ISO/FDIS 7042

Fasteners — Prevailing torque hexagon nuts — High nuts (all metal)

ISO 7042:2012 specifies the characteristics of prevailing torque type all-metal hexagon high nuts with threads from M5 up to and including M36, in product grade A for threads up to and including M16 and product grade B for threads above M16, and with property classes 5, 8, 10 and 12.

Fixations — Écrous hexagonaux autofreinés — Écrous hauts (tout métal)

L'ISO 7042:2012 spécifie les caractéristiques des écrous hexagonaux hauts autofreinés tout métal, de diamètre de filetage M5 à M 36 inclus, de grade A pour les filetages jusqu'à M16 et de grade B pour les filetages supérieurs à M16, et de classes de qualité 5, 8, 10 et 12.

General Information

• Status: Not Published
• ICS: 21.060.20 - Nuts
• Technical Committee: ISO/TC 2/SC 12 - Fasteners with metric internal thread
• Drafting Committee: ISO/TC 2/SC 12 - Fasteners with metric internal thread
• Current Stage: 5020 - FDIS ballot initiated: 2 months. Proof sent to secretariat
• Start Date: 24-Mar-2025
• Due Date: 24-Mar-2025
• Completion Date: 24-Mar-2025
