Technical Report
Telecommunications and Internet converged Services and
Protocols for Advanced Networking (TISPAN);
NGN based IPTV mapping or
interconnect between IPTV systems

2 ETSI TR 182 030 V3.1.1 (2011-05)

Reference
DTR/TISPAN-02079-NGN-R3
Keywords
architecture, IMS, interconnection, interworking,
IP, TV
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: [phone]  Fax: [phone]

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
Some material contained herein is the copyright of, or has been supplied by ITU-T and the Open IPTV Forum.

© European Telecommunications Standards Institute 2011.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 ETSI TR 182 030 V3.1.1 (2011-05)
Contents
Intellectual Property Rights . 4
Foreword . 4
1 Scope . 5
2 References . 5
2.1 Normative references . 5
2.2 Informative references . 5
3 Definitions and abbreviations . 7
3.1 Definitions . 7
3.2 Abbreviations . 7
4 TISPAN NGN IPTV architectures - comparing of functionalities and services . 8
5 Mapping and interworking with other IPTV systems . 11
5.1 NGN Integrated IPTV . 11
5.1.1 NGN non-IMS based IPTV in ITU-T . 11
5.1.2 NGN non-IMS based IPTV in ATIS . 12
5.2 IMS based IPTV . 12
5.2.1 IMS based IPTV in ITU-T . 13
5.2.2 IMS based IPTV in ATIS . 14
5.2.3 IMS based PSS and MBMS User Service in 3GPP . 14
5.2.3.1 Mapping between TISPAN entities and 3GPP IMS based PSS and MBMS . 15
5.2.3.2 Mapping between 3GPP IMS based PSS and MBMS and TISPAN IMS based IPTV architecture . 16
5.2.3.3 Mapping to TISPAN reference points . 17
5.2.4 IMS based IPTV in OIPF . 17
5.2.4.1 Mapping between TISPAN entities and OIPF IMS based IPTV . 17
5.2.4.2 Mapping to TISPAN reference points . 19
6 Selected TISPAN IPTV services to mobile UE over existing mobile access networks . 19
6.1 3GPP mobile access network . 19
6.2 DVB-H access network . 20
7 TISPAN IPTV Interconnection models and support for mobility . 21
7.1 Use cases . 21
7.1.1 Remote pure data access to IPTV provider . 21
7.1.2 Interconnect to home IPTV provider . 21
7.1.3 Visited - home network roaming between IPTV providers -served only from home network . 21
7.1.4 Visited - home network roaming between IPTV providers -served from home and/or visited network . 22
7.1.5 Visited - home network roaming between IPTV providers -served only from visited network . 22
7.2 IPTV interconnection mechanisms for mobility support . 22
7.3 IMS based IPTV Interconnection model and related signalling flow . 22
7.3.1 Interconnection model using IMS roaming to home IMS IPTV . 23
7.3.2 Signalling flows . 23
7.3.2.1 UE start-up procedures . 24
7.3.2.2 CoD procedures . 25
7.4 NGN integrated IPTV Interconnection model and related signalling flow . 26
7.5 Support for hybrid services and related examples of signalling flow . 26
7.5.1 Support for hybrid services with NGN integrated IPTV. 27
7.5.2 Support for hybrid services with IMS based IPTV . 28
History . 30

ETSI
4 ETSI TR 182 030 V3.1.1 (2011-05)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Technical Report (TR) has been produced by ETSI Technical Committee Telecommunications and Internet
converged Services and Protocols for Advanced Networking (TISPAN).
ETSI
5 ETSI TR 182 030 V3.1.1 (2011-05)
1 Scope
The present document analyses existing NGN-based IPTV functional architectures (IMS based IPTV, NGN integrated
IPTV) and its features.
The scope of the present document includes:
• comparison of architectural aspects between TISPAN NGN based IPTV and 3GPP MBMS/PSS (IMS based or
non-IMS based MBMS/PSS) with aim to consider possible mappings of functionalities or feasibility of
scenarios for interworking;
• consider IPTV work within other SDOs/Fora with relation to TISPAN NGN based IPTV architecture
(e.g. relation with ITU-T IMS/non-IMS based IPTV);
• consider the impacts for providing selected TISPAN IPTV services to mobile UE over existing mobile access
networks;
• consider the impacts to support IPTV interconnection models from TISPAN stage 2 specification.
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
Not applicable.
