TECHNICAL SPECIFICATION ISO/TS 18876-2:2003(E)
Industrial automation systems and integration —
Integration of industrial data for exchange, access and
sharing —
Part 2:
Integration and mapping methodology
1 Scope

This Technical Specification establishes an architecture, a methodology, and other specifications for integrating

industrial data for exchange, access and sharing. Together these support the following activities:

— integrating data which may be:
— from different sources or with different model contexts,
— described by different models, or
— defined in different modelling languages;
— sharing data among applications through systems integration architectures;
— resolving conflict between models developed with different objectives;
— translating data between different encodings;
— translating models between different modelling languages.
This part of ISO 18876 specifies methods for the following:
— creating and extending integration models;

— evaluating and selecting an integration model that can integrate two or more application models;

— creating an application model that is a constrained subset of an integration model to support particular ap-

plication domain requirements for exchange, sharing, or both;

— creating a mapping specification between an application model and an integration model.

The following are within the scope of this part of ISO 18876:

— modelling language independent methods for creating and extending an integration model;

— methods for integrating an application model with an integration model;

— mapping language independent methods for mapping an application model to an integration model;

— criteria for the selecting modelling languages and mapping languages that can be used within the specified

methods for integration and mapping.
The following are outside the scope of this part of ISO 18876:
© ISO 2003 – All rights reserved 1
---------------------- Page: 7 ----------------------
ISO/TS 18876-2:2003(E)
— the structure and content of particular integration models;
— methods for creating and extending particular integration models;
— methods for mapping application models to particular integration models.

NOTE The specific methods that apply to mappings between particular application models and integration models de-

pend on the modelling paradigm(s) applied and on the structure and content of the models.

2 Normative references

The following referenced documents are indispensable for the application of this document. For dated references,

only the edition cited applies. For undated references, the latest edition of the referenced document (including

any amendments) applies.

ISO/IEC 8824-1:1998, Information technology — Abstract Syntax Notation One (ASN.1): Specification of basic

notation

ISO 10303-1:1994, Industrial automation systems and integration — Product data representation and

exchange — Part 1: Overview and fundamental principles

ISO/TS 18876-1:2003, Industrial automation systems and integration — Integration of industrial data for exchange,

access and sharing — Part 1: Architecture overview and description
3 Terms, definitions, and abbreviations
3.1 Terms and definitions

For the purposes of this document, the following terms and definitions apply; those taken or adapted

from ISO 10303-1 and ISO/TS 18876-1 are repeated below for convenience.

NOTE 1 Definitions copied verbatim from other standards are followed by a reference to the standard in brackets, such as

“[ISO 10303-1]”. In these cases the definition in the referenced document is normative; its repetition here is informative and

in the case of any discrepancy the definition in the referenced document has precedence. An explanatory note follows

definitions that have been adapted from other standards. In these cases the definition given here is normative for the pur-

poses of this part of ISO 18876.
3.1.1
application model (AM)
model that represents information used for some particular purpose
NOTE 1 Some application models are also integration models (see 3.1.15).
2 © ISO 2003 – All rights reserved
---------------------- Page: 8 ----------------------
ISO/TS 18876-2:2003(E)

NOTE 2 An application model is not necessarily a data model, but may be a model of some other sort, such as a logic

based model.
[ISO/TS 18876-1]
3.1.2
class
category or division of things

NOTE There are a number of ways that class can be defined. This definition is intended to be as broad as possible, and

is broader than that used in ISO 15926-2.

EXAMPLE Pump, power station, engineer, and fictional space vehicle are examples of classes.

