ISO 21771-2

Cylindrical involute gears and gear pairs — Part 2: Calculation and measurement of tooth thickness and backlash

This standard establishes the calculation procedures for determining specification limits for external and internal cylindrical involute gearing with constant gear ratio when the desired tooth thickness is known. This standard also shows the relationships between backlash and the tooth thickness, centre distance, and tooth deviations in a pinion and gear mesh.

Roues dentées et engrenages cylindriques en développante de cercle — Partie 2: Calcul et mesurage de l'épaisseur de dent et du jeu de battement

General Information

• Status: Not Published
• ICS: 21.200 - Gears
• Technical Committee: ISO/TC 60 - Gears
• Drafting Committee: ISO/TC 60/WG 2 - Accuracy of gears
• Current Stage: 6000 - International Standard under publication
• Start Date: 17-Jul-2025
• Completion Date: 09-Aug-2025

Standards Content (Sample)

FINAL DRAFT
International
Standard
ISO/FDIS 21771-2
ISO/TC 60
Cylindrical involute gears and gear
Secretariat: ANSI
pairs —
Voting begins on:
2025-05-21
Part 2:
Calculation and measurement of
Voting terminates on:
2025-07-16
tooth thickness and backlash
Roues et engrenages cylindriques en développante de cercle —
Partie 2: Calcul et mesurage de l'épaisseur de dent et du jeu de
battement
