ETSI EN 301 908-11 V5.2.1 (2011-07)
IMT cellular networks; Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive; Part 11: CDMA Direct Spread (UTRA FDD) (Repeaters)
IMT cellular networks; Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive; Part 11: CDMA Direct Spread (UTRA FDD) (Repeaters)
REN/MSG-TFES-006-11
Celična omrežja IMT - Harmonizirani EN, ki zajema bistvene zahteve člena 3.2 direktive R&TTE - 11. del: CDMA z neposrednim razprševanjem (“Direct Spread”) (UTRA FDD) (ponavljalniki (repetitorji))
Ta dokument velja za naslednjo vrsto radijske opreme:
• ponavljalnike za IMT-2000 neposredno razprševanje (UTRA FDD).
Ta vrsta radijske opreme je zmožna delovati v vseh ali katerem koli delu frekvenčnega pasu, kot so navedeni v preglednici 1-1.
Ta dokument zajema zahteve za ponavljalnik UTRA FDD za izdaje 4, 5, 6, 7, 8 in 9. Poleg tega ta dokument zajema zahteve za ponavljalnik UTRA v pasovih delovanja, določenih v TS 102 735 [i.5].
Ta dokument zajema določbe člena 3.2. Direktive 1999/5/ES [i.6] (direktive R&TTE), ki navaja, da » … radijska oprema je narejena tako, da učinkovito izrablja spekter, razporejen za prizemne/vesoljske radiokomunikacije in orbitalne vire, tako da ne pride do škodljivega motenja«.
Poleg tega dokumenta se preostali EN, ki določajo tehnične zahteve v skladu z bistvenimi zahtevami v drugih delih člena 3 direktive R&TTE [i.6], lahko uporabljajo za opremo v okviru uporabe tega dokumenta.
General Information
Standards Content (Sample)
Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
Harmonized European Standard (Telecommunications series)
Base Stations (BS), Repeaters and User Equipment (UE)
for IMT-2000 Third-Generation cellular networks;
Part 11: Harmonized EN for IMT-2000,
CDMA Direct Spread (UTRA FDD and E-UTRA FDD)
(Repeaters) covering the essential requirements
of article 3.2 of the R&TTE Directive
2 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
Reference
REN/MSG-TFES-006-11
Keywords
3G, 3GPP, cellular, digital, IMT-2000, mobile,
radio, regulation, repeater, testing, UMTS, UTRA,
WCDMA
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2010.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
Contents
Intellectual Property Rights . 5
Foreword . 5
Introduction . 6
1 Scope . 7
2 References . 7
2.1 Normative references . 7
2.2 Informative references . 8
3 Definitions, symbols and abbreviations . 9
3.1 Definitions . 9
3.2 Symbols . 9
3.3 Abbreviations . 9
4 Technical requirements specifications . 10
4.1 Environmental profile . 10
4.2 Conformance requirements . 10
4.2.1 Introduction. 10
4.2.2 Operating band unwanted emissions . 11
4.2.2.1 Definition . 11
4.2.2.2 Limit . 11
4.2.2.2.1 General operating band unwanted emission requirements . 11
4.2.2.2.2 Operating band emission mask requirements . 12
4.2.2.2.3 Protection of the BS receiver in the operating band . 13
4.2.2.2.4 Co-existence with services in adjacent frequency bands . 13
4.2.2.2.5 Protection of DTT. 14
4.2.2.3 Conformance . 14
4.2.3 Spurious emissions . 14
4.2.3.1 Definition . 14
4.2.3.2 Limit . 15
4.2.3.2.1 Spurious emissions . 15
4.2.3.2.2 Co-existence with other systems . 15
4.2.3.3 Conformance . 16
4.2.4 Maximum output power . 16
4.2.4.1 Definition . 16
4.2.4.2 Limit . 17
4.2.4.3 Conformance . 17
4.2.5 Input intermodulation . 17
4.2.5.1 Definition . 17
4.2.5.2 Limit . 17
4.2.5.2.1 General input intermodulation requirement . 17
4.2.5.2.2 Co-existence with other systems . 18
4.2.5.3 Conformance . 19
4.2.6 Out of band gain . 19
4.2.6.1 Definition . 19
4.2.6.2 Limits . 19
4.2.6.3 Conformance . 19
4.2.7 Adjacent Channel Rejection Ratio . 20
4.2.7.1 Definition . 20
4.2.7.2 Limit . 20
4.2.7.3 Conformance . 20
4.2.8 Output intermodulation . 20
4.2.8.1 Definition . 20
4.2.8.2 Limit . 20
4.2.8.3 Conformance . 20
5 Testing for compliance with technical requirements . 21
ETSI
4 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
5.1 Environmental conditions for testing . 21
5.2 Interpretation of the measurement results . 21
5.3 Essential radio test suites . 23
5.3.1 Operating band unwanted emission . 23
5.3.1.1 Initial conditions . 23
5.3.1.2 Procedures . 23
5.3.2 Spurious emissions . 24
5.3.2.1 Initial conditions . 24
5.3.2.2 Procedure . 24
5.3.3 Maximum output power . 24
5.3.3.1 Initial conditions . 24
5.3.3.2 Procedure . 25
5.3.4 Input intermodulation . 25
5.3.4.1 Initial conditions . 25
5.3.4.2 Procedures . 25
5.3.5 Out of band gain . 25
5.3.5.1 Initial conditions . 25
5.3.5.2 Procedure . 26
5.3.6 Adjacent Channel Rejection Ratio . 26
5.3.6.1 Initial conditions . 26
5.3.6.2 Procedures . 26
5.3.7 Output intermodulation . 27
5.3.7.1 Initial conditions . 27
5.3.7.2 Procedures . 27
Annex A (normative): HS Requirements and conformance Test specifications Table
(HS-RTT) . 28
Annex B (normative): Repeater configurations . 30
B.1 Power supply . 30
B.2 Power supply options . 30
B.3 Combining of Repeaters . 30
Annex C (informative): Environmental profile specification . 31
Annex D (informative): The EN title in the official languages . 32
Annex E (informative): Bibliography . 33
History . 34
ETSI
5 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (Telecommunications series) has been produced by ETSI Technical Committee
Mobile Standards Group (MSG), and is now submitted for the Public Enquiry phase of the ETSI standards Two-step
Approval Procedure.
The present document has been produced by ETSI in response to a mandate M/284 from the European Commission
issued under Council Directive 98/34/EC [i.1] (as amended) laying down a procedure for the provision of information
in the field of technical standards and regulations.
The present document is intended to become a Harmonized Standard, the reference of which will be published in the
Official Journal of the European Union referencing the Directive 1999/5/EC [i.6] of the European Parliament and of the
Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual recognition
of their conformity ("the R&TTE Directive").
The requirements relevant to Directive 1999/5/EC [i.6] are summarised in annex A.
The present document is part 11 of a multi-part deliverable covering the Base Stations (BS), Repeaters and User
Equipment (UE) for IMT-2000 Third-Generation cellular networks, as identified below:
Part 1: "Harmonized EN for IMT-2000, introduction and common requirements, covering the essential
requirements of article 3.2 of the R&TTE Directive";
Part 2: "Harmonized EN for IMT-2000, CDMA Direct Spread (UTRA FDD and E-UTRA FDD) (UE) covering
the essential requirements of article 3.2 of the R&TTE Directive";
Part 3: "Harmonized EN for IMT-2000, CDMA Direct Spread (UTRA FDD and E-UTRA FDD) (BS) covering
the essential requirements of article 3.2 of the R&TTE Directive";
Part 4: "Harmonized EN for IMT-2000, CDMA Multi-Carrier (cdma2000) and Evolved CDMA Multi-Carrier
Ultra Mobile Broadband (UMB) (UE) covering the essential requirements of article 3.2 of the R&TTE
Directive";
Part 5: "Harmonized EN for IMT-2000, CDMA Multi-Carrier (cdma2000) and Evolved CDMA Multi-Carrier
Ultra Mobile Broadband (UMB) (BS) covering the essential requirements of article 3.2 of the R&TTE
Directive";
Part 6: "Harmonized EN for IMT-2000, CDMA TDD (UTRA TDD and E-UTRA TDD) (UE) covering the
essential requirements of article 3.2 of the R&TTE Directive";
Part 7: "Harmonized EN for IMT-2000, CDMA TDD (UTRA TDD and E-UTRA TDD) (BS) covering the
essential requirements of article 3.2 of the R&TTE Directive";
Part 8: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (UE) covering essential requirements
of article 3.2 of the R&TTE Directive";
Part 9: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (BS) covering essential requirements
of article 3.2 of the R&TTE Directive";
ETSI
6 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
Part 10: "Harmonized EN for IMT-2000, FDMA/TDMA (DECT) covering essential requirements of article 3.2 of
the R&TTE Directive";
Part 11: "Harmonized EN for IMT-2000, CDMA Direct Spread (UTRA FDD and E-UTRA FDD)
(Repeaters) covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 12: "Harmonized EN for IMT-2000, CDMA Multi-Carrier (cdma2000) (Repeaters) covering the essential
requirements of article 3.2 of the R&TTE Directive";
Part 13: "Harmonized EN for IMT-2000, Evolved Universal Terrestrial Radio Access (E-UTRA) (UE) covering
the essential requirements of article 3.2 of the R&TTE Directive";
Part 14: "Harmonized EN for IMT-2000, Evolved Universal Terrestrial Radio Access (E-UTRA) (BS) covering
the essential requirements of article 3.2 of the R&TTE Directive";
Part 15: "Harmonized EN for IMT-2000, Evolved Universal Terrestrial Radio Access (E-UTRA) (FDD
Repeaters) covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 16: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (UE)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 17: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (BS)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 18: "Harmonized EN for Multi-Standard Radio (UTRA, E-UTRA, GSM/EDGE) Base Stations (BS) covering
the essential requirements of article 3.2 of the R&TTE Directive";
Part 19: "Harmonized EN for IMT-2000 OFDMA TDD WMAN (Mobile WiMAX) TDD User Equipment (UE)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 20: "Harmonized EN for IMT-2000 OFDMA TDD WMAN (Mobile WiMAX) TDD Base Station (BS)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 21: "Harmonized EN for IMT-2000 OFDMA TDD WMAN (Mobile WiMAX) FDD User Equipment (UE)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 22: "Harmonized EN for IMT-2000 OFDMA TDD WMAN (Mobile WiMAX) FDD Base Stations (BS)
covering the essential requirements of article 3.2 of the R&TTE Directive".
Proposed national transposition dates
Date of latest announcement of this EN (doa): 3 months after ETSI publication
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 6 months after doa
Date of withdrawal of any conflicting National Standard (dow): 18 months after doa
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.6]. The
modular structure is shown in EG 201 399 [i.2].
ETSI
7 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
1 Scope
The present document applies to the following radio equipment type:
• Repeaters for IMT-2000 CDMA Direct Spread (UTRA FDD and E-UTRA FDD).
This radio equipment type is capable of operating in all or any part of the frequency bands given below.
Table 1-1: UTRA Repeater operating bands
UTRA FDD Direction of transmission UTRA Repeater operating bands
Band
I Downlink 2 110 MHz to 2 170 MHz
Uplink 1 920 MHz to 1 980 MHz
III Downlink 1 805 MHz to 1 880 MHz
Uplink 1 710 MHz to 1 785 MHz
VII Downlink 2 620 MHz to 2 690 MHz
Uplink 2 500 MHz to 2 570 MHz
VIII Downlink 925 MHz to 960 MHz
Uplink 880 MHz to 915 MHz
XV Downlink 2 600 MHz to 2 620 MHz
Uplink 1 900 MHz to 1 920 MHz
XVI Downlink 2 585 MHz to 2 600 MHz
Uplink 2 010 MHz to 2 025 MHz
XX Downlink 791 MHz to 821 MHz
Uplink 832 MHz to 862 MHz
The present document covers requirements for UTRA FDD Repeater for Release 4, 5, 6, 7, 8 and 9 and E-UTRA FDD
Repeater for Release 8 and 9. In addition, the present document covers requirements for UTRA Repeater in the
operating bands specified in TS 102 735 [i.5].
The present document is intended to cover the provisions of Directive 1999/5/EC [i.6] (R&TTE Directive), article 3.2,
which states that "… radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [i.6] may apply to equipment within the scope of the present
document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
[1] Void.
ETSI
8 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
[2] Void.
[3] ETSI TS 125 143 (V9.1.0): "Universal Mobile Telecommunications System (UMTS); UTRA
repeater conformance testing (3GPP TS 25.143 version 9.1.0 Release 9)".
[4] ITU-R Recommendation SM.329-10 (2003): "Unwanted emissions in the spurious domain".
[5] ETSI TS 125 141 (V9.5.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) conformance testing (FDD) (3GPP TS 25.141 version 9.5.0 Release 9)".
[6] IEC 60068-2-1 (2007): "Environmental testing - Part 2-1: Tests - Test A: Cold".
[7] IEC 60068-2-2 (2007): "Environmental testing - Part 2-2: Tests - Test B: Dry heat".
[8] ETSI EN 301 908-1 (V5.1.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Base Stations (BS), Repeaters and User Equipment (UE) for IMT-2000 Third-Generation cellular
networks; Part 1: Harmonized EN for IMT-2000, introduction and common requirements,
covering the essential requirements of article 3.2 of the R&TTE Directive".
