethylene of
1
Raised Temperature (PE-RT) Tubing
This standard is issued under the fixed designation F3348; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope* mathematical conversions to SI units that are provided for
information only and are not considered standard.
1.1 Thisspecificationcoversplasticpressinsertfittingswith
1.3 This standard does not purport to address all of the
factory assembled stainless steel press sleeves incorporating 3
safety concerns, if any, associated with its use. It is the
view holes and a tool locator ring. These fittings are for use
responsibility of the user of this standard to establish appro-
with cross-linked polyethylene (PEX) tubing in nominal sizes
3 1 3 1 1
priate safety, health, and environmental practices and deter-
⁄8, ⁄2, ⁄4,1,1 ⁄4,1 ⁄2, and 2 that meet the requirements for
mine the applicability of regulatory limitations prior to use.
Specification F876 or F3253 and for use with polyethylene of
3 1 3
1.4 This international standard was developed in accor-
raised temperature (PE-RT) tubing in nominal sizes ⁄8, ⁄2, ⁄4,
1 1
dance with internationally recognized principles on standard-
1, 1 ⁄4,1 ⁄2, and 2 that meet the requirements of Specification
ization established in the Decision on Principles for the
F2769. These fittings are intended for use in 100 psi (690 kPa)
Development of International Standards, Guides and Recom-
cold- and hot-water distribution systems operating at tempera-
mendations issued by the World Trade Organization Technical
tures up to and including 180 °F (82 °C). Included are the
Barriers to Trade (TBT) Committee.
requirements for material, molded part properties,
performance, workmanship, dimensions, and markings to be
2. Referenced Documents
used on the fittings and sleeves.
2
1.1.1 When used with PEX tubing in accordance with
2.1 ASTM Standards:
SpecificationF876,thefittingscoveredbythisspecificationare
A269/A269M Specification for Seamless and Welded Aus-
intended for use in, but not limited to, residential and
tenitic Stainless Steel Tubing for General Service
commercial, hot- and cold-potable water distribution systems,
D1600 Terminology forAbbreviatedTerms Relating to Plas-
water service lines, reclaimed water, fire protection, radiant
tics
heating and cooling systems, hydronic distribution systems,
D2122 Test Method for Determining Dimensions of Ther-
snow and ice melting systems, geothermal ground loops,
moplastic Pipe and Fittings
district heating, turf conditioning, compressed air distribution
D2837 Test Method for Obtaining Hydrostatic Design Basis
and building services pipe.
forThermoplasticPipeMaterialsorPressureDesignBasis
1.1.2 When used with PEX tubing in accordance with
for Thermoplastic Pipe Products
Specification F3253, the fittings covered by this specification
D6394 Classification System for and Basis for Specification
are intended for use in residential and commercial hydronic
for Sulfone Plastics (SP)
heating and cooling systems.
E92 Test Methods for Vickers Hardness and Knoop Hard-
1.1.3 When used with PE-RT tubing in accordance with
ness of Metallic Materials
Specification F2769, the fittings covered by this specification
F412 Terminology Relating to Plastic Piping Systems
are intended for use in residential and commercial, hot- and
F876 SpecificationforCrosslinkedPolyethylene(PEX)Tub-
cold-potable water distribution systems.
ing
F877 SpecificationforCrosslinkedPolyethylene(PEX)Hot-
1.2 Units—The values stated in inch-pound units are to be
and Cold-Water Distribution Systems
regarded as standard. The values given in parentheses are
1
This test method is under the jurisdiction of ASTM Committee F17 on Plastic
2
Piping Systems and is the direct responsibility of Subcommittee F17.10 on Fittings. For referenced ASTM standards, visit the ASTM website, www.astm.org, or
Current edition approved Aug. 1, 2021. Published August 2021. Originally contact ASTM Customer Service at [e-mail]. For Annual Book of ASTM
approved in 2018. Last previous edition approved in 2021 as F3348–21. DOI: Standards volume information, refer to the standard’s Document Summary page on
10.1520/F3348–21A the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1

---------------------- Page: 1
...

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: F3348 − 21 F3348 − 21a An American National Standard
Standard Specification for
Plastic Press Insert Fittings with Factory Assembled
Stainless Steel Press Sleeve for SDR9 Cross-linked
Polyethylene (PEX) Tubing and SDR9 Polyethylene of
1
Raised Temperature (PE-RT) Tubing
This standard is issued under the fixed designation F3348; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This specification covers plastic press insert fittings with factory assembled stainless steel press sleeves incorporating 3 view
3 1 3
holes and a tool locator ring. These fittings are for use with cross-linked polyethylene (PEX) tubing in nominal sizes ⁄8, ⁄2, ⁄4,
1 1
1, 1 ⁄4, 1 ⁄2, and 2 that meet the requirements for Specification F876 or F3253 and for use with polyethylene of raised temperature
3 1 3 1 1
(PE-RT) tubing in nominal sizes ⁄8, ⁄2, ⁄4, 1, 1 ⁄4, 1 ⁄2, and 2 that meet the requirements of Specification F2769. These fittings are
intended for use in 100 psi (690 kPa) cold- and hot-water distribution systems operating at temperatures up to and including 180 °F
(82 °C). Included are the requirements for material, molded part properties, performance, workmanship, dimensions, and markings
to be used on the fittings and sleeves. The components covered by this specification are intended for use in residential and
commercial, hot and cold, potable water distribution systems as well as sealed central heating, including under-floor
heating/cooling systems, and residential fire sprinkler systems.
1.1.1 When used with PEX tubing in accordance with Specification F876, the fittings covered by this specification are intended
for use in, but not limited to, residential and commercial, hot- and cold-potable water distribution systems, water service lines,
reclaimed water, fire protection, radiant heating and cooling systems, hydronic distribution systems, snow and ice melting systems,
geothermal ground loops, district heating, turf conditioning, compressed air distribution and building services pipe.
1.1.2 When used with PEX tubing in accordance with Specification F3253, the fittings covered by this specification are intended
for use in residential and commercial hydronic heating and cooling systems.
1.1.3 When used with PE-RT tubing in accordance with Specification F2769, the fittings covered by this specification are intended
for use in residential and commercial, hot- and cold-potable water distribution systems.
1.2 Units—The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical
conversions to SI units that are provided for information only and are not considered standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
1
This test method is under the jurisdiction of ASTM Committee F17 on Plastic Piping Systems and is the direct responsibility of Subcommittee F17.10 on Fittings.
Current edition approved May 1, 2021Aug. 1, 2021. Published May 2021August 2021. Originally approved in 2018. Last previous edition approved in 20202021 as
F3348–20b.–21. DOI: 10.1520/F3348–21
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1

---------------------- Page: 1 ----------------------
F3348 − 21a
2. Referenced Documents
2
2.1 ASTM Standards:
A269/A269M Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
D1600 Terminology for Abbreviated Terms Relating to Plastics
D2122 Test Method for Determining Dimensions of Thermoplastic Pipe and Fittings
D2837 Test Method for Obtaining Hydrostatic Design Basis for Thermoplastic Pipe Materials or Pressure Design Basis for
Thermo
...
