Standards Content (Sample)

TECHNICAL SPECIFICATION
Universal Mobile Telecommunications System (UMTS);
LTE;
Universal Subscriber Identity Module (USIM)
conformance test specification
(3GPP TS 31.122 version 15.1.0 Release 15)

3GPP TS 31.122 version 15.1.0 Release 15 1 ETSI TS 131 122 V15.1.0 (2019-06)

Reference
RTS/TSGC-0631122vf10
Keywords
LTE,UMTS
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: [phone]  Fax: [phone]

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
The present document can be downloaded from:
http://www.etsi.org/standards-search
The present document may be made available in electronic versions and/or in print. The content of any electronic and/or
print versions of the present document shall not be modified without the prior written authorization of ETSI. In case of any
existing or perceived difference in contents between such versions and/or in print, the prevailing version of an ETSI
deliverable is the one made publicly available in PDF format at www.etsi.org/deliver.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
https://portal.etsi.org/TB/ETSIDeliverableStatus.aspx
If you find errors in the present document, please send your comment to one of the following services:
https://portal.etsi.org/People/CommiteeSupportStaff.aspx
Copyright Notification
No part may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying
and microfilm except as authorized by written permission of ETSI.
The content of the PDF version shall not be modified without the written authorization of ETSI.
The copyright and the foregoing restriction extend to reproduction in all media.

© ETSI 2019.
All rights reserved.
DECT™, PLUGTESTS™, UMTS™ and the ETSI logo are trademarks of ETSI registered for the benefit of its Members.

3GPP™ and LTE™ are trademarks of ETSI registered for the benefit of its Members and
of the 3GPP Organizational Partners.
oneM2M™ logo is a trademark of ETSI registered for the benefit of its Members and
of the oneM2M Partners. ®
GSM and the GSM logo are trademarks registered and owned by the GSM Association.
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 2 ETSI TS 131 122 V15.1.0 (2019-06)
Intellectual Property Rights
Essential patents
IPRs essential or potentially essential to normative deliverables may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (https://ipr.etsi.org/).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Trademarks
The present document may include trademarks and/or tradenames which are asserted and/or registered by their owners.
ETSI claims no ownership of these except for any which are indicated as being the property of ETSI, and conveys no
right to use or reproduce any trademark and/or tradename. Mention of those trademarks in the present document does
not constitute an endorsement by ETSI of products, services or organizations associated with those trademarks.
Legal Notice
This Technical Specification (TS) has been produced by ETSI 3rd Generation Partnership Project (3GPP).
The present document may refer to technical specifications or reports using their 3GPP identities. These shall be
interpreted as being references to the corresponding ETSI deliverables.
The cross reference between 3GPP and ETSI identities can be found under http://webapp.etsi.org/key/queryform.asp.
Modal verbs terminology
In the present document "shall", "shall not", "should", "should not", "may", "need not", "will", "will not", "can" and
"cannot" are to be interpreted as described in clause 3.2 of the ETSI Drafting Rules (Verbal forms for the expression of
provisions).
"must" and "must not" are NOT allowed in ETSI deliverables except when used in direct citation.