[9] ETSI EN 301 908-15 (V5.1.1): "Base Stations (BS), Repeaters and User Equipment (UE) for
IMT-2000 Third-Generation cellular networks; Part 15: Harmonized EN for IMT-2000, Evolved
Universal Terrestrial Radio Access (E-UTRA) (FDD Repeaters) covering the essential
requirements of article 3.2 of the R&TTE Directive".
[10] ETSI TS 125 104 (V9.5.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) radio transmission and reception (FDD) (3GPP TS 25.104 version 9.5.0 Release 9)".
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
[i.2] ETSI EG 201 399 (V2.2.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
A guide to the production of Harmonized Standards for application under the R&TTE Directive".
[i.3] ETSI TR 102 215 (V1.3.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Recommended approach, and possible limits for measurement uncertainty for the measurement of
radiated electromagnetic fields above 1 GHz".
[i.4] ETSI TR 100 028 (all parts) (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters
(ERM); Uncertainties in the measurement of mobile radio equipment characteristics".
[i.5] ETSI TS 102 735 (V7.1.0): "Universal Mobile Telecommunications System (UMTS);
Band-specific requirements for UMTS Frequency Division Duplex (FDD) operation in the bands
1 900 MHz to 1 920 MHz paired with 2 600 MHz to 2 620 MHz and 2 010 MHz to 2 025 MHz
paired with 2 585 MHz to 2 600 MHz".
[i.6] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity (R&TTE Directive).
ETSI
9 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the following terms and definitions apply:
donor coupling loss: coupling loss between the Repeater and the donor Base Station
downlink: signal path where Base Station transmits and mobile receives
downlink operating band: part of the operating band designated for downlink (BS transmit)
maximum output power (Pmax): mean power level per carrier measured at the antenna connector of the Repeater in
specified reference condition
maximum rated output power: maximum rated output power of the repeater is the mean power level per carrier that
the manufacturer has declared to be available at the antenna connector
operating band: frequency range that is defined with a specific set of technical requirements, in which UTRA FDD
operates
NOTE: The operating band(s) for an UTRA FDD repeater is declared by the manufacturer according to the
designations in table 1-1. Operating bands for UTRA are designated with Roman numerals, while the
corresponding operating bands for E-UTRA are designated with Arabic numerals.
pass band: frequency range that the Repeater operates in with operational configuration
NOTE 1: This frequency range can correspond to one or several consecutive nominal 5 MHz channels. If they are
not consecutive each subset of channels has to be considered as an individual pass band.
NOTE 2: The Repeater can have one or several pass bands.
repeater: device that receives, amplifies and transmits the radiated or conducted RF carrier both in the downlink
direction (from the Base Station to the mobile area) and in the uplink direction (from the mobile to the Base Station)
uplink: signal path where mobile transmits and Base Station receives
uplink operating band: part of the operating band designated for downlink (BS transmit)
3.2 Symbols
For the purposes of the present document, the following symbols apply:
Δf The separation between the centre frequency of first or last 5 MHz channel used in the pass band
and the nominal -3 dB point of the measuring filter closest to the carrier frequency
Δf The largest value of Δf used for defining the requirement
max
F Filter centre frequency
filter
P Declared emission level for channel N
EM,N
Pmax Maximum output power
Pout Output power
3.3 Abbreviations
For the purposes of the present document, the following abbreviations apply:
ACLR Adjacent Channel Leakage power Ratio
ACRR Adjacent Channel Rejection Ratio
BS Base Station
BTS Base Transceiver Station
ETSI
10 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
CW Continuous Wave
NOTE: Unmodulated signal.
DCS Digital Cellular System
DTT Digital Terrestrial Television
DUT Device Under Test
E-UTRA Evolved Universal Terrestrial Radio Access
EUT Equipment Under Test
FDD Frequency Division Duplexing
GSM Global System for Mobile Communications
IMT-2000 International Mobile Telecommunications 2000
MS Mobile Station
PCCPCH Primary Common Control Physical CHannel
R&TTE Radio and Telecommunications Terminal Equipment
RF Radio Frequency
RMS Root Mean Square
RRC Root Raised Cosine
RSS Root Sum Square
SCCPCH Secondary Common Control Physical CHannel
TDD Time Division Duplexing
UARFCN UTRA Absolute Radio Frequency Channel Number
UE User Equipment
UMTS Universal Mobile Telecommunications System
UTRA Universal Terrestrial Radio Access
WCDMA Wideband Code Division Multiple Access
4 Technical requirements specifications
4.1 Environmental profile
The technical requirements of the present document apply under the environmental profile for operation of the
equipment, which shall be declared by the supplier. The equipment shall comply with all the technical requirements of
the present document at all times when operating within the boundary limits of the declared operational environmental
profile.
For guidance on how a supplier can declare the environmental profile see annex C.
4.2 Conformance requirements
The requirements in the present document are based on the assumption that the operating band (e.g. band I, III, VII and
VIII) is shared between systems of the IMT-2000 family (for band III and VIII also GSM) or systems having
compatible characteristics. Requirements for E-UTRA FDD Repeater are given in EN 301 908-15 [9].
4.2.1 Introduction
To meet the essential requirement under article 3.2 of Directive 1999/5/EC [i.6] (R&TTE Directive) for IMT-2000
Repeater five essential parameters in addition to those in EN 301 908-1 [8] have been identified. Table 4.2.1-1 provides
a cross reference between these five essential parameters and the corresponding seven technical requirements for
equipment within the scope of the present document.
ETSI
11 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
Table 4.2.1-1: Cross references
Essential parameter Corresponding technical requirements
Spectrum emissions mask 4.2.2 Operating band unwanted emissions
Conducted spurious emissions from the antenna connector 4.2.3 Spurious emissions
Accuracy of maximum output power 4.2.4 Maximum output power
Receiver immunity 4.2.5 Input intermodulation
4.2.6 Out of band gain
4.2.7 Adjacent Channel Rejection Ratio
Intermodulation attenuation of the output 4.2.8 Output intermodulation
The supplier shall declare operating band(s) for the Repeater. The technical requirements apply for the declared
operating band(s) as outlined for each requirement. For a Repeater supporting more than one operating band,
conformance testing for each technical requirement in clause 5 shall be performed. For each operating band, Repeater
supporting E-UTRA FDD shall fulfil requirements in EN 301 908-15 [9].
The technical requirements also apply to Repeater configurations described in annex B.
For a Repeater declared to support Band XX, the manufacturer shall additionally declare the following quantities
associated with the applicable test conditions of table 4.2.2.2-5 and information in annex G of TS 125 104 [10]:
• P Declared emission level for channel N
EM,N
• P Maximum output Power in 10 MHz
10MHz
4.2.2 Operating band unwanted emissions
4.2.2.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The out of band emissions requirement for repeater is specified both in terms operating band unwanted emissions and
protection of the BS receiver in the operating band. The operating band unwanted emissions define all unwanted
emissions in the repeater operating band plus the frequency ranges 10 MHz above and 10 MHz below that band.
Unwanted emissions outside of this frequency range are limited by a spurious emissions requirement.
Operating band unwanted emissions comprise an emission mask applied outside the repeater passband and a general
requirement applied outside the mask but inside the frequency range of the operating band unwanted emissions.
4.2.2.2 Limit
4.2.2.2.1 General operating band unwanted emission requirements
The general operating band unwanted emissions limits are given in table 4.2.2.2.1-1.
Table 4.2.2.2.1-1: General operating band unwanted emissions requirements
Frequency range of Maximum level Measurement Notes
operating band bandwidth
-16 dBm 100 kHz 1, 2
≤ 1 GHz
-15 dBm 1 MHz 2, 3
≥ 1 GHz
NOTE 1: Bandwidth as in ITU-R Recommendation SM.329-10 [4], section 4.1.
NOTE 2: Limit based on ITU-R Recommendation SM.329-10 [4], section 4.3 and annex 7.
NOTE 3: Bandwidth as in ITU-R Recommendation SM.329-10 [4], section 4.1. Upper
frequency as in ITU-R Recommendation SM.329-10 [4], section 2.5, table 1.
ETSI
12 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
4.2.2.2.2 Operating band emission mask requirements
The requirement shall be met by a Repeater's RF-signal output at maximum gain with WCDMA signals in the pass
band of the Repeater, at levels that produce the maximum rated output power per channel, configured in accordance
with the manufacturer's specification. Emissions shall not exceed the maximum level specified in tables 4.2.2.2.2-1,
4.2.2.2.2-2, 4.2.2.2.2-3 and 4.2.2.2.2-4 for the appropriate Repeater maximum output power, in the frequency range
from Δf = 2,5 MHz to Δf from the 5 MHz channel, where:
max
• Δf is the separation between the centre frequency of first or last 5 MHz channel used in the pass band and the
nominal -3 dB point of the measuring filter closest to the carrier frequency;
• f_offset is the separation between the centre frequency of first or last 5 MHz channel in the pass band and the
centre of the measuring filter;
• f_offset is 12,5 MHz;
max
• Δf is equal to f_offset minus half of the bandwidth of the measurement filter.
max max
To select the table of the maximum level for the spectrum emission mask test, use the maximum output power as
defined in clause 3.1. If one channel is used for the spectrum emission mask test use this power for the selection. If two
channels are used for the spectrum emission mask test use the power of one of these.
Table 4.2.2.2.2-1: Emission mask values, maximum output power P ≥ 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
-3 dB point, Δf frequency, f_offset
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz -12,5 dBm 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
−12,5 dBm−15 × −2,715 dB
⎜ ⎟
MHz
⎝ ⎠
-24,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
-11,5 dBm 1 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz
-11,5 dBm 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
Table 4.2.2.2.2-2: Emission mask values, maximum output power 39 ≤ P < 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
-12,5 dBm 30 kHz
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz 30 kHz
f_offset
⎛ ⎞
−12,5 dBm −15 ×⎜ − 2,715⎟ dB
MHz
⎝ ⎠
-24,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz -11,5 dBm 1 MHz
P - 54,5 dB 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
ETSI
13 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
Table 4.2.2.2.2-3: Emission mask values, maximum output power 31 ≤ P < 39 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz P - 51,5 dB 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
P −51,5 dB −15 × − 2,715 dB
⎜ ⎟
MHz
⎝ ⎠
P - 63,5 dB 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
P - 50,5 dB 1 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset P - 54,5 dB 1 MHz
max max
Table 4.2.2.2.2-4: Emission mask values, maximum output power P < 31 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz -20,5 dBm 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
− 20,5 dBm−15 × −2,715 dB
⎜ ⎟
MHz
⎝ ⎠
3,515 MHz ≤ f_offset < 4,0 MHz -32,5 dBm 30 kHz
-19,5 dBm 1 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset -23,5 dBm 1 MHz
max max
4.2.2.2.3 Protection of the BS receiver in the operating band
This requirement shall be applied for the protection of UTRA FDD BS receiver in geographic areas in which
UTRA-FDD Repeater and UTRA-FDD BS are deployed.
The requirement applies at frequencies that are more than 10 MHz below or more than 10 MHz above the repeater pass
band.
This requirement applies to the uplink of the repeater, at maximum gain.
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.3-1.
Table 4.2.2.2.3-1: Uplink operating band unwanted emissions limits for
protection of the BS receiver
Maximum Measurement Note
Level Bandwidth
-53 dBm 100 kHz
4.2.2.2.4 Co-existence with services in adjacent frequency bands
This requirement shall be applied for the protection in bands adjacent to band I.
The requirement applies only to the down-link direction of the repeater.
ETSI
14 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.4-1:
Table 4.2.2.2.4-1: UTRA Repeater down-link operating band unwanted emission limits
for protection of adjacent band services
Operating Band Band Maximum Level Measurement
Bandwidth
I 2 100 MHz to 2 105 MHz -30 + 3,4 (f – 2 100 MHz) dBm 1 MHz
2 175 Mhz to 2 180 MHz -30 + 3,4 (2 180 MHz - f) dBm 1 MHz
4.2.2.2.5 Protection of DTT
The following requirement shall apply for protection of DTT. For UTRA Repeater operating in Band XX, the level of
emissions in the band 470 MHz to 790 MHz, measured in an 8 MHz filter bandwidth on centre frequencies F
filter
according to table 4.2.2.2.5-1, shall not exceed the maximum emission level P declared by the manufacturer. This
EM,N
requirement applies in the frequency range 470 MHz to 790 MHz even though part of the range falls in the spurious
domain.
Table 4.2.2.2.5-1: Declared emissions levels for protection of DTT
Filter centre frequency, Measurement bandwidth Declared emission level
F [dBm]
filter
F = 8*N + 306 (MHz); 8 MHz P
filter EM,N
21 ≤ N ≤ 60
NOTE: Compliance with the declared emission levels above provides the characteristics of the Repeater needed
to verify compliance with the corresponding CEPT/ECC technical condition using the method outlined in
annex G of TS 125 104 [10].
4.2.2.3 Conformance
Conformance tests described in clause 5.3.1 shall be carried out.
4.2.3 Spurious emissions
4.2.3.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The spurious emission limits apply from 9 kHz to 12,75 GHz, excluding the frequency range from 10 MHz below the
lowest frequency of the repeaters operating band up to 10 MHz above the highest frequency of the repeaters operating
band.
The requirements shall apply whatever the type of repeater considered (one or several pass bands). It applies for all
configurations foreseen by the manufacturer's specification. The measurements shall apply to both paths uplink and
downlink of the Repeater.