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] ETSI TS 182 027: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); IPTV Architecture; IPTV functions supported by the IMS
subsystem".
[i.2] ETSI TS 182 028: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); NGN integrated IPTV subsystem Architecture".
[i.3] ITU-T Recommendation Y.1910 (2008): "IPTV functional architecture".
[i.4] ETSI TS 126 237: "Universal Mobile Telecommunications System (UMTS); LTE; IMS based PSS
and MBMS User Service; Protocols (3GPP TS 26.237 version 8.0.0 Release 8)".
[i.5] ETSI TS 123 506: "Digital cellular telecommunications system (Phase 2+); Universal Mobile
Telecommunications System (UMTS); TISPAN; IP Multimedia Subsystem (IMS); Stage 2
description [3GPP TS 23.228 Release 7, modified] (3GPP TS 23.506 version 8.1.0 Release 8)".
ETSI
6 ETSI TR 182 030 V3.1.1 (2011-05)
[i.6] ETSI TS 123 002: "Digital cellular telecommunications system (Phase 2+); Universal Mobile
Telecommunications System (UMTS); LTE; Network architecture (3GPP TS 23.002)".
[i.7] ATIS-0800007: "ATIS IPTV High Level Architecture".
[i.8] Open IPTV Forum: "Open IPTV Forum - Functional Architecture - V2.0".
[i.9] ETSI TS 183 063: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); IMS-based IPTV stage 3 specification".
[i.10] ETSI TS 183 064: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); NGN integrated IPTV subsystem stage 3 specification".
[i.11] ETSI TR 102 469 (V1.1.1): "Digital Video Broadcasting (DVB); IP Datacast over DVB-H:
Architecture".
[i.12] ETSI TS 102 796 (V1.1.1):"Hybrid Broadcast Broadband TV".
[i.13] ETSI TS 181 016 (V3.3.1): "Telecommunications and Internet converged Services and Protocols
for Advanced Networking (TISPAN); Service Layer Requirements to integrate NGN Services and
IPTV".
[i.14] ETSI TS 102 034: "Digital Video Broadcasting (DVB); Transport of MPEG-2 TS Based DVB
Services over IP Based Networks".
[i.15] ETSI TS 102 539: "Digital Video Broadcasting (DVB); Carriage of Broadband Content Guide
(BCG) information over Internet Protocol (IP)".
[i.16] IETF RFC 2326: "Real Time Streaming Protocol (RTSP)".
[i.17] ETSI TS 126 234: "Universal Mobile Telecommunications System (UMTS); LTE; Transparent
end-to-end Packet-switched Streaming Service (PSS); Protocols and codecs (3GPP TS 26.234)".
[i.18] ETSI TS 123 228: "Digital cellular telecommunications system (Phase 2+); Universal Mobile
Telecommunications System (UMTS); LTE; IP Multimedia Subsystem (IMS); Stage 2
(3GPP TS 23.228)".
[i.19] ETSI TS 123 060: "Digital cellular telecommunications system (Phase 2+); Universal Mobile
Telecommunications System (UMTS); General Packet Radio Service (GPRS); Service
description; Stage 2 (3GPP TS 23.060)".
[i.20] ETSI TS 123 203: "Digital cellular telecommunications system (Phase 2+); Universal Mobile
Telecommunications System (UMTS); LTE; Policy and charging control architecture
(3GPP TS 23.203)".
[i.21] ETSI TS 133 220: "Digital cellular telecommunications system (Phase 2+); Universal Mobile
Telecommunications System (UMTS); LTE; Generic Authentication Architecture (GAA); Generic
Bootstrapping Architecture (GBA) (3GPP TS 33.220)".
[i.22] ETSI ES 282 003: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); Resource and Admission Control Sub-System (RACS):
Functional Architecture".
[i.23] ETSI TS 123 246: "Universal Mobile Telecommunications System (UMTS); LTE; Multimedia
Broadcast/Multicast Service (MBMS); Architecture and functional description
(3GPP TS 23.246)".
[i.24] ETSI EN 302 304: " Digital Video Broadcasting (DVB); Transmission System for Handheld
Terminals (DVB-H)".
[i.25] ETSI ES 282 004: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); NGN Functional Architecture; Network Attachment
Sub-System (NASS)".
ETSI
7 ETSI TR 182 030 V3.1.1 (2011-05)
[i.26] ETSI TS 182 019: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); Content Delivery Network (CDN) architecture -
Interconnection with TISPAN IPTV architectures".