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 3 ETSI TS 131 122 V15.1.0 (2019-06)
Contents
Intellectual Property Rights . 2
Legal Notice . 2
Modal verbs terminology . 2
Foreword . 5
1 Scope . 6
2 Normative References . 6
3 Definitions, symbols, abbreviations and coding . 7
3.1 Definitions . 7
3.2 Symbols . 7
3.3 Abbreviations . 7
3.4 Coding Conventions . 7
3.5 Applicability . 7
3.5.1 Applicability of the present document . 7
3.5.2 Applicability to the UICC . 8
3.5.3 Applicability of the individual tests. 8
3.5.4 Applicability of conformance requirements . 8
3.6 Table of optional features . 9
3.7 Applicability table . 11
4 Test environment . 25
4.1 Test equipment . 25
4.1.1 ME simulator . 25
4.1.2 Signal generation device . 25
4.1.2.1 Vcc . 25
4.1.2.2 RST . 25
4.1.2.3 CLK. 25
4.1.2.4 I/O . 26
4.1.3 Precision force-inducing contacting device . 26
4.1.4 Temperature controllable environment . 26
4.1.5 Temperature measuring device . 26
4.1.6 Voltage measuring device . 26
4.1.7 Precision measuring device. 26
4.1.8 Current measuring device . 26
4.1.9 Timing Measurements on contact I/O . 27
4.2 IUT default conditions . 27
4.3 Default data formatting . 27
4.4 Test definition and applicability . 27
4.5 Initial conditions . 28
4.6 Test procedure . 29
4.7 Test requirement . 30
5 Void . 30
6 Test Procedure (TS 102.221) . 30
6.1 Physical characteristic s . 31
6.2 Electrical specifications of the UICC – Terminal interface . 31
7.1 Contents of the Elementary Files (EF) . 31
7.1.1 Definition and applicability . 31
7.1.2 Conformance requirement . 31
7.1.3 Test purpose . 32
7.1.4 Method of test . 32
7.2 Security features . 33
7.2.1 Definition and applicability . 33
7.2.2 Conformance requirement . 34
7.2.3 Test purpose . 34
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 4 ETSI TS 131 122 V15.1.0 (2019-06)
7.2.4 Method of test . 34
7.3 USIM commands . 34
7.3.1 AUTHENTICATE . 34
7.3.1.1 Definition and applicability . 34
7.3.1.2 Conformance requirement . 34
7.3.1.3 Test purpose . 35
7.3.1.4 Method of test . 35
7.3.2 Status Conditions Returned by the USIM . 36
7.3.2.1 Security management . 36
7.3.2.1.1 Definition and applicability . 36
7.3.2.1.2 Conformance requirement . 36
7.3.2.1.3 Test purpose . 36
7.3.2.1.4 Method of test . 36
7.3.2.2 Status Words of the Commands . 36
7.3.2.2.1 Definition and applicability . 36
7.3.2.2.2 Conformance requirement . 36
7.3.2.2.3 Test purpose . 36
7.3.2.2.4 Method of test . 37
7.3.3 GET IDENTITY . 37
7.3.3.1 Definition and applicability . 37
7.3.3.2 Conformance requirement . 37
7.3.3.3 Test purpose . 37
7.3.3.4 Method of test . 37
7.4 Void . 39
8 Test Procedure (31.101) . 39
8.1 General 3GPP platform requirements. 40
8.1.1 GSM/USIM application interaction and restrictions . 40
8.1.1.1 Definition and applicability . 40
8.1.1.2 Conformance requirement . 40
8.1.1.3 Test purpose . 40
8.1.1.4 Method of test . 40
8.2 Physical and logical characteristics . 40
8.2.1 Transmission speed . 40
8.2.1.1 Definition and applicability . 40
8.2.1.2 Conformance requirement . 40
8.2.1.3 Test purpose . 41
8.2.1.4 Method of test . 41
8.2.2 Voltage classes . 41
8.2.2.1 Definition and applicability . 41
8.2.2.2 Conformance requirement . 41
8.2.2.3 Test purpose . 41
8.2.2.4 Method of test . 41
8.2.3 File Control Parameters (FCP). 42
8.2.3.1 Definition and applicability . 42
8.2.3.2 Conformance requirement . 42
8.2.3.3 Test purpose . 42
8.2.3.4 Method of test . 42
8.3 User verification and file access conditions . 42
8.3.1 Definition and applicability . 42
8.3.2 Conformance requirement . 42
8.3.3 Test purpose . 43
8.3.4 Method of test . 43
8.4 Files . 43
8.4.1 Contents of the EFs at the MF level . 43
8.4.1.1 Definition and applicability . 43
8.4.1.2 Conformance requirement . 43
8.4.1.3 Test purpose . 44
8.4.1.4 Method of test . 44
Annex A (informative): Change history . 45
History . 47
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 5 ETSI TS 131 122 V15.1.0 (2019-06)
Foreword
rd
This Technical Specification has been produced by the 3 Generation Partnership Project (3GPP).
The contents of the present document are subject to continuing work within the TSG and may change following formal
TSG approval. Should the TSG modify the contents of the present document, it will be re-released by the TSG with an
identifying change of release date and an increase in version number as follows:
Version x.y.z
where:
x the first digit:
1 presented to TSG for information;
2 presented to TSG for approval;
3 or greater indicates TSG approved document under change control.
y the second digit is incremented for all changes of substance, i.e. technical enhancements, corrections,
updates, etc.
z the third digit is incremented when editorial only changes have been incorporated in the document.
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 6 ETSI TS 131 122 V15.1.0 (2019-06)
1 Scope
The present document provides the Conformance Test Specification for a Universal IC Card (UICC) defined in
TS 31.101 [2] with Universal Subscriber Identity Module (USIM) defined in TS 31.102 [3].