Unless otherwise stated, all requirements are measured as mean power (RMS).
ETSI
15 Draft ETSI EN 301 908-11 V5.1.1 (2010-10)
4.2.3.2 Limit
The requirements apply to the uplink and downlink of the repeater, at maximum gain, and with the following input
signals:
• without UTRA input signal;
•
...
Harmonized European Standard
IMT cellular networks;
Harmonized EN covering the essential requirements
of article 3.2 of the R&TTE Directive;
Part 11: CDMA Direct Spread (UTRA FDD) (Repeaters)
2 ETSI EN 301 908-11 V5.2.1 (2011-07)
Reference
REN/MSG-TFES-006-11
Keywords
3G, 3GPP, cellular, digital, IMT, IMT-2000,
mobile, radio, regulation, repeater, testing,
UMTS, UTRA, WCDMA
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2011.
All rights reserved.
TM TM TM
DECT , PLUGTESTS , UMTS and the ETSI logo are Trade Marks of ETSI registered for the benefit of its Members.
TM
3GPP and LTE™ are Trade Marks of ETSI registered for the benefit of its Members and
of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 ETSI EN 301 908-11 V5.2.1 (2011-07)
Contents
Intellectual Property Rights . 5
Foreword . 5
Introduction . 6
1 Scope . 7
2 References . 7
2.1 Normative references . 7
2.2 Informative references . 8
3 Definitions, symbols and abbreviations . 8
3.1 Definitions . 8
3.2 Symbols . 9
3.3 Abbreviations . 9
4 Technical requirements specifications . 10
4.1 Environmental profile . 10
4.2 Conformance requirements . 10
4.2.1 Introduction. 10
4.2.2 Operating band unwanted emissions . 11
4.2.2.1 Definition . 11
4.2.2.2 Limit . 11
4.2.2.2.1 General operating band unwanted emission requirements . 11
4.2.2.2.2 Operating band emission mask requirements . 11
4.2.2.2.3 Protection of the BS receiver in the operating band . 13
4.2.2.2.4 Co-existence with services in adjacent frequency bands . 13
4.2.2.2.5 Protection of DTT. 13
4.2.2.3 Conformance . 14
4.2.3 Spurious emissions . 14
4.2.3.1 Definition . 14
4.2.3.2 Limit . 14
4.2.3.2.1 Spurious emissions . 15
4.2.3.2.2 Co-existence with other systems . 15
4.2.3.3 Conformance . 16
4.2.4 Maximum output power . 16
4.2.4.1 Definition . 16
4.2.4.2 Limit . 16
4.2.4.3 Conformance . 17
4.2.5 Input intermodulation . 17
4.2.5.1 Definition . 17
4.2.5.2 Limit . 17
4.2.5.2.1 General input intermodulation requirement . 17
4.2.5.2.2 Co-existence with other systems . 18
4.2.5.3 Conformance . 19
4.2.6 Out of band gain . 19
4.2.6.1 Definition . 19
4.2.6.2 Limits . 19
4.2.6.3 Conformance . 19
4.2.7 Adjacent Channel Rejection Ratio . 19
4.2.7.1 Definition . 19
4.2.7.2 Limit . 20
4.2.7.3 Conformance . 20
4.2.8 Output intermodulation . 20
4.2.8.1 Definition . 20
4.2.8.2 Limit . 20
4.2.8.3 Conformance . 20
5 Testing for compliance with technical requirements . 20
ETSI
4 ETSI EN 301 908-11 V5.2.1 (2011-07)
5.1 Environmental conditions for testing . 20
5.2 Interpretation of the measurement results . 21
5.3 Essential radio test suites . 22
5.3.1 Operating band unwanted emission . 22
5.3.1.1 Initial conditions . 22
5.3.1.2 Procedures . 23
5.3.2 Spurious emissions . 23
5.3.2.1 Initial conditions . 23
5.3.2.2 Procedure . 23
5.3.3 Maximum output power . 24
5.3.3.1 Initial conditions . 24
5.3.3.2 Procedure . 24
5.3.4 Input intermodulation . 24
5.3.4.1 Initial conditions . 24
5.3.4.2 Procedures . 25
5.3.5 Out of band gain . 25
5.3.5.1 Initial conditions . 25
5.3.5.2 Procedure . 25
5.3.6 Adjacent Channel Rejection Ratio . 25
5.3.6.1 Initial conditions . 25
5.3.6.2 Procedures . 26
5.3.7 Output intermodulation . 26
5.3.7.1 Initial conditions . 26
5.3.7.2 Procedures . 26
Annex A (normative): HS Requirements and conformance Test specifications Table
(HS-RTT) . 28
Annex B (normative): Repeater configurations . 30
B.1 Power supply . 30
B.2 Power supply options . 30
B.3 Combining of Repeaters . 30
Annex C (informative): Environmental profile specification . 31
Annex D (informative): The EN title in the official languages . 32
Annex E (informative): Bibliography . 33
History . 34
ETSI
5 ETSI EN 301 908-11 V5.2.1 (2011-07)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://ipr.etsi.org).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (EN) has been produced by ETSI Technical Committee Mobile Standards Group
(MSG).
The present document has been produced by ETSI in response to mandate M/284 from the European Commission
issued under Council Directive 98/34/EC [i.1] (as amended) laying down a procedure for the provision of information
in the field of technical standards and regulations.
The title and reference to the present document are intended to included in the publication in the Official Journal of the
European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [i.6].
See article 5.1 of Directive 1999/5/EC [i.6] for information on presumption of conformity and Harmonised Standards or
parts thereof the references of which have been published in the Official Journal of the European Union.
The requirements relevant to Directive 1999/5/EC [i.6] are summarised in annex A.
The present document is part 11 of a multi-part deliverable covering the essential requirements under article 3.2 of
Directive 1999/5/EC [i.6] (R&TTE Directive) for Base Stations (BS), Repeaters and User Equipment (UE) for IMT
cellular networks, as identified below:
Part 1: "Introduction and common requirements";
Part 2: "CDMA Direct Spread (UTRA FDD) User Equipment (UE)";
Part 3: "CDMA Direct Spread (UTRA FDD) Base Stations (BS)";
Part 4: "CDMA Multi-Carrier (cdma2000) User Equipment (UE)";
Part 5: "CDMA Multi-Carrier (cdma2000) Base Stations (BS)";
Part 6: "CDMA TDD (UTRA TDD) User Equipment (UE)";
Part 7: "CDMA TDD (UTRA TDD) Base Stations (BS)";
Part 8: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (UE) covering essential requirements
of article 3.2 of the R&TTE Directive";
Part 9: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (BS) covering essential requirements
of article 3.2 of the R&TTE Directive";
Part 10: "Harmonized EN for IMT-2000, FDMA/TDMA (DECT) covering essential requirements of article 3.2 of
the R&TTE Directive";
Part 11: "CDMA Direct Spread (UTRA FDD) (Repeaters)";
Part 12: "Harmonized EN for IMT-2000, CDMA Multi-Carrier (cdma2000) (Repeaters) covering the essential
requirements of article 3.2 of the R&TTE Directive";
Part 13: "Evolved Universal Terrestrial Radio Access (E-UTRA) User Equipment (UE)";
ETSI
6 ETSI EN 301 908-11 V5.2.1 (2011-07)
Part 14: "Evolved Universal Terrestrial Radio Access (E-UTRA) Base Stations (BS)";
Part 15: "Evolved Universal Terrestrial Radio Access (E-UTRA FDD) (Repeaters)";
Part 16: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (UE)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 17: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (BS)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 18: "E-UTRA, UTRA and GSM/EDGE Multi-Standard Radio (MSR) Base Station (BS)";
Part 19: "OFDMA TDD WMAN (Mobile WiMAX) TDD User Equipment (UE)";
Part 20: "OFDMA TDD WMAN (Mobile WiMAX) TDD Base Stations (BS)";
Part 21: "OFDMA TDD WMAN (Mobile WiMAX) FDD User Equipment (UE)";
Part 22: "OFDMA TDD WMAN (Mobile WiMAX) FDD Base Stations (BS)".
National transposition dates
Date of adoption of this EN: 4 July 2011
Date of latest announcement of this EN (doa): 31 October 2011
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 30 April 2012
Date of withdrawal of any conflicting National Standard (dow): 30 April 2013
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.6]. The
modular structure is shown in EG 201 399 [i.2].
ETSI
7 ETSI EN 301 908-11 V5.2.1 (2011-07)
1 Scope
The present document applies to the following radio equipment type:
• Repeaters for IMT-2000 CDMA Direct Spread (UTRA FDD).
This radio equipment type is capable of operating in all or any part of the frequency bands given in table 1-1.
Table 1-1: UTRA Repeater operating bands
UTRA FDD Direction of transmission UTRA Repeater operating bands
Band
I Downlink 2 110 MHz to 2 170 MHz
Uplink 1 920 MHz to 1 980 MHz
III Downlink 1 805 MHz to 1 880 MHz
Uplink 1 710 MHz to 1 785 MHz
VII Downlink 2 620 MHz to 2 690 MHz
Uplink 2 500 MHz to 2 570 MHz
VIII Downlink 925 MHz to 960 MHz
Uplink 880 MHz to 915 MHz
XV Downlink 2 600 MHz to 2 620 MHz
Uplink 1 900 MHz to 1 920 MHz
XVI Downlink 2 585 MHz to 2 600 MHz
Uplink 2 010 MHz to 2 025 MHz
XX Downlink 791 MHz to 821 MHz
Uplink 832 MHz to 862 MHz
The present document covers requirements for UTRA FDD Repeater for Releases 4, 5, 6, 7, 8 and 9. In addition, the
present document covers requirements for UTRA Repeater in the operating bands specified in TS 102 735 [i.5].
The present document is intended to cover the provisions of Directive 1999/5/EC [i.6] (R&TTE Directive), article 3.2,
which states that "… radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [i.6] may apply to equipment within the scope of the present
document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
[1] Void.
[2] Void.
ETSI
8 ETSI EN 301 908-11 V5.2.1 (2011-07)
[3] ETSI TS 125 143 (V9.2.0): "Universal Mobile Telecommunications System (UMTS); UTRA
repeater conformance testing (3GPP TS 25.143 version 9.2.0 Release 9)".
[4] ITU-R Recommendation SM.329-11 (2011): "Unwanted emissions in the spurious domain".
[5] ETSI TS 125 141 (V9.7.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) conformance testing (FDD) (3GPP TS 25.141 version 9.7.0 Release 9)".
[6] IEC 60068-2-1 (2007): "Environmental testing - Part 2-1: Tests - Test A: Cold".
[7] IEC 60068-2-2 (2007): "Environmental testing - Part 2-2: Tests - Test B: Dry heat".
[8] ETSI EN 301 908-1 (V5.2.1): "IMT cellular networks; Harmonized EN covering the essential
requirements of article 3.2 of the R&TTE Directive; Part 1: Introduction and common
requirements".
[9] ETSI EN 301 908-15 (V5.2.1): "IMT cellular networks; Harmonized EN covering the essential
requirements of article 3.2 of the R&TTE Directive; Part 15: Evolved Universal Terrestrial Radio
Access (E-UTRA FDD) (Repeaters)".
[10] ETSI TS 125 104 (V9.6.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) radio transmission and reception (FDD) (3GPP TS 25.104 version 9.6.0 Release 9)".
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
[i.2] ETSI EG 201 399 (V2.2.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
A guide to the production of Harmonized Standards for application under the R&TTE Directive".
[i.3] ETSI TR 102 215 (V1.3.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Recommended approach, and possible limits for measurement uncertainty for the measurement of
radiated electromagnetic fields above 1 GHz".
[i.4] ETSI TR 100 028 (all parts) (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters
(ERM); Uncertainties in the measurement of mobile radio equipment characteristics".
[i.5] ETSI TS 102 735 (V7.1.0): "Universal Mobile Telecommunications System (UMTS);
Band-specific requirements for UMTS Frequency Division Duplex (FDD) operation in the bands
1 900 MHz to 1 920 MHz paired with 2 600 MHz to 2 620 MHz and 2 010 MHz to 2 025 MHz
paired with 2 585 MHz to 2 600 MHz".
[i.6] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity (R&TTE Directive).
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the following terms and definitions apply:
donor coupling loss: coupling loss between the Repeater and the donor Base Station
downlink: signal path where Base Station transmits and mobile receives
downlink operating band: part of the operating band designated for downlink (BS transmit)
ETSI
9 ETSI EN 301 908-11 V5.2.1 (2011-07)
maximum output power (Pmax): mean power level per carrier measured at the antenna connector of the Repeater in
specified reference condition
maximum rated output power: maximum rated output power of the repeater is the mean power level per carrier that
the manufacturer has declared to be available at the antenna connector
operating band: frequency range that is defined with a specific set of technical requirements, in which UTRA FDD
operates
NOTE: The operating band(s) for an UTRA FDD repeater is declared by the manufacturer according to the
designations in table 1-1. Operating bands for UTRA are designated with Roman numerals, while the
corresponding operating bands for E-UTRA are designated with Arabic numerals.
pass band: frequency range that the Repeater operates in with operational configuration
NOTE 1: This frequency range can correspond to one or several consecutive nominal 5 MHz channels. If they are
not consecutive each subset of channels has to be considered as an individual pass band.