[i.27] ETSI ES 283 003: "Telecommunications and Internet converged Services and Protocols for
Advanced Networking (TISPAN); IP Multimedia Call Control Protocol based on Session
Initiation Protocol (SIP) and Session Description Protocol (SDP) Stage 3
[3GPP TS 24.229 [Release 7], modified]".
[i.28] ETSI TS 102 471: "Digital Video Broadcasting (DVB); IP Datacast over DVB-H: Electronic
Service Guide (ESG)".
[i.29] ETSI TS 126 346: "Universal Mobile Telecommunications System (UMTS); LTE; Multimedia
Broadcast/Multicast Service (MBMS); Protocols and codecs (3GPP TS 26.346 version 10.0.0
Release 10)".
3 Definitions and abbreviations
3.1 Definitions
For the purposes of the present document, the following terms and definitions apply:
IMS-based IPTV: IMS-based IPTV architecture that provides IPTV services to NGN users
NOTE: Defined in TS 182 027 [i.1].
NGN-based IPTV: multimedia system that provides IPTV services over the NGN architecture and may be
implemented as an integrated subsystem with the NGN (NGN integrated IPTV) or may use the IMS subsystem
(IMS-based IPTV) in the NGN
NGN integrated IPTV: IPTV subsystem integrated with the NGN architecture that provides IPTV services to NGN
users
NOTE: Defined in TS 182 028 [i.2].
TISPAN IPTV services: interactive personalized multimedia IPTV services specified by ETSI TISPAN to provide
selected IPTV services and features to NGN users
NOTE: Defined in TS 181 016 [i.13].
3.2 Abbreviations
For the purposes of the present document, the following abbreviations apply:
BC BroadCast
BCG Broadband Content Guide
CFIA Customer Facing IPTV Applications
CoD Content on Demand
DVB Digital Video Broadcasting
DVBSTP DVB SD&S Transport Protocol
e-UTRAN/EPC Evolved UTRAN Evolved Packet Core
GUP Generic User Profile
HTTP HyperText Transfer Protocol
IGMP Internet Group Management Protocol
IMS IP Multimedia Subsystem
IPTV IP Television
IPTVC IPTV Control
IUDF IPTV User Data Function
MBMS Multimedia Broadcast/Multicast Service
MCF Media Control Function
ETSI
8 ETSI TR 182 030 V3.1.1 (2011-05)
MDF Media Delivery Function
NASS Network Attachment SubSystem
PSS Packet-switched Streaming Service
RACS Resource and Admission Control Subsystem
RTP Real Time Protocol
SCF Service Control Function
SD&S Service Discovery and Selection
SDF Service Discovery Function
SDO Standard Development Organization
SIP AS Session Initiation Protocol Application Server
SSF Service Selection Function
UDP User Datagram Protocol
UE User Equipment
UPSF User Profile Server Function
UTRAN UMTS Terrestrial Radio Access Network
UTRAN/PS UTRAN Packet Switched
VoD Video on Demand
XCAP XML Configuration Access Protocol
4 TISPAN NGN IPTV architectures - comparing of
functionalities and services
When IMS based IPTV [i.1] is compared with NGN integrated IPTV [i.2] main differences between both solutions are
following:
• Separation of service selection and discovery in IMS based IPTV (SIP based discovery).
• Similar service selection specs, IMS based IPTV additionally support OMA BCAST ESG.
• SIP based service initiation and service control.
• Support of the direct RTP encapsulation.
• Related differences in interfaces and protocols (from Tr to Ut, Xa and change from http based Ct, Ss, Sa to SIP
based Gm, ISC, y2 interfaces).
