High-voltage switchgear and controlgear - Part 105: Alternating current switch-fuse combinations for rated voltages above 1 kV up to and including 52 kV

IEC 62271-105:2021 is available as IEC 62271-105:2021 RLV which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition.
IEC 62271-105:2021 applies to three-pole units for public and industrial distribution systems which are functional assemblies of switches composed of switches or switch-disconnectors and current-limiting fuses designed so as to be capable of
- breaking, at the rated voltage, any current up to and including the rated short-circuit breaking current;
- making, at the rated voltage, circuits to which the rated short-circuit breaking current applies.
This third edition cancels and replaces the second edition published in 2012. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
- the document has been updated to be in alignment with the second edition of IEC 62271-1:2017;
- rated TRV has been removed (TRV is only a test parameter), as in the latest revision of IEC 62271-100;
- differentiation has been introduced between requirements expressed for fulfilling the function expected from a switch-fuse combination, from requirements only relevant when the function is performed by a stand-alone device. The goal is to avoid duplication or conflicts of requirements with a standard dealing with assemblies, when the function is implemented within such an assembly.

Appareillage à haute tension - Partie 105: Combinés interrupteurs-fusibles pour courant alternatif de tensions assignées supérieures à 1 kV et jusqu'à 52 kV inclus

IEC 62271-105:2021 est disponible sous forme de IEC 62271-105:2021 RLV qui contient la Norme internationale et sa version Redline, illustrant les modifications du contenu technique depuis l'édition précédente.
L’IEC 62271-105:2021 est applicable aux appareils tripolaires utilisés dans les réseaux de distribution publics ou les installations industrielles. Ces derniers forment des ensembles fonctionnels composés d'interrupteurs ou d'interrupteurs-sectionneurs et de fusibles limiteurs de courant, conçus pour être capables de
- couper, à la tension assignée, tous les courants jusqu'au pouvoir de coupure assigné en court-circuit inclus;
- établir, à la tension assignée, des circuits pour lesquels le pouvoir de coupure assigné en court-circuit s’applique.
Cette troisième édition annule et remplace la deuxième édition parue en 2012. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
- le document a été mis à jour conformément à la 2e édition de l’IEC 62271-1:2017;
- la TTR assignée est supprimée (la TTR n’est qu’un paramètre d’essai) comme dans la dernière édition de l’IEC 62271‑100;
- une distinction est désormais faite entre les exigences spécifiées pour l’exécution de la fonction attendue d’un combiné interrupteur-fusibles, et les exigences qui ne sont pertinentes que lorsque la fonction est exécutée par un appareil autonome. Cette distinction a pour but d’éviter des répétitions ou des contradictions d’exigences avec une norme traitant d’ensembles, lorsque la fonction est mise en œuvre au sein d’un tel ensemble.