2 Normative References
The following documents contain provisions, which through reference in this text, constitute provisions of the present
document.
- References are either specific (identified by date of publication, edition number, version number, etc.) or
non-specific.
- For a specific reference, subsequent revisions do not apply.
- For a non-specific reference to a non-3GPP document, the latest version applies.
- For a non-specific reference to a 3GPP document, the latest version in the same release as the implementation
release of the UICC under test applies.
[1] ETSI TS 102 221: "UICC-Terminal Interface; Physical and Logical Characteristics".
[2] 3GPP TS 31.101: "UICC-Terminal Interface; Physical and Logical Characteristics".
[3] 3GPP TS 31.102: "Characteristics of the USIM application".
[4] ISO/IEC 7816-1: "Identification cards - Integrated circuit(s) cards with contacts, Part 1: Physical
characteristics".
[5] ISO/IEC 7816-2: "Identification cards - Integrated circuit cards - Part 2: Card with contacts -
Dimensions and locations of the contacts".
[6] ISO/IEC 7816-3: "Identification cards - Integrated circuit(s) cards with contacts, Part 3: Electronic
signals and transmission protocols".
[7] ISO/IEC 7816-4: "Identification cards - Integrated circuit cards - Part 4: Organization, security and
commands for interchange".
[8] Void
[9] Void
[10] Void
[11] Void
[12] ISO/IEC 7811-1: "Identification cards - Recording technique - Part 1: Embossing"
[13] Void
[14] 3GPP TS 11.11: "Digital cellular telecommunications system (Phase 2+); Specification of the
Subscriber Identity Module - Mobile Equipment (SIM - ME) interface".
[15] ETSI TS 101 220: "Smart cards; ETSI numbering system for telecommunication application
providers".
[16] ETSI TS 102 221 Release 99: "UICC-Terminal Interface; Physical and Logical Characteristics".
[17] ETSI TS 102 221 Release 4: "UICC-Terminal Interface; Physical and Logical Characteristics".
[18] ETSI TS 102 221 Release 5: "UICC-Terminal Interface; Physical and Logical Characteristics".
[19] ISO/IEC 9646-7 (1995): "Information technology - Open Systems Interconnection - Conformance
testing methodology and framework - Part 7: Implementation Conformance Statements".
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 7 ETSI TS 131 122 V15.1.0 (2019-06)
[20] ETSI TS 102 230 - 2 v9.1.0: "UICC-Terminal interface; Physical, electrical and logical test
specification; Part 2: UICC features".

3 Definitions, symbols, abbreviations and coding
3.1 Definitions
For the purposes of the present document, the following definitions apply in addition to the terms defined in
TS 102.221 [1] and TS 31.102 [3].
Implementation Conformance Statement (ICS): A statement made by the supplier of an implementation or system
claimed to conform to a given specification, stating which capabilities have been implemented. The ICS can take
several forms: protocol ICS, profile ICS, profile specific ICS, information object ICS, etc.
ICS proforma: A document, in the form of a questionnaire, which when completed for an implementation or system
becomes an ICS.
3.2 Symbols
For the purposes of the present document, the following symbols apply:
t fall time
F
rise time
tR
V Input Voltage (high)
IH
V Input Voltage (low)
IL
V Output Voltage (high)
OH
V Output Voltage (low)
OL
3.3 Abbreviations
For the purposes of the present document, the following abbreviations apply:
CRn Conformance Requirement 'n'
IUT Implementation Under Test
ME Mobile Equipment
TS Test Specification
UICC Universal Integrated Circuit Card
USIM Universal Subscriber Identity Module

3.4 Coding Conventions
The following coding conventions apply to the present document:
All lengths are presented in bytes, unless otherwise stated. Each byte is represented by bit b8 to b1, where b8 is the most
significant bit (MSB) and b1 is the least significant bit (LSB). In each representation, the leftmost bit is the MSB.
3.5 Applicability
3.5.1 Applicability of the present document
The present document applies to a UICC which supports one or more USIMs.
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 8 ETSI TS 131 122 V15.1.0 (2019-06)
3.5.2 Applicability to the UICC
The applicability to a UICC supporting one or more USIMs is specified in table B.1, unless otherwise specified in the
specific clause.
