CWA 16926-15:2022
(Main)Extensions for Financial Services (XFS) interface specification Release 3.50 - Part 15: Cash-In Module Device Class Interface - Programmer's Reference
Extensions for Financial Services (XFS) interface specification Release 3.50 - Part 15: Cash-In Module Device Class Interface - Programmer's Reference
This specification describes the functionality of an XFS compliant Cash-In Module (CIM) Service Provider. It defines the service-specific commands that can be issued to the Service Provider using the WFSGetInfo, WFSAsyncGetInfo, WFSExecute and WFSAsyncExecute functions.
Persistent values are maintained through power failures, open sessions, close session and system resets.
This specification covers the acceptance of items. An “item” is defined as any media that can be accepted and includes coupons, documents, bills and coins. However, if coins and bills are both to be accepted separate Service Providers must be implemented for each.
All currency parameters in this specification are expressed as a quantity of minimum dispense units, as defined in the description of the WFS_INF_CIM_CURRENCY_EXP command.
There are two types of CIM: Self-Service CIM and Teller CIM. A Self-Service CIM operates in an automated environment, while a Teller CIM has an operator present. The functionality provided by the following commands is only applicable to a Teller CIM:
WFS_CMD_CIM_SET_TELLER_INFO
WFS_INF_CIM_SET_TELLER_INFO
It is possible for the CIM to be part of a compound device with the Cash Dispenser Module (CDM). This CIM\CDM combination is referred to throughout this specification as a “cash recycler”. For details of the CDM interface see [Ref. 3].
If the device is a cash recycler then, if cash unit exchanges are required on both interfaces, the exchanges cannot be performed concurrently. An exchange on one interface must be complete (the WFS_CMD_CIM_END_EXCHANGE must have completed) before an exchange can start on the other interface. The WFS_ERR_CIM_EXCHANGEACTIVE error code will be returned if the correct sequence is not adhered to.
The CIM interface can be used for all exchange operations on cash recycle devices, and this interface should be used for cash units of multiple currencies and/or denominations (including multiple note identifiers associated with the same denomination).
The event WFS_SRVE_CIM_COUNTS_CHANGED will be posted if an operation on the CDM interface affects the recycle cash unit counts which are available through the CIM interface.
Specifikacija vmesnika razširitev za finančne storitve (XFS), izdaja 3.50 - 15. del: Razred vmesnika naprave modula za unovčevanje - Referenca za programerje
Ta specifikacija opisuje funkcionalnost ponudnika storitve modula za unovčevanje (CIM), združljivega z razširitvami za finančne storitve (XFS). Določa ukaze, značilne za določeno storitev, ki jih je mogoče izdati ponudniku storitve s funkcijami WFSGetInfo, WFSAsyncGetInfo, WFSExecute in WFSAsyncExecute.
Stalne vrednosti se vzdržujejo z izpadi električne energije, odprtimi in zaprtimi sejami ter ponastavitvami sistema
Ta specifikacija zajema sprejem elementov. »Element« je opredeljen kot katero koli sredstvo, ki ga je mogoče sprejeti, ter vključuje kupone, dokumente, bankovce in kovance. V primeru sprejema tako kovancev kot bankovcev je treba implementirati ločene ponudnike storitev.
Vsi parametri valute v tej specifikaciji so izraženi kot količina najmanjših izdajnih enot, kot je opredeljeno v opisu ukaza WFS_INF_CIM_CURRENCY_EXP.
Obstajata dve vrsti modulov za unovčevanje: samopostrežni in blagajniški modul. Samopostrežni modul za unovčenje deluje v avtomatiziranem okolju, pri blagajniškem modulu pa je prisoten upravljavec. Funkcionalnost, ki jo zagotavljata spodnja ukaza, se uporablja samo za blagajniški modul:
WFS_CMD_CIM_SET_TELLER_INFO
WFS_INF_CIM_SET_TELLER_INFO
Modul za unovčevanje je lahko del sestavljene naprave skupaj z modulom za izdajanje gotovine (CDM). Kombinacija teh dveh modulov se v tej specifikaciji imenuje »modul za recikliranje gotovine«. Za podrobne informacije o vmesniku modula za izdajanje gotovine glej [Ref. 3].
Če je naprava modul za recikliranje gotovine in je potrebna izmenjava gotovinske enote v obeh vmesnikih, tega ni mogoče izvesti sočasno. Izmenjava v enem vmesniku mora biti dokončana (ukaz WFS_CMD_CIM_END_EXCHANGE se mora zaključiti), preden se lahko začne izmenjava v drugem vmesniku. Če pravilno zaporedje ni upoštevano, se prikaže koda napake WFS_ERR_CIM_EXCHANGEACTIVE.
Vmesnik modula za unovčevanje je mogoče uporabiti za vse operacije izmenjave v napravah za recikliranje gotovine in naj bi se uporabljal za gotovinske enote z več valutami in/ali oznakami (vključno z več napravami za prepoznavanje bankovcev, ki so povezane z isto oznako).
Če operacija, ki se izvaja v vmesniku modula za izdajanje gotovine, vpliva na štetje enote za recikliranje gotovine prek vmesnika modula za unovčevanje, bo objavljen dogodek WFS_SRVE_CIM_COUNTS_CHANGED.
