EN IEC 60793-1-49:2018

Optical fibres - Part 1-49: Measurement methods and test procedures - Differential mode delay

IEC 60793-49:2018 applies only to multimode, graded-index glass-core (category A1) fibres. The test method is commonly used in production and research facilities, but is not easily accomplished in the field. This document describes a method for characterizing the modal structure of a graded-index multimode fibre. This information is useful for assessing the bandwidth performance of a fibre especially when the fibre is intended to support a range of launch conditions, for example, those produced by standardized laser transmitters. This third edition cancels and replaces the second edition published in 2006. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: a) better alignment with original intent by filling some omissions and therefore improving measurement rigor; b) the measurement of fibres with smaller differential mode delay (and higher modal bandwidth) such as type A1a.3 fibres of IEC 60793-2-10 that are used in constructing OM4 performance category cables; new requirements on specifying detector amplitude and temporal response, specimen deployment conditions, four-quadrant scanning, and uniformity of radial locations for calculating bandwidth. Keywords: modal structure of a graded-index multimode fibre, bandwidth performance

Lichtwellenleiter - Teil 1-49: Messmethoden und Prüfverfahren - Gruppenlaufzeitdifferenz

Fibres optiques - Partie 1-49: Méthodes de mesure et procédures d'essai - Retard différentiel de mode

IEC 60793-1-49:2018 s'applique uniquement aux fibres multimodales à cœur en verre à gradient d'indice (catégorie A1). Cette méthode d'essai, qui est généralement utilisée dans les installations de production et de recherche, n'est pas facilement réalisée sur le terrain. Le présent document décrit une méthode de caractérisation de la structure modale d'une fibre multimodale à gradient d'indice. Cette information est utile pour évaluer les performances de largeur de bande d'une fibre, en particulier lorsque la fibre est destinée à supporter une plage de conditions d'injection, par exemple celles produites par les émetteurs lasers normalisés. Cette troisième édition annule et remplace la deuxième édition parue en 2006 dont elle constitue une révision technique. La présente édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente: a) un meilleur alignement sur l'objectif initial en remédiant à certaines omissions pour améliorer la rigueur des mesures; b) la mesure des fibres avec un plus petit retard différentiel de mode (et une plus grande largeur de bande modale) telles que des fibres de type A1a.3 de l'IEC 60793-2-10 utilisées pour construire des câbles de catégorie de performance OM4, de nouvelles exigences sur la spécification de l'amplitude du détecteur et de la réponse temporelle, les conditions de déploiement des spécimens, le balayage des quatre quadrants et l'uniformité des emplacements radiaux pour calculer la largeur de bande. Mots clés: structure modale d'une fibre multimodale à gradient d'indice, performances de largeur de bande

Optična vlakna - 1-49. del: Merilne metode in postopki preskušanja - Diferenčna zakasnitev rodov (IEC 60793-1-49:2018)

Ta del standarda IEC 60793 se uporablja samo za večrodna gradientna steklena vlakna (kategorija A1). Preskusna metoda se običajno uporablja v proizvodnji in raziskovalnih ustanovah, na terenu pa ni lahko izvedljiva.
Ta dokument opisuje metodo za opredelitev rodovne strukture gradientnih večrodnih vlaken. Te informacije so uporabne pri ocenjevanju prenosne zmogljivosti vlaken, še posebej, ko so vlakna namenjena podpori različnim zagonskim pogojem, na primer tistim, ki jih proizvedejo standardizirani laserski oddajniki.
S to metodo izhod enorodnega vlakna na sondi pri preskusni valovni dolžini presega preskušano večrodno vlakno. Točka sonde se skenira na končnem delu preskušanega optičnega vlakna v določenih radialnih položajih, na teh položajih pa se pridobi niz odzivnih impulzov.
Iz zbranega nabora podatkov je mogoče izpeljati tri določljive parametre.
• Prvi parameter, diferenčna zakasnitev rodov (DMD), je razlika v času zakasnitve optičnega impulza med najhitrejšimi in najpočasnejšimi skupinami rodov pri preskušanem vlaknu. Specifikacije diferenčne zakasnitve rodov omejujejo zakasnitev rodov v določenem območju radialno izravnanih položajev vlaken v sondi. Specifikacije diferenčne zakasnitve rodov se določijo z modeliranjem in eksperimentiranjem, da ustrezajo minimalni učinkoviti pasovni širini rodov (EMB) za pričakovan obseg oddajnikov, uporabljenih v povezavi na določeni ravni zmogljivosti.
• Drugi določljiv parameter je izpeljan z združevanjem impulzov s pomočjo niza določenih radialnih bremen, da se določi približek niza impulzov pri tipičnih oddajnikih. S Fourierovimi transformacijami se izračuna učinkovita pasovna širina rodov (EMBc) za vsak niz bremena. Najnižja vrednost teh vrednosti EMBc (minEMBc) je določljiv parameter.
• Tretji določljiv parameter, izračunana pasovna širina prepolnega zagona (OMBc), se določi na način, podoben vrednosti EMBc, vendar z uporabo samo enega niza bremena pri nizu impulzov; ta niz bremena ustreza pogoju prenapolnjenosti, kjer so vse skupine rodov enako vzbujene.
Namen preskusa je kvantifikacija učinkov interakcij rodovne strukture vlaken in izvornih rodovnih značilnosti, razen spektralne interakcije vira z barvno razpršenostjo vlaken. Dodajanje učinkov barvne razpršenosti vlaken in spektralnih značilnosti vira bo zmanjšalo skupno pasovno širino prenosa, vendar je to v večini modelov prenosa ločen izračun. Pri tem preskusu se prispevek barvne razpršenosti nadzoruje z omejevanjem spektralne širine uporabnih preskusnih virov. Praktični preskusni viri bodo imeli neničelno spektralno širino in bodo tako nekoliko izkrivili vrednosti DMD, minEMBc in OMBc. Ti učinki barvne razpršenosti so obravnavani v dodatku A.
OPOMBA: Primerjava med standardom IEC 60793-1-49 in priporočili ITU: Priporočilo ITU-T G.650.1 [2] ne vsebuje nobenih informacij o tem, kako izmeriti DMD gradientnega večrodnega vlakna.