3.5.3 Applicability of the individual tests
Table B.1 lists the optional, conditional or mandatory features for which the supplier of the implementation states the
support. As pre-condition the supplier of the implementation shall state the support of possible options in table A.1.
The "Release XY UICC" columns shows the status of the entries as follows:
The following notations, defined in ISO/IEC 9646-7 [19], are used for the status column:
M mandatory - the capability is required to be supported.
O optional - the capability may be supported or not.
N/A not applicable - in the given context, it is impossible to use the capability.
X prohibited (excluded) - there is a requirement not to use this capability in the given context.
O.i qualified optional - for mutually exclusive or selectable options from a set. "i" is an integer which
identifies an unique group of related optional items and the logic of their selection which is
defined immediately following the table.
Ci conditional - the requirement on the capability ("M", "O", "X" or "N/A") depends on the support
of other optional or conditional items. "i" is an integer identifying an unique conditional status
expression which is defined immediately following the table. For nested conditional expressions,
the syntax "IF . THEN (IF . THEN . ELSE.) ELSE ." shall be used to avoid ambiguities.
References to items
For each possible item answer (answer in the support column) there exists a unique reference, used, for example, in the
conditional expressions. It is defined as the table identifier, followed by a solidus character "/", followed by the item
number in the table. If there is more than one support column in a table, the columns shall be discriminated by letters
(a, b, etc.), respectively.
EXAMPLE: A.1/4 is the reference to the answer of item 4 in table A.1.
3.5.4 Applicability of conformance requirements
All conformance requirements are annotated with their applicability. This clause defines the notation used.
The basic notation is as follows:
(DefinedRelease) ReleaseRange: Options
The components of the notation are as follows:
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 9 ETSI TS 131 122 V15.1.0 (2019-06)

Component Content Example content
DefinedRelease Contains a single release. R99
Optional (along with the surrounding parentheses). Rel-6
If present, it indicates the release of the core
specification in which the conformance requirement was
first defined. This is intended for conformance
requirements which were defined in a certain release of
the core specification but for which tests were not
introduced into this document until a later release.
If absent, this indicates that the conformance
requirement was introduced in the first release
contained in ReleaseRange.
ReleaseRange Contains a single release or a range of releases. An R99
ellipsis (…) in the right-hand part indicates the current R99 - Rel-5
release of this document. Rel-6 - …
Optional; but at least one of ReleaseRange and Options
must be present.
If present, it indicates the range of releases for which
the conformance requirement is tested.
If absent, it is equivalent to "R99 - …".
Options A comma-separated list containing at least one of the O_LOG_CHANS
options in table A.1.
Optional (along with the preceding colon); but at least O_LOG_CHANS,
one of ReleaseRange and Options must be present. O_SHAREABLE
If present, this indicates that the conformance
requirement is only applicable to UICCs supporting all of
the specified options.
If absent, this indicates that the conformance
requirement applies to all UICCs.

An additional shortcut notation for "R99 - …" is specified: "M". This indicates that the conformance requirement is
mandatory for all UICCs of all releases.
Examples of the notation are as follows:

Example Meaning
(Rel-4) Rel-6 – …: Conformance requirement introduced in Rel-4, but not tested until
O_LOG_CHANS Rel-6, where it is only applicable if O_LOG_CHANS is supported.
(Rel-4) Rel-6 – …: Conformance requirement introduced in Rel-4, but not tested until
O_LOG_CHANS, Rel-6, where it is only applicable if O_LOG_CHANS and
O_SHAREABLE O_SHAREABLE are supported.
Rel-6 – …: Conformance requirement introduced in Rel-6, where it is only
O_LOG_CHANS applicable if O_LOG_CHANS is supported.
Rel-6 – …: Conformance requirement introduced in Rel-6, where it is only
O_LOG_CHANS, applicable if O_LOG_CHANS and O_SHAREABLE are supported.
O_SHAREABLE
R99 - Rel-5 Mandatory for all UICCs from R99 to Rel-5.
Rel-6 - … Mandatory for all UICCs from all releases up to and including the
current release of this document.
O_MONO_APP Applies to all releases, but only applicable if O_MONO_APP is
supported by the UICC.
M Mandatory for all releases; equivalent to "R99 - …".

3.6 Table of optional features
Support of several features is optional, release dependent or configuration dependent for the UICC. However, if a UICC
states conformance with a specific 3GPP release, it is mandatory for the UICC to support all mandatory functions of
that release, as stated in table A.1.