NOTE 2: The Repeater can have one or several pass bands.
repeater: device that receives, amplifies and transmits the radiated or conducted RF carrier both in the downlink
direction (from the Base Station to the mobile area) and in the uplink direction (from the mobile to the Base Station)
uplink: signal path where mobile transmits and Base Station receives
uplink operating band: part of the operating band designated for downlink (BS transmit)
3.2 Symbols
For the purposes of the present document, the following symbols apply:
Δf The separation between the centre frequency of first or last 5 MHz channel used in the pass band
and the nominal -3 dB point of the measuring filter closest to the carrier frequency
Δf The largest value of Δf used for defining the requirement
max
F Filter centre frequency
filter
P Declared emission level for channel N
EM,N
Pmax Maximum output power
Pout Output power
3.3 Abbreviations
For the purposes of the present document, the following abbreviations apply:
ACLR Adjacent Channel Leakage power Ratio
ACRR Adjacent Channel Rejection Ratio
BS Base Station
BTS Base Transceiver Station
CW Continuous Wave
NOTE: Unmodulated signal.
DCS Digital Cellular System
DTT Digital Terrestrial Television
DUT Device Under Test
E-UTRA Evolved Universal Terrestrial Radio Access
ERM Electromagnetic compatibility and Radio spectrum Matters
EUT Equipment Under Test
FDD Frequency Division Duplexing
ITU-R International Telecommunication Union - Radiocommunication
GSM Global System for Mobile Communications
IMT International Mobile Telecommunications
ETSI
10 ETSI EN 301 908-11 V5.2.1 (2011-07)
MS Mobile Station
NOTE: For GSM.
MSG Mobile Standards Group
PCCPCH Primary Common Control Physical CHannel
R&TTE Radio and Telecommunications Terminal Equipment
RF Radio Frequency
RMS Root Mean Square
RRC Root Raised Cosine
RSS Root Sum Square
SCCPCH Secondary Common Control Physical CHannel
TDD Time Division Duplexing
TFES Task Force for European Standards for IMT
UARFCN UTRA Absolute Radio Frequency Channel Number
UE User Equipment
UMTS Universal Mobile Telecommunications System
UTRA Universal Terrestrial Radio Access
UMB Ultra Mobile Broadband
WCDMA Wideband Code Division Multiple Access
4 Technical requirements specifications
4.1 Environmental profile
The technical requirements of the present document apply under the environmental profile for operation of the
equipment, which shall be declared by the supplier. The equipment shall comply with all the technical requirements of
the present document at all times when operating within the boundary limits of the declared operational environmental
profile.
For guidance on how a supplier can declare the environmental profile see annex C.
4.2 Conformance requirements
The requirements in the present document are based on the assumption that the operating band (e.g. band I, III, VII and
VIII) is shared between systems of the IMT family (for band III and VIII also GSM) or systems having compatible
characteristics.
4.2.1 Introduction
To meet the essential requirement under article 3.2 of Directive 1999/5/EC [i.6] (R&TTE Directive) for IMT Repeater
five essential parameters in addition to those in EN 301 908-1 [8] have been identified. Table 4.2.1-1 provides a cross
reference between these five essential parameters and the corresponding seven technical requirements for equipment
within the scope of the present document.
Table 4.2.1-1: Cross references
Essential parameter Corresponding technical requirements
Spectrum emissions mask 4.2.2 Operating band unwanted emissions
Conducted spurious emissions from the antenna connector 4.2.3 Spurious emissions
Accuracy of maximum output power 4.2.4 Maximum output power
Receiver immunity 4.2.5 Input intermodulation
4.2.6 Out of band gain
4.2.7 Adjacent Channel Rejection Ratio
Intermodulation attenuation of the output 4.2.8 Output intermodulation
ETSI
11 ETSI EN 301 908-11 V5.2.1 (2011-07)
The supplier shall declare operating band(s) for the Repeater. The technical requirements apply for the declared
operating band(s) as outlined for each requirement. For a Repeater supporting more than one operating band,
conformance testing for each technical requirement in clause 5 shall be performed.
The technical requirements also apply to Repeater configurations described in annex B.
For a Repeater declared to support Band XX, the manufacturer shall additionally declare the following quantities
associated with the applicable test conditions of table 4.2.2.2-5 and information in annex G of TS 125 104 [10]:
• P Declared emission level for channel N
EM,N
• P Maximum output Power in 10 MHz
10MHz
4.2.2 Operating band unwanted emissions
4.2.2.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The out of band emissions requirement for repeater is specified both in terms operating band unwanted emissions and
protection of the BS receiver in the operating band. The operating band unwanted emissions define all unwanted
emissions in the repeater operating band plus the frequency ranges 10 MHz above and 10 MHz below that band.
Unwanted emissions outside of this frequency range are limited by a spurious emissions requirement.
Operating band unwanted emissions comprise an emission mask applied outside the repeater passband and a general
requirement applied outside the mask but inside the frequency range of the operating band unwanted emissions.
4.2.2.2 Limit
4.2.2.2.1 General operating band unwanted emission requirements
The general operating band unwanted emissions limits are given in table 4.2.2.2.1-1.
Table 4.2.2.2.1-1: General operating band unwanted emissions requirements
Frequency range of Maximum level Measurement Notes
operating band bandwidth
-16 dBm 100 kHz 1, 2
≤ 1 GHz
≥ 1 GHz -15 dBm 1 MHz 2, 3
NOTE 1: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1.
NOTE 2: Limit based on ITU-R Recommendation SM.329-11 [4], section 4.3 and annex 7.
NOTE 3: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1. Upper
frequency as in ITU-R Recommendation SM.329-11 [4], section 2.5, table 1.
4.2.2.2.2 Operating band emission mask requirements
The requirement shall be met by a Repeater's RF-signal output at maximum gain with WCDMA signals in the pass
band of the Repeater, at levels that produce the maximum rated output power per channel, configured in accordance
with the manufacturer's specification. Emissions shall not exceed the maximum level specified in tables 4.2.2.2.2-1,
4.2.2.2.2-2, 4.2.2.2.2-3 and 4.2.2.2.2-4 for the appropriate Repeater maximum output power, in the frequency range
from Δf = 2,5 MHz to Δf from the 5 MHz channel, where:
max
• Δf is the separation between the centre frequency of first or last 5 MHz channel used in the pass band and the
nominal -3 dB point of the measuring filter closest to the carrier frequency;
• f_offset is the separation between the centre frequency of first or last 5 MHz channel in the pass band and the
centre of the measuring filter;
ETSI
12 ETSI EN 301 908-11 V5.2.1 (2011-07)
• f_offset is 12,5 MHz;
max
• Δf is equal to f_offset minus half of the bandwidth of the measurement filter.
max max
To select the table of the maximum level for the spectrum emission mask test, use the maximum output power as
defined in clause 3.1. If one channel is used for the spectrum emission mask test use this power for the selection. If two
channels are used for the spectrum emission mask test use the power of one of these.
Table 4.2.2.2.2-1: Emission mask values, maximum output power P ≥ 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz -12,5 dBm 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
−12,5 dBm−15 × −2,715 dB
⎜ ⎟
MHz
⎝ ⎠
3,515 MHz ≤ f_offset < 4,0 MHz -24,5 dBm 30 kHz
-11,5 dBm 1 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset -11,5 dBm 1 MHz
max max
Table 4.2.2.2.2-2: Emission mask values, maximum output power 39 ≤ P < 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
-12,5 dBm 30 kHz
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz 30 kHz
⎛ f_offset ⎞
−12,5 dBm −15 ×⎜ − 2,715⎟ dB
MHz
⎝ ⎠
-24,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz -11,5 dBm 1 MHz
P - 54,5 dB 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
Table 4.2.2.2.2-3: Emission mask values, maximum output power 31 ≤ P < 39 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz P - 51,5 dB 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
P −51,5 dB −15 × − 2,715 dB
⎜ ⎟
MHz
⎝ ⎠
P - 63,5 dB 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz P - 50,5 dB 1 MHz
P - 54,5 dB 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
ETSI
13 ETSI EN 301 908-11 V5.2.1 (2011-07)
Table 4.2.2.2.2-4: Emission mask values, maximum output power P < 31 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
-20,5 dBm 30 kHz
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz 30 kHz
f_offset
⎛ ⎞
− 20,5 dBm−15 ×⎜ −2,715⎟dB
MHz
⎝ ⎠
-32,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz -19,5 dBm 1 MHz
-23,5 dBm 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
4.2.2.2.3 Protection of the BS receiver in the operating band
This requirement shall be applied for the protection of UTRA FDD BS receiver in geographic areas in which
UTRA-FDD Repeater and UTRA-FDD BS are deployed.
The requirement applies at frequencies that are more than 10 MHz below or more than 10 MHz above the repeater pass
band.
This requirement applies to the uplink of the repeater, at maximum gain.
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.3-1.
Table 4.2.2.2.3-1: Uplink operating band unwanted emissions limits for
protection of the BS receiver
Maximum Measurement Note
Level Bandwidth
-53 dBm 100 kHz
4.2.2.2.4 Co-existence with services in adjacent frequency bands
This requirement shall be applied for the protection in bands adjacent to band I.
The requirement applies only to the down-link direction of the repeater.
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.4-1.
Table 4.2.2.2.4-1: UTRA Repeater down-link operating band unwanted emission limits
for protection of adjacent band services
Operating Band Band Maximum Level Measurement
Bandwidth
I 2 100 MHz to 2 105 MHz -30 + 3,4 (f – 2 100 MHz) dBm 1 MHz
2 175 Mhz to 2 180 MHz -30 + 3,4 (2 180 MHz - f) dBm 1 MHz
4.2.2.2.5 Protection of DTT
The following requirement shall apply for protection of DTT. For UTRA Repeater operating in Band XX, the level of
emissions in the band 470 MHz to 790 MHz, measured in an 8 MHz filter bandwidth on centre frequencies F
filter
according to table 4.2.2.2.5-1, shall not exceed the maximum emission level P declared by the manufacturer. This
EM,N
requirement applies in the frequency range 470 MHz to 790 MHz even though part of the range falls in the spurious
domain.
ETSI
14 ETSI EN 301 908-11 V5.2.1 (2011-07)
Table 4.2.2.2.5-1: Declared emissions levels for protection of DTT
Filter centre frequency, Measurement bandwidth Declared emission level
F [dBm]
filter
F = 8*N + 306 (MHz); 8 MHz P
filter EM,N
21 ≤ N ≤ 60
NOTE: Compliance with the declared emission levels above provides the characteristics of the Repeater needed
to verify compliance with the corresponding CEPT/ECC technical condition using the method outlined in
annex G of TS 125 104 [10].
4.2.2.3 Conformance
Conformance tests described in clause 5.3.1 shall be carried out.
4.2.3 Spurious emissions
4.2.3.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The spurious emission limits apply from 9 kHz to 12,75 GHz, excluding the frequency range from 10 MHz below the
lowest frequency of the repeaters operating band up to 10 MHz above the highest frequency of the repeaters operating
band.
The requirements shall apply whatever the type of repeater considered (one or several pass bands). It applies for all
configurations foreseen by the manufacturer's specification. The measurements shall apply to both paths uplink and
downlink of the Repeater.
Unless otherwise stated, all requirements are measured as mean power (RMS).
4.2.3.2 Limit
The requirements apply to the uplink and downlink of the repeater, at maximum gain, and with the following input
signals:
• without UTRA input signal;
• with UTRA input signals in the pass band of the repeater, at levels that produce the maximum rated power
output per channel;
• with 10 dB increased UTRA input signals in all channels in the pass band, compared to the input level
producing the maximum rated output power.
ETSI
15 ETSI EN 301 908-11 V5.2.1 (2011-07)
4.2.3.2.1 Spurious emissions
The power of any spurious emission shall not exceed the limits specified in table 4.2.3.2.1-1.
Table 4.2.3.2.1-1: General spurious emissions limits
Frequency range Maximum Measurement Note
Level Bandwidth
9 kHz ↔ 150 kHz -36 dBm 1 kHz Note 1
-36 dBm 10 kHz Note 1
150 kHz ↔ 30 MHz
-36 dBm 100 kHz Note 1
30 MHz ↔ 1 GHz
-30 dBm 1 MHz Note 2
1 GHz ↔ 12,75 GHz
NOTE 1: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1.
NOTE 2: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1. Upper frequency as
in ITU-R Recommendation SM.329-11 [4], section 2.5, table 1.
4.2.3.2.2 Co-existence with other systems
This requirement shall be applied for the protection of UE/MS and BS/BTS receivers of other systems.
The power of any spurious emission shall not exceed the limit specified in table 4.2.3.2.2-1.
Table 4.2.3.2.2-1: Spurious emissions limits for protection of other systems
Protected Frequency range for co- Maximum Measurement Note
system existence requirement Level Bandwidth
921 MHz to 960 MHz -57 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band VIII.
GSM900 876 MHz to 915 MHz -61 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band VIII, since it is already
covered by the requirement in clause 4.2.2.2.3.
1 805 MHz to 1 880 MHz -47 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band III.
DCS1800
1 710 MHz to 1 785 MHz -61 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band III, since it is already
covered by the requirement in clause 4.2.2.2.3.
2 110 MHz to 2 170 MHz -52 dBm 1 MHz This requirement does not apply to UTRA FDD
UTRA FDD
repeater operating in band I.
