IEC 61753-086-02:2025

Fibre optic interconnecting devices and passive components - Performance standard - Part 086-02: Non-connectorized single-mode bidirectional 1 490 / 1 550 nm downstream and 1 310 nm upstream WWDM devices for category C - Indoor controlled environment

IEC 61753-086-02:2025 contains the minimum initial performance, test and measurement requirements and severities which a fibre optic pigtailed 1 490/1 550 nm downstream and 1 310 nm upstream wide wavelength division multiplexing (WWDM) passive optical network (PON) device will satisfy in order to be categorized as meeting the requirements of category C (indoor controlled environment), as defined in IEC 61753-1:2018, Annex A. WWDM is defined in IEC 62074-1. Annex B gives general information for these PON WWDM devices.
This first edition cancels and replaces the first edition of IEC 61753-086-2 published in 2009. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) Change of test conditions harmonizing with IEC 61753-1: 2018.

Dispositifs d'interconnexion et composants passifs fibroniques - Norme de performance – Partie 086-02: Dispositifs WWDM unimodaux non connectorisés bidirectionnels 1 490 nm/1 550 nm en voie descendante et 1 310 nm en voie montante pour la catégorie C – Environnement intérieur contrôlé

IEC 61753-086-02:2025 La présente partie de l’IEC 61753 contient les exigences minimales initiales de performance, d’essai et de mesure, ainsi que les sévérités auxquelles un dispositif de réseau optique passif (PON, Passive Optical Network) de multiplexage par répartition en longueur d'onde large (WWDM, Wide Wavelength Division Multiplexing) 1 490/1 550 nm en voie descendante et 1 310 nm en voie montante équipé de fibres amorces satisfait pour être classé conforme aux exigences de la catégorie C (environnement intérieur contrôlé), selon la définition donnée à l’Annexe A de l’IEC 61753-1:2018. Le WWDM est défini dans l’IEC 62074-1. L'Annexe B donne des informations générales pour ces dispositifs PON WWDM.
Cette première édition annule et remplace la première édition de l'IEC 61753-086-2 parue en 2009. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) Modification des conditions d'essai pour harmonisation avec l’IEC 61753-1: 2018.

General Information

• Status: Published
• Publication Date: 05-Mar-2025
• ICS: 33.180.10 - Fibres and cables
• Technical Committee: SC 86B - Fibre optic interconnecting devices and passive components
• Drafting Committee: WG 7 - TC 86/SC 86B/WG 7
• Current Stage: PPUB - Publication issued
• Start Date: 06-Mar-2025
• Completion Date: 04-Apr-2025

Relations

• Replaces: IEC 61753-086-2:2009 - Fibre optic interconnecting devices and passive components performance standard - Part 086-2: Non-connectorized single-mode bidirectional 1490 / 1550 nm downstream 1310 nm upstream WWDM devices for category C - Controlled environment
• Effective Date: 08-Dec-2023

Standards Content (Sample)

IEC 61753-086-02 ®
Edition 1.0 2025-03
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Fibre optic interconnecting devices and passive components – Performance
standard –
Part 086-02: Non-connectorized single-mode bidirectional 1490 / 1550 nm
downstream and 1310 nm upstream WWDM devices for category C – Indoor
controlled environment
Dispositifs d'interconnexion et composants passifs fibroniques - Norme de
performance –
Partie 086-02: Dispositifs WWDM unimodaux non connectorisés bidirectionnels
1 490 nm/1 550 nm en voie descendante et 1 310 nm en voie montante pour la
catégorie C – Environnement intérieur contrôlé