The "Option defined in Releases" column indicates the releases of the relevant core specification(s) in which the option
is defined.
The supplier of the implementation shall state the support of possible options in table A.1.
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 10 ETSI TS 131 122 V15.1.0 (2019-06)
A supplier may choose to use a single UICC and reconfigure it as required for each test; or may choose to use a number
of UICCs which are based on the same platform but are configured differently. The supplier shall state the chosen
solution and in the latter case shall confirm usage of identical platforms.
Table A.1: Options
Option Status Option defined in Support Mnemonic
Releases
ID-1 UICC O.1 R99 O_ID1_UICC
Plug-in UICC O.1 R99 O_PLUG_IN_UICC
Type 1 (i.e. UICC which always enters the negotiable O.2 R99 O_TYPE_1
mode after a warm reset)
Type 2 (UICC which always enters the specific mode O.2 R99 O_TYPE_2
after a warm reset)
T=0 O.3 R99 O_T0
T=1 O.3 R99 O_T1
Mono application UICC O.4 R99 O_MONO_APP
Multi-application UICC O.4 R99 O_MULTI_APP
Single verification capable UICC O.5 R99 O_SINGLE_VER
Multi-verification capable UICC O.5 R99 O_MULTI_VER
More than one logical channel supported O Rel-4 O_LOG_CHANS
More than two logical channels supported O Rel-4 O_LOG_CHANS_34
Shareable files O Rel-4 O_SHAREABLE
Non-shareable files O Rel-4 O_NON_SHAREABLE
GET CHALLENGE O Rel-4 O_GET_CHALLENGE
Mini-UICC O.1 Rel-6 O_MINI_UICC
(F, D) = (512, 64) O Rel-6 O_F_D_512_64
Low impedance drivers O Rel-6 O_LOW_IMPEDANCE
BER-TLV structure EFs O Rel-6 O_BER_TLV_FILES
GET IDENTITY when SUCI calculation performed by O Rel-15 O_GET
the USIM IDENTITY_SUCI
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 11 ETSI TS 131 122 V15.1.0 (2019-06)
3.7 Applicability table
Table B.1: Applicability of tests
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 12 ETSI TS 131 122 V15.1.0 (2019-06)
Clause Descriptio Test Tested R99 Rel- Rel- Rel- Rel- Rel- Rel- Rel-10 Rel-11 Rel-12 Rel-13 Rel-14 Rel-15 Support
n procedur features UICC 4 5 6 7 8 9 UICC UICC UICC UICC UICC UICC
e defined in UIC UIC UIC UIC UIC UIC
Release C C C C C C
6.1.1 ID-1 UICC 1 R99 C001 C00 C00 C00 C00 C00 C00 C001 C001 C001 C001 C001 C001
1 1 1 1 1 1
6.1.2 Plug-in 1 R99 C002 C00 C00 C00 C00 C00 C00 C002 C002 C002 C002 C002 C002
UICC 2 2 2 2 2 2
6.1.3 Temperatur 1 R99 M M M
e range for
card
operation
2 Rel-6  M M M M M M M M M M
6.1.4 Contacts N/A
6.1.5 Mini-UICC 1 Rel-6  C00 C00 C00 C00 C003 C003 C003 C003 C003 C003
3 3 3 3
6.2.1.1 Vcc – 1 R99 M M M M M M M M M M M M M
Voltage
limits
6.2.1.2 Vcc - Idle 1 R99 M M M M M M M M M M M M M
current
limits
6.2.1.3 Vcc - 1 R99 M M M M M M M M M M M M M
Current
limits in clk-
stop-mode
6.2.2.1 RST - 1 R99 M M M M M M M M M M M M M
Static
operation
6.2.3.1 Vpp - Static 1 R99 M M M M M M M M M M M M M
operation
6.2.4.1 CLK - 1 R99 M M M M M M M M M M M M M
Frequency
and duty
cycle
6.2.4.2 Voltage 1 R99 M M M M M M M M M M M M M
and current
6.2.5.1 I/O - 1 R99 M M M C01 C01 C01 C01 C018 C018 C018 C018 C018 C018
Voltage 8 8 8 8
and current
2 Rel-6  C01 C01 C01 C01 C019 C019 C019 C019 C019 C019
9 9 9 9
3 Rel-6  C02 C02 C02 C02 C020 C020 C020 C020 C020 C020