ETSI
9 ETSI TR 182 030 V3.1.1 (2011-05)
Table 4.1: Informational Comparison of TISPAN characteristics for non-IMS
and IMS based NGN IPTV concepts
General characteristics IMS based IPTV architecture NGN integrated dedicated IPTV
(NGN IMS based) architecture
(NGN Non-IMS)
ETSI TISPAN specification TS 182 027 [i.1] TS 182 028 [i.2]
TS 183 063 [i.9] TS 183 064 [i.10]
1. SD&S TS 102 034 [i.14] based SD&S model - TS 102 034 [i.14] based SD&S model -
separate SDF, SSF single SD&S
SIP based (Mandatory), HTTP HTTP based (Mandatory) DVBSTP
(Optional), DVBSTP (Optional) via Xa (Optional) via Tr to SD&S - HTTP
to SSF - HTTP based based
2. Service selection information DVB SD&S (TS 102 034 [i.14]) DVB SD&S (TS 102 034 [i.14])
(e.g. program guides) DVB BCG (TS 102 539 [i.15]) DVB BCG (TS 102 539 [i.15])
OMA BCAST ESG
TISPAN XML
3. Multicast control - IGMP SIP based initiation Pure IGMP/MLD based
IGMP join to ECF/EFF IGMP join to ECF/EFF
IGMPv3, MDLDv2 IGMPv3, MDLDv2
4. Unicast control - RTSP methods SIP based initiation RTSP based on TS 102 034 [i.14]
Mixture RTSP control (RFC 2326 [i.16]), Coupled, decoupled mode
partially TS 102 034 [i.14] based
Method 1 - new coupled SIP/RTSP
Method 2 - SIP and RTSP separated
5. Media Delivery MPEG2TS over RTP MPEG2TS over RTP
MPEG2TS over UDP MPEG2TS over UDP
direct RTP encapsulation
6. Service control (initialization, SIP based service control using IMS IPTV-C, CFIA control
modification, teardown) SIP Session based control HTTP resp. RTSP based
7. Service configuration Ut - XCAP Tr - XCAP
8. Resource allocation & reservation Via core IMS IPTV-C
Gq' to RACS Gq' to RACS
9. User profile, user data Federated, Consolidated User Profile located:
User Profile located: Federated (UPSF, IUDF, CFIA,
Federated (UPSF, SCF)
IPTV-C)
(SSP located) Consolidated (UPSF)
Consolidated (UPSF)SCF (SIP AS) Federated, Consolidated
SSPUser Profile used (SSF, SDF via UPSF (SSP located), IUDF
Sh) CFIA (http AS), IPTVC
User Profile SSP used (SD&S, IPTVC,
CFIA)
Comparison of IPTV services and feature between TISPAN NGN based architecture (NGN integrated IPTV and IMS
based IPTV).
NOTE: Table 4.2 has informative character and summarized and refer to table 1 in [i.1] and table 1 in [i.2].
ETSI
10 ETSI TR 182 030 V3.1.1 (2011-05)
Table 4.2: Informational Comparison of services and feature for non-IMS
and IMS based NGN IPTV concepts
Service & Feature IPTV NGN IMS based IPTV
Requirements dedicated/integrated
IPTV subsystem
TISPAN Release R2 R3 R2 R3 R2 R3
Linear/Broadcast TV M M M M M M
Linear/Broadcast TV with M M M M O O
Trick Play
Time Shifted TV O O O O O O
Content on Demand M M M M M M
Push CoD NA O M M NA O
Near COD M M M M NA NA
Network PVR M M M M M/O M/O
Client PVR NA O NA O NA O
Audio M M M M O O
Pay-Per-View NA M M M NA O
Interactive TV NA M M M NA O
Service discovery M M M M M M
Service Information (EPG) M M M M M M
Parental Control M M M M M M
User Profiling & O O O O O O
personalization
Communications and NA O O O NA O
Messaging
Notifications NA O O O NA O
IPTV Presence O O O O O O
Interaction between users NA O O O N/A O
Interaction with NGN O O O O O O
services
Advertising M M M M M M
Targeted Advertising NA O NA O NA O
User Generated Content NA M NA O NA O
Internationalization O O O O O O
Content recommendation NA O NA O NA O
Games NA O NA O NA O
Picture NA O NA O NA O
Bookmarks (Content NA O NA O NA O
Marking)
Personalized channel NA O NA O NA O
Personalized Service NA O NA O NA O
Composition
Service Portability NA O NA O NA O
Service Continuation NA O NA O NA O
between IPTV UEs
Service Continuation fixed- NA O NA O NA O
mobile
Remote Control of IPTV NA O NA O NA O
services
Emergency Information NA O NA O NA O
rd
NA O NA O NA O
Interaction with 3 Party
application (e.g. Parlay)
Interaction with Internet NA O NA O NA O
Services
Service synchronization NA O NA O NA O
Incoming call management NA O O O NA

ETSI
11 ETSI TR 182 030 V3.1.1 (2011-05)
5 Mapping and interworking with other IPTV systems
5.1 NGN Integrated IPTV
The clause provides mapping and interworking of NGN integrated IPTV with other SDOs IPTV systems.
