ISO/IEC 15444-11:2007
(Main)Information technology — JPEG 2000 image coding system: Wireless — Part 11:
Information technology — JPEG 2000 image coding system: Wireless — Part 11:
ISO/IEC 15444-11:2007 provides a syntax that allows JPEG 2000 coded image data to be protected for transmission over wireless channels and networks. Protection services include error detection and correction capability for header and bitstream, description of the error sensitivity of different portions of the compressed data, and description of possible residual errors in the compressed data. The syntax allows these protection services to be applied to coded image data in part or in their entirety. These services are designed so as to maintain the inherent features of JPEG 2000, such as scalability and access to various spatial areas, resolution levels, colour components and quality layers, while providing protection services on these elements.
Technologies de l'information — Système de codage d'images JPEG 2000: Transmission radioélectrique — Partie 11:
L'ISO/CEI 15444-11:2007 a pour but de définir une syntaxe qui permette de protéger les données d'images codées à transmettre via les canaux et réseaux hertziens. Les services de protection font appel à plusieurs moyens: capacité de détection et de correction des erreurs dans les en-têtes et dans les flux binaires, description de la sensibilité aux erreurs de telle ou telle portion des données comprimées, et description des erreurs résiduelles possibles dans les données comprimées. La syntaxe permet d'appliquer ces services de protection à une partie ou à l'intégralité des données d'image codées. Ces services sont conçus pour conserver les propriétés intrinsèques du système JPEG 2000, telles que la capacité d'évolution et l'accès à diverses zones spatiales, les niveaux de résolution, les composantes couleurs et les couches de qualité, tout en assurant des services de protection pour ces éléments.
General Information
Relations
Standards Content (Sample)
INTERNATIONAL ISO/IEC
STANDARD 15444-11
First edition
2007-04-15
Information technology — JPEG 2000
image coding system: Wireless
Technologies de l'information — Système de codage d'image
JPEG 2000: Sans fil
Reference number
©