0 0 0 0
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 13 ETSI TS 131 122 V15.1.0 (2019-06)
Clause Descriptio Test Tested R99 Rel- Rel- Rel- Rel- Rel- Rel- Rel-10 Rel-11 Rel-12 Rel-13 Rel-14 Rel-15 Support
n procedur features UICC 4 5 6 7 8 9 UICC UICC UICC UICC UICC UICC
e defined in UIC UIC UIC UIC UIC UIC
Release C C C C C C
6.3.1.1 Supply N/A
voltage
switching -
Supply
voltage
classes
6.3.1.2 Supply 1 R99 M M M M M M M M M M M M M
voltage
switching -
Power
consumptio
n of the
UICC
during ATR
6.3.1.3 Supply 1 R99 M M M M M M M M M M M M M
voltage
switching -
Application
related
electrical
parameters
6.3.2.1 ATR - 1 R99 M M M M M M M M M M M M M
Major
capabilities
6.3.2.2 ATR - 1 R99 M M M M M M M M M M M M M
Speed
enhanceme
nt
6.3.2.3 Global 1 Rel-6  M M M M M M M M M M
Interface
bytes
6.3.3 PPS 1 R99  M M M M M M M M M M
procedure
6.3.4 Reset 1 R99 M M M M M M M M M M M M M
procedures
2 R99  M M M M M M M M M M
3 R99  C00 C00 C00 C00 C004 C004 C004 C004 C004 C004
4 4 4 4
4 R99  C00 C00 C00 C00 C005 C005 C005 C005 C005 C005
5 5 5 5
6.3.5 Clock stop 1 R99 M M M M M M M M M M M M M
mode
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 14 ETSI TS 131 122 V15.1.0 (2019-06)
Clause Descriptio Test Tested R99 Rel- Rel- Rel- Rel- Rel- Rel- Rel-10 Rel-11 Rel-12 Rel-13 Rel-14 Rel-15 Support
n procedur features UICC 4 5 6 7 8 9 UICC UICC UICC UICC UICC UICC
e defined in UIC UIC UIC UIC UIC UIC
Release C C C C C C
6.3.6 Bit/charact N/A
er duration
and
sampling
time
6.3.7 Error 1 R99 M M M M M M M M M M M M M
handling
6.3.8 Compatibilit N/A
y
6.4.1 Physical N/A
Layer
6.4.2.1 Character 1 R99 M M M M M M M M M M M M M
Frame
6.4.2.2 Transmissi 1 R99 C006 C00 C00 C00 C00 C00 C00 C006 C006 C006 C006 C006 C006
on Protocol 6 6 6 6 6 6
T=0
6.4.2.3.1.1 T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
Information 7 7 7 7 7 7
field size
6.4.2.3.1.2 T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
Character 7 7 7 7 7 7
waiting
integer
6.4.2.3.1.3 T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
Character 7 7 7 7 7 7
waiting
time
6.4.2.3.1.4 T=1 - Block 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
guard time 7 7 7 7 7 7
6.4.2.3.1.5 T=1 - N/A
Waiting
time
extension
6.4.2.3.1.6 T=1 - Error 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
detection 7 7 7 7 7 7
code
6.4.2.3.2.1. T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
1 Prologue 7 7 7 7 7 7
field - Node
address
byte
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 15 ETSI TS 131 122 V15.1.0 (2019-06)
Clause Descriptio Test Tested R99 Rel- Rel- Rel- Rel- Rel- Rel- Rel-10 Rel-11 Rel-12 Rel-13 Rel-14 Rel-15 Support
n procedur features UICC 4 5 6 7 8 9 UICC UICC UICC UICC UICC UICC
e defined in UIC UIC UIC UIC UIC UIC
Release C C C C C C
6.4.2.3.2.1. T=1 - N/A
2 Prologue
field -
Protocol
Control
Byte
6.4.2.3.2.1. T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
3 Prologue 7 7 7 7 7 7
field -
Length
6.4.2.3.2.1. T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
4 Information 7 7 7 7 7 7
field
6.4.2.3.2.3 T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
Epilogue 7 7 7 7 7 7
field
6.4.2.3.3 T=1 - Error 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