[ISO/TS 18876-1]
3.1.3
concept
internal conception of some thing; general notion or idea of some thing
[ISO/TS 18876-1]
3.1.4
construct
representation of a concept in some formal notation system
NOTE A construct may be a part or the whole of a data model.
3.1.5
data

representation of information in a formal manner suitable for communication, interpretation, or processing by

computers and possibly human beings
[ISO 10303-1]
3.1.6
data model

set of constructs that procvides the definition, structure, and format of data, whether physical or abstract in the

sense of being bound to some recording medium
[ISO/TS 18876-1]
3.1.7
derived concept

concept in an integration model that is wholly defined in terms of primitive concepts

[ISO/TS 18876-1]
3.1.8
encoding transformation
transformation of the way data elements are represented for computer processing

EXAMPLE Conversion of data governed by an EXPRESS schema from an ISO 10303-21 file to an XML document is an

example of an encoding transformation.
[ISO/TS 18876-1]
© ISO 2003 – All rights reserved 3
---------------------- Page: 9 ----------------------
ISO/TS 18876-2:2003(E)
3.1.9
extension

process or result of adding concepts to an integration model in order to increase the model scope, without

changing the concepts already represented
[ISO/TS 18876-1]
3.1.10
foundation concept

primitive concept that determines the underlying world viewpoint of an integration model

NOTE There can be a number of integration models. Each will have its own modelling paradigm which is characterised

by the primitive concepts that it contains.

EXAMPLE The concepts of class and individual are foundation concepts for a general integration model.

[ISO/TS 18876-1]
3.1.11
general concept

primitive concept that has very wide applicability, but is a specialization of some foundation concept

NOTE A concept may be considered to be a foundation concept by one community, while it is considered to be a gen-

eral concept by another..
[ISO/TS 18876-1]
3.1.12
individual
thing that exists in space and time

NOTE This includes things that actually exist, or have existed, and things that possibly exist in the past, present or fu-

ture.

EXAMPLE The pump with serial number ABC123, Battersea Power Station, Sir Joseph Whitworth, and the Starship

“Enterprise” are examples of individuals.
[ISO/TS 18876-1]
3.1.13
information
facts, concepts, or instructions
[ISO 10303-1]
3.1.14
integration
activity that creates, modifies, or extends an integration model
[ISO/TS 18876-1]
3.1.15
integration model (IM)

application model that can represent the information that is represented by two or more application models

NOTE Being an integration model is about the role one model plays with respect to one or more application models.

[ISO/TS 18876-1]
4 © ISO 2003 – All rights reserved
---------------------- Page: 10 ----------------------
ISO/TS 18876-2:2003(E)
3.1.16
mapping

correspondence between instances of one model and instances of another model that represent the same mean-

ing
NOTE 1 A mapping can be uni-directional or bi-directional.

NOTE 2 A mapping is the result of applying a mapping specification to particular models.

[ISO/TS 18876-1]
3.1.17
mapping specification

specification of the transformations necessary to take information governed by one model and represent it by

information governed by another model with the same meaning

NOTE 1 A mapping specification can include data structure transformations, data value transformations, data encoding

transformations, and terminology transformations.

NOTE 2 Mapping specifications can be procedural, or declarative, or a combination of these.

[ISO/TS 18876-1]
3.1.18
model
limited information representation of something suitable for some purpose

NOTE A model can be data, or a data model, or take some other form. See Annex D for further discussion of the rela-

tionship between models, data, and data models.
[ISO/TS 18876-1]
3.1.19
model context

sum of constraints that limit the possibility of adding to a model without changing any existing declarations

NOTE 1 The model context is therefore the class of all possible extensions to a model.

NOTE 2 This term is more general than application context as defined in ISO 10303-1.

[ISO/TS 18876-1]
3.1.20
model scope
range of information that an application model can describe
[ISO/TS 18876-1]
3.1.21
primitive concept

concept in an integration model that is not wholly defined in terms of other concepts

[ISO/TS 18876-1]
3.1.22
structural transformation
type of mapping specification that is a transformation to the structure of data
© ISO 2003 – All rights reserved 5
---------------------- Page: 11 ----------------------
ISO/TS 18876-2:2003(E)

NOTE The change in structure could be to the rearranging of attributes, the splitting of attributes across entity data

types, or the creation of new attributes.
[ISO/TS 18876-1]
3.1.23
terminology transformation
transformation of the term used to refer to a thing

NOTE This could be between synonyms in one language, or between different languages.

