ISO/PRF 1436

Rubber hoses and hose assemblies — Wire-braid-reinforced hydraulic types for oil-based or water-based fluids — Specification

This document specifies requirements for six types of wire-braid-reinforced hoses and hose assemblies of nominal size from 5 to 51. This document also specifies the hose of nominal size 63 for types 2SN and R2AT, and the hose of nominal size 76 for type 2SN. They are suitable for use with: — oil-based hydraulic fluids HH, HL, HM, HR and HV as defined in ISO 6743‑4 at temperatures ranging from −40 °C to +100 °C; — water-based fluids HFC, HFAE, HFAS and HFB as defined in ISO 6743‑4 at temperatures ranging from −40 °C to +70 °C; — water at temperatures ranging from 0 °C to +70 °C. This document does not include requirements for end fittings. It is limited to requirements for hoses and hose assemblies. NOTE It is the responsibility of the user, in consultation with the hose manufacturer, to establish the compatibility of the hose with the fluid to be used.

Tuyaux et flexibles en caoutchouc — Types hydrauliques avec armature de fils métalliques tressés pour fluides à base d'huile ou à base d'eau— Spécifications

General Information

• Status: Not Published
• ICS: 23.100.40 - Piping and couplings
• ICS: 83.140.40 - Hoses
• Technical Committee: ISO/TC 45/SC 1 - Rubber and plastics hoses and hose assemblies
• Drafting Committee: ISO/TC 45/SC 1/WG 3 - Hydraulic hoses
• Current Stage: 5020 - FDIS ballot initiated: 2 months. Proof sent to secretariat
• Start Date: 12-Nov-2025
• Completion Date: 15-Nov-2025

Standards Content (Sample)

International
Standard
ISO 1436
Seventh edition
Rubber hoses and hose
assemblies — Wire-braid-
reinforced hydraulic types for
oil-based or water-based fluids —
Specification
Tuyaux et flexibles en caoutchouc — Types hydrauliques avec
armature de fils métalliques tressés pour fluides à base d'huile ou
à base d'eau— Spécifications
PROOF/ÉPREUVE