free 7 7 7 7 7 7
operation
6.4.2.3.4.1 T=1 - Error 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
Handling - 7 7 7 7 7 7
Protocol
initialisation
6.4.2.3.4.2. T=1 - Error 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
1 Handling - 7 7 7 7 7 7
Sending
invalid
blocks to
the UICC
6.4.2.3.5 T=1 - 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
Chaining 7 7 7 7 7 7
6.4.3.1.1 Transportat 1 R99 C006 C00 C00 C00 C00 C00 C00 C006 C006 C006 C006 C006 C006
ion of an 6 6 6 6 6 6
APDU
using T=0 -
Case 1
6.4.3.1.2 Transportat 1 R99 C006 C00 C00 C00 C00 C00 C00 C006 C006 C006 C006 C006 C006
ion of an 6 6 6 6 6 6
APDU
using T=0 -
Case 2
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 16 ETSI TS 131 122 V15.1.0 (2019-06)
Clause Descriptio Test Tested R99 Rel- Rel- Rel- Rel- Rel- Rel- Rel-10 Rel-11 Rel-12 Rel-13 Rel-14 Rel-15 Support
n procedur features UICC 4 5 6 7 8 9 UICC UICC UICC UICC UICC UICC
e defined in UIC UIC UIC UIC UIC UIC
Release C C C C C C
6.4.3.1.3 Transportat 1 R99 C006 C00 C00 C00 C00 C00 C00 C006 C006 C006 C006 C006 C006
ion of an 6 6 6 6 6 6
APDU
using T=0 -
Case 3
6.4.3.1.4 Transportat 1 R99 C006 C00 C00 C00 C00 C00 C00 C006 C006 C006 C006 C006 C006
ion of an 6 6 6 6 6 6
APDU
using T=0 -
Case 4
6.4.3.1.5.1 Use of 1 R99 C006 C00 C00 C00 C00 C00 C00 C006 C006 C006 C006 C006 C006
Procedure 6 6 6 6 6 6
Bytes
'61xx' and
'6Cxx' -
Case 2
Commands
6.4.3.1.5.2 Use of N/A
Procedure
Bytes
'61xx' and
'6Cxx' -
Case 4
Commands
6.4.3.2.1 Transportat 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
ion of an 7 7 7 7 7 7
APDU
using T=1 -
Case 1
6.4.3.2.2 Transportat 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
ion of an 7 7 7 7 7 7
APDU
using T=1 -
Case 2
6.4.3.2.3 Transportat 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
ion of an 7 7 7 7 7 7
APDU
using T=1 -
Case 3
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 17 ETSI TS 131 122 V15.1.0 (2019-06)
Clause Descriptio Test Tested R99 Rel- Rel- Rel- Rel- Rel- Rel- Rel-10 Rel-11 Rel-12 Rel-13 Rel-14 Rel-15 Support
n procedur features UICC 4 5 6 7 8 9 UICC UICC UICC UICC UICC UICC
e defined in UIC UIC UIC UIC UIC UIC
Release C C C C C C
6.4.3.2.4 Transportat 1 R99 C007 C00 C00 C00 C00 C00 C00 C007 C007 C007 C007 C007 C007
ion of an 7 7 7 7 7 7
APDU
using T=1 -
Case 4
6.4.4 Application N/A
Layer
6.5.1 UICC 1 R99 M M M M M M M M M M M M M
Application
structure
6.5.2.1 Dedicated N/A
files
6.5.2.2.1 Transparen 1 R99 M M M M M M M M M M M M M
t EF
6.5.2.2.2 Linear fixed 1 R99 M M M M M M M M M M M M M
EF
6.5.2.2.3 Cyclic EF 1 R99 M M M M M M M M M M M M M
6.5.2.2.4 BER-TLV N/A
structure
EF
6.5.3 File N/A
referencing
6.5.4.1 SELECT by 1 R99 M M M M M M M M M M M M M
File
Identifier
Referencin
g
6.5.4.2 SELECT by 1 R99 M M M M M M M M M M M M M
Path
Referencin
g
6.5.4.3 Short File 1 R99 M M M M M M M M M M M M M
Identifier
6.5.5.1.1 SELECT by 1 R99 M M M M M M M M M M M M M
DF Name
6.5.5.1.2 SELECT by 1 R99  C00 C00 C00 C00 C009 C009 C009 C009 C009 C009
partial DF 9 9 9 9
Name
2 R99 C008 C00 C00
8 8
3 R99  C00 C00 C00 C00 C008 C008 C008 C008 C008 C008
8 8 8 8
ETSI
3GPP TS 31.122 version 15.1.0 Release 15 18 ETSI TS 131 122 V15.1.0 (2019-06)
Cla
...