Band I,
1 920 MHz to 1 980 MHz -49 dBm 1 MHz This requirement does not apply to UTRA FDD
E-UTRA
repeater operating in band I, since it is already
Band 1
covered by the requirement in clause 4.2.2.2.3.
This requirement does not apply to UTRA FDD
1 805 MHz to 1 880 MHz -52
...
Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
Harmonized European Standard
IMT cellular networks;
Harmonized EN covering the essential requirements
of article 3.2 of the R&TTE Directive;
Part 11: CDMA Direct Spread (UTRA FDD) (Repeaters)
2 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
Reference
REN/MSG-TFES-006-11
Keywords
3G, 3GPP, cellular, digital, IMT, IMT-2000,
mobile, radio, regulation, repeater, testing,
UMTS, UTRA, WCDMA
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2011.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
Contents
Intellectual Property Rights . 5
Foreword . 5
Introduction . 6
1 Scope . 7
2 References . 7
2.1 Normative references . 7
2.2 Informative references . 8
3 Definitions, symbols and abbreviations . 8
3.1 Definitions . 8
3.2 Symbols . 9
3.3 Abbreviations . 9
4 Technical requirements specifications . 10
4.1 Environmental profile . 10
4.2 Conformance requirements . 10
4.2.1 Introduction. 10
4.2.2 Operating band unwanted emissions . 11
4.2.2.1 Definition . 11
4.2.2.2 Limit . 11
4.2.2.2.1 General operating band unwanted emission requirements . 11
4.2.2.2.2 Operating band emission mask requirements . 11
4.2.2.2.3 Protection of the BS receiver in the operating band . 13
4.2.2.2.4 Co-existence with services in adjacent frequency bands . 13
4.2.2.2.5 Protection of DTT. 13
4.2.2.3 Conformance . 14
4.2.3 Spurious emissions . 14
4.2.3.1 Definition . 14
4.2.3.2 Limit . 14
4.2.3.2.1 Spurious emissions . 15
4.2.3.2.2 Co-existence with other systems . 15
4.2.3.3 Conformance . 16
4.2.4 Maximum output power . 16
4.2.4.1 Definition . 16
4.2.4.2 Limit . 16
4.2.4.3 Conformance . 17
4.2.5 Input intermodulation . 17
4.2.5.1 Definition . 17
4.2.5.2 Limit . 17
4.2.5.2.1 General input intermodulation requirement . 17
4.2.5.2.2 Co-existence with other systems . 18
4.2.5.3 Conformance . 19
4.2.6 Out of band gain . 19
4.2.6.1 Definition . 19
4.2.6.2 Limits . 19
4.2.6.3 Conformance . 19
4.2.7 Adjacent Channel Rejection Ratio . 19
4.2.7.1 Definition . 19
4.2.7.2 Limit . 20
4.2.7.3 Conformance . 20
4.2.8 Output intermodulation . 20
4.2.8.1 Definition . 20
4.2.8.2 Limit . 20
4.2.8.3 Conformance . 20
5 Testing for compliance with technical requirements . 20
ETSI
4 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
5.1 Environmental conditions for testing . 20
5.2 Interpretation of the measurement results . 21
5.3 Essential radio test suites . 22
5.3.1 Operating band unwanted emission . 22
5.3.1.1 Initial conditions . 22
5.3.1.2 Procedures . 23
5.3.2 Spurious emissions . 23
5.3.2.1 Initial conditions . 23
5.3.2.2 Procedure . 23
5.3.3 Maximum output power . 24
5.3.3.1 Initial conditions . 24
5.3.3.2 Procedure . 24
5.3.4 Input intermodulation . 24
5.3.4.1 Initial conditions . 24
5.3.4.2 Procedures . 25
5.3.5 Out of band gain . 25
5.3.5.1 Initial conditions . 25
5.3.5.2 Procedure . 25
5.3.6 Adjacent Channel Rejection Ratio . 25
5.3.6.1 Initial conditions . 25
5.3.6.2 Procedures . 26
5.3.7 Output intermodulation . 26
5.3.7.1 Initial conditions . 26
5.3.7.2 Procedures . 26
Annex A (normative): HS Requirements and conformance Test specifications Table
(HS-RTT) . 28
Annex B (normative): Repeater configurations . 30
B.1 Power supply . 30
B.2 Power supply options . 30
B.3 Combining of Repeaters . 30
Annex C (informative): Environmental profile specification . 31
Annex D (informative): The EN title in the official languages . 32
Annex E (informative): Bibliography . 33
History . 34
ETSI
5 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This final draft Harmonized European Standard (EN) has been produced by ETSI Technical Committee Mobile
Standards Group (MSG), and is now submitted for the Vote phase of the ETSI standards Two-step Approval Procedure.
The present document has been produced by ETSI in response to mandate M/284 from the European Commission
issued under Council Directive 98/34/EC [i.1] (as amended) laying down a procedure for the provision of information
in the field of technical standards and regulations.
The title and reference to the present document are intended to included in the publication in the Official Journal of the
European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [i.6].
See article 5.1 of Directive 1999/5/EC [i.6] for information on presumption of conformity and Harmonised Standards or
parts thereof the references of which have been published in the Official Journal of the European Union.
The requirements relevant to Directive 1999/5/EC [i.6] are summarised in annex A.
The present document is part 11 of a multi-part deliverable covering the essential requirements under article 3.2 of
Directive 1999/5/EC [i.6] (R&TTE Directive) for Base Stations (BS), Repeaters and User Equipment (UE) for IMT
cellular networks, as identified below:
Part 1: "Introduction and common requirements";
Part 2: "CDMA Direct Spread (UTRA FDD) User Equipment (UE)";
Part 3: "CDMA Direct Spread (UTRA FDD) Base Stations (BS)";
Part 4: "CDMA Multi-Carrier (cdma2000) User Equipment (UE)";
Part 5: "CDMA Multi-Carrier (cdma2000) Base Stations (BS)";
Part 6: "CDMA TDD (UTRA TDD) User Equipment (UE)";
Part 7: "CDMA TDD (UTRA TDD) Base Stations (BS)";
Part 8: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (UE) covering essential requirements
of article 3.2 of the R&TTE Directive";
Part 9: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (BS) covering essential requirements
of article 3.2 of the R&TTE Directive";
Part 10: "Harmonized EN for IMT-2000, FDMA/TDMA (DECT) covering essential requirements of article 3.2 of
the R&TTE Directive";
Part 11: "CDMA Direct Spread (UTRA FDD) (Repeaters)";
Part 12: "Harmonized EN for IMT-2000, CDMA Multi-Carrier (cdma2000) (Repeaters) covering the essential
requirements of article 3.2 of the R&TTE Directive";
Part 13: "Evolved Universal Terrestrial Radio Access (E-UTRA) User Equipment (UE)";
ETSI
6 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
Part 14: "Evolved Universal Terrestrial Radio Access (E-UTRA) Base Stations (BS)";
Part 15: "Evolved Universal Terrestrial Radio Access (E-UTRA FDD) (Repeaters)";
Part 16: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (UE)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 17: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (BS)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 18: "E-UTRA, UTRA and GSM/EDGE Multi-Standard Radio (MSR) Base Station (BS)";
Part 19: "OFDMA TDD WMAN (Mobile WiMAX) TDD User Equipment (UE)";
Part 20: "OFDMA TDD WMAN (Mobile WiMAX) TDD Base Stations (BS)";
Part 21: "OFDMA TDD WMAN (Mobile WiMAX) FDD User Equipment (UE)";
Part 22: "OFDMA TDD WMAN (Mobile WiMAX) FDD Base Stations (BS)".
Proposed national transposition dates
Date of latest announcement of this EN (doa): 3 months after ETSI publication
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 6 months after doa
Date of withdrawal of any conflicting National Standard (dow): 18 months after doa
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.6]. The
modular structure is shown in EG 201 399 [i.2].
ETSI
7 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
1 Scope
The present document applies to the following radio equipment type:
• Repeaters for IMT-2000 CDMA Direct Spread (UTRA FDD).
This radio equipment type is capable of operating in all or any part of the frequency bands given in table 1-1.
Table 1-1: UTRA Repeater operating bands
UTRA FDD Direction of transmission UTRA Repeater operating bands
Band
I Downlink 2 110 MHz to 2 170 MHz
Uplink 1 920 MHz to 1 980 MHz
III Downlink 1 805 MHz to 1 880 MHz
Uplink 1 710 MHz to 1 785 MHz
VII Downlink 2 620 MHz to 2 690 MHz
Uplink 2 500 MHz to 2 570 MHz
VIII Downlink 925 MHz to 960 MHz
Uplink 880 MHz to 915 MHz
XV Downlink 2 600 MHz to 2 620 MHz
Uplink 1 900 MHz to 1 920 MHz
XVI Downlink 2 585 MHz to 2 600 MHz
Uplink 2 010 MHz to 2 025 MHz
XX Downlink 791 MHz to 821 MHz
Uplink 832 MHz to 862 MHz
The present document covers requirements for UTRA FDD Repeater for Releases 4, 5, 6, 7, 8 and 9. In addition, the
present document covers requirements for UTRA Repeater in the operating bands specified in TS 102 735 [i.5].
The present document is intended to cover the provisions of Directive 1999/5/EC [i.6] (R&TTE Directive), article 3.2,
which states that "… radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [i.6] may apply to equipment within the scope of the present
document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
[1] Void.
[2] Void.
ETSI
8 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
[3] ETSI TS 125 143 (V9.2.0): "Universal Mobile Telecommunications System (UMTS); UTRA
repeater conformance testing (3GPP TS 25.143 version 9.2.0 Release 9)".
[4] ITU-R Recommendation SM.329-11 (2011): "Unwanted emissions in the spurious domain".
[5] ETSI TS 125 141 (V9.7.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) conformance testing (FDD) (3GPP TS 25.141 version 9.7.0 Release 9)".
[6] IEC 60068-2-1 (2007): "Environmental testing - Part 2-1: Tests - Test A: Cold".
[7] IEC 60068-2-2 (2007): "Environmental testing - Part 2-2: Tests - Test B: Dry heat".
[8] ETSI EN 301 908-1 (V5.2.1): "IMT cellular networks; Harmonized EN covering the essential
requirements of article 3.2 of the R&TTE Directive; Part 1: Introduction and common
requirements".
[9] ETSI EN 301 908-15 (V5.2.1): "IMT cellular networks; Harmonized EN covering the essential
requirements of article 3.2 of the R&TTE Directive; Part 15: Evolved Universal Terrestrial Radio
Access (E-UTRA FDD) (Repeaters)".
[10] ETSI TS 125 104 (V9.6.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) radio transmission and reception (FDD) (3GPP TS 25.104 version 9.6.0 Release 9)".
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
[i.2] ETSI EG 201 399 (V2.2.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
A guide to the production of Harmonized Standards for application under the R&TTE Directive".
[i.3] ETSI TR 102 215 (V1.3.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Recommended approach, and possible limits for measurement uncertainty for the measurement of
radiated electromagnetic fields above 1 GHz".
[i.4] ETSI TR 100 028 (all parts) (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters
(ERM); Uncertainties in the measurement of mobile radio equipment characteristics".
[i.5] ETSI TS 102 735 (V7.1.0): "Universal Mobile Telecommunications System (UMTS);
Band-specific requirements for UMTS Frequency Division Duplex (FDD) operation in the bands
1 900 MHz to 1 920 MHz paired with 2 600 MHz to 2 620 MHz and 2 010 MHz to 2 025 MHz
paired with 2 585 MHz to 2 600 MHz".
[i.6] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity (R&TTE Directive).
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the following terms and definitions apply:
donor coupling loss: coupling loss between the Repeater and the donor Base Station
downlink: signal path where Base Station transmits and mobile receives
downlink operating band: part of the operating band designated for downlink (BS transmit)
ETSI
9 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
maximum output power (Pmax): mean power level per carrier measured at the antenna connector of the Repeater in
specified reference condition
maximum rated output power: maximum rated output power of the repeater is the mean power level per carrier that
the manufacturer has declared to be available at the antenna connector
operating band: frequency range that is defined with a specific set of technical requirements, in which UTRA FDD
operates
NOTE: The operating band(s) for an UTRA FDD repeater is declared by the manufacturer according to the
designations in table 1-1. Operating bands for UTRA are designated with Roman numerals, while the
corresponding operating bands for E-UTRA are designated with Arabic numerals.
pass band: frequency range that the Repeater operates in with operational configuration
NOTE 1: This frequency range can correspond to one or several consecutive nominal 5 MHz channels. If they are
not consecutive each subset of channels has to be considered as an individual pass band.
NOTE 2: The Repeater can have one or several pass bands.
repeater: device that receives, amplifies and transmits the radiated or conducted RF carrier both in the downlink
direction (from the Base Station to the mobile area) and in the uplink direction (from the mobile to the Base Station)
uplink: signal path where mobile transmits and Base Station receives
uplink operating band: part of the operating band designated for downlink (BS transmit)
3.2 Symbols
For the purposes of the present document, the following symbols apply:
Δf The separation between the centre frequency of first or last 5 MHz channel used in the pass band
and the nominal -3 dB point of the measuring filter closest to the carrier frequency
Δf The largest value of Δf used for defining the requirement
max
F Filter centre frequency
filter
P Declared emission level for channel N
EM,N
Pmax Maximum output power
Pout Output power
3.3 Abbreviations
For the purposes of the present document, the following abbreviations apply:
ACLR Adjacent Channel Leakage power Ratio
ACRR Adjacent Channel Rejection Ratio
BS Base Station
BTS Base Transceiver Station
CW Continuous Wave
NOTE: Unmodulated signal.