5.1.1 NGN non-IMS based IPTV in ITU-T
The NGN Integrated IPTV subsystem architecture supports IPTV service level requirements defined in [i.1] and
provides integration of new or existing IPTV solutions (such as those defined by DVB, ATIS IIF, ITU, etc.) into the
TISPAN NGN architecture.
Comparing ITU-T IPTV architecture (ITU-T Recommendation Y.1910 [i.3]) with ETSI TISPAN NGN integrated IPTV
(TS 182 028 [i.2]) the following mapping of functional entities can be identified.
Table 5.1: Mapping between ITU-T non-IMS IPTV functions
and TISPAN NGN Integrated IPTV functional entities
ITU-T non-IMS NGN IPTV Y.1910 [i.3] TISPAN NGN Integrated IPTV
IPTV Application Functions 9.2.1 Customer Facing IPTV Application FE (CFIA),
Service Discovery and Selection (SD&S) (see note 1) (in part)
IPTV Service Control Functional Block 9.3.1 IPTV Control (IPTV-C)
Service User Profile Functional Block 9.3.2 User Data Function (UPSF)
Content Distribution & Location 9.4.1 Media Control Function (MCF)
Control Functions
Content Delivery & Storage Functions 9.4.2 Media Delivery Function (MDF)
Media Control Function (MCF) (see note 2)
Content Preparation Functions 9.2.3 Content acquisition & preparation functions
Application Profile Functional Block 9.2.2 IPTV User Data FE (IUDF)
Service & content protection Service & Content Protection (SCP)
NOTE 1: The in ITU-T non-IMS NGN IPTV application functions enable the UE to select and purchase content as
well as provide content metadata and other information which are in TISPAN Integrated IPTV Service
Discovery & Selection function.
NOTE 2: Content Delivery & Storage Functions also perform some of the MCF tasks (e.g. managing interaction with
the UE for trick mode commands).

Figure 5.1 illustrates mapping between functional entities discussed in table 5.1.
ETSI
12 ETSI TR 182 030 V3.1.1 (2011-05)
SD&S
Content
IUDF
acquisition &
preparation
functions
DRM
CFIA
MCF
UPSF
MDF
IPTV-C
Figure 5.1: Mappings of ITU-T non-IMS functional architecture to TISPAN NGN integrated IPTV
(Source: ITU-T Y.1910 (09/2008) [i.3], figure 10-2: NGN non-IMS IPTV architecture)
5.1.2 NGN non-IMS based IPTV in ATIS
Comparing ATIS [i.7] non-IMS based IPTV architecture with ETSI TISPAN NGN integrated IPTV (TS 182 028 [i.2])
the following mapping of functional entities can be identified.
Table 5.2: Mapping between ATIS non-IMS IPTV functions
and TISPAN NGN Integrated IPTV functional entities
ATIS non-IMS NGN IPTV ATIS TISPAN NGN Integrated IPTV
IPTV Applications 9.2.4 Customer Facing IPTV Application FE (CFIA),
Service Discovery and Selection (SD&S) (see note) (in part)
IPTV Service Control Function 9 IPTV Control (IPTV-C)
User Profile Functions 9.2.5 IPTV User Data Function (IUDF)
Media Delivery Broadcast & VoD 9.2.2 Media Control Function (MCF)
Media Delivery Function (MDF)
NOTE: The recommendation in ATIS non-IMS NGN IPTV applications enable to UE select and purchase content as
well as provide content metadata and other information which are in TISPAN Integrated IPTV functions of
Service Discovery & Selection function.

5.2 IMS based IPTV
The clause provides mapping and interworking of IMS based IPTV with other SDOs IMS based IPTV systems.
ETSI
13 ETSI TR 182 030 V3.1.1 (2011-05)
5.2.1 IMS based IPTV in ITU-T
The NGN IMS based IPTV specifies the architecture and functions of an IPTV system that makes use of the NGN IMS
architecture and its features, implementing the requirements defined in [i.1].
Comparing ITU-T IPTV architecture (ITU-T Recommendation Y.1910 [i.3]) with ETSI TISPAN NGN IMS based
IPTV (TS 182 028 [i.2]) the following mapping of functional entities can be identified.