[ISO/TS 18876-1]
3.1.24
transformation
change of form
[ISO/TS 18876-1]
3.1.25
view
model that is a constrained subset of another model
[ISO/TS 18876-1]
3.2 Abbreviations
For the purposes of this document, the following abbreviations apply.
AM application model

NOTE In ISO 10303 the abbreviation AM is used for Application Module. An Application Module is not the same as an

Application Model.
IM integration model
4 Usage scenarios

The methodology defined in this part of ISO 18876 is designed to meet requirements typified by the following

usage scenarios:
— integrating two or more existing application models (see 4.1);

— integrating one or more existing application models with an existing integration model (see 4.2);

— defining an application model and its mapping to an integration model (see 4.3);

— integrating an application model with more than one integration model (see 4.4);

— improving an integration model (see 4.5).
4.1 Integrating application models

This component of the methodology integrates two or more application models by creating an integration model

that is capable of representing all of the concepts and constraints of the application models. Such an integration

model supports the communication of data between applications and users that operate using the application

models.
6 © ISO 2003 – All rights reserved
---------------------- Page: 12 ----------------------
ISO/TS 18876-2:2003(E)
This requirement and its solution are illustrated in Figure 1 below.
Modelling
Paradigm and
Principles
Integration
Model
Mapping
Specifications
Application Application
Application Application
Model Model
1 2
Model Model
1 2
Figure 1 — Creating an integration model that integrates two application models
The inputs to the activity are as follows:
— two or more application models;

— the modelling paradigm and principles chosen for the creation of integration models.

NOTE The use of such principles is an important criterion in determining the future extensibility and reuse of an integra-

tion model.
The outputs of this activity are as follows:

— an integration model that represents the concepts and constraints of the input application models;

— mapping specifications that represent the relationships between constructs of each application model and

their corresponding subsets of the integration model.

The mapping specifications include any constraints that apply for the application models. The subset of the in-

tegration model that corresponds to each application model includes concepts that are not explicit in the applica-

tion model and have been discovered during the integration process.
4.2 Integrating application models with an integration model

This component of the methodology integrates one or more application models and an existing integration

model. The purpose of this activity may be either or both of the following:
— integrating the application models;

— improving the quality of the application models by representing their concepts and constraints in a more

consistent and extensible form and structure;
— To extend the model scope of the integration model.
© ISO 2003 – All rights reserved 7
---------------------- Page: 13 ----------------------
ISO/TS 18876-2:2003(E)

The nature and results of this activity depend on the nature of the integration model and the other application

models that are to be integrated. This subclause describes the scenario in which the model context of the appli-

cation models to be integrated is a subset of the model context of the integration model.

NOTE 1 See 4.5 for a description of the scenario in which the model context of the application models to be integrated is

not a subset of the model context of the integration model. The relationship between scope and context of different models is

explained in ISO/TS 18876-1:2003, 5.1.2.
This requirement and its solution are illustrated in Figure 2 below.
Modelling
Paradigm and
Principles
Integration
Extended
Model
Integration Model
Mapping
Specifications
Application Application Application
Application Application Application
Model Model Model
1 2 n
Model Model Model
1 2 n
input output
Figure 2 — Integrating an application model with an existing integration model
The inputs to the activity are as follows:
— an existing integration model;

— one or more application models that are integrated with the integration model, including the mapping speci-

fications that relate each application model to its corresponding subset of the integration model;

— the modelling paradigm and principles used to create the integration model – these also determine how the

integration model is extended to meet the requirements of the application model.
The outputs of the activity are as follows:

— an extended integration model (if the input integration model does not precisely satisfy the requirements of

the application models);

NOTE 2 Extensions to an integration model do not make any change to the objects and relationships in the input inte-

gration model. The model scope of the integration model is increased. The context of a model cannot be increased ex-

cept by removing constraints. This would be a change to the existing integration model, so the change would not be an

extension.

— a mapping specification that represents the relationships between constructs of the application models and

the corresponding subsets of the extended integration model;
— improvements to the application model (if appropriate).
8 © ISO 2003 – All rights reserved
---
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