DCS Digital Cellular System
DTT Digital Terrestrial Television
DUT Device Under Test
E-UTRA Evolved Universal Terrestrial Radio Access
ERM Electromagnetic compatibility and Radio spectrum Matters
EUT Equipment Under Test
FDD Frequency Division Duplexing
ITU-R International Telecommunication Union - Radiocommunication
GSM Global System for Mobile Communications
IMT International Mobile Telecommunications
ETSI
10 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
MS Mobile Station
NOTE: For GSM.
MSG Mobile Standards Group
PCCPCH Primary Common Control Physical CHannel
R&TTE Radio and Telecommunications Terminal Equipment
RF Radio Frequency
RMS Root Mean Square
RRC Root Raised Cosine
RSS Root Sum Square
SCCPCH Secondary Common Control Physical CHannel
TDD Time Division Duplexing
TFES Task Force for European Standards for IMT
UARFCN UTRA Absolute Radio Frequency Channel Number
UE User Equipment
UMTS Universal Mobile Telecommunications System
UTRA Universal Terrestrial Radio Access
UMB Ultra Mobile Broadband
WCDMA Wideband Code Division Multiple Access
4 Technical requirements specifications
4.1 Environmental profile
The technical requirements of the present document apply under the environmental profile for operation of the
equipment, which shall be declared by the supplier. The equipment shall comply with all the technical requirements of
the present document at all times when operating within the boundary limits of the declared operational environmental
profile.
For guidance on how a supplier can declare the environmental profile see annex C.
4.2 Conformance requirements
The requirements in the present document are based on the assumption that the operating band (e.g. band I, III, VII and
VIII) is shared between systems of the IMT family (for band III and VIII also GSM) or systems having compatible
characteristics.
4.2.1 Introduction
To meet the essential requirement under article 3.2 of Directive 1999/5/EC [i.6] (R&TTE Directive) for IMT Repeater
five essential parameters in addition to those in EN 301 908-1 [8] have been identified. Table 4.2.1-1 provides a cross
reference between these five essential parameters and the corresponding seven technical requirements for equipment
within the scope of the present document.
Table 4.2.1-1: Cross references
Essential parameter Corresponding technical requirements
Spectrum emissions mask 4.2.2 Operating band unwanted emissions
Conducted spurious emissions from the antenna connector 4.2.3 Spurious emissions
Accuracy of maximum output power 4.2.4 Maximum output power
Receiver immunity 4.2.5 Input intermodulation
4.2.6 Out of band gain
4.2.7 Adjacent Channel Rejection Ratio
Intermodulation attenuation of the output 4.2.8 Output intermodulation
ETSI
11 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
The supplier shall declare operating band(s) for the Repeater. The technical requirements apply for the declared
operating band(s) as outlined for each requirement. For a Repeater supporting more than one operating band,
conformance testing for each technical requirement in clause 5 shall be performed.
The technical requirements also apply to Repeater configurations described in annex B.
For a Repeater declared to support Band XX, the manufacturer shall additionally declare the following quantities
associated with the applicable test conditions of table 4.2.2.2-5 and information in annex G of TS 125 104 [10]:
• P Declared emission level for channel N
EM,N
• P Maximum output Power in 10 MHz
10MHz
4.2.2 Operating band unwanted emissions
4.2.2.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The out of band emissions requirement for repeater is specified both in terms operating band unwanted emissions and
protection of the BS receiver in the operating band. The operating band unwanted emissions define all unwanted
emissions in the repeater operating band plus the frequency ranges 10 MHz above and 10 MHz below that band.
Unwanted emissions outside of this frequency range are limited by a spurious emissions requirement.
Operating band unwanted emissions comprise an emission mask applied outside the repeater passband and a general
requirement applied outside the mask but inside the frequency range of the operating band unwanted emissions.
4.2.2.2 Limit
4.2.2.2.1 General operating band unwanted emission requirements
The general operating band unwanted emissions limits are given in table 4.2.2.2.1-1.
Table 4.2.2.2.1-1: General operating band unwanted emissions requirements
Frequency range of Maximum level Measurement Notes
operating band bandwidth
-16 dBm 100 kHz 1, 2
≤ 1 GHz
≥ 1 GHz -15 dBm 1 MHz 2, 3
NOTE 1: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1.
NOTE 2: Limit based on ITU-R Recommendation SM.329-11 [4], section 4.3 and annex 7.
NOTE 3: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1. Upper
frequency as in ITU-R Recommendation SM.329-11 [4], section 2.5, table 1.
4.2.2.2.2 Operating band emission mask requirements
The requirement shall be met by a Repeater's RF-signal output at maximum gain with WCDMA signals in the pass
band of the Repeater, at levels that produce the maximum rated output power per channel, configured in accordance
with the manufacturer's specification. Emissions shall not exceed the maximum level specified in tables 4.2.2.2.2-1,
4.2.2.2.2-2, 4.2.2.2.2-3 and 4.2.2.2.2-4 for the appropriate Repeater maximum output power, in the frequency range
from Δf = 2,5 MHz to Δf from the 5 MHz channel, where:
max
• Δf is the separation between the centre frequency of first or last 5 MHz channel used in the pass band and the
nominal -3 dB point of the measuring filter closest to the carrier frequency;
• f_offset is the separation between the centre frequency of first or last 5 MHz channel in the pass band and the
centre of the measuring filter;
ETSI
12 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
• f_offset is 12,5 MHz;
max
• Δf is equal to f_offset minus half of the bandwidth of the measurement filter.
max max
To select the table of the maximum level for the spectrum emission mask test, use the maximum output power as
defined in clause 3.1. If one channel is used for the spectrum emission mask test use this power for the selection. If two
channels are used for the spectrum emission mask test use the power of one of these.
Table 4.2.2.2.2-1: Emission mask values, maximum output power P ≥ 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz -12,5 dBm 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
−12,5 dBm−15 × −2,715 dB
⎜ ⎟
MHz
⎝ ⎠
3,515 MHz ≤ f_offset < 4,0 MHz -24,5 dBm 30 kHz
-11,5 dBm 1 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset -11,5 dBm 1 MHz
max max
Table 4.2.2.2.2-2: Emission mask values, maximum output power 39 ≤ P < 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
-12,5 dBm 30 kHz
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz 30 kHz
⎛ f_offset ⎞
−12,5 dBm −15 ×⎜ − 2,715⎟ dB
MHz
⎝ ⎠
-24,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz -11,5 dBm 1 MHz
P - 54,5 dB 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
Table 4.2.2.2.2-3: Emission mask values, maximum output power 31 ≤ P < 39 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz P - 51,5 dB 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
P −51,5 dB −15 × − 2,715 dB
⎜ ⎟
MHz
⎝ ⎠
P - 63,5 dB 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz P - 50,5 dB 1 MHz
P - 54,5 dB 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
ETSI
13 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
Table 4.2.2.2.2-4: Emission mask values, maximum output power P < 31 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
-20,5 dBm 30 kHz
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz 30 kHz
f_offset
⎛ ⎞
− 20,5 dBm−15 ×⎜ −2,715⎟dB
MHz
⎝ ⎠
-32,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz -19,5 dBm 1 MHz
-23,5 dBm 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
4.2.2.2.3 Protection of the BS receiver in the operating band
This requirement shall be applied for the protection of UTRA FDD BS receiver in geographic areas in which
UTRA-FDD Repeater and UTRA-FDD BS are deployed.
The requirement applies at frequencies that are more than 10 MHz below or more than 10 MHz above the repeater pass
band.
This requirement applies to the uplink of the repeater, at maximum gain.
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.3-1.
Table 4.2.2.2.3-1: Uplink operating band unwanted emissions limits for
protection of the BS receiver
Maximum Measurement Note
Level Bandwidth
-53 dBm 100 kHz
4.2.2.2.4 Co-existence with services in adjacent frequency bands
This requirement shall be applied for the protection in bands adjacent to band I.
The requirement applies only to the down-link direction of the repeater.
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.4-1.
Table 4.2.2.2.4-1: UTRA Repeater down-link operating band unwanted emission limits
for protection of adjacent band services
Operating Band Band Maximum Level Measurement
Bandwidth
I 2 100 MHz to 2 105 MHz -30 + 3,4 (f – 2 100 MHz) dBm 1 MHz
2 175 Mhz to 2 180 MHz -30 + 3,4 (2 180 MHz - f) dBm 1 MHz
4.2.2.2.5 Protection of DTT
The following requirement shall apply for protection of DTT. For UTRA Repeater operating in Band XX, the level of
emissions in the band 470 MHz to 790 MHz, measured in an 8 MHz filter bandwidth on centre frequencies F
filter
according to table 4.2.2.2.5-1, shall not exceed the maximum emission level P declared by the manufacturer. This
EM,N
requirement applies in the frequency range 470 MHz to 790 MHz even though part of the range falls in the spurious
domain.
ETSI
14 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
Table 4.2.2.2.5-1: Declared emissions levels for protection of DTT
Filter centre frequency, Measurement bandwidth Declared emission level
F [dBm]
filter
F = 8*N + 306 (MHz); 8 MHz P
filter EM,N
21 ≤ N ≤ 60
NOTE: Compliance with the declared emission levels above provides the characteristics of the Repeater needed
to verify compliance with the corresponding CEPT/ECC technical condition using the method outlined in
annex G of TS 125 104 [10].
4.2.2.3 Conformance
Conformance tests described in clause 5.3.1 shall be carried out.
4.2.3 Spurious emissions
4.2.3.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The spurious emission limits apply from 9 kHz to 12,75 GHz, excluding the frequency range from 10 MHz below the
lowest frequency of the repeaters operating band up to 10 MHz above the highest frequency of the repeaters operating
band.
The requirements shall apply whatever the type of repeater considered (one or several pass bands). It applies for all
configurations foreseen by the manufacturer's specification. The measurements shall apply to both paths uplink and
downlink of the Repeater.
Unless otherwise stated, all requirements are measured as mean power (RMS).
4.2.3.2 Limit
The requirements apply to the uplink and downlink of the repeater, at maximum gain, and with the following input
signals:
• without UTRA input signal;
• with UTRA input signals in the pass band of the repeater, at levels that produce the maximum rated power
output per channel;
• with 10 dB increased UTRA input signals in all channels in the pass band, compared to the input level
producing the maximum rated output power.
ETSI
15 Final draft ETSI EN 301 908-11 V5.2.1 (2011-05)
4.2.3.2.1 Spurious emissions
The power of any spurious emission shall not exceed the limits specified in table 4.2.3.2.1-1.
Table 4.2.3.2.1-1: General spurious emissions limits
Frequency range Maximum Measurement Note
Level Bandwidth
9 kHz ↔ 150 kHz -36 dBm 1 kHz Note 1
-36 dBm 10 kHz Note 1
150 kHz ↔ 30 MHz
-36 dBm 100 kHz Note 1
30 MHz ↔ 1 GHz
-30 dBm 1 MHz Note 2
1 GHz ↔ 12,75 GHz
NOTE 1: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1.
NOTE 2: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1. Upper frequency as
in ITU-R Recommendation SM.329-11 [4], section 2.5, table 1.
4.2.3.2.2 Co-existence with other systems
This requirement shall be applied for the protection of UE/MS and BS/BTS receivers of other systems.
The power of any spurious emission shall not exceed the limit specified in table 4.2.3.2.2-1.
Table 4.2.3.2.2-1: Spurious emissions limits for protection of other systems
Protected Frequency range for co- Maximum Measurement Note
system existence requirement Level Bandwidth
921 MHz to 960 MHz -57 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band VIII.
GSM900 876 MHz to 915 MHz -61 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band VIII, since it is already
covered by the requirement in clause 4.2.2.2.3.
1 805 MHz to 1 880 MHz -47 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band III.
DCS1800
1 710 MHz to 1 785 MHz -61 dBm 100 kHz This requirement does not apply to UTRA FDD
repeater operating in band III, since it is a
...
SLOVENSKI STANDARD
01-september-2011
&HOLþQDRPUHåMD,07+DUPRQL]LUDQL(1NL]DMHPDELVWYHQH]DKWHYHþOHQD
GLUHNWLYH5 77(GHO &'0$]QHSRVUHGQLPUD]SUãHYDQMHP ³'LUHFW6SUHDG´
875$)'' SRQDYOMDOQLNL UHSHWLWRUML
IMT cellular networks - Harmonized EN covering the essential requirements of article 3.2
of the R&TTE Directive - Part 11: CDMA Direct Spread (UTRA FDD) (Repeaters)
Ta slovenski standard je istoveten z: EN 301 908-11 Version 5.2.1
ICS:
33.060.99 Druga oprema za radijske Other equipment for
komunikacije radiocommunications
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
Harmonized European Standard
IMT cellular networks;
Harmonized EN covering the essential requirements
of article 3.2 of the R&TTE Directive;
Part 11: CDMA Direct Spread (UTRA FDD) (Repeaters)
2 ETSI EN 301 908-11 V5.2.1 (2011-07)
Reference
REN/MSG-TFES-006-11
Keywords
3G, 3GPP, cellular, digital, IMT, IMT-2000,
mobile, radio, regulation, repeater, testing,
UMTS, UTRA, WCDMA
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2011.