Table 5.3: Mapping between ITU-T IMS IPTV functions
and TISPAN NGN IMS based IPTV functional entities
ITU-T IMS NGN IPTV Y.1910 [i.3] TISPAN NGN IMS based IPTV
IPTV Application Functions 9.2.1 Service Discovery Functions (SDF)
Service Selection Function (see note 1) (in part)
Core IMS functions 10.2.2.2 Core IMS (Core IMS)
IPTV Service Control Functional Block 9.3.1 Service Control Function (SCF)
Service User Profile Functional Block 9.3.2 User Data Function (UPSF)
Content Distribution & Location Control 9.4.1 Media Control Function (MCF)
Functions
Content Delivery & Storage Functions 9.4.2 Media Delivery Function (MDF)
Media Control Function (MCF) (see note 2)
Content Preparation Functions 9.2.3 -
Application Profile Functional Block 9.2.2 -
Service & content protection -
NOTE 1: The ITU-T IMS NGN IPTV application functions enable UE to select and purchase content, as well as
provide content metadata and other information which are provided in the TISPAN IMS based IPTV
Service Selection Function.
NOTE 2: Content Delivery & Storage Functions also perform some of the MCF tasks (e.g. managing
interaction with the UE for trick mode commands).

SDF
SSF
SCF
MCF
Core
IMS
UPSF
MDF
Figure 5.2: Mappings of ITU-T IMS functional architecture to TISPAN NGN IMS based IPTV
(Y.1910 (09/2008) [i.3], figure 10-3: NGN IMS IPTV architecture)
ETSI
14 ETSI TR 182 030 V3.1.1 (2011-05)
5.2.2 IMS based IPTV in ATIS
Comparing ATIS [i.7] IMS based IPTV architecture with ETSI TISPAN IMS based IPTV (TS 182 027 [i.1]) the
following mapping of functional entities can be identified.
Table 5.4: Mapping between ATIS IMS based IPTV functions
and TISPAN IMS based IPTV functional entities
ATIS IMS based IPTV ATIS TISPAN IMS based IPTV
IPTV Applications 9.2.4 Service Discovery Functions (SDF)
Service Selection Function (see note 1) (in part)
IPTV Service Control Functions(SCF) (see note 2) (in part)
Core IMS 9.3.2 Core IMS
Service User Profile Function 9.3.2 User Profile Server Function (UPSF)
Media Delivery Broadcast & VoD 9.2.2 Media Control Function (MCF)
Media Delivery Function (MDF)
NOTE 1: IPTV applications within ATIS IMS based IPTV enable the UE to select and purchase content as well
as provide content metadata and other information; these functions are provided in TISPAN IMS based
IPTV by the Service Selection Functions (SSF).
NOTE 2: IPTV applications in ATIS IMS based IPTV perform service logic functions for IPTV services
(e.g. Broadcast, CoD etc.), which are provided within TISPAN IMS based IPTV by the Service Control
Functions (SCF).
5.2.3 IMS based PSS and MBMS User Service in 3GPP
The IP Multimedia Subsystem (IMS) enables the deployment of IP multimedia applications. PSS and MBMS User
Services are IP multimedia services, but they were specified by 3GPP prior to standardization of IMS. IMS brings
enablers and features to operators and subscribers that can enhance the experience of PSS and MBMS User Services.
The main goal of this clause is principal concept for providing selected TISPAN IPTV services to mobile UE over
3GPP mobile access networks supporting unicast based streaming services (using PSS) or multicast based streaming
services (using MBMS).
This clause will explain how IMS based IPTV from TISPAN may be combined with 3GPP IMS based PSS and
MBMS [i.4].
NOTE: There should be a limitation which services could be provided over such a combined architecture
(TISPAN IMS based IPTV with support for PSS or MBMS based streaming).
ETSI
15 ETSI TR 182 030 V3.1.1 (2011-05)
5.2.3.1 Mapping between TISPAN entities and 3GPP IMS based PSS and MBMS
Table 5.5 shows entities defined in the 3GPP IMS based PSS and MBMS user services, their roles and relevant
TISPAN entities.
Table 5.5: Conceptual mapping of functional entities
3GPP Entity 3GPP entity tasks TISPAN TISPAN entity task covered
TS 126 237 [i.4], clause 4.2.2 Entity
Service Discovery This function provides an entry point to SDF Provides the service attachment
Function SSF for the client to attach to the service 5.1.5.1 information. Provides personalized
provided by the service provider. service discovery
Service Selection Provides a list of available PSS and MBMS SSF Provides the service selection
Function User Services and relevant User Service 5.1.5.1 information
Description information.
Service Control Provides service logic and functions SCF SC
...