All rights reserved.
TM TM TM
DECT , PLUGTESTS , UMTS and the ETSI logo are Trade Marks of ETSI registered for the benefit of its Members.
TM
3GPP and LTE™ are Trade Marks of ETSI registered for the benefit of its Members and
of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 ETSI EN 301 908-11 V5.2.1 (2011-07)
Contents
Intellectual Property Rights . 5
Foreword . 5
Introduction . 6
1 Scope . 7
2 References . 7
2.1 Normative references . 7
2.2 Informative references . 8
3 Definitions, symbols and abbreviations . 8
3.1 Definitions . 8
3.2 Symbols . 9
3.3 Abbreviations . 9
4 Technical requirements specifications . 10
4.1 Environmental profile . 10
4.2 Conformance requirements . 10
4.2.1 Introduction. 10
4.2.2 Operating band unwanted emissions . 11
4.2.2.1 Definition . 11
4.2.2.2 Limit . 11
4.2.2.2.1 General operating band unwanted emission requirements . 11
4.2.2.2.2 Operating band emission mask requirements . 11
4.2.2.2.3 Protection of the BS receiver in the operating band . 13
4.2.2.2.4 Co-existence with services in adjacent frequency bands . 13
4.2.2.2.5 Protection of DTT. 13
4.2.2.3 Conformance . 14
4.2.3 Spurious emissions . 14
4.2.3.1 Definition . 14
4.2.3.2 Limit . 14
4.2.3.2.1 Spurious emissions . 15
4.2.3.2.2 Co-existence with other systems . 15
4.2.3.3 Conformance . 16
4.2.4 Maximum output power . 16
4.2.4.1 Definition . 16
4.2.4.2 Limit . 16
4.2.4.3 Conformance . 17
4.2.5 Input intermodulation . 17
4.2.5.1 Definition . 17
4.2.5.2 Limit . 17
4.2.5.2.1 General input intermodulation requirement . 17
4.2.5.2.2 Co-existence with other systems . 18
4.2.5.3 Conformance . 19
4.2.6 Out of band gain . 19
4.2.6.1 Definition . 19
4.2.6.2 Limits . 19
4.2.6.3 Conformance . 19
4.2.7 Adjacent Channel Rejection Ratio . 19
4.2.7.1 Definition . 19
4.2.7.2 Limit . 20
4.2.7.3 Conformance . 20
4.2.8 Output intermodulation . 20
4.2.8.1 Definition . 20
4.2.8.2 Limit . 20
4.2.8.3 Conformance . 20
5 Testing for compliance with technical requirements . 20
ETSI
4 ETSI EN 301 908-11 V5.2.1 (2011-07)
5.1 Environmental conditions for testing . 20
5.2 Interpretation of the measurement results . 21
5.3 Essential radio test suites . 22
5.3.1 Operating band unwanted emission . 22
5.3.1.1 Initial conditions . 22
5.3.1.2 Procedures . 23
5.3.2 Spurious emissions . 23
5.3.2.1 Initial conditions . 23
5.3.2.2 Procedure . 23
5.3.3 Maximum output power . 24
5.3.3.1 Initial conditions . 24
5.3.3.2 Procedure . 24
5.3.4 Input intermodulation . 24
5.3.4.1 Initial conditions . 24
5.3.4.2 Procedures . 25
5.3.5 Out of band gain . 25
5.3.5.1 Initial conditions . 25
5.3.5.2 Procedure . 25
5.3.6 Adjacent Channel Rejection Ratio . 25
5.3.6.1 Initial conditions . 25
5.3.6.2 Procedures . 26
5.3.7 Output intermodulation . 26
5.3.7.1 Initial conditions . 26
5.3.7.2 Procedures . 26
Annex A (normative): HS Requirements and conformance Test specifications Table
(HS-RTT) . 28
Annex B (normative): Repeater configurations . 30
B.1 Power supply . 30
B.2 Power supply options . 30
B.3 Combining of Repeaters . 30
Annex C (informative): Environmental profile specification . 31
Annex D (informative): The EN title in the official languages . 32
Annex E (informative): Bibliography . 33
History . 34
ETSI
5 ETSI EN 301 908-11 V5.2.1 (2011-07)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://ipr.etsi.org).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (EN) has been produced by ETSI Technical Committee Mobile Standards Group
(MSG).
The present document has been produced by ETSI in response to mandate M/284 from the European Commission
issued under Council Directive 98/34/EC [i.1] (as amended) laying down a procedure for the provision of information
in the field of technical standards and regulations.
The title and reference to the present document are intended to included in the publication in the Official Journal of the
European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [i.6].
See article 5.1 of Directive 1999/5/EC [i.6] for information on presumption of conformity and Harmonised Standards or
parts thereof the references of which have been published in the Official Journal of the European Union.
The requirements relevant to Directive 1999/5/EC [i.6] are summarised in annex A.
The present document is part 11 of a multi-part deliverable covering the essential requirements under article 3.2 of
Directive 1999/5/EC [i.6] (R&TTE Directive) for Base Stations (BS), Repeaters and User Equipment (UE) for IMT
cellular networks, as identified below:
Part 1: "Introduction and common requirements";
Part 2: "CDMA Direct Spread (UTRA FDD) User Equipment (UE)";
Part 3: "CDMA Direct Spread (UTRA FDD) Base Stations (BS)";
Part 4: "CDMA Multi-Carrier (cdma2000) User Equipment (UE)";
Part 5: "CDMA Multi-Carrier (cdma2000) Base Stations (BS)";
Part 6: "CDMA TDD (UTRA TDD) User Equipment (UE)";
Part 7: "CDMA TDD (UTRA TDD) Base Stations (BS)";
Part 8: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (UE) covering essential requirements
of article 3.2 of the R&TTE Directive";
Part 9: "Harmonized EN for IMT-2000, TDMA Single-Carrier (UWC 136) (BS) covering essential requirements
of article 3.2 of the R&TTE Directive";
Part 10: "Harmonized EN for IMT-2000, FDMA/TDMA (DECT) covering essential requirements of article 3.2 of
the R&TTE Directive";
Part 11: "CDMA Direct Spread (UTRA FDD) (Repeaters)";
Part 12: "Harmonized EN for IMT-2000, CDMA Multi-Carrier (cdma2000) (Repeaters) covering the essential
requirements of article 3.2 of the R&TTE Directive";
Part 13: "Evolved Universal Terrestrial Radio Access (E-UTRA) User Equipment (UE)";
ETSI
6 ETSI EN 301 908-11 V5.2.1 (2011-07)
Part 14: "Evolved Universal Terrestrial Radio Access (E-UTRA) Base Stations (BS)";
Part 15: "Evolved Universal Terrestrial Radio Access (E-UTRA FDD) (Repeaters)";
Part 16: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (UE)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 17: "Harmonized EN for IMT-2000, Evolved CDMA Multi-Carrier Ultra Mobile Broadband (UMB) (BS)
covering the essential requirements of article 3.2 of the R&TTE Directive";
Part 18: "E-UTRA, UTRA and GSM/EDGE Multi-Standard Radio (MSR) Base Station (BS)";
Part 19: "OFDMA TDD WMAN (Mobile WiMAX) TDD User Equipment (UE)";
Part 20: "OFDMA TDD WMAN (Mobile WiMAX) TDD Base Stations (BS)";
Part 21: "OFDMA TDD WMAN (Mobile WiMAX) FDD User Equipment (UE)";
Part 22: "OFDMA TDD WMAN (Mobile WiMAX) FDD Base Stations (BS)".
National transposition dates
Date of adoption of this EN: 4 July 2011
Date of latest announcement of this EN (doa): 31 October 2011
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 30 April 2012
Date of withdrawal of any conflicting National Standard (dow): 30 April 2013
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.6]. The
modular structure is shown in EG 201 399 [i.2].
ETSI
7 ETSI EN 301 908-11 V5.2.1 (2011-07)
1 Scope
The present document applies to the following radio equipment type:
• Repeaters for IMT-2000 CDMA Direct Spread (UTRA FDD).
This radio equipment type is capable of operating in all or any part of the frequency bands given in table 1-1.
Table 1-1: UTRA Repeater operating bands
UTRA FDD Direction of transmission UTRA Repeater operating bands
Band
I Downlink 2 110 MHz to 2 170 MHz
Uplink 1 920 MHz to 1 980 MHz
III Downlink 1 805 MHz to 1 880 MHz
Uplink 1 710 MHz to 1 785 MHz
VII Downlink 2 620 MHz to 2 690 MHz
Uplink 2 500 MHz to 2 570 MHz
VIII Downlink 925 MHz to 960 MHz
Uplink 880 MHz to 915 MHz
XV Downlink 2 600 MHz to 2 620 MHz
Uplink 1 900 MHz to 1 920 MHz
XVI Downlink 2 585 MHz to 2 600 MHz
Uplink 2 010 MHz to 2 025 MHz
XX Downlink 791 MHz to 821 MHz
Uplink 832 MHz to 862 MHz
The present document covers requirements for UTRA FDD Repeater for Releases 4, 5, 6, 7, 8 and 9. In addition, the
present document covers requirements for UTRA Repeater in the operating bands specified in TS 102 735 [i.5].
The present document is intended to cover the provisions of Directive 1999/5/EC [i.6] (R&TTE Directive), article 3.2,
which states that "… radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [i.6] may apply to equipment within the scope of the present
document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
[1] Void.
[2] Void.
ETSI
8 ETSI EN 301 908-11 V5.2.1 (2011-07)
[3] ETSI TS 125 143 (V9.2.0): "Universal Mobile Telecommunications System (UMTS); UTRA
repeater conformance testing (3GPP TS 25.143 version 9.2.0 Release 9)".
[4] ITU-R Recommendation SM.329-11 (2011): "Unwanted emissions in the spurious domain".
[5] ETSI TS 125 141 (V9.7.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) conformance testing (FDD) (3GPP TS 25.141 version 9.7.0 Release 9)".
[6] IEC 60068-2-1 (2007): "Environmental testing - Part 2-1: Tests - Test A: Cold".
[7] IEC 60068-2-2 (2007): "Environmental testing - Part 2-2: Tests - Test B: Dry heat".
[8] ETSI EN 301 908-1 (V5.2.1): "IMT cellular networks; Harmonized EN covering the essential
requirements of article 3.2 of the R&TTE Directive; Part 1: Introduction and common
requirements".
[9] ETSI EN 301 908-15 (V5.2.1): "IMT cellular networks; Harmonized EN covering the essential
requirements of article 3.2 of the R&TTE Directive; Part 15: Evolved Universal Terrestrial Radio
Access (E-UTRA FDD) (Repeaters)".
[10] ETSI TS 125 104 (V9.6.0): "Universal Mobile Telecommunications System (UMTS); Base
Station (BS) radio transmission and reception (FDD) (3GPP TS 25.104 version 9.6.0 Release 9)".
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
[i.2] ETSI EG 201 399 (V2.2.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
A guide to the production of Harmonized Standards for application under the R&TTE Directive".
[i.3] ETSI TR 102 215 (V1.3.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Recommended approach, and possible limits for measurement uncertainty for the measurement of
radiated electromagnetic fields above 1 GHz".
[i.4] ETSI TR 100 028 (all parts) (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters
(ERM); Uncertainties in the measurement of mobile radio equipment characteristics".
[i.5] ETSI TS 102 735 (V7.1.0): "Universal Mobile Telecommunications System (UMTS);
Band-specific requirements for UMTS Frequency Division Duplex (FDD) operation in the bands
1 900 MHz to 1 920 MHz paired with 2 600 MHz to 2 620 MHz and 2 010 MHz to 2 025 MHz
paired with 2 585 MHz to 2 600 MHz".
[i.6] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity (R&TTE Directive).
3 Definitions, symbols and abbreviations
3.1 Definitions
For the purposes of the present document, the following terms and definitions apply:
donor coupling loss: coupling loss between the Repeater and the donor Base Station
downlink: signal path where Base Station transmits and mobile receives
downlink operating band: part of the operating band designated for downlink (BS transmit)
ETSI
9 ETSI EN 301 908-11 V5.2.1 (2011-07)
maximum output power (Pmax): mean power level per carrier measured at the antenna connector of the Repeater in
specified reference condition
maximum rated output power: maximum rated output power of the repeater is the mean power level per carrier that
the manufacturer has declared to be available at the antenna connector
operating band: frequency range that is defined with a specific set of technical requirements, in which UTRA FDD
operates
NOTE: The operating band(s) for an UTRA FDD repeater is declared by the manufacturer according to the
designations in table 1-1. Operating bands for UTRA are designated with Roman numerals, while the
corresponding operating bands for E-UTRA are designated with Arabic numerals.
pass band: frequency range that the Repeater operates in with operational configuration
NOTE 1: This frequency range can correspond to one or several consecutive nominal 5 MHz channels. If they are
not consecutive each subset of channels has to be considered as an individual pass band.
NOTE 2: The Repeater can have one or several pass bands.
repeater: device that receives, amplifies and transmits the radiated or conducted RF carrier both in the downlink
direction (from the Base Station to the mobile area) and in the uplink direction (from the mobile to the Base Station)
uplink: signal path where mobile transmits and Base Station receives
uplink operating band: part of the operating band designated for downlink (BS transmit)
3.2 Symbols
For the purposes of the present document, the following symbols apply:
Δf The separation between the centre frequency of first or last 5 MHz channel used in the pass band
and the nominal -3 dB point of the measuring filter closest to the carrier frequency
Δf The largest value of Δf used for defining the requirement
max
F Filter centre frequency
filter
P Declared emission level for channel N
EM,N
Pmax Maximum output power
Pout Output power
3.3 Abbreviations
For the purposes of the present document, the following abbreviations apply:
ACLR Adjacent Channel Leakage power Ratio
ACRR Adjacent Channel Rejection Ratio
BS Base Station
BTS Base Transceiver Station
CW Continuous Wave
NOTE: Unmodulated signal.
DCS Digital Cellular System
DTT Digital Terrestrial Television
DUT Device Under Test
E-UTRA Evolved Universal Terrestrial Radio Access
ERM Electromagnetic compatibility and Radio spectrum Matters
EUT Equipment Under Test
FDD Frequency Division Duplexing
ITU-R International Telecommunication Union - Radiocommunication
GSM Global System for Mobile Communications
IMT International Mobile Telecommunications
ETSI
10 ETSI EN 301 908-11 V5.2.1 (2011-07)
MS Mobile Station
NOTE: For GSM.
MSG Mobile Standards Group
PCCPCH Primary Common Control Physical CHannel
R&TTE Radio and Telecommunications Terminal Equipment
RF Radio Frequency
RMS Root Mean Square
RRC Root Raised Cosine
RSS Root Sum Square
SCCPCH Secondary Common Control Physical CHannel
TDD Time Division Duplexing
TFES Task Force for European Standards for IMT
UARFCN UTRA Absolute Radio Frequency Channel Number
UE User Equipment
UMTS Universal Mobile Telecommunications System
UTRA Universal Terrestrial Radio Access
UMB Ultra Mobile Broadband
WCDMA Wideband Code Division Multiple Access
4 Technical requirements specifications
4.1 Environmental profile
The technical requirements of the present document apply under the environmental profile for operation of the
equipment, which shall be declared by the supplier. The equipment shall comply with all the technical requirements of
the present document at all times when operating within the boundary limits of the declared operational environmental
profile.
For guidance on how a supplier can declare the environmental profile see annex C.
4.2 Conformance requirements
The requirements in the present document are based on the assumption that the operating band (e.g. band I, III, VII and
VIII) is shared between systems of the IMT family (for band III and VIII also GSM) or systems having compatible
characteristics.
4.2.1 Introduction
To meet the essential requirement under article 3.2 of Directive 1999/5/EC [i.6] (R&TTE Directive) for IMT Repeater
five essential parameters in addition to those in EN 301 908-1 [8] have been identified. Table 4.2.1-1 provides a cross
reference between these five essential parameters and the corresponding seven technical requirements for equipment
within the scope of the present document.
Table 4.2.1-1: Cross references
Essential parameter Corresponding technical requirements
Spectrum emissions mask 4.2.2 Operating band unwanted emissions
Conducted spurious emissions from the antenna connector 4.2.3 Spurious emissions
Accuracy of maximum output power 4.2.4 Maximum output power
Receiver immunity 4.2.5 Input intermodulation
4.2.6 Out of band gain
4.2.7 Adjacent Channel Rejection Ratio
Intermodulation attenuation of the output 4.2.8 Output intermodulation
ETSI
11 ETSI EN 301 908-11 V5.2.1 (2011-07)
The supplier shall declare operating band(s) for the Repeater. The technical requirements apply for the declared
operating band(s) as outlined for each requirement. For a Repeater supporting more than one operating band,
conformance testing for each technical requirement in clause 5 shall be performed.
The technical requirements also apply to Repeater configurations described in annex B.
For a Repeater declared to support Band XX, the manufacturer shall additionally declare the following quantities
associated with the applicable test conditions of table 4.2.2.2-5 and information in annex G of TS 125 104 [10]:
• P Declared emission level for channel N
EM,N
• P Maximum output Power in 10 MHz
10MHz
4.2.2 Operating band unwanted emissions
4.2.2.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The out of band emissions requirement for repeater is specified both in terms operating band unwanted emissions and
protection of the BS receiver in the operating band. The operating band unwanted emissions define all unwanted
emissions in the repeater operating band plus the frequency ranges 10 MHz above and 10 MHz below that band.
Unwanted emissions outside of this frequency range are limited by a spurious emissions requirement.
Operating band unwanted emissions comprise an emission mask applied outside the repeater passband and a general
requirement applied outside the mask but inside the frequency range of the operating band unwanted emissions.
4.2.2.2 Limit
4.2.2.2.1 General operating band unwanted emission requirements
The general operating band unwanted emissions limits are given in table 4.2.2.2.1-1.
Table 4.2.2.2.1-1: General operating band unwanted emissions requirements
Frequency range of Maximum level Measurement Notes
operating band bandwidth
-16 dBm 100 kHz 1, 2
≤ 1 GHz
≥ 1 GHz -15 dBm 1 MHz 2, 3
NOTE 1: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1.
NOTE 2: Limit based on ITU-R Recommendation SM.329-11 [4], section 4.3 and annex 7.
NOTE 3: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1. Upper
frequency as in ITU-R Recommendation SM.329-11 [4], section 2.5, table 1.
4.2.2.2.2 Operating band emission mask requirements
The requirement shall be met by a Repeater's RF-signal output at maximum gain with WCDMA signals in the pass
band of the Repeater, at levels that produce the maximum rated output power per channel, configured in accordance
with the manufacturer's specification. Emissions shall not exceed the maximum level specified in tables 4.2.2.2.2-1,
4.2.2.2.2-2, 4.2.2.2.2-3 and 4.2.2.2.2-4 for the appropriate Repeater maximum output power, in the frequency range
from Δf = 2,5 MHz to Δf from the 5 MHz channel, where:
max
• Δf is the separation between the centre frequency of first or last 5 MHz channel used in the pass band and the
nominal -3 dB point of the measuring filter closest to the carrier frequency;
• f_offset is the separation between the centre frequency of first or last 5 MHz channel in the pass band and the
centre of the measuring filter;
ETSI
12 ETSI EN 301 908-11 V5.2.1 (2011-07)
• f_offset is 12,5 MHz;
max
• Δf is equal to f_offset minus half of the bandwidth of the measurement filter.
max max
To select the table of the maximum level for the spectrum emission mask test, use the maximum output power as
defined in clause 3.1. If one channel is used for the spectrum emission mask test use this power for the selection. If two
channels are used for the spectrum emission mask test use the power of one of these.
Table 4.2.2.2.2-1: Emission mask values, maximum output power P ≥ 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz -12,5 dBm 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
−12,5 dBm−15 × −2,715 dB
⎜ ⎟
MHz
⎝ ⎠
3,515 MHz ≤ f_offset < 4,0 MHz -24,5 dBm 30 kHz
-11,5 dBm 1 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset -11,5 dBm 1 MHz
max max
Table 4.2.2.2.2-2: Emission mask values, maximum output power 39 ≤ P < 43 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
-12,5 dBm 30 kHz
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz 30 kHz
⎛ f_offset ⎞
−12,5 dBm −15 × ⎜ − 2,715⎟ dB
MHz
⎝ ⎠
-24,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz -11,5 dBm 1 MHz
P - 54,5 dB 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
Table 4.2.2.2.2-3: Emission mask values, maximum output power 31 ≤ P < 39 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz P - 51,5 dB 30 kHz
30 kHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz
f_offset
⎛ ⎞
P −51,5 dB −15 × − 2,715 dB
⎜ ⎟
MHz
⎝ ⎠
P - 63,5 dB 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz P - 50,5 dB 1 MHz
P - 54,5 dB 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
ETSI
13 ETSI EN 301 908-11 V5.2.1 (2011-07)
Table 4.2.2.2.2-4: Emission mask values, maximum output power P < 31 dBm
Frequency offset of Frequency offset of Maximum level Measurement
measurement filter measurement filter centre bandwidth
frequency, f_offset
-3 dB point, Δf
-20,5 dBm 30 kHz
2,5 MHz ≤ Δf < 2,7 MHz 2,515 MHz ≤ f_offset < 2,715 MHz
2,7 MHz ≤ Δf < 3,5 MHz 2,715 MHz ≤ f_offset < 3,515 MHz 30 kHz
f_offset
⎛ ⎞
− 20,5 dBm−15 × ⎜ −2,715⎟dB
MHz
⎝ ⎠
-32,5 dBm 30 kHz
3,515 MHz ≤ f_offset < 4,0 MHz
3,5 MHz ≤ Δf < 7,5 MHz 4,0 MHz ≤ f_offset < 8,0 MHz -19,5 dBm 1 MHz
-23,5 dBm 1 MHz
7,5 MHz ≤ Δf ≤ f 8,0 MHz ≤ f_offset < f_offset
max max
4.2.2.2.3 Protection of the BS receiver in the operating band
This requirement shall be applied for the protection of UTRA FDD BS receiver in geographic areas in which
UTRA-FDD Repeater and UTRA-FDD BS are deployed.
The requirement applies at frequencies that are more than 10 MHz below or more than 10 MHz above the repeater pass
band.
This requirement applies to the uplink of the repeater, at maximum gain.
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.3-1.
Table 4.2.2.2.3-1: Uplink operating band unwanted emissions limits for
protection of the BS receiver
Maximum Measurement Note
Level Bandwidth
-53 dBm 100 kHz
4.2.2.2.4 Co-existence with services in adjacent frequency bands
This requirement shall be applied for the protection in bands adjacent to band I.
The requirement applies only to the down-link direction of the repeater.
The power of any operating band unwanted emission shall not exceed the limits in table 4.2.2.2.4-1.
Table 4.2.2.2.4-1: UTRA Repeater down-link operating band unwanted emission limits
for protection of adjacent band services
Operating Band Band Maximum Level Measurement
Bandwidth
I 2 100 MHz to 2 105 MHz -30 + 3,4 (f – 2 100 MHz) dBm 1 MHz
2 175 Mhz to 2 180 MHz -30 + 3,4 (2 180 MHz - f) dBm 1 MHz
4.2.2.2.5 Protection of DTT
The following requirement shall apply for protection of DTT. For UTRA Repeater operating in Band XX, the level of
emissions in the band 470 MHz to 790 MHz, measured in an 8 MHz filter bandwidth on centre frequencies F
filter
according to table 4.2.2.2.5-1, shall not exceed the maximum emission level P declared by the manufacturer. This
EM,N
requirement applies in the frequency range 470 MHz to 790 MHz even though part of the range falls in the spurious
domain.
ETSI
14 ETSI EN 301 908-11 V5.2.1 (2011-07)
Table 4.2.2.2.5-1: Declared emissions levels for protection of DTT
Filter centre frequency, Measurement bandwidth Declared emission level
F [dBm]
filter
F = 8*N + 306 (MHz); 8 MHz P
filter EM,N
21 ≤ N ≤ 60
NOTE: Compliance with the declared emission levels above provides the characteristics of the Repeater needed
to verify compliance with the corresponding CEPT/ECC technical condition using the method outlined in
annex G of TS 125 104 [10].
4.2.2.3 Conformance
Conformance tests described in clause 5.3.1 shall be carried out.
4.2.3 Spurious emissions
4.2.3.1 Definition
Unwanted emissions consist of out of band emissions and spurious emissions [4]. Out of band emissions are emissions
immediately outside the pass band bandwidth resulting from the modulation process and non-linearity in the transmitter,
but excluding spurious emissions. Spurious emissions are emissions which are caused by unwanted transmitter effects
such as harmonics emission, parasitic emission, intermodulation products and frequency conversion products, but
exclude out of band emissions.
The spurious emission limits apply from 9 kHz to 12,75 GHz, excluding the frequency range from 10 MHz below the
lowest frequency of the repeaters operating band up to 10 MHz above the highest frequency of the repeaters operating
band.
The requirements shall apply whatever the type of repeater considered (one or several pass bands). It applies for all
configurations foreseen by the manufacturer's specification. The measurements shall apply to both paths uplink and
downlink of the Repeater.
Unless otherwise stated, all requirements are measured as mean power (RMS).
4.2.3.2 Limit
The requirements apply to the uplink and downlink of the repeater, at maximum gain, and with the following input
signals:
• without UTRA input signal;
• with UTRA input signals in the pass band of the repeater, at levels that produce the maximum rated power
output per channel;
• with 10 dB increased UTRA input signals in all channels in the pass band, compared to the input level
producing the maximum rated output power.
ETSI
15 ETSI EN 301 908-11 V5.2.1 (2011-07)
4.2.3.2.1 Spurious emissions
The power of any spurious emission shall not exceed the limits specified in table 4.2.3.2.1-1.
Table 4.2.3.2.1-1: General spurious emissions limits
Frequency range Maximum Measurement Note
Level Bandwidth
9 kHz ↔ 150 kHz -36 dBm 1 kHz Note 1
-36 dBm 10 kHz Note 1
150 kHz ↔ 30 MHz
-36 dBm 100 kHz Note 1
30 MHz ↔ 1 GHz
-30 dBm 1 MHz Note 2
1 GHz ↔ 12,75 GHz
NOTE 1: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1.
NOTE 2: Bandwidth as in ITU-R Recommendation SM.329-11 [4], section 4.1. Upper frequency as
in ITU-R Recommendation SM.329-11 [4], section 2.5, table 1.
4.2.3.2.2 Co-existence with othe
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
Loading comments...
